Levante LEVHC2P User manual

levante-products.com LEV0608bb/Page 1 of 12/Issue 1/06.19
Operation Manual
Note: These instructions must be read fully before commencing use of the controls.
Please retain these instructions for future reference.
2 Channel Multi-purpose
Programmer
Model: LEVHC2P

levante-products.com LEV0608bb/Page 2 of 12/Issue 1/06.19

levante-products.com LEV0608bb/Page 3 of 12/Issue 1/06.19
THANK YOU FOR CHOOSING LEVANTÉ CONTROLS
All our products are tested in the UK so we are confident this product will reach you in
perfect condition and give you many years of service.
Model covered by this instruction guide:
LEVHC2P
- 2 Channel Multi-purpose Programmer
CONTENTS
What is a Channel Programmer?
An explanation for householders ................................ 4
An introduction to the 2 Channel Programmer.......... 4
Quick Operating Guide................................................. 5
Programming the Unit
The Factory-set Programme ......................................... 6
Setting the Programmer Option (5/2, 7 Day, 24hr)..... 6
Setting the Central Heating ......................................... 6
Setting the Hot Water Programme ................................7
Setting the Operation (ON/OFF/AUTO/ALL DAY)........ 7
Operating the Unit
Temporary Overrides .................................................... 8
The Advance Function .................................................. 8
The +HR Boost Function ............................................... 8
Holiday Mode................................................................ 9
Basic Settings
Setting the Time & Date............................................. 10
Setting the Backlight .................................................. 10
Resetting the Unit....................................................... 10
Power Interruption ..................................................... 10

levante-products.com LEV0608bb/Page 4 of 12/Issue 1/06.19
WHAT IS A CHANNEL PROGRAMMER?
An explanation for householders
Programmers allow you to set ‘ON’ and
‘OFF’ time periods. Some models switch the
Central Heating and domestic Hot Water on
and off at the same time, while others allow
the domestic Hot Water and Central Heating
to come on and go off at different times. Set
the ‘ON’ and ‘OFF’ time periods to suit your
own lifestyle.
On some programmers you must also set
whether you want the Central Heating and
Hot Water to run continuously, run under the
chosen ‘ON’ and ‘OFF’ heating periods, or be
permanently off. The time on the programmer
must be correct. Some types have to be
adjusted in Spring and Autumn upon the
changes between Winter and Summer time.
You may be able to temporarily adjust
the heating programme, for example,
‘Override’,‘Advance’ or ‘Boost’. These are
explained in the manufacturer’s instructions.
The Central Heating will not work if the room
thermostat has switched the Central Heating
off. And, if you have a Hot Water cylinder, the
water heating will not work if the cylinder
thermostat detects that the Central Hot Water
has reached the correct temperature.
Introduction to the 2 Channel
Programmer
This programmer can automatically switch
your Central Heating and Hot Water ON and
OFF either 2 or 3 times a day, at whatever
times you choose. Timekeeping is maintained
through power interruptions by a replaceable
internal battery (by Qualified Installer/
Electrician only) designed to last for the
lifetime of the programmer and the clock is
automatically put forward 1 hour at 1:00am
on the last Sunday of March and back 1 hour
at 2:00am on the last Sunday of October.
The clock is factory pre-set to UK time and
date, but you can alter it if you want. During
installation, the installer selects 24 hour, 5/2
day, or 7 day programming and either 2 or
3 ON/OFF periods per day, via the Technical
Settings (see installation instructions).
The large, easy to read display makes
programming easy and the unit is designed to
eliminate the possibility of accidental changes
to your programme. Buttons normally visible,
only affect your set programme temporarily.
All buttons which can permanently change
your programme are located behind the flip
over facia.
- The 24 hour programmer option runs the
same programme every day.
- The 5/2 Day programmer option allows
different ON/OFF times at weekends.
- The 7 Day programmer option allows
different ON/OFF times for each day of the
week.
- Pumped System (PU) allows independent
control of Central Heating and Hot Water.
- Gravity System (GR) does not allow
Central Heating without Hot Water but can
provide Hot Water without Central Heating.
NB: When 5/2, 7 day or 24hr is selected for
HW then the same will be applied to Heating
and vise-versa.
IMPORTANT: This programmer is not suitable
for the switching of devices greater than 6
Amp rated. (e.g. Not suitable for use as an
immersion timer)

levante-products.com LEV0608bb/Page 5 of 12/Issue 1/06.19
ADV
ON OFF
AUTO
ALL DAY
ADV
ON OFF
AUTO
ALL DAY
+1 HR
+3 HR
+3 HR
+1 HR
+3 HR
+3 HR
ADV
ON OFF
AUTO
ALL DAY
ADV
ON OFF
AUTO
ALL DAY
+1 HR
+3 HR
+3 HR
+1 HR
+3 HR
+3 HR
TIME/DATE
HEATING HW PROG RUN
ADV
ON OFF
AUTO
ALL DAY
ADV
ON OFF
AUTO
ALL DAY
+1 HR
+3 HR
+3 HR
+1 HR
+3 HR
+3 HR
ADV
ON OFF
AUTO
ALL DAY
ADV
ON OFF
AUTO
ALL DAY
+1 HR
+3 HR
+3 HR
+1 HR
+3 HR
+3 HR
TIME/DATE
HEATING HW PROG RUN
Home (takes you back to home screen)
Next (moves you to the next option
within a function)
Advance to the next programmed
ON/OFF (ADV)
Add up to 3 hours of extra Central
Heating/Hot Water (+HR)
Set Time and Date
Set Programmer Option (24hr, 5/2, 7 Day)
& Central Heating/Hot Water
Set Programmer Option (24hr, 5/2, 7 Day)
& Hot Water
Reset
Set Operation Mode (ON/AUTO/ALL
DAY/OFF)
Runs the programme
+/– buttons for settings adjustment
Moves between days when programming
Central Heating/Hot Water (DAY)
Copy function (COPY)
Holiday Mode
Day of the week
Time Display
AM/PM
Date Display
Displays which ON/OFF period (1/2/3) is
being set when programming Central
Heating/Hot Water
Displays whether setting the ON time
or OFF time when programming Central
Heating/Hot Water (ON/OFF)
Operating Mode (ON/OFF/AUTO/ALL DAY)
Advanced temporary override is active (ADV)
Radiator/Tap symbol show that Central
Heating/Hot Water is currently ON
+ 1hr / 2hr / 3hr temporary override
is active
QUICK OPERATING GUIDE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
1
2
3 4
5
6
7
891110 12 13 14
15 16 17 18 19 20
2421 22 23

levante-products.com LEV0608bb/Page 6 of 12/Issue 1/06.19
PROGRAMMING THE UNIT
The Factory Pre-Set Programme
This Channel Programmer has been designed
to be simple to use, requiring minimal user
intervention with a pre-programmed heating
profile.
The pre-set heating times and temperatures
will suit most people (see table below). To
accept the factory pre-set settings, move
the slider to RUN which will revert the
programmer to Run Mode (the colon (:) in the
LCD display will begin to flash).
If the user changes from the factory-set
programme and wants to return to it,
pressing the reset button with a non metallic
pointed tool will return the unit to the
factory-set programme.
N.B. Every time the reset is pressed, the time
and date must be set again (page 5).
7 Day:
In 7 day setting, the pre-set settings are the
same as 5/2 Day programme (Mon to Fri and
Sat/Sun).
24 Hr:
In 24hr setting, the pre-set settings are
the same as Mon to Fri of the 5/2 Day
programme.
Setting the Programmer Option
(5/2, 7 day, 24hr)
1. Switch the slider to HEATING. Press either
the +/– button to move between 7 day,
5/2 day or 24hr operation.
5/2 Day operation is shown by MO, TU,
WE, TH, FR flashing (5 Day) and then SA,
SU flashing (2 Day)
7 Day operation is shown by just one day
flashing at a time
24 hr operation is shown by MO, TU,WE,
TH, FR, SA, SU flashing at the same time.
2. Wait 15 seconds to automatically confirm
or press the Home button. Move the
slider to RUN to return to Run Mode.
Setting the Central Heating Programme
1. Move the slider to HEATING. Choose
between 5/2 day, 7 day or 24 hr
programmer operation (see above steps
1-2).
2. Press the Next button. Press the Day
button until the desired day/block of days
you want to programme is flashing.
3. The display shows the 1st ON time.
Press +/– to set the time (10 minutes
increments). Press the Next button.
4. The display shows the 1st OFF time.
Press +/– to set the time (10 minutes
increments). Press the Next button.
5. The display will now show the 2nd ON
time. Repeat steps 3-4 until all remaining
ON/OFF periods have been set. On the
last OFF period, press the Day button
until the next desired day/block of days
you want to programme is flashing.
Event Std Time Econ
Time Std Time Econ Time
Week Days
1st ON 06:30 00:00
Weekends
07:30 00:00
1st OFF 08:30 05:00 10:00 05:00
2nd ON 12:00 13:00 12:00 13:00
2nd OFF 12:00 16:00 12:00 16:00
3rd ON 17:00 20:00 17:00 20:00
3rd OFF 22:30 22:00 22:30 22:00
N.B. If 2PU or 2GR is selected, then events 2nd ON and 2nd OFF
are skipped

levante-products.com LEV0608bb/Page 7 of 12/Issue 1/06.19
PROGRAMMING THE UNIT
6. Repeat steps 3-5 until all days/block of
days have been programmed.
7. Wait 15 seconds to automatically confirm
or press the Home button. Move the
slider to RUN to return to Run Mode.
N.B. The copy button can be used in the 7
day setting to copy any chosen day to
the next day (e.g Mon to Tues or Sat to
Sun). Simply change the program for
that day, then push copy repeatedly until
all 7 days (if you so wished) have been
changed.
Setting the Hot Water Programme
1. Move the slider to HW. Choose between
5/2, 7 day or 24hr programmer operation
(see page 6)
2. Press the Next button. Press the Day
button until the desired day/block of days
you want to programme is flashing.
3. The display shows the 1st ON time.
Press +/– to set the time (10 minutes
increments). Press the Next button.
4. The display shows the 1st OFF time.
Press +/– to set the time (10 minutes
increments). Press the Next button.
5. The display will now show the 2nd ON
time. Repeat steps 3-4 until all remaining
ON/OFF periods have been set. On the
last OFF period, press the Day button
until the next desired day/block of days
you want to programme is flashing.
6. Repeat steps 3-5 until all days/block of
days have been programmed. Wait 15
seconds to automatically confirm or press
the Home button. Move the slider to
RUN to return to Run Mode.
N.B. The copy button can be used in the 7
day setting to copy any chosen day to
the next day (e.g Monday to Tuesday or
Saturday to Sunday). Simply change the
program for that day, then push copy
repeatedly until all 7 days (if you so
wished) have been changed.
Setting the Operation
1. Switch the slider to PROG. Press either
the +/– button to move between ON/
OFF/AUTO/ALL DAY. Press the Next
button to move between 2 channels.
ON: Central Heating and Hot Water is
ON continuously
AUTO: Central Heating and Hot
Water will be switched ON and OFF in
accordance with set programmes
ALL DAY: Central Heating and Hot Water
will switch ON at the first ON and switch
OFF at last OFF
OFF: Central Heating and Hot Water will
be permanently OFF
2. Wait 15 seconds to automatically confirm
or press the Home button. Move the
slider to RUN to return to Run Mode.

levante-products.com LEV0608bb/Page 8 of 12/Issue 1/06.19
OPERATING THE UNIT
Temporary Manual Overrides
The Advance Function
The ADVANCE function allows the user
to move to the next ON/OFF programme
for a “one off” event, without having to
change the programme or use the ON or
OFF buttons.
N.B. The ADVANCE function is only available
when the programme is in AUTO or ALL
DAY operating modes and the slider
must be switched to RUN.
To Advance Central Heating
1. Press the Next button until the
radiator symbol is displayed. Press the
ADV button. This will turn the Central
Heating ON if it is in an OFF period and
OFF if it is in an ON period. The word
ADV will appear to the left hand side of
the radiator symbol.
2. It will stay in this state until either
the button is pressed again, or until a
programmed ON/OFF period commences.
To Advance Hot Water
1. Press the Next button until the tap
symbol is displayed. Press the ADV
button. This will turn the Hot Water ON if
it is in an OFF period and OFF if it is in an
ON period. The word ADV will appear to
the left hand side of the tap symbol.
2. It will stay in this state until either the
ADV button is pressed again, or until a
programmed ON/OFF period commences.
The +HR Boost Function
The +HR function allows the user to have
up to 3 hours of extra Central Heating or
Hot Water, without having to change the
programme.
N.B. The +HR function is only available
when the programme is in AUTO, ALL
DAY or OFF operating modes and the
slider must be switched to RUN. If the
programmer is in AUTO or ALL DAY
mode when the +HR button is pressed
and the resulting time of the boost
overlaps a START/ON time, the boost will
disengage.
To +HR Boost Central Heating
1. Press the Next until the radiator
symbol is displayed.Press the +HR
button.
2. One press of the button will give one
extra hour of Central Heating; two
presses of the button will give two extra
hours; three presses of the button will
give the maximum three extra hours.
Pressing it again will switch off the
+HR function.
3. The +1HR, +2HR or +3HR status will
appear on the right hand side of the
radiator symbol.
To +HR Boost Hot Water
1. Press the Next button until the tap
symbol is displayed. Press the +HR
button.
2. One press of the button will give one
extra hour of Hot Water; two presses
of the button will give two extra hours;
three presses of the button will give the
maximum three extra hours. Pressing it
again will switch off the +HR function.
3. The +1HR, +2HR or +3HR status will
appear on the right hand side of the tap
symbol.

levante-products.com LEV0608bb/Page 9 of 12/Issue 1/06.19
Holiday Mode
Holiday Mode saves energy by letting you
reduce the temperature for 1 to 99 days
while you are away from home, resuming
normal operation on your return.
1. Press to enter Holiday Mode and the
screen will display d:1.
2. Press +/– buttons to select the number of
days you would like the holiday mode to
run for (between 1-99 days).
3. Press the Home button to confirm.
The system will now turn OFF for the
number of days chosen. The number of
days will alternate with the time symbol
on display and the number of days will
count down.
4. Once the countdown has finished,
the programmer will return to normal
operation. It may be advisable to set the
Holiday Mode 1 day less so the house is
back up to temperature for your return.
5. To cancel the Holiday Mode, press
the button to revert back to run mode.

levante-products.com LEV0608bb/Page 10 of 12/Issue 1/06.19
BASIC SETTINGS
Setting the Time and Date
The time and date are factory set and changes
between summer and winter time are handled
automatically by the unit.
1. Switch the slider to TIME/DATE.
2. The hour symbols will flash, use the +/–
buttons to adjust.
3. Press the Next button and the minute
symbols will flash, use the +/– buttons to
adjust.
4. Press the Next button and the day
date will flash, use the +/– buttons to
adjust the day.
5. Press the Next button and the month
date will flash, use the +/– buttons to
adjust the month.
6. Press the Next button and the year
date will flash, use the +/– buttons to
adjust the year.
Setting the Backlight
The backlight can either be set permanently
ON or OFF.
The programmer backlight is pre-set to be
permanently OFF. When the backlight is
permanently OFF, the backlight will turn
ON for 15 seconds when + or – button is
pressed, then turn OFF automatically.
To change setting to permanently ON, move
the slider to TIME/DATE. Press the Next
button repeatedly until Lit is displayed. Press
+or –to turn backlight ON or OFF. Press
the Next button or wait for 15 seconds
to automatically confirm and return to Run
Mode.
N.B. Do not use Advance or +HR Boost
Button to activate the backlight as it
may engage the Advance or +HR facility
and turn on the boiler. Only use the
Home button.
Resetting the Unit
Press the reset button with a non-metallic
pointed tool to reset the unit. This will
restore the built in programme and also
reset the time to 12:00pm and the date to
01/01/2000. To set the time and date, (please
refer to page 6).
N.B. As a safety feature after resetting the
unit will be in OFF operating mode.
Reselect your required operating mode
(page 4). Use of excessive force may
result in the reset button sticking behind
the front cover of the programmer. If
this happens the unit will “freeze” and
the button can only be released by a
qualified installer.
Power Interruption
In the event of a mains supply failure the
screen will go blank but the back-up battery
ensures that the programmer continues
to keep the time and retain your stored
programme. When power is restored, switch
the slider to RUN to return to Run mode.

levante-products.com LEV0608bb/Page 11 of 12/Issue 1/06.19

levante-products.com LEV0608bb/Page 12 of 12/Issue 1/06.19
LIMITED WARRANTY
This product has been made under strictest quality control procedures to ensure good performance and reliability.
This product has a warranty against defects in materials and workmanship for 3 years from the date of purchase.
PROVIDED:
1. Reasonable evidence is supplied to prove the product has been purchased within 3 years prior to the
date of claim.
2. The defect is not due to misuse, neglect, accidental damage or repair by unqualified engineers.
This warranty does not cover any claims for consequential loss or damage.
These statements do not affect your statutory rights as a customer.
DISPOSAL
In accordance with European Directive
2002/96/EG concerning waste electrical
and electronic equipment (WEEE), please
return any electrical equipment that you
will no longer use to the collection points provided for
their disposal.
This symbol indicates that the appliance cannot be
treated as normal domestic waste, but must be handed
to a collection point for where electric and electronic
appliances are recycled.
Information concerning where the equipment can be
disposed of can be obtained from your local authority.
CARE AND CLEANING
Wipe with a dry cloth to remove dust or with a
damp (not wet) cloth to clean stains. Ensure that no
moisture gets into the unit.
Do not use abrasive cleaning powder, metal polish or
furniture polish on any part of the product.
CUSTOMER SERVICE
Repairs must be carried out by authorised specialists,
thus ensuring electrical safety. Please contact a service
agent or a suitably qualified electrician. Improper repairs
could lead to danger to the user.
The warranty does not cover damage of failure which
results from alteration, accident, misuse, abuse, neglect,
commercial use or improper maintenance.
In line with our policy of continuous product
development we reserve the right to change the product
and documentation specifications without notice.
