Leuze lumiflex ASM1E Quick start guide

607020-07/04 A002 Technische Änderungen vorbehalten / Subject to change without prior notice
AS-i Sicherheitsmonitor ASM1/ASM1E
Anschluss- und Betriebsanleitung
AS-i Safety Monitor ASM1/ASM1E
Connecting and Operating Instructions

64 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
Notes on using these connection and operating instructions
This connecting and operating instructions contain information regarding the proper
and effective use of the AS-i Safety monitor ASM1 and ASM1E.
Safety precautions and warnings are designated by the symbol (see also Chap.
1.1: Explanation of symbols).
Leuze lumiflex GmbH + Co. KG is not liable for damage resulting from improper
use of its equipment. Familiarity with these instructions constitutes part of the
knowledge required for proper use.
© Reprint and reproduction, in whole or in part, only with the explicit permission of
Leuze lumiflex GmbH + Co. KG
Liebigstraße 4
D-82256 Fürstenfeldbruck, Germany
Tel. [phone] / 53 50 - 0
Fax [phone] / 53 50 - 1 90
E-Mail: [e-mail]
http://www.leuze.de

ASM1, ASM1E 65
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS
Table of Contents
1 General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
1.1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
1.2 Manufacturer Certificates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
1.3 Approval and Declaration of EC Conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
1.4 Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
1.5 Definition of terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
1.6 Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
1.7 Brief description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
1.8 Different types of AS-i safety monitors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
2 Safety Notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
2.1 Safety standard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
2.2 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
2.2.1 Application requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
2.2.2 Residual risks (EN 292-1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
2.2.3 Areas of application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
2.3 Organisational measures . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
3 Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
3.1 General technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
3.2 Consideration of failure probability according to IEC 61508 . . . . . . . . . . . . . . . . . . . . . . . . 78
3.3 Dimensioned drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
4 Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
4.1 Mounting in the switching cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
5 Electrical connection ASM1/1 and ASM1E/1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
5.1 Terminal assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
5.2 Connection overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
6 Electrical connection ASM1/2 and ASM1E/2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
6.1 Terminal assignment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
6.2 Connection overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
7 Electrical Connection of All Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
7.1 AS-i bus connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
7.2 Serial interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
8 Function and Commissioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
8.1 Function and operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
8.1.1 Start-up operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
8.1.2 Configuration operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
8.1.3 Protective operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
8.2 Display and operating elements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
8.3 Switching on the device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
8.4 Device configuration and parameterisation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
8.5 Technical safety documentation for the application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
9 Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
9.1 Checking for safe shutdown . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
10 Status Display, Errors and Error Rectification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
10.1 Status display on the device / error diagnosis on the PC . . . . . . . . . . . . . . . . . . . . . . . . . . 95

66 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
10.2 Troubleshooting tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
10.3 Error release with the "Service" button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
10.4 Replacing defective safe AS-i slaves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
10.4.1Replacing a defective safe AS-i slave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
10.4.2Replacing several defective safe AS-i slaves . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
10.5 Replacing a defective AS-i safety monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
10.6 What to do if you forget the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
11 Diagnostics via AS-Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
11.1 General procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
11.2 Telegrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
11.2.1Diagnosis of AS-i safety monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
11.2.2Diagnosis of modules, sorted according to OSSD . . . . . . . . . . . . . . . . . . . . . . . . . 103
11.2.3Diagnosis of modules, unsorted . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
11.3 Example: Querying with diagnosis sorted according to OSSD . . . . . . . . . . . . . . . . . . . . . 107
12 Safe Bus Systems with AS-Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
12.1 General description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
12.2 Transmission-specific hardware structure of the bus subscribers . . . . . . . . . . . . . . . . . . . 110
12.3 Safe telegram structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
12.4 Measures against transmission errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
12.5 Determining the residual error probability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
12.6 Commissioning/repair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
12.7 Availability . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
12.8 Manufacturers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
12.9 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
13 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
14 Declaration of conformity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124

ASM1, ASM1E 67
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS

68 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
1 General Information
1.1 Explanation of symbols
The symbols used in this connecting and operating instructions are explained below.
Attention!
Pay attention to passages marked with this symbol. Failure to observe the provided
instructions could lead to personal injury or damage to equipment.
Notice!
This symbol indicates text which contains important information.
1.2 Manufacturer Certificates
The manufacturer of the AS-i Safety Monitor ASM1, ASM1E, Leuze lumiflex GmbH +
Co. KG, in D-82256 Fürstenfeldbruck possesses a certified quality assurance system
in accordance with ISO 9001.
The AS-i Safety Monitor ASM1, ASM1E was developed and manufactured considering
of valid European standards and guidelines.
1.3 Approval and Declaration of EC Conformity
Notice!
The corresponding Declaration of Conformity and prototype test certificate can be
found at the end of this connecting and operating instructions.
EU Prototype Testing (Europe) USA
TÜV IndustrieService GmbH
Geschäftsfeld ASi
Automation, Software und Informations-
technologie
Am Grauen Stein
51105 Köln, Germany
UL and CSA
*) in progress
**

ASM1, ASM1E 69
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS
1.4 Standards
• Draft: Fundamentals for the testing and certification of "Bus systems for the
transmission of safety-relevant messages"
• DIN V VDE 801 – Fundamentals for computers in systems with safety tasks
• EN 954-1 – Safety of machines – safety-related elements of control systems
• EN 50295 – Low-voltage switching devices; control-system and device interfaces;
actuator sensor interface (AS-i)
• EN 60204-1 – Safety of machines – electrical equipment for machines – Part 1:
general requirements
• EN 60947-5-1 – Low-voltage switchgear and controlgear – Part 5-1: control
devices and switching elements; electromechanical control devices
• EN 61496-1 – Non-contact safety guards
1.5 Definition of terms
Output switching element (safety output) of the AS-i safety monitor
Element activated by the logic of the monitor which is able to safely switch off the
downstream control elements. The output switching element may switch to or remain in
the ON state only when all components are functioning as intended.
Output circuit
Consists of the two logically connected output switching elements.
OSSD
The safe AS-i components and functional components assigned to an output circuit.
They are responsible for releasing the machine element which generates the hazar-
dous movement.
Integrated slave
Component in which sensor and/or actuator functions are grouped together with the
slave to form a unit.
Configuration operation
Operating state of the safety monitor in which the configuration is loaded and checked.
Master
Component for data transmission which controls the logical and temporal behaviour on
the AS-i line.
External device monitoring circuit (contactor monitoring)
The external device monitoring circuit allows the switching function of the contactors
connected to the AS-i safety monitor to be monitored.
Safety output
See output switching element.
Safe input slave
Slave which reads in the safe ON or OFF state of the connected sensor or command
device and transmits it to the master or safety monitor.

70 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
Safe slave
Slave for connecting safe sensors, actuators and other devices.
Safety monitor
Component which monitors the safe slaves and the correct functioning of the network.
Slave
Component for data transmission; the master cyclically requests these components by
their BUS addresses. Only then do they generate an answer.
Standard slave
Slave for connecting non-safe sensors, actuators and other devices.
Synchronisation time
The maximum permissible temporal offset between the occurrence of two events which
are dependent on one another.
1.6 Abbreviations
AS-i Actuator Sensor AS-Interface
BWS Non-contact safety guard
CRC Cyclic Redundancy Check
I/O Input/Output
EDM External Device Monitoring
EMC Electromagnetic compatibility
ESD Electrostatic Discharge
PELV Protective Extra-Low Voltage
PFD Probability of Failure on Demand
PLC Programmable Logic Control

ASM1, ASM1E 71
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS
1.7 Brief description
The actuator-sensor interface (AS-i) has established itself as a system for networking
primarily binary sensors and actuators at the lowest level of the automation hierarchy.
The high number of installed systems, the ease of use and the reliable operating
behaviour also make the AS-i interesting in the area of machine safety.
The safe AS-i system is intended for safety applications up to Category 4 in
accordance with EN 954-1. Mixed operation of standard components and safe com-
ponents is possible.
Notice!
A brief description of the safe AS-i transmission can be found in Chapter 12 at the end
of this operating manual.
The AS-i safety monitor monitors within an AS-i system the safe slaves which have
been assigned according to the configuration specified by the user with the configura-
tion software. Depending on the device model, up to two dependent or independent
OSSDs, each with external device monitoring circuit, are available. In the event of a
stop request or a defect, the AS-i safety monitor safely switches off the system in
protective operation mode with a maximum reaction time of 40ms.
Fig. 1.7-1: Safe and standard components in an AS-i network
Multiple AS-i safety monitors can be used within an AS-i system. In this way, a safe
slave can be monitored by multiple AS-i safety monitors.
a = Standard PLC with standard
AS-i master
b = Standard I/O-module
c = Safety monitor
d = Safety E-STOP push button
e = Safety I-module
f = AS-i power supply unit
g = Safety light barrier
h = Safety light grid
i = Standard I/O-module
j = Safety position switch
a
f
g
b
i
h
cde
j

72 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
1.8 Different types of AS-i safety monitors
The safety monitor is available in a total of four versions which differ with regard to the
functions provided by the operating software and the initial configuration.
The "Basic" and "Enhanced" functions differ as follows:
Table 1.8-1: "Basic" and "Enhanced" functions
Notice!
A detailed description of all functions can be found in the user manual for the asimon
configuration software.
Initial configuration
Features of device versions
Table 1.8-2: Features of device versions
"Basic""Enhanced"
Number of functional components at logic level 32 48
OR gates (inputs) 2 6
AND gates (inputs) – 6
Safe time function, turn-on and turn-off delay no yes
Function "button" no yes
Safety guard/module with debouncing no yes
Deactivation of functional components yes yes
Error release yes yes
Diagnosis stop yes yes
Support of A/B technology for non-safe slaves yes yes
New functional components (flip-flop, pulse with pos. edge, etc.) no yes
Dummy module (NOP) yes yes
ASM1/1 and ASM1E/1 One output circuit
ASM1/2 and ASM1E/2 Two output circuits
Functions
"Basic""Enhanced"
Number of output circuits 1 ASM1/1 ASM1E/1
2 ASM1/2 ASM1E/2

ASM1, ASM1E 73
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS
2 Safety Notices
2.1 Safety standard
The AS-i safety monitor has been designed, manufactured, tested and presented for
prototype design testing in accordance with the safety standards applicable at the time
of testing. The technical safety requirements acc. to Category 4 as per EN 954-1 and
SIL 3 as per IEC 61508 are fulfilled for all devices.
Notice!
A detailed list of failure probability values (PFD values) can be found in Chapter 3.2.
Following a risk analysis, you may use the AS-i safety monitor in accordance with its
Safety Category (4) as a disconnecting protective device for securing danger areas.
2.2 Intended use
2.2.1 Application requirements
The AS-i safety monitor has been designed as a disconnecting protective device for
securing danger areas on power-driven working materials.
Attention!
The protection of personnel and the device cannot be guaranteed if the device is
operated in a manner not corresponding to its intended use.
Attention!
Access and changes to the device, except where expressly described in this operating
manual, are not authorised.
2.2.2 Residual risks (EN 292-1)
The wiring suggestions shown in this manual have been tested with utmost care. The
relevant standards and regulations are adhered to when the shown components and
appropriate wiring are used. Residual risks remain when:
• the suggested wiring concept is not adhered to and, as a result, the connected
safety-relevant components or protective devices are not or are inadequately
integrated into the safety circuit.
• relevant safety regulations specified for the operation, adjustment and mainte-
nance of the machine are not adhered to by the operator. Here, the inspection and
maintenance intervals for the machine should be strictly adhered to.
2.2.3 Areas of application
When used as intended, the AS-i safety monitor allows the operation of sensor-
controlled systems for the protection of persons and other protective components up to
and including Category 4 acc. to EN 954-1.
The safety monitor also performs the mandatory emergency shutdown function for all
non-hand-operated machines (Stop Category 0 or 1), the dynamic monitoring of the
restart function and the contactor control function.

74 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
Examples for the use of the AS-i safety monitor:
The safety monitor is used commercially in machines and systems in which the
standard AS-i bus functions as the local bus. Thus, by using the safety monitor as a
bus subscriber, existing AS-i bus configurations can be expanded easily and safety
elements with corresponding "AS-i safety at work" interface easily integrated. If a safety
component does not have an "AS-i safety at work" interface, a so-called coupling
module can be used to make the connection. Existing AS-i master and AS-i power
supply units can continue to be used.
There are no branch-specific restrictions. Several of the primary areas of application
are listed here:
• Machine tools
• Expanded machining machines with multiple control elements and safety sensors
for wood and metal applications
• Printing and paper processing machines, cutting machines
• Packaging machines, single and as part of a system
• Food processing equipment
• Piece and bulk material transport systems
• Machinery in the rubber and plastics industry
• Assembly machines and manipulators
2.3 Organisational measures
Documentation
All entries in this operating manual must be heeded, in particular those in the sections
"Safety Notices" and "Commissioning".
Keep this operating manual in a safe place. It should be accessible at all times.
Safety regulations
Observe the locally applicable legal regulations and the rules of the employer's liability
insurance association.
Qualified personnel
Mounting, commissioning and maintenance of the device may only be carried out by
qualified personnel.
Work on electrical installations may only be carried out by qualified electricians.
Settings and changes of the device configuration via PC and asimon configuration
software must only be performed by an authorised safety officer.
The password for changing a device configuration is to be held under lock and key by
the safety officer.
Repair
Repairs, in particular the opening of the housing, may only be carried out by the
manufacturer or a person authorised by the manufacturer.

ASM1, ASM1E 75
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS
Disposal
Notice!
Electrical scrap is a special waste product! Observe the local regulations regarding
disposal of the product.
The AS-i safety monitor contains no batteries of any type which would need to be
removed prior to disposal of the product.

76 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
3 Specifications
3.1 General technical data
Electrical data
Operating voltage Ub24V DC +/- 15%
Residual ripple < 15%
Rated operating current ASM1/1 and ASM1E/1: 150 mA; ASM1/2 and ASM1E/2:
200 mA
Peak switch-on current a
a. Simultaneous switch-on of all relays; the current for the message outputs is not taken
into consideration
with all versions: 600mA
Reaction time (safety-relevant) < 40ms
Delay before start-up < 10s
AS-i data
AS-i profile Monitor 7.F
AS-i voltage range 18.5 … 31.6V
AS-i current consumption < 45mA
Number of devices per
AS-interface network
In a fully configured AS-i network with 31 used standard
addresses, it is possible to additionally install a maximum of
four safety monitors without address.
If fewer than 31 standard addresses are used, an additional
monitor can be installed for each standard address that is not
used. If additional subscribers are installed without address
(e.g. earth-fault monitoring modules), the number of installa-
ble safety monitors is reduced accordingly. If repeaters are
used, this applies for each segment.
Configuration interface
RS 232 9600 baud, no parity, 1 start bit, 1 stop bit, 8 data bits
Inputs and outputs
"Start" input Optical coupling input (high active),
input current approx. 10mA at 24V DC
"External device monitoring circuit"
input
Optical coupling input (high active),
input current approx. 10mA at 24V DC
Message output "safety on" aPNP transistor output, 200mA,
short-circuit and polarity-reversal protection
Safety output Potential-free make contact,
max. contact load: 1A DC-13 at 24V DC
3A AC-15 at 230V AC

ASM1, ASM1E 77
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS
Attention!
The AS-i power supply unit for supplying the AS-i components must demonstrate safe
mains separation acc. to IEC 60742 and the ability to bridge brief mains failures of up
to 20ms.
The power supply unit for 24V supply must also demonstrate safe mains separation
acc. to IEC 60742 and the ability to bridge brief mains failures of up to 20ms.
Notice!
The safety monitor has been tested for interference-free operation acc. to EN 61000-4-
2 with 8kV air discharging. The air discharging value of 15 kV stipulated by EN 61496-
1 is not relevant for the safety monitor as the safety monitor is installed in a system
Continuous thermal current (max.) ASM1/1 and ASM1E/1:
max. total current for all output switching elements: 6A
i.e. output circuit 1: 3A per output switching element
ASM1/2 and ASM1E/2:
max. total current for all output switching elements: 8A
i.e. output circuit 1: 3A per output switching element
output circuit 2: 1A per output switching element
or output circuit 1: 2A per output switching element
output circuit 2: 2A per output switching element
Safeguarding External with max. 4A slow blow
Overvoltage category 3, for rated operating voltage 300V AC
acc. to VDE 0110 part 1
a. The "Safety on" message output is not relevant to safety!
Environmental data
Operating temperature -20 … +60°C
Storage temperature -30 … +70°C
Protection class IP 20 (only suitable for use in electrical operating rooms /
switching cabinets with minimum protection class IP 54)
Mechanical data
Dimensions (WxHxD) 45mm x 105mm x 120mm
Housing material Polyamide PA 66
Weight ASM1/1 and ASM1E/1: approx. 350g; ASM1/2 and ASM1E/
2: approx. 450g
Mounting Snap-on mounting on top-hat rail acc. to EN 50022
Connection
M3,5 0,8 ... 1,2 Nm
7 to 10.3 LB.IN
1 x (0,5 ... 4,0) mm≤
2 x (0,5 ... 2,5) mm≤
1 x (0,5 ... 2,5) mm≤
2 x (0,5 ... 1,5) mm≤
AWG 2 x 20 to 14
10
10

78 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
which is contained either in a protective housing or a switching cabinet and the monitor
can be accessed only by trained personnel. Nevertheless, we recommend that before
the user inserts the parameterisation cable into the safety monitor he perform a
discharge (earthing) at a suitable location.
3.2 Consideration of failure probability according to IEC 61508
To allow calculation of failure probability for the entire system, the AS-i safety monitor
returns a component which depends on the maximum uninterrupted switch-on time of
the output circuit(s).
This results in the following table:
Table 3.2-1: Failure probability depending on switch-on time
The switch-on time describes the period of time until the safety function was requested,
or the maximum period of time between two executed safety checks. During this check,
safe shutdown is tested by actuating every safe sensor.
The total operating time describes the safety system's service life from commissioning
to disassembly; it is used as the basis for calculating the failure probability.
Together with the failure probabilities of the other components used in the safety
system (e.g. AS-interface slaves) it is then possible to determine the overall failure
probability. The resulting value can be used for categorising the safety system under
the respective safety level in accordance with IEC 61508.
Switch-on time Total operating time PFD
3 months 10 years ≤4 x 10-5
6 months 10 years ≤6 x 10-5
12 months 10 years ≤9 x 10-5

ASM1, ASM1E 79
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS
3.3 Dimensioned drawings
Fig. 3.3-1: Dimensions
102
90,9
81,1
104,2
5
120
63,2
86,4
7,2 (5x)
45

80 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
4 Mounting
4.1 Mounting in the switching cabinet
The AS-i safety monitor is mounted on 35mm standard rails acc. to DIN EN 50022 in
the switching cabinet.
Attention!
The housing of the AS-i safety monitor is not suitable for open wall mounting. Provide a
protective housing in all cases when the device is not mounted in the switching cabinet.
Fig. 4.1-1: Mounting
To mount, position the device on the bottom edge of the standard rail and then snap it
onto the upper edge.

ASM1, ASM1E 81
DEUTSCHENGLISHFRANÇAISITALIANOESPAÑOLNEDERLANDS
Notice!
When drilling above the device, cover the AS-i safety monitor. No particles, no metal
shavings in particular, should be allowed to penetrate into the housing through
ventilation openings as they may cause a short-circuit.
Mounting accessories
As the AS-i safety monitor is a safety component, it is possible to protect the device
from unauthorised access by sealing the CONFIG configuration interface and the
Service button. Included in the delivery contents for the device is a transparent cover
with safety hook through which you can pass a lead sealing wire or thread when the
device is in its mounted state (siehe Bild 4.1-2). You must break the safety hook off the
cover before using.
Fig. 4.1-2: Mounting accessories for sealing the device
Notice!
The transparent cover with safety hook should always be used as they provide good
protection against electrostatic discharges (ESD) and the penetration of foreign bodies
into the CONFIG socket of the AS-i safety-monitor configuration interface.
The sealing wire is not included in the delivery contents.
1
2
3
4
5
4

82 ASM1, ASM1E
DEUTSCH ENGLISH FRANÇAIS ITALIANO ESPAÑOL NEDERLANDS
5 Electrical connection ASM1/1 and ASM1E/1
Notice!
Work on electrical installations may only be carried out by qualified electricians.
5.1 Terminal assignment
Terminal arrangement / block diagram
Fig. 5.1-1: Terminal arrangement / block diagram of AS-i safety monitor ASM1/1 and
ASM1E/1
Terminal assignment
➀Power supply unit
➁Control logic
➂Control for output switching element 1
➃Control for output switching element 2
Terminal Signal / description
AS-i+ Connection at the AS-i bus
AS-i–
L+ +24V DC / supply voltage
M GND / reference ground
FE Functional earth
