LEGRAND DA2154 User manual

Page i
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
4 Port Desktop N-Wireless Router
(P/N DA2154)
User’s Guide
1308210 REV. A

Page ii
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
Compliance
FCC Notice –FCC ID:YV8-DA2154V1
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Canadian Department of Communications –IC:9922A-DA2154V1
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not cause interference, and (2) this device must accept any
interference, including interference that may cause undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.

Page iii
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
TABLE OF CONTENTS
1.0 Introduction ................................................................................................................1
1.1 Overview of the Router...........................................................................................1
1.2 Main Features.........................................................................................................1
1.3 Panel Layout...........................................................................................................2
1.3.1 The Front Panel..............................................................................................2
1.3.2 The Rear Panel ..............................................................................................3
2.0 Connecting the Router...............................................................................................4
2.1 System Requirements.............................................................................................4
2.2 Installation Environment Requirements...................................................................4
2.3 Connecting the Router............................................................................................4
3.0 Quick Installation Guide ............................................................................................6
3.1 TCP/IP Configuration..............................................................................................6
3.2 Quick Installation Guide..........................................................................................7
4.0 Configuring the Router............................................................................................13
4.1 Login.....................................................................................................................13
4.2 Status....................................................................................................................14
4.3 Quick Setup ..........................................................................................................14
4.4 WPS......................................................................................................................14
4.5 Network.................................................................................................................17
4.5.1 WAN.............................................................................................................18
4.5.2 MAC Clone...................................................................................................28
4.5.3 LAN ..............................................................................................................28
4.6 Wireless................................................................................................................29
4.6.1 Wireless Settings..........................................................................................30
4.6.2 Wireless Security..........................................................................................33
4.6.3 Wireless MAC Filtering.................................................................................35
4.6.4 Wireless Advanced.......................................................................................37
4.6.5 Wireless Statistics.........................................................................................38
4.7 DHCP....................................................................................................................39
4.7.1 DHCP Settings .............................................................................................39
4.7.2 DHCP Client List...........................................................................................40
4.7.3 Address Reservation ....................................................................................41
4.8 Forwarding............................................................................................................42
4.8.1 Virtual Servers..............................................................................................42
4.8.2 Port Triggering..............................................................................................44
4.8.3 DMZ..............................................................................................................46
4.8.4 UPnP............................................................................................................46
4.9 Security.................................................................................................................47
4.9.1 Basic Security...............................................................................................47
4.9.2 Advanced Security........................................................................................49
4.9.3 Local Management.......................................................................................50
4.9.4 Remote Management...................................................................................51
4.10 Parental Control..................................................................................................52
4.11 Access Control ....................................................................................................54

Page iv
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
4.11.1 Rule ............................................................................................................55
4.11.2 Host ............................................................................................................60
4.11.3 Target..........................................................................................................61
4.11.4 Schedule.....................................................................................................63
4.12 Advanced Routing...............................................................................................65
4.12.1 Static Routing .............................................................................................65
4.12.2 System Routing Table.................................................................................66
4.13 Bandwidth Control...............................................................................................67
4.13.1 Control Settings..........................................................................................67
4.13.2 Rules List....................................................................................................67
4.14 IP & MAC Binding ...............................................................................................69
4.14.1 Binding Settings..........................................................................................69
4.14.2 ARP List......................................................................................................70
4.15 Dynamic DNS .....................................................................................................71
4.15.1 Comexe.cn DDNS ......................................................................................72
4.15.2 Dyndns.org DDNS......................................................................................73
4.15.3 No-ip.com DDNS........................................................................................74
4.16 System Tools.......................................................................................................75
4.16.1 Time Settings..............................................................................................75
4.16.2 Diagnostic...................................................................................................77
4.16.3 Firmware Upgrade......................................................................................78
4.16.4 Factory Defaults..........................................................................................79
4.16.5 Backup & Restore.......................................................................................80
4.16.6 Reboot........................................................................................................80
4.16.7 Password....................................................................................................81
4.16.8 System Log.................................................................................................81
4.16.9 Statistics .....................................................................................................83
Appendix A: FAQ............................................................................................................85
Appendix B: Configuring the PC...................................................................................91
Appendix C: Specifications...........................................................................................94
Appendix D: Glossary....................................................................................................95

Page 1
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
1.0 Introduction
1.1 Overview of the Router
The Legrand DA2154-V1 Desktop 300Mbps Wireless N Router integrates a 4-port Switch, Firewall,
NAT-Router and Wireless Access Point to fullymeet the need of Small Office/Home Office (SOHO)
network users demanding higher networking performance. It provides a wireless connection up to
300Mbps with other 802.11n wireless clients, whilestill being compatible with all IEEE 802.11g and IEEE
802.11b products.The DA2154-V1 provides security features such as SSID broadcast control, wireless
LAN 64/128/152-bit WEP encryption, WiFi protected Access (WPA2- PSK, WPA- PSK), as well as
advanced Firewall protection for complete data privacy. It also supports flexible access control, Virtual
Server and DMZ host for Port Triggering, and allows for remote management.
1.2 Main Features
Complies with IEEE 802.11n to provide a wireless data rate of up to 300Mbps.
One 10/100M Auto-Negotiation RJ45 WAN port and four 10/100M Auto-Negotiation RJ45 LAN
ports, supporting Auto MDI/MDIX.
Provides WPA/WPA2, WPA-PSK/WPA2-PSK authentication and TKIP/AES encryption security.
Supports Dynamic IP/Static IP/PPPoE Internet access.
Supports Virtual Server and DMZ host.
Supports UPnP, Dynamic DNS and Static Routing.
Provides Automatic-connection and Scheduled (time-based) Connection to the Internet
Built-in NAT and DHCP server supporting static IP address distributing.
Supports Parental Control and Access Control.
Connects Internet on demand and disconnects from the Internet when idle for PPPoE.
Provides 64/128/152-bit WEP encryption security and wireless LAN ACL (Access Control List).
Supports Flow Statistics.
Supports firmware upgrades and web management.

Page 2
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
1.3 Panel Layout
1.3.1 The Front Panel
Figure 1-1 Front Panel sketch
The Router’s LEDs are located on the front panel (View from left to right).
Name
Status
Indication
PWR
Off
Power is off.
On
Power is on.
SYS
Flashing
The Router is working properly.
On /Off
The Router has a system error.
WLAN
Off
The Wireless function is disabled.
Flashing
The Wireless function is enabled.
WAN /LAN 1-4
Off
There is no device linked to the corresponding port.
On
There is a device linked to the corresponding port but there
is no activity.
Flashing
There is an active device linked to the corresponding port.
WPS
Slow Flash
A wireless device is connecting to the network by WPS
function. This process will last in the first 2 minutes.
On
A wireless device has been successfully added to the
network by WPS function.
Quick Flash
A wireless device failed to be added to the network by WPS
function.
Table 1-1 The LEDs Description
Note:
1. After a device is successfully added to the network by WPS function, the WPS LED will
stay on for about 5 minutes and then turn off.
2. Press and hold the WPS/Reset button for more than 5 seconds, to reset the router.
DA2154-V1

Page 3
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
1.3.2 The Rear Panel
Figure 1-2 Rear Panel sketch
The following parts are located on the rear panel (View from left to right).
POWER: The Power socket is where you will connect the power adapter. Please use the power
adapter provided with this product.
ON/OFF: The switch for the power.
4,3,2,1 (LAN): These ports (4,3,2,1) connect the Router to the local devices (ie.PCs).
WAN: This WAN port is where you will connect the DSL/Cable Modem, or Ethernet.
Wireless antenna: To receive and transmit the wireless data.

Page 4
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
2.0 Connecting the Router
2.1 System Requirements
Broadband Internet Access Service (DSL/Cable/Ethernet)
One DSL/Cable Modem that has an RJ45 connector (which is not necessary if the Router is
connected directly to the Ethernet.)
PCs with a working Ethernet Adapter and an Ethernet cable with RJ45 connectors
TCP/IP protocol on each PC
Web browser, such as Microsoft Internet Explorer, Mozilla Firefox or Apple Safari
2.2 Installation Environment Requirements
Place the Router in a well ventilated place far from any heater or heating vent
Avoid direct sunlight
Keep at least 2 inches (5 cm) of clear space around the Router
Operating Temperature: 0°C~40°C (32°F~104°F)
Operating Humidity: 10%~90%RH, Non-condensing
2.3 Connecting the Router
Before installing the Router, make sure your PC is able to be connected to the Internet through the
broadband service successfully. If there is any problem, please contact your ISP. After that, please
install the Router according to the following steps. Don't forget to pull out the power plug and keep
your hands dry.
1. Power off your PC, Cable/DSL Modem, and the Router.
2. Locate an optimum location for the Router. The best place is usually at the center of your wireless
network.
3. Adjust the direction of the antenna. Normally, upright is a good direction.
4. Connect the PC(s) and each Switch/Hub in your LAN to the LAN Ports on the Router, shown in
Figure 2-1. (If you have the wireless NIC and want to use the wireless function, you can skip this
step.)
5. Connect the DSL/Cable Modem to the WAN port on the Router, shown in Figure 2-1.

Page 5
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
6. Connect the power adapter to the power socket on the Router, and the other end into an electrical
outlet. The Router will start to work automatically.
7. Power on your PC and Cable/DSL Modem.
Figure 2-1 Hardware Installation of the DA2154-V1 Desktop Router

Page 6
301 Fulling Mill Road, Suite G ©Copyright 2012 by Legrand,
Middletown, PA 17057 Inc All Rights Reserved.
(800)-321-2343 www.onqlegrand.com
3.0 Quick Installation Guide
This chapter will show you how to configure the basic functions of your DA2154-V1 Desktop Router
using the Quick Setup Wizard within minutes.
3.1 TCP/IP Configuration
The default IP address of the DA2154-V1 is 192.168.40.254, and the default Subnet Mask is
255.255.255.0. These values can be changed as you desire.
Connect a local PC to a LAN port of the Router. And then you can configure the IP address for your
PC in the following two ways.
Configure the IP address manually
1) Set up the TCP/IP Protocol for your PC. If you need instructions as to how to do this, please
refer to Appendix B: "Configuring the PC".
2) Configure the network parameters. The IP address is 192.168.40.xxx ("xxx" is any number
from 1 to 250), Subnet Mask is 255.255.255.0, and Gateway is 192.168.40.254 (The
Router's default IP address)
Obtain an IP address automatically
1) Set up the TCP/IP Protocol in "Obtain an IP address automatically" mode on your PC. If
you need instructions as to how to do this, please refer to Appendix B: "Configuring the PC”.
2) Then the built-in DHCP server will assign IP address for the PC.
Now, you can run the Ping command in the command prompt to verify the network connection
between your PC and the Router. The following example is in Windows 2000 OS.
Open a command prompt, and type ping 192.168.40.254, and then press Enter.
If the result displayed is similar to the Figure 3-1, it means the connection between your PC and
the Router has been established well.
Figure 3-1 Success result of Ping command
Pinging 192.168.40.254 with 32 bytes of data:
Reply from 192.168.40.254: bytes=32 time<1ms TTL=64
Reply from 192.168.40.254: bytes=32 time<1ms TTL=64
Reply from 192.168.40.254: bytes=32 time<1ms TTL=64
Reply from 192.168.40.254: bytes=32 time<1ms TTL=64
Ping statistics for 192.168.40.254:
Packets: Sent = 4, Received = 4, Lost = 0 (0% loss),
Approximate round trip times in milli-seconds:
Minimum = 0ms, Maximum = 0ms, Average = 0ms
