Leisure WONDER 2018 User manual

Owner’s Manual

1
WONDER MOTORHOME TABLE OF CONTENTS
TABLE OF CONTENTS
INTRODUCTION 5
Owner’s Manual ������������������������������������������� 5
Motorhome Information Kit �������������������������� 6
Options and Equipment ������������������������������� 6
Vehicle Certification Labels ������������������������� 6
Reference Number Codes �������������������������������������������6
Certication Label Samples �����������������������������������������7
Wonder Floor Plans ������������������������������������� 8
Service Assistance ��������������������������������������14
Reporting Safety DefectS ��������������������������14
Coach Specifications ����������������������������������15
SAFETY 16
General Safety ��������������������������������������������16
Alarms ���������������������������������������������������������17
Combination Carbon Monoxide / LP Gas Alarm �������17
Fuel and Propane Safety �������������������������������������������18
Smoke Alarm ��������������������������������������������������������������18
Fire Prevention ��������������������������������������������19
Fire Safety Tips ����������������������������������������������������������19
Fire Extinguisher �����������������������������������������20
MOTORHOME OPERATION 22
MOTORHOME Preparation �����������������������22
motorhome loading and weights ����������������22
Tow in g ���������������������������������������������������������23
Auxiliary Vehicle Towing �����������������������������23
Pre-Trip Inspection ��������������������������������������24
Emergency Equipment Checklist ��������������24
Final Checks �����������������������������������������������25
Maximum Occupancy ���������������������������������25
Seat/Shoulder Belts ������������������������������������25
Driver/Passenger Seat Controls�����������������27
Travelling �����������������������������������������������������27
Driving Characteristics ��������������������������������28
Controls ����������������������������������������������������������������������28
General Handling �������������������������������������������������������28
High Wind Handling ���������������������������������������������������28
Mountain Driving ��������������������������������������������������������28
Driving Safety Tips ��������������������������������������29
Travel Tips ���������������������������������������������������29
Severe Weather Information ����������������������30
Emergencies While Driving ������������������������30
Hazard Warning Lights ����������������������������������������������30
Flat Tire �����������������������������������������������������������������������30
When the Vehicle is Disabled ������������������������������������31
Overheating ����������������������������������������������������������������31
Parking ��������������������������������������������������������32
Parking �����������������������������������������������������������������������32
Backing Up �����������������������������������������������������������������32
Extended Occupancy ���������������������������������33
Leveling the Motorhome �����������������������������33
Refueling the Vehicle Chassis ��������������������33
Fuel Tank Capacity�����������������������������������������������������33
Fuel Types ������������������������������������������������������������������33
Removing The Fuel Cap ��������������������������������������������34
Filling The Tank ����������������������������������������������������������34
Door Locks ��������������������������������������������������34
Locking and Unlocking Procedures ���������������������������35
Keys ����������������������������������������������������������������������������35
Entry Door Step ������������������������������������������36
Entry Step Electrical Diagram �����������������������������������37
Step Override Switch �������������������������������������������������37
LIGHTING ���������������������������������������������������38
Cab Entry Light ����������������������������������������������������������38
Interior Overhead Light Dimmer Switch ��������������������38
Exterior/Interior Light Switches ����������������������������������38
Under Cabinet Light Switches �������������������������������������39
Awning���������������������������������������������������������39
Extending the Awning ������������������������������������������������39
Retracting the Awning ������������������������������������������������40
APPLIANCE AND EQUIPMENT OPERATION
42
Refrigerator �������������������������������������������������42
Operating the Refrigerator �����������������������������������������42
Refrigerator Operating Tips ���������������������������������������43
Exterior Refrigerator Compartment ���������������������������43
Stove Top ����������������������������������������������������43
Lighting Burners ���������������������������������������������������������43
Microwave/Convection Oven ���������������������44
Operating the Microwave Convection Oven �������������44
Microwave/Convection Oven Operating Tips �����������44
Exterior BBQ Connection ���������������������������45
Operating the Exterior BBQ Connection �������������������45
LP Gas Furnace ������������������������������������������45
Operating the LP Gas Furnace ������������������������������������45
LP Gas Furnace Operating Tips ��������������������������������45
Dometic Capacitive Touch Thermostat ������46
Operating the Thermostat ������������������������������������������46
Roof Air Conditioner with Heat Strip�����������46
Heat Strip ��������������������������������������������������������������������47
Maintaining the Roof Air Conditioner/Heat Strip �������47
Coach Power Roof Vent �����������������������������47
Operating Controls �����������������������������������������������������47
Cleaning Instructions �������������������������������������������������48

2
TABLE OF CONTENTS WONDER MOTORHOME
Additional Battery Maintenance Suggestions �����������68
Inverter ��������������������������������������������������������69
Inverter Remote Control Panel ����������������������������������70
Surge guard (optional) ��������������������������������70
Accidental 240 Volt Protection �����������������������������������71
Troubleshooting Guide �����������������������������������������������71
Solar Power Unit �����������������������������������������71
Lighting Maintenance ���������������������������������72
Exterior Lighting ���������������������������������������������������������72
Interior Lighting �����������������������������������������������������������73
WATER AND PLUMBING SYSTEM 75
Water Supply�����������������������������������������������75
Fresh Water System �����������������������������������75
City Water Supply ������������������������������������������������������75
Filling the Fresh Water Tank ��������������������������������������76
Water Pump Switch ���������������������������������������������������77
Disinfecting the Water Tank ������������������������78
Water Pump ������������������������������������������������78
Water Pump Electrical Diagram ��������������������������������79
Water Pump Troubleshooting ������������������������������������79
Draining the Fresh Water System ��������������80
Draining The Hot and Cold Water Systems ��������������80
Waste Systems �������������������������������������������81
Grey Water Waste Holding Tank �������������������������������81
Black Water Waste Holding Tank �������������������������������������81
Dumping Holding Tanks ���������������������������������������������81
Black Water Waste Tank Rinse ���������������������������������82
Macerator �������������������������������������������������������������������83
Waste Water Holding Tank - Do's and Don'ts �����������83
Using On-Site Sewer Hook-Ups ��������������������������������84
Water Heater (Standard) ����������������������������84
Water Heater Operation ���������������������������������������������84
Filling the Hot Water Heater ��������������������������������������85
Hot Water Heater Operating Features ����������������������85
Water Heater Thermal Cut-Off �����������������������������������86
Water Heater (On Demand Option) �����������86
On-Demand Water Heater Operation �����������������������86
Winterizing the On-Demand Water Heater ���������������87
Water Fixtures ���������������������������������������������87
Fresh Water Toilet ������������������������������������������������������87
Operating the Manual Flush Toilet �����������������������������87
Cleaning the Manual Flush Toilet ������������������������������88
Showers ������������������������������������������������������88
Interior Shower �����������������������������������������������������������88
Exterior Shower ��������������������������������������������� 89
LIQUID PROPANE GAS SYSTEM 91
LP Gas Control Valve ���������������������������������91
Bathroom Roof Vent �����������������������������������48
Operating Controls �����������������������������������������������������48
Cleaning Instructions �������������������������������������������������48
Side Window Vents �������������������������������������49
Manual Roof Vent ���������������������������������������49
Opening the Roof Vent ����������������������������������������������49
Closing the Roof Vent ������������������������������������������������49
roller shade controls �����������������������������������50
Positioning Device������������������������������������������������������50
Ten si on �����������������������������������������������������������������������50
Entertainment Systems ������������������������������50
TV/BluRay® Player/Sound Bar ���������������������������������50
Dash Radio�����������������������������������������������������������������51
TV Utility Panel ����������������������������������������������������������51
External Cable TV Connection ����������������������������������51
External Satellite TV Connection �������������������������������51
TV Antenna�����������������������������������������������������������������51
WiFi Extender (Optional) �������������������������������������������52
Entertainment System Schematics ���������������������������53
Satellite Pre-wire Schematic ��������������������������������������55
Lounge/Dinette �������������������������������������������56
W24MB �����������������������������������������������������������������������56
W24FTB ��������������������������������������������������������������������57
ELECTRICAL SYSTEM OPERATION 58
Electrical Supply �����������������������������������������58
Shore Power ��������������������������������������������������������������58
Battery Disconnect Switch �����������������������������������������58
Wiring Schematic �������������������������������������������������������59
System Monitor �������������������������������������������61
Power Distribution Panel ����������������������������62
120 Volt AC Circuit Breakers �������������������������������������62
12 Volt DC Coach Fuses �������������������������������������������62
12 Volt DC Chassis Fuses �����������������������������������������63
Ground Fault Circuit Interrupter (GFCI) ��������������������63
Auxiliary LP Gas Generator (Optional) ������63
Operating the Auxiliary LP Gas Generator ����������������63
Starting the Auxiliary LP Gas Generator ������������������64
Stopping the Auxiliary LP Gas Generator �����������������64
Generator Hour Meter ������������������������������������������������64
Generator Safety ����������������������������������������65
Automatic Power Transfer Switch �����������������������������65
12 Volt DC system ��������������������������������������66
Chassis Battery ����������������������������������������������������������66
Coach Batteries (12 Volt DC Power Supply) ������������66
Coach Battery Condition Meter ���������������������������������67
Battery Maintenance �����������������������������������67
Battery Problems��������������������������������������������������������67
Long-Term Storage ����������������������������������������������������67

3
WONDER MOTORHOME TABLE OF CONTENTS
Maintenance and Servicing ����������������������105
Entry Door Step ������������������������������������������������������� 105
NEW VEHICLE LIMITED WARRANTY 107
Safe Use of LP Gas ������������������������������������91
Precautions for the Safe Use of LP Gas �������������������91
How LP Gas Works ������������������������������������92
Selecting Fuel Types ����������������������������������92
LP Gas Tank System ����������������������������������92
Relling the LP Gas Tank ������������������������������������������92
After Relling the LP Gas Tank ����������������������������������93
Air in the LP Gas Tank �����������������������������������������������93
Travelling with LP Gas ��������������������������������93
LP Gas Tank Regulator ������������������������������94
LP Gas Leaks ���������������������������������������������94
Avoiding Asphyxiation ������������������������������������������������95
MOTORHOME MAINTENANCE 97
Exterior Care and Maintenance �����������������97
Roof ����������������������������������������������������������������������������97
Underbody ������������������������������������������������������������������97
Washing, Waxing and Polishing ��������������������������������97
Stripes and Decals �����������������������������������������������������97
Exterior Lighting ���������������������������������������������������������97
Solar Panels ���������������������������������������������������������������98
Interior Care ������������������������������������������������98
Carpets �����������������������������������������������������������������������98
Upholstery ������������������������������������������������������������������98
Spots and Stains ��������������������������������������������������������98
Vinyl Fabrics ���������������������������������������������������������������98
Draperies, Curtains and Bedspreads ������������������������99
Walls ���������������������������������������������������������������������������99
Cabinetry, Tables and Countertops ���������������������������99
Sinks ���������������������������������������������������������������������������99
Refrigerator ����������������������������������������������������������������99
Stove Top - General ���������������������������������������������������99
Stove Top - Burners ���������������������������������������������������99
Microwave/Convection Oven �������������������������������������99
Bathroom - General ������������������������������������������������ 100
Toi le t ������������������������������������������������������������������������ 100
Doors and Windows ������������������������������������������������ 100
Storage and Winterization ������������������������100
Storage Checklist ���������������������������������������������������� 100
Cold Temperature Storage ������������������������������������� 101
Spring Startup ��������������������������������������������������������� 101
Cold Temperature Operation ���������������������������������� 102
Chassis �������������������������������������������������������������������� 102
LP Gas ��������������������������������������������������������������������� 102
Waste System ��������������������������������������������������������� 102
Water System Winterization ���������������������102
Adding Plumbing Non-toxic Antifreeze ������������������ 102
De-Winterizing the Water Systems ������������������������ 103
Winterizing Comfort Water Heater ������������������������� 104

4
TABLE OF CONTENTS WONDER MOTORHOME

5
WONDER MOTORHOME INTRODUCTION
INTRODUCTION
Congratulations! Thank you for selecting a Leisure
Travel Vans Motorhome.
Welcome to the exciting world of motorhome travel
and camping, with all the comforts of home with you,
while you travel and enjoy the outdoors.
Your motorhome has been designed and
manufactured to enhance your travel and camping
experience and to provide you with safe, efcient
and trouble-free operation�
Before your rst drive, become familiar with the
operation of the vehicle chassis and all functions and
operations of the motorhome. Spend adequate time
with your dealer when you take delivery to learn all
you can about your new motorhome.
OWNER’S MANUAL
This manual was prepared to aid the operator
and occupants in the operation and care of the
motorhome. There are many options to Leisure
Travel Vans, so ensure that you are familiar with
your motorhome’s systems and equipment. All
operators and occupants of the motorhome should
read, understand and follow the instructions in this
manual, the vehicle chassis manual & the information
contained in the Motorhome Information Kit provided
with your new motorhome.
Your motorhome contains a number of systems,
components, equipment and appliances manufactured
by vendors that supply components for Triple E RV.
These vendors are unrelated to Triple E RV.
Before operating the motorhome for the rst time –
even if an experienced motorhome operator – read
and become familiar with all of the relevant manuals
to your motorhome, components, equipment and
appliances provided in the Motorhome Information
Kit. Your familiarity with the detailed operation of
your motorhome will assist in your safe, efcient and
trouble-free motorhome operation�
KEEP the Motorhome Information Kit within your
motorhome for readily available reference.
PASS this manual, the Chassis Operation Manual
and the Motorhome Information Kit to any subsequent
operator or owner�
For clarication or further details on any of the
enclosed information, please contact:
Your Leisure Travel Vans Dealer or Triple E RV
Customer Service at:
Email: info@tripleerv.com
Toll F r ee : 87 7- 99 2- 99 06
Tele p h on e: 2 04 -3 25 -4 36 1
Fax: 204-325-5241

6
INTRODUCTION WONDER MOTORHOME
MOTORHOME INFORMATION KIT
The Motorhome Information Kit includes but isn’t
limited to information on the components, equipment
and appliances listed below�
• Refrigerator
• Stove top
• Furnace
• Electrical Panel
• Toil e t
• Water Heater
• Water Pump
• Water Filtration
• Vent (roof)
• Fire Extinguisher
• Smoke Detector
• Thermostat
• CO Detector
• Propane Detector
• Gas Regulator
• TV Antenna
• TV/DVD
• Chassis
• Air Conditioner
• Generator
• View Monitor
• Inverter
• Entertainment System
• Safety
• Flooring and Countertops
• Electric Step
• Solar Panel
• Surge Protector
• Safe
OPTIONS AND EQUIPMENT
Leisure Travel Vans are available in various sizes
and oor plan congurations and with differing
optional equipment. The equipment, accessories
and components described in this manual may not
apply in all respects to your motorhome. Read the
material and manuals provided in the Motorhome
Information Kit for detailed instructions regarding the
equipment specic to your motorhome.
VEHICLE CERTIFICATION LABELS
The vehicle certication labels afxed to your
motorhome contain vehicle identication and other
important reference information. Never remove or
destroy these labels. The labels are located on the
driver & passenger door frames. See location details
on the following page�
REFERENCE NUMBER CODES
MANUFACTURE/CONVERSION DATE
The date on which the coach portion of your motorhome
was built�
GROSS VEHICLE WEIGHT RATING (GVWR)
The maximum permissible weight of this fully loaded
motorhome�
SLEEPING CAPACITY WEIGHT RATING (SCWR)
The manufacturer’s designated number of sleeping
positions multiplied by 154 lbs (70 Kgs).
OCCUPANT AND CARGO CARRYING CAPACITY
(OCCC)
The value equal to the GVWR minus UVW and full
LP� In other words, OCCC is the amount of weight in
occupants, cargo, water and trailer tongue weight that
can be added to the motorhome without exceeding the
GVWR�
GROSS COMBINED WEIGHT RATING (GCWR)
The Gross Combined Weights Rating of the motorhome,
i.e, combined weight of the Motorhome and any towed
vehicle.
DESIGNATED SLEEPING CAPACITY
The manufacturer’s designated number of sleeping
positions�
GROSS AXLE WEIGHT RATING (GAWR)
The value specied as the load carrying capacity of
a single axle system, as measured at the tire-ground
interface�
TIRE SPECIFICATION
Recommended tires specication to meet handling,
loading and safety requirements. Replacement tires
must meet these specications.

7
WONDER MOTORHOME INTRODUCTION
LOCATED ON DRIVER-SIDE DOOR FRAME (CANADA MODELS)
LOCATED ON DRIVER-SIDE DOOR FRAME (US MODELS)
LOCATED ON PASSENGER-SIDE DOOR FRAME (US MODELS)
LOCATED ON DRIVER-SIDE DOOR FRAME (ALL MODELS)
LOCATED IN WARDROBE CLOSET (ALL MODELS)
LOCATED IN WARDROBE CLOSET (ALL MODELS)
COLD TIRE INFLATION PRESSURE
Ination pressures recommended (while cold) for the
tires originally installed on your motorhome. These
tire pressure levels must be maintained to ensure
proper handling, safety and fuel economy.
CARGO CARRYING CAPACITY(CCC)(CANADA)
Equal to GVWR minus each of the following: UVW,
full fresh (potable) water weight (including water
heater), full LP-Gas weight and SCWR.
UNLOADED VEHICLE WEIGHT (UVW)
The weight of this motorhome as manufactured at
the factory with full fuel, engine oil and coolants.
MASS OF WASTE WATER TANKS
Tota l weig h t of the black and grey water tanks when
lled to capacity.
VEHICLE IDENTIFICATION NUMBER (VIN)
This number identies the chassis on which the
motorhome is built�
TYPE
The National Highway Trafc Safety Association
(NHTSA) designated usage classication for your
Motorhome. MPV signies a Multi-purpose vehicle.
CERTIFICATION LABEL SAMPLES
LOCATED IN WARDROBE CLOSET (CANADA MODELS ONLY)

8
INTRODUCTION WONDER MOTORHOME
WONDER FLOOR PLANS
W24MB PASSENGER SIDE VIEW
1 Light
2 Refrigerator Vents
3 External Receptacle
4 Generator Compartment
W24MB DRIVER SIDE VIEW
1 Sewer Termination
2 Water Heater
3 Diesel and Diesel Exhaust Fluid Fill
5 BBQ Hook-Up
6 Storage Compartment
7 Inverter/ Battery Compartment
8 Electrical Step
4 Sewer Hose Hatch (Behind Doors)
5 Shore Power Connection
6 Utility Center (Behind Doors)
9 Awning
10 Ladder (Optional)
7 Storage Compartment
8 Propane Tank (Behind Door)
9 Furnace Exhaust
1
2
3 4 5 67 8 9
1
2
2 345
6
6
78
910

9
WONDER MOTORHOME INTRODUCTION
W24MB TOP VIEW
1Skylight
2Stack Vent
3Roof Vent
4Ladder (Optional)
5Satellite
6Solar Panels (Optional)
7A/C
8Radio Antenna
9TV Antenna
10 Awning
11 WiFi Antenna
W24MB FLOOR PLAN
1 6 6 1
2
3
3
4
511
6
6
7
8
910

10
INTRODUCTION WONDER MOTORHOME
W24MB FRONT VIEW
1 Skylight
2 Clearance Lights
3 TV Antenna
4 Awning
5 Radio Antenna
6 Side Mirrors
W24MB REAR VIEW
1 Ladder (Optional)
2 Clearance Lights
3 Awning
4 Side Marker Light
5 Reectors
6 BBQ Hook-Up
7 Trailer Hitch
8 Trailer Plug
9 Sewer Dump
1
234
5
6
1
2
3
4
5
6789

11
WONDER MOTORHOME INTRODUCTION
W24FTB PASSENGER SIDE VIEW
1Light
2External Receptacle
3Generator Compartment
4BBQ Hook-up
W24FTB DRIVER SIDE VIEW
1Sewer Termination
2Diesel and Diesel Exhaust Fluid Fill
3Sewer Hose Hatch (Behind Doors)
5Storage Compartment
6Water Heater
7Inverter/ Battery Compartment
8Electrical Step
4Utility Center (Behind Doors)
5Shore Power Connection
6Storage Compartment
9Awning
10 Ladder (Optional)
11 Furnace Exhaust
7Propane Tank (Behind Door)
1
23
4
557
8
9
10
11
1
2 3 456 6 7
6
6

12
INTRODUCTION WONDER MOTORHOME
W24FTB TOP VIEW
1Skylight
2Stack Vent
3Roof Vent
4Ladder (Optional)
5Satellite
6Solar Panels (Optional)
7A/C
8Radio Antenna
9TV Antenna
10 Awning
11 WiFi Antenna
W24FTB FLOOR PLAN
76 6 11
6 6
9 8
4
3
3
1
2
10
2
15

13
WONDER MOTORHOME INTRODUCTION
W24FTB FRONT VIEW
1Skylight
2Clearance Lights
3TV Antenna
4Awning
5Radio Antenna
6Side Mirrors
W24FTB REAR VIEW
1Ladder (Optional)
2Clearance Lights
3Awning
4Side Marker Light
5Re ectors
6BBQ Hook-Up
7Trailer Hitch
8Trailer Plug
9Sewer Dump
1
234
5
6
2
3
4
5
6789
1

14
INTRODUCTION WONDER MOTORHOME
SERVICE ASSISTANCE
Your dealer will assist you with any additional
information you need and will answer any questions
you have about the operation of your motorhome.
When it’s time to service the vehicle, remember
that your dealer knows your motorhome best and is
dedicated to your satisfaction. Your dealer will provide
quality maintenance and assistance during your
period ownership. Triple E RV strongly recommends
that you follow a regular maintenance schedule to
keep your motorhome functioning at its best.
Call the following numbers if you require warranty
assistance while travelling:
Triple E RV: 1-877-992-9906
Ford Roadside Assistance (Canada)
1-800-665-2006
Ford Customer Center (Canada)
1-800-565-3673
Ford Roadside Assistance (USA)
1-800-241-3673
Ford Customer Center (USA)
1-800-392-3673
*This Emergency Roadside Service is available to
owner of the motorhome during the rst two years
after purchase�
REPORTING SAFETY DEFECTS
If you suspect your motorhome has a safety defect
that could cause injury or death, immediately contact
Triple E RV. Also, contact the National Highway
Trafc Safety Administration (NHTSA) in the US or
Transport Canada to report your concern.
NHTSA will investigate the concern if there are
a number of similar complaints. NHTSA has the
authority to order a recall and repair campaign
depending on the nature and severity of the problem.
You can reach the NHTSA by calling the Auto Safety
Hotline at 1-800-424-9393 (202-366-0123 in the
Washington, DC, area) or by writing to NHTSA,
US Department of Transportation, Washington,
DC 20590. The hotline also will provide you with
additional information on motor vehicle safety.
In Canada, call 1-613-993-9851 or write to Transport
Canada and Road Safety, 2780 Shefeld Road,
Ottawa, Ontario K1B 3V9.

15
WONDER MOTORHOME INTRODUCTION
COACH SPECIFICATIONS
1� The height of the motorhome is measured from the ground to the top of the highest standard component
and is based on the UVW of a typically equipped motorhome. The actual height of your motorhome may
vary depending on chassis, equipment, build variations or tire pressures. It is important that you know the
actual height of your motorhome.
2� The load capacity of your motorhome is designated by weight, not by volume, so you cannot necessarily
use all available space when loading your motorhome.
3� Tank capac i t ie s are base d on measure m e nt s pri o r to tank instal l a ti on . Sli g h t vari a t io ns ma y occu r due to
tank shrinkage or expansion.
4� Actual lled propane tank capacity is 80% of listed capacity due to overlling prevention device on tank.
5� Exterior storage capacity is approximate. Total volume may vary.
Chassis Transit- 350 HD
Engine - 3.2L I5 Diesel 185hp / 350 lb-ft Torque
Transmission - 6 Speed Automatic overdrive with
Select Shift
Turning Circle - 56.4'
Axle Ratio - 3.73:1
Tires - 195/75R16C
W24MB W24FTB
GVWR - lbs (kg)
10,360 (4699) 10,360 (4699)
GCWR - lbs (kg) 13,500 (6125) 13,500 (6125)
GAWR Front- lbs (kg) 4,130 (1873) 4,130 (1873)
GAWR Rear - lbs (kg) 7,275 (3300) 7,275 (3300)
Wheelbase - in (mm) 178” (4521) 178” (4521)
*Length - ft (mm) 24' 9"(7544) 24' 9"(7544)
**EXT. Width - ft (mm) 7’10.5” (2400) 7’10.5” (2400)
INT. Width - ft (mm) 7’5” (2260) 7’5” (2260)
***EXT. Height Incl. A/C - ft (mm) 9’11.5” (3035) 9’11.5” (3035)
INT. Height - ft (mm) 6’ 5” (1958) 6’ 5” (1958)
****Fresh Water Tank Cap. - gal (L) 34 (129) 34 (129)
Black Holding Tank Cap. - gal (L) 37 (140) 28 (106)
Grey Holding Tank Cap. - gal (L) 28 (106) 37 (140)
Fuel Cap. - gal (L) 25 (95) 25 (95)
Propane Cap. - gal (L) 13.2 (50) 13.2 (50)
Exterior Storage Capacity 38 cu. ft. 48 cu.ft.
* Bumper to bumper; add 4” for Ladder Option
** Outside to outside of rear fender skirts
*** Add 2” for Winegard WIFI Option and 3” for Roadtrip Satellite Option
**** Add 6 gallons for standard water heater

16
SAFETY WONDER MOTORHOME
SAFETY
Safety, comfort and ease of operation are key
considerations during the design and manufacture of
all Triple E RVs.
It is the responsibility of the owner and operator to read,
understand and follow all instructions in this manual,
the chassis manual, all appliance/equipment system
manuals located in the Motorhome Information Kit,
and on safety labels or signs on the motorhome.
Specic items, procedures or instructions are
identied with the key words Danger, Warning and
Caution which emphasize areas of special concern.
These key words are dened as follows:
DANGER
Danger - Indicates a hazardous situation which, if
not avoided, WILL result in death or serious injury.
WARNING
Warning - Indicates a hazardous situation which,
if not avoided, COULD result in death or serious
personal injury and/or damage to the motorhome.
CAUTION
Caution - Indicates a hazardous situation which,
if not avoided, COULD result in minor or moderate
personal injury and/or damage to the motorhome.
NOTICE
Notice - Identies hazards not related to personal
injury.
The safety symbol, used in conjunction with the
Danger, Warning and Caution symbols, identies an
area that involves the personal safety of the operator,
passengers or bystanders. Read, understand and
follow the instructions and information in the safety
label or sign or manual. Do not take chances with
safety. Most accidents are preventable.
Follow the safety precautions outlined in this section
of the manual, but keep in mind that the manual may
not cover all situations. Every person who occupies
the motorhome or operates any of its components,
devices or subassemblies must be familiar with
this manual and the manuals in the Motorhome
Information Kit. Every operator and occupant is
responsible for following all safety items covered in
this and other manuals�
GENERAL SAFETY
• The most important safety feature on your
motorhome is a safe and knowledgeable
operator. It is the operator’s responsibility to
read, understand and follow all the safety and
operating instructions in the operator’s, chassis,
appliance, and system manuals. Most accidents
that involve motorhomes are preventable.
• An operator who has not read and understood all
operating and safety instructions is not qualied
to operate the motorhome�
• Untrained or uninformed operators and
occupants expose themselves, passengers and
other drivers to possible injury or death, and
they subject the motorhome, other vehicles and
property to potential damage.
• Do not modify the motorhome in any way.
Unauthorized modications may impair the
function and/or safety of the motorhome.
• All driver and passenger seats are equipped with
seatbelts. Occupied seats must be locked in the
forward facing direction when the motorhome
is moving, and passengers may occupy only
approved seats with the seatbelt securely
fastened. Do not allow any passengers to travel
in the motorhome unless they are in an approved
seat with the seatbelt secured� Motorhome seats
with seatbelts installed by the manufacturer are
the only seats approved and safe for travel.
• Always fasten the seatbelt low on the torso and
keep it snug to transmit the force from the belt
into the hip/pelvic region of the body. Pregnant
women should wear a lap/shoulder belt whenever
possible� Wear the belt snug and low throughout
the pregnancy.
• Establish a monthly re extinguisher inspection
program to ensure the extinguisher is fully
charged and in proper working condition. Inspect
the extinguisher prior to each time you operate or
occupy the motorhome.

17
WONDER MOTORHOME SAFETY
ALARMS
All models are equipped with a combination LP gas,
carbon monoxide, and smoke alarm as standard
safety equipment.
Recurring alarms indicate the slow
accumulation of LP gas, carbon monoxide
or smoke and may warn of low battery levels.
Have an authorized service center check
the system and identify the source of the
alarm. Correct the problem before using the
motorhome. Keep all alarms in good working
order. For detailed information, refer to the
alarm manuals provided in the Motorhome
Information Kit.
CAUTION
COMBINATION CARBON MONOXIDE
/ LP GAS ALARM
The Combination Carbon Monoxide/Liquid Propane
Alarm 1 is mounted on the lower cabinets�
1
The LP alarm sounds whenever there is an unsafe
amount of LP gas in the motorhome� If the LP gas
monitor sounds an alarm, follow these steps:
1� Follow instructions on the safety sign next to the
stove and air out the vehicle to silence the alarm.
2� Have a qualied service center nd the leak and
correct the problem before using the motorhome�
3� Refer to the “Liquid Propane Gas System”
section in this manual and LP Gas Alarm owner’s
manual located in the Motorhome Information Kit
for further details�
If you smell gas, immediately follow these
steps:
1. Extinguish open ames, pilot lights and
all smoking materials.
2. Do not touch any electrical switches.
3. Shut off the LP gas tank valve.
4. Open doors, windows and roof vents after
making sure the roof vent fans are “OFF”.
5. Leave the motorhome and its immediate
vicinity until odor is gone.
6. Have a qualied service technician
check the system for leaks and make any
necessary corrections and repairs.
NOTE: Do NOT remove the label from the
glass stove top cover.
WARNING
Carbon monoxide is an colorless and odorless
gas that is lethal to humans and pets.
Do not breathe heating or cooking fumes or
engine exhaust to prevent asphyxiation.
DANGER
VISUAL AND AUDIBLE ALARM SIGNALS
This SAFE-T-ALERT™ CO/Propane Gas Alarm is
designed to be easy to operate. The alarm has two
indicator lights that display a specic color for each
monitored condition. There also is a distinct sound
pattern for each alarm condition�
CO ALARM
The Red CO LED will ash and the alarm will sound 4
“beeps” then will become silent for 5 seconds. These
signals indicate that the CO is at a dangerously high
level. Immediate action is required. See procedure
and warning information at start of "Combination
Carbon Monoxide/LP Gas Alarm" section for
procedures in the event of an alarm. This alarm cycle
will continue until the Test/Mute button on the front of
the alarm is pressed. Ventilate the RV. The RED light
will stay ON until the CO has cleared, or the alarm
will reactivate in approximately 6 minutes if the CO
is still present. Do not re-enter the RV. This alarm will
cease and return to normal operation after the RV is
properly ventilated.

18
SAFETY WONDER MOTORHOME
PROPANE GAS ALARM
The Red Gas LED will Flash and the alarm will
sound a steady tone whenever a dangerous level
of propane gas is detected� Immediate action is
required. See procedure and warning information
at start of "Combination Carbon Monoxide/LP Gas
Alarm" section for procedures in the event of an
alarm. The detector will continue to alarm until the
Test / M ut e button o n the f ro nt of th e alarm i s press e d .
Ventilate the RV. The RED Gas LED will continue to
ash until the gas has cleared, or the gas alarm will
reactivate in approximately 5 minutes if the gas is
still present. Do not re-enter the RV. This alarm will
cease and return to normal operation after the RV is
properly ventilated.
MALFUNCTION/SERVICE SIGNAL
If any malfunction is detected, the Gas LED will
remain off and the Operational/CO LED will alternate
RED/GREEN and the alarm will sound (refer to the
table for the corresponding audible signal.) Press
the Test/Mute button. If the Test/Mute button does
not clear the alarm, check the coach battery voltage.
If the battery voltage is not low and the unit will not
return to normal operation, immediately remove the
alarm and return for service or warranty replacement.
See the warranty section in this manual.
Use of the motorhome is not recommended
without a working CO/LP Gas detector
installed.
WARNING
OPERATION AUDIBLE
SIGNAL VISUAL SIGNAL
NORMAL None Steady Green
C.O. ALARM 4 beeps 5 seconds off Steady Red
PROPANE ALARM Constant beeping Flashing red
ALARM
MALFUNCTION Beep every 30 seconds Alternating red/green
END OF LIFE Beep every 20-30 seconds Red, red, green, green ashing
WARM-UP CYCLE No sound Flashing green
Test this alarm’s operation after each storage
period, before each trip and at least once per
week during use.
WARNING
FUEL AND PROPANE SAFETY
Turn off all pilot lights, appliances and
appliance igniters before refueling motorhome
diesel or propane tanks. Failure to comply
could result in death or serious injury.
DANGER
Never use a ame to check for LP gas leaks.
DANGER
Do NOT place or store gasoline, propane
or any other ammable liquids onboard the
motorhome, because re or explosion may
result. Failure to comply could result in
serious injury or death.
Propane containers are equipped with
safety valves that relieve excess pressure
by discharging explosive gas into the
atmosphere.
WARNING
SMOKE ALARM
The smoke alarm 2 sounds whenever there is an
unsafe amount of smoke in the motorhome. Always
open the roof vent before cooking.
2
3

19
WONDER MOTORHOME SAFETY
FIRE PREVENTION
Fires can start in a variety of ways including, but
not limited to, smoking, malfunctioning appliances
or equipment, placing ammable materials on
hot surfaces, etc. It is best to prevent res, but be
prepared to extinguish a re if necessary. Review the
following sections with all operators and occupants
on a regular basis�
Any exterior heat source (BBQs, space
heaters, etc.) must be positioned away from
the sidewall and directed away from the
motorhome.
CAUTION
FIRE SAFETY TIPS
1� Establish and maintain good housekeeping
practices. Never allow combustible materials to
accumulate in or around the motorhome�
2� Store ammable liquids in approved containers in
a well-ventilated space.
3� Have fully charged re extinguishers readily
available.
4� Avoid using ammable products in the motorhome.
5� Never smoke in bed or when relaxing on the
couch�
6� Do not overload electrical outlets.
7� Do not leave food unattended while cooking.
8� Keep children away from electrical outlets and LP
gas controls�
9� If there is a re, evacuate everyone from the
motorhome. Use your re extinguisher if safe to
do so, and close all LP gas valves if possible.
Call the re department and stay a safe distance
away from the motorhome. Do not re-enter the
motorhome until the re ofcials declare that it’s
safe�
• Open doors, windows and roof vents to air out
motorhome and silence the alarm. Identify and
eliminate the source of the smoke.
• Replace the battery at least once per year, and
test the battery after replacement. Remove the
cover to replace the battery.
• Clean and vacuum opening on smoke alarm
once a month�
Do not remove the battery to silence the
alarm. If the alarm “beeps” every minute, the
battery is weak and requires replacement.
Do not allow the battery to go dead. Use
only recommended replacement batteries
(see Smoke Detector operator’s manual
in Motorhome Information Kit for detailed
instructions).
WARNING
• Test the smoke alarm before each trip by
depressing the test button 3. Test the smoke
alarm after removing the motorhome from
storage, before each trip and weekly thereafter.
Test t he smoke a la rm sensor b y b lo wi ng smoke
(from a safe, re-free source) past the sensor. If
the alarm does not sound, identify and correct
the source of the problem or replace the smoke
alarm�
• Make sure the wires are properly connected to
the device battery. Position and close cover.
• If you suspect the smoke alarm is not functioning
properly, replace the alarm - do NOT attempt to
repair it�
Smoke alarms are not perfect and do not
respond in all situations. The best safeguard
is re prevention.
NOTICE
