LED Bollard
Instruction Manual
Cat. RGLLED001
1 Specifications
Cat No RGLLED001
Voltage 12Vac
Power 1W
IP rating IP54
CCT 2700K
Lumen output 100 lm (lamp only)
Replacement globe 1W G4 LED Bi-Pin LAMP
Mounting Plastic Ground stake
Wiring connection Jaw Lock connector
Housing Material / Finish Stainless Steel 304
Lifetime (Lamp) 6000hrs @ 25˚C
Warranty 1 yr (Excludes Globe)
2 Globe Assembly
Box includes 1x LED 1W G4 lamp (in a separate box).
When installing the Ìrst time, twist open the opal diffuser and push in lamp
RGLLED001
3 Cable Layout
If your installation includes multiple lights, HPM strongly recommends that you limit individual
cable lengths to 20 metres, or use HPM heavier duty cable, otherwise lights may get progressively
dimmer towards the end of the cable (voltage drop). See section for accessories
If your installation requires a total of more than 20 metres of cable, consider running two seperate
cables from the transformer output.
It is recommended that the LED lighting does not exceed 50% of the load rating of the transformer.
Refer to section ‘Choosing a suitable transformer’ for further information
330mm165mm

4 Installation
To connect your garden lights, follow the instructions below:
STEP 1 Place your garden lights in the approximate position you want them to be.
STEP 2 Lay out the cable where you want your lights to be located, remembering to allow sufÌcient cable to connect to the transformer. Try to avoid laying the
cable where frequent digging may occur.
STEP 3 - Installation of a 12V Timer (if applicable)
If a 12 volt timer (HPM Cat No RGL10) is purchased, it must be positioned between
the transformer and the lights. With the power turned off, connect the wire strands,
on the end of the timer cable, into the output terminals of the transformer. Secure
firmly with a screwdriver.
STEP 4 - Installation of the transformer
Connect the cable to the transformer terminals (or timer, if applicable) by stripping
back a small amount of insulation from each wire strand (approx. 10mm). Be careful
not to damage wires. Twist wire strands to prevent loose wire escaping from terminal
and to help ensure a tight connection. Place stripped ends into screw terminals on
transformer, or timer, and secure firmly with a screwdriver.
STEP 5 First connect the garden light that will be positioned the furthest away from
the transformer.
The special connector on each light is designed to make electrical connection by
piercing the insulation cable as the two halves of the connector are pushed together.
(See connection diagrams).
5 Connecting your garden lights
The special jaw lock connectors are designed to make electrical
connection by piercing the insulation cable as the jaw lock
connecter is attached.
STEP 1 Lay the cable flat on one half of the connector as shown.
STEP 2 Lay the other half of the connector on top of the cable,
upside down, taking care to align the pins into their matchng
holes on the other half. Push together firmly until they lock.
Check that the two halves are pushed tightly together. (This will
cause the spikes to deeply pierce into the copper centre of the
cable and make a solid electrical connection).
STEP 3 Plug the transformer into the powerpoint and check
whether the furthest positioned garden light operates. (If it doesn’t light up, refer to ‘Troubleshooting’ section). If light does light up, switch off the transformer
and proceed to connect all the other garden lights using the steps above.
To check each light connection is secure, first turn the transormer on from the powerpoint, then gently wiggle the cable and connector.
(This is perfectly safe - the voltage at this point is very low). If the light flickers, the connection is not firm enough and should be re-connected
(repeat ‘Connecting your gaden lights’ Steps 1-2).
6 Setup
STEP 1 Switch off the transformer from the powerpoint.
STEP 2 If you wish to cover the cable in the ground, dig a narrow channel, about 100mm deep (just deep enough to hide the cable).
STEP 3 Lay the cable at the bottom of the channel, or fasten the cable to the wall or step using appropriate fixings.
If your cable will be covered in the ground, we recommend, at this point, that you observe the overall lighting effectiveness in the dark before covering the
channel.
7 Globe replacement
To replace lamp follow instructions for Globe Assembly.
Note: If lamps do not turn ON or Óicker when powered ON, repeat steps for Globe Assembly to see if there is a loose contact.
8 Choosing a suitable transformer
The total wattage of your LED garden lights must not be greater than ½of the rating of the transformer.
For example if the RGLTR60 60W transformer is used then adding up the wattages of each LED light (e.g 4 x 6W = 24W) should not exceed the 30W max load.
Total LED lamp Wattage must not exceed 0.5 times the VA rating of Transformer.
Eg: With 60VA transformer - Total LED lamps to be used = 30W max ( ie., 30x of lamps in this box)

08_2017 LE10384AAA HPML1697
Warranty
Legrand warrants this product for a period of 1 year from the date of purchase when used
in accordance with these instructions and considering the disclaimers listed herein.
These goods come with guarantees that cannot be excluded under the Australian and
New Zealand Consumer Laws. You are entitled to a replacement or a refund for a major
failure and for compensation for any other reasonably foreseeable loss or damage. You
are also entitled to have the goods repaired if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
See the Warranty card enclosed with this product for further details.
Customer Service
For all Customer Service and Technical Support
please call Monday to Friday during business hours.
Legrand Australia
1300 369 777
www.hpm.com.au
Legrand New Zealand
0800 476 009
www.hpm.co.nz
ABN: 31 000 102 661
8 Choosing a suitable transformer
9 Accessories
Outdoor Garden Cables:
RGL8 (2-core 1.3mm²10m length)
RGL9 (2-core 1.3mm²20m length)
RGLCL21/20 (2-core 2.1mm²20m length)
RGLCL21/30 (2-core 2.1mm²30m length)
RGLCL33/30 (2-core 3.3mm²30m length)
RGLHSC15 (2-core 0.5mm²15m length)
Connectors:
CDGLCC4 (pack of 4 cable connector)
Transformers:
RGLTR60
RGLTR105
RGLTR220
RGLTR400
RGLPCTAW20
Sensor & Timers
(Compatible only with 60VA-200VA transformers)
RGL10 (200W sunset timer)
DGLS150 (150W dusk to dawn sensor)
10 Troubleshooting
11 Maintenance
Transformer Load rating (incandescent lighting) Load rating (LED lighting)
RGLTR60 60W 30W
RGLTR105 105W 50W
RGLTR220 200W 100W
RGLTR400 400W 200W
RGLPCTAW20 10W 5W
Problem Possible Solution
The powerpoint is turned on,
but the lights are off.
1. The connections at the base of transformer may be loose. Tighten firmly
2. There is no power to the powerpoint, (Consult an electrician).
3. You may not have pierced the cable well enough with the metal spikes in the jaw-lock connectors. Check that
the cable insulation has been fully pierced by the spikes.
Some lights are working, one or
more are not.
1. If one or more of the lights are not working, first check the connection of the light to the cable (See
‘Connecting your garden lights’ section). If this is firm, check the globes by putting the ‘non-working’ globes
into a working fitting. Replace unserviceable globes, (If applicable).
One or more lights flicker. 1. The connection to the light is loose. (See ‘Connecting your garden lights’ section).
2. The globe is loose. Push in firmly, (Watch out that globe is not hot). (HPM recommends paper or cloth be used
to handle the globe).
To prolong the life of your Gardenlights HPM recommends the following:
• Install away from salty or corrosive environments
• Install away from highly fertilised areas
• Do not submerse in treated water such as chlorinated pools
To keep your lights looking new, keep lenses free of dust and residue by wiping occasionally with a dry cloth, or warm soapy water if necessary.
If using soapy water, ensure that you thoroughly dry your light after cleaning.
