LENCO M-7001 User manual

OWNER’S MANUAL
7” MONITOR
M-7001

GB-2
INSTALLATION
The unit includes the screen display (Fig. 1) and the base (Fig. 2). You can mount the
unit according to the following steps.
CAUTION:
1. Insert the round slice (1) on the top of the base into the rectangular slot (2). Before
fix the display, you can rotate the display left or right to adjust it at a proper angle
to view. Then rotate the knob (3) to fix it.
2. You can also turn the display upward or downward to find a good viewing angle,
then rotate the knob (4) to fix the trestle (5).
3. On the bottom of the base, there is a layer of magic tape, When you remove the
protective paper, you can stick the unit to the desired location of your vehicle system.
Be sure that the mounting surface is clear and dry. And you don’t have to put it
on a stable flat surface, you can bend the fan-shape pieces (6) at your ease to fix
the unit easily.
(2)
Fig. 1
(5)
(1)
(3)
(4)
(6)
Fig. 2

INSTALLATION
INSTALL THE MONITOR TO THE MOUNTING BAG
1. As shown in Fig.1, the monitor is well installed in the bag.
INSTALL THE MOUNTING BAG WITH THE MONITOR
METHOD A
1. You can separate the bag and place the monitor individually. Place the monitor on
the headrest. The monitor is fixed by using the straps on the bag as shown in Fig.2.
2. Regular set-up allows only one viewer: By slightly tilting the display to the right,
when mounted behind driver, both rear passengers can view.
GB-3
Fig. 1
Fig. 2

METHOD B
1. The monitor can be positioned between seats. By using “strap extenders”, the
monitor can be mounted on the console between the front seats. Convenient
for differentiation, the three “strap extenders”have been marked 1#, 2#, 3#.
As shown in Fig.3, stick the 1#, 2# and 3# strap extenders to the proper position
of the mounting bag according to the direction of the arrows.
2. Let the right and left straps go around the side of the console with the top
strap coming straight back over the console to meet the right and left. Then
the monitor is mounted on the console between the front seats as shown in
Fig.4 below.
INSTALLATION
Fig. 3
Strap#1
Strap#2 Strap#3
Fig. 4
GB-4

INSTALLATION
INSTALL THE HEADREST BRACKET WITH THE MONITOR
Plastic Bracket
1. Press the switch under the headrest of the car seat and pull out the headrest.
2. Assemble the Screen Mounting Bracket (2) to Screen Mounting Bracket (1) and
Rotate combined bracket, then place them on the poles of the removed headrest
to select proper hold position to install the base.
Headrest
Switch
(1)
(2)
GB-5

INSTALLATION
3. Remove the Bracket from headrest and loosen the two screws by using the
screwdriver, then place the two plastic tubes (3) on the holes that you just selected,
then adjust them to proper position as shown in diagram below.
4. Install the base on the poles of the headrest and adjust to proper position, then
use four screws (ø3x10 (4) to fix the base 1 and base 2.
5. Install the headrest with the base and rotate the Mounting Bracket to the car seat
in proper position, then use the screwdriver to fasten the two screws to fix the
base.
(3) Plastic tube
GB-6
(1)
(2)
(4) Screw

INSTALL THE SCREEN ON THE BRACKET
Insert the position plate on the screen unit into the clip screw plate and screw on the
clip screw to fix the screen unit to the Mounting Bracket.
ADJUST THE ANGLE OF THE DISPLAY
1. Loose the clip screw on the side of the rotate bracket, then adjust the Mounting
Bracket to the angle of the display to your need and screw on the clip screw to fix the
Mounting Bracket.
2. In order to adjust swing arm, you must first loosen as indicated by diagram with
appropriate screwdriver.
Adjusted by force will damage the Screen Mounting Bracket.
Position plate
Rotate Bracket
(6) Clip screw
(5) Position Clip-screw
Clip screw
GB-7

GB-8
ELECTRICAL CONNECTION
CAUTION:
1. Put the 9-pin mini din plug (1) into the 9-pin mini din socket (2) on the back of the
display.
2. The yellow socket (3) is connected to the VIDEO socket. The white socket (4) is
connected to the AUDIO Out-Left socket and the red socket (5) is connected to the
AUDIO Out-Right socket.
3. When you want to use the unit, please cut the (7) and (8) two wires from the DC
plug (6). Then connect the red wire (7) to the positive (+) terminal of the power supply
and the black wire (8) to the negative (–) of the power supply.
(8) BLACK
(7) RED
(2)
PVC CABLE (BLACK)
(3) YELLOW
(4) WHITE
(5) RED
(6) BLACK
(1)

GB-9
CONTROL & FUNCTION KEYS
7 inch COLOR TFT LCD MONITOR
9
1 2 3 5 6 7 84
13
12
10
1111
10

GB-10
1. POWER
Press POWER button (1) to turn on the unit. Press it again to turn it off.
2. POWER INDICATOR LIGHT
When the system is on, the indicator light (2) will be illuminated.
3. RX (REMOTE SENSOR)
Point the remote control handset to the remote sensor (3).
Press the function keys on the handset to control the TV, it would be worked for
connecting the TV unit or DVD only.
4. SPEAKER
Press the SPEAKER button (4) to turn on the speaker. Press it again to turn it
off.
5. VOLUME
Slide the VOLUME knob (5) right to increase volume level, and slide the knob left
to decrease volume level.
6. COLOR
Slide the COLOR knob (6) right or left to adjust the color level.
7. CONTRAST
Slide the CONTRAST knob (7) right or lift to adjust the contrast level.
8. BRIGHT
Slide the BRIGHT knob (8) right or left to adjust the bright level.
9. TFT LIQUID CRYSTAL DISPLAY
The 7 inch color TFT LCD (9) can show the current state of the unit.
10. JACKS FOR EARPHONE
There are two jacks (10) for earphone. You can connect earphone to any one of
the jacks to receive sound signal.
11. EARPHONE VOLUME CONTROL KNOB
Slide the knob (11) to change the volume of the earphone.
12. REMOTE
When connect DVD unit or another unit to the monitor through the jack (12), you
can control the DVD unit or another unit by pointing the remote control handset
directly to the remote sensor (3).
13. 9-PIN MINI DIN SOCKET
The socket is used for AUDIO IN, VIDEO IN and power supply input. Through the
socket (13), you can connect audio/video system to the unit.
