Leviton 42A00-2 User manual
INSTALLATION ENGLISH
DI-021-SY422-05AAR2253
(42I00-2)
WIRELESS RECEIVER
Cat. No. 42A00-2
Installation Instructions
WARNINGS AND CAUTIONS
• Readandunderstandallinstructions.Followallwarningsandinstructionsmarkedontheproduct.
• Donotusethisproductnearwater-e.g.,nearatub,washbasin,kitchensinkorlaundrytub,inawetbasement,ornearaswimmingpool.
• Neverpushobjectsofanykindintothisproductthroughopenings,astheymaytouchdangerousvoltages.
• SAVETHESEINSTRUCTIONS.
WARNINGS AND CAUTIONS
• Neverinstallcommunicationswiringorcomponentsduringalightningstorm.
• Neverinstallcommunicationscomponentsinwetlocationsunlessthecomponentsaredesignedspecicallyforuseinwetlocations.
• Nevertouchuninsulatedwiresorterminalsunlessthewiringhasbeendisconnectedatthenetworkinterface.
• Usecautionwheninstallingormodifyingcommunicationswiringorcomponents.
DESCRIPTION
TheModel42A00-2SupervisedWirelessReceiverallowsupto64uniquewireless
securitytransmitterstoreportinformationtoanOmniLT,Omni,OmniII,OmniIIe,
OmniPro,OmniProII,Lumina,andLuminaProcontroller.Thewirelesstransmitters
replacewireddoorandwindowsensors,aswellaswiredsmoke,motion,andglassbreak
detectors.Thesetransmittersreportstatusinformationtothe42A00-2Receiverwhich,in
turn,processestheinformationandreportsittotheHAIcontroller.
The42A00-2Receiverfeaturesspatialdiversity,whichminimizeswirelesssignalnullsor
deadspots.Thereceivermaybemountedupto1000feetfromtheHAIcontroller.
COMPATIBLE TRANSMITTERS
TheModel42A00-2SupervisedWirelessReceiveriscompatiblewithall319.5MHz
GESecurity(a.k.a.ITIorInterlogix)andCaddx(crystalorSAW)LearnModeTM63-bit
wirelesstransmitters.Thisreceiverisnotcompatiblewith80-bitwirelesstransmitters.
INSTALLATION
Installthereceiverinacentralareaofthepremises,ashighabovegroundaspractical
(allowatleasta9-inchclearanceabovereceivertomounttheantennas).
• Thereceivershouldbeatleast5feetfromthecontrolleroranyotherelectronicdevice.
• Theopen-airrangeis1000feet;buildingconstructionwillreducetherange.
• Avoidareaswherereceiverwillbeexposedtomoisture.
• Avoidareaswithexcessivemetalorelectricalwiring.Ifunavoidable,mountwhere
antennasextendabovethemetallicsurface.
Whenthelocationofthereceiverhasbeenestablished:
1. Removethecoverbyinsertingascrewdriverintotheslotonthebottomedgeofthe
cover,pushgentlytoreleasethelatch,andthenliftthecoverfromthebase.
2. Removethewirelessreceivercircuitboardfromthebasebygentlypryingdownthe
bottomlatchwhileslidingthecircuitboardfromunderthetwotoplatches.
3. Holdthebaseagainstthemountingsurfaceandmarkthetwo(2)mountingholes(see
Figure 1).Remembertoallowatleasta9-inchclearancetomounttheantennas.
4. Drillaholeateachmountingholemarkingandinstallthesuppliedwallanchors.
5. Mountthebase,usingthesuppliedscrews,tothewallanchors.
6. Inserttheantennasintothesuppliedantennashrouds(see Figure 1).
7. Gentlyslidethetopofthewirelessreceivercircuitboardunderthetwotoplatches.
8. Snapthecircuitboardinatthebottomlatchandsecureitinplace(see Figure 1).
TYPE
LED
LED
DISPLAY
MODE
LED
GND
BA+12V
MOUNTING
HOLES (2)
ANTENNAS
SHROUDS
MODE /
ADVANCE
SWITCH
SET
SWITCH
TOP LATCHES
BOTTOM LATCH
STATUS
LEDs
OPERATION
Thetwooperatingmodesofthereceiverare"Run"and"Setup".
InRunMode,withthereceiverconnectedtoandcommunicatingwiththecontroller,
theModeLED(see Figure 1)shouldblinkoncepersecond.Thereceivermonitorsthe
statusofeachtransmitter.Ifthestatusconditionofatransmitterchanges,itisreported
tothereceiverandtheinformationisupdatedontheLEDdisplayandtheStatusLEDwill
ash.Thetransmitternumberashesonthedisplaywheneverareportisreceivedfrom
atransmitter.Thedisplaywillcontinuallydisplaythestatusofanytransmittersthatare
violated(notready)orthathavetrouble.Thetransmitternumberashesonthedisplay
followedbythestatuscondition(s).
NOTE:Ifthereceiverisnotcommunicatingwiththecontroller,theModeLEDwillblink
fourtimespersecond.
SET-TheSetswitch(see Figure 1)isusedtoincrementorchangethecurrentselection.
MODE /ADVANCE-TheMode/Advanceswitch(see Figure 1)isusedtoenterSetup
Mode,advancetothenextSetupitem,andtoconrmaselection.Itisalsousedtoexit
SetupMode.
LED DISPLAY-TheLEDDisplay(see Figure 1)isusedtoshowthestatusofeach
transmitterandtoensurepropersetup.
MODE LED-InRunMode,theModeLED(see Figure 1)isusedtoindicate
communicationstatuswiththecontroller.InSetupMode,theModeLEDisusedto
indicateifatransmittersendsarestorecode.
TYPE LED-InSetupMode,theTypeLED(see Figure 1)isusedtoindicateifa
transmitterissupervised.
STATUS LEDs–ThefollowingtableshowsthestatusoftheStatusLEDindicators:
Indication Green LED Red LED
Poweredup On Off
Validtransmitterpacketreceived Oneashoff Offorashing
SETUP MODE
TheSetupModeisusedtocongurethegeneraloperatingparametersofthereceiver,
toprogramatransmitterintothereceiver,andtochangethecharacteristicsofa
programmedtransmitter.TheModeLEDdoesnotblinkinSetupMode.
To enter the Setup Mode:
A.PressandholdtheMode/Advanceswitchforapproximatelytwoseconds.
B.PresstheSetswitchtoincrementthevalueofaSetupitem.
C.PresstheMode/AdvanceswitchistoadvancetothenextSetupitem.
Receiver Address
You are rst prompted to enter the receiver address. "A" is shown on the left of the display
and the current address is shown on the right. Press the Set switch to increment the
address value. The current address will be stored into memory when the Mode/Advance
switch is pressed. Setup Mode is exited when the Mode/Advance switch is pressed and
held for two seconds.
Number of Addresses
Next,youarepromptedtoenterthe"numberofaddresses"(seetheSetupinformation
inthisdocumentforcongurationofeachHAIcontroller).Theletter"n"isshownonthe
leftofthedisplayandthedigitforthecurrentnumberofaddressesisshownontheright
ofthedisplay.PresstheSetswitchtoincrementthenumberofaddressesvalue.The
currentnumberofaddresseswillbestoredintomemorywhentheMode/Advanceswitch
ispressed.SetupModeisexitedwhentheMode/Advanceswitchispressedandheldfor
twoseconds.
Configuring Transmitters
Allofthefollowinglocationsareusedforconguringandprogrammingtransmitters.Each
newtransmittercanbeprogrammedintothereceiverandeachprogrammedtransmitter,
alongwithitscharacteristics,isdisplayedandcanbemodied.Thetransmitternumberis
shownintheLEDDisplay.
If no transmitter is programmed in an address location, neither the Mode LED nor the
Type LED will be lit.
Ifatransmitterisprogrammedinanaddresslocation:
1. TheModeLEDindicateswhetherthetransmittersendsrestoretransmissions
• TheModeLEDisonifthetransmittersendsrestoretransmissions,andoffifit
doesn't.
2. TheTypeLEDshowswhetherthetransmitterissupervised.
• TheTypeLEDisonsteadyifthetransmitterissupervised,andblinksifitisn't.
TheSetswitchisusedtochangethecharacteristicsofaprogrammedtransmitter.Each
pressoftheSetswitchcyclesthrougheachcombinationofsupervised,sendsrestores,or
notransmitterprogrammed.
TheMode/Advanceswitchisusedtoadvancetothenexttransmitteraddresslocation.
SetupModeisexitedbypressingandholdingtheMode/Advanceswitchfortwoseconds.
TEACHING THE RECEIVER A TRANSMITTER ADDRESS
Ifnotransmitterisprogrammedinanaddresslocation,anewtransmittermaybe
programmedintothataddresslocationbyactivatingthedesiredtransmitter.Theactivated
transmitterwillthenbeenteredintothataddresslocation.Thetransmittermustbe
activatedaccordingtotheinstructionsthataccompanythetransmitter.
Basedonthetypeoftransmitter,thereceiverwilltrytosetthesupervisoryandrestore
characteristicsthatareappropriateforthattypeoftransmitter.Thesecanbechangedas
desiredusingtheSetswitch.
Onceatransmitterisprogrammedintoanaddresslocation,thetransmitteraddresswill
brieyturnoffwheneveratransmissionfromthattransmitterisreceived.Thiscanbeused
toverifythatthecorrecttransmitterhasbeenprogrammedandisoperatingreliably.
NOTE:Thecontrollerignoresthecurrentstatusofeachtransmitterwhilethereceiverisin
SetupMode.
TRANSMITTER SETUP
1. PressandholdtheMode/Advancebuttonfortwo(2)seconds.
2. "A1"willappear.OnOmniLT,Omni,OmniII,OmniIIe,andLumina,"A1"isalways
used.OnOmniPro,OmniProII,andLuminaPro,theaddresswilldependonthe
numberofexpansionenclosuresused.
3. PresstheMode/Advancebuttontosaveanychangesandproceed.
4. Next,"n1"willappear.Thevalueof"n"willdeterminethenumberofaddressesused.
5. PresstheMode/Advancebuttontosaveanychangesandproceed.
6. "1"willappear(1sttransmitteraddresslocation).Tripthetransmitter.Whenthe
42A00-2receivesthetransmission,the42A00willdisplaythedigit(transmitter
address)withadotoneitherside(thedotsindicatethetransmitter'scharacteristics).
7. PresstheMode/Advancebuttontosavethechangesandproceed.
8. "2"willappear(2ndtransmitteraddresslocation).Tripthetransmitter.Whenthe
42A00-2receivesthetransmission,the42A00-2willdisplaythedigit(transmitter
address)withadotoneitherside(thedotsindicatethetransmitter'scharacteristics).
9. PresstheMode/Advancebuttontosavethechangesandproceed.
10. Repeatforeachtransmitteraddress(1-64)untilalltransmittershavebeen
programmed.
11. Afteralltransmittershavebeenprogrammed,replacethecover.
RESETTING OR REMOVING A TRANSMITTER
Toreplaceanexistingtransmitter,resetthecharacteristicsofatransmitter,orremove
atransmitter,enterSetupModeasdescribedunder"TransmitterSetup"inthismanual.
Whenthetransmitteraddresslocationappearsonthedisplay,removethetransmitter's
characteristicsbypressingtheSETbuttonuntiltherearenodots(blinkingorotherwise)
oneithersideoftheaddressnumber.Thetransmitterinnowremoved.
Toreplacethetransmitter,simplytripthenewtransmitter.Whenthe42A00-2receivesthe
transmission,the42A00-2willdisplaythedigit(transmitteraddresslocation)withadoton
eitherside(thedotsindicatethetransmitter'scharacteristics).
RESET MEMORY
Toerasealltransmittersfrommemoryandtoresettothefactorydefaultconguration,
pressandholdboththeSetandMode/Advanceswitchessimultaneouslyfor2seconds.
Thedisplaywillshow"EE".Ifyouchoosetocontinue,pressandholdtheSetandMode/
Advanceswitchessimultaneouslyfor2secondsonceagain.Memoryisresetattheendof
thetwoseconds.
NOTE:Ifyouchoosenottoresetmemoryatthe"EE"display,don’tpressanykeysfor10
secondsandthereceiverwillreturntoRunMode.
CONNECTING TO OMNILT
ConnectthereceivertotheOmniLTcontrollerusing4-conductor,22-gaugeorlargerwire
asfollows:
1. Connectthe"A"and"B"terminalsofthe42A00-2tothe"YEL"(Yellow)and"GRN"
(Green)terminalsunderthesectionmarked"CONSOLE"ontheOmniLTcontroller
(Yellow=AandGreen=B).
2. Connectthe"+12"and"GND"terminalsofthe42A00-2tothe"RED"and"BLK"(Black)
terminalsunderthesectionmarked"CONSOLE"ontheOmniLTcontroller(Red=
+12VandBlack=GND).VerifythattheStatusLEDonthereceiverisilluminated.
OMNILT SETUP
A.Ataconsole,select"InstallerSetup"(press9,installercode,then#).Press2for
"Zones",andthenpress1#("WirelessReceiver?"Yes =1).
B.WhenconnectedtoOmniLT,Zones9-24arethewirelessreceiverzones.
C.WhenconnectedtoOmniLT,thereceiveraddressonthe42A00-2mustbesetto"A1"
andthenumberofaddressesmustbesetto"n1".
D.OmniLTcanhandleupto4transmittersperzone.
Thechartbelowshowstherelationshipofeachwirelesstransmitteronthe42A00-2
WirelessReceivertoeachzoneontheOmniLT.
Zones on OmniLT Transmitter Numbers on Wireless Receiver
Zone09 1 17 33 49
Zone10 218 34 50
Zone11 319 35 51
Zone12 4 20 36 52
Zone13 5 21 37 53
Zone14 6 22 38 54
Zone15 7 23 39 55
Zone16 8 24 40 56
Zone17 9 25 41 57
Zone18 10 26 42 58
Zone19 11 27 43 59
Zone20 12 28 44 60
Zone21 13 29 45 61
Zone22 14 30 46 62
Zone23 15 31 47 63
Zone24 16 32 48 64
BLACK
GREEN
YELLOW
RED
Wireless Receiver
BGND+12V A
GREEN
YELLOW
BLACK
RED
Controller
SPECIFICATIONS
Dimensions: 4.5Wx6.4Hx1.2D,excludingantennas
Nominal Current Consumption: 45mA
Operating Temperature: 32oF-120oF(0oC-49oC)
Maximum Humidity: 90%relativehumidity,non-condensing
NOTE:ThisproductcannotbesoldinthestateofCaliforniaifusedtoreceiveresignals
(persection208-g.Chapter1.5ConstructionMaterialsandEquipmentListings,Title19,
CaliforniaCodeofRegulations.
LED DISPLAY INFORMATION ABOUT THE LED DISPLAY
| . | Displaysthenumberofthetransmitterwithachangeincondition.
A L Displaysthatthecurrenttransmitteris"NOTREADY".
C D Displaysthatthecoverwasremovedfromthecurrenttransmitter.
S F Displaysthatthecurrenttransmitterhasasupervisionfailure.
L D Displaysthatthecurrenttransmitterhasreportedabatterylow.
WEB VERSION
For Technical Assistance Call: 800-824-3005 - www.leviton.com
DI-021-SY422-05AAR2253
FOR CANADA ONLY
Forwarrantyinformationand/orproductreturns,residentsofCanadashouldcontactLevitoninwritingat
Leviton Manufacturing of Canada Ltd to the attention of the Quality Assurance Department, 165
Hymus Blvd, Pointe-Claire (Quebec), Canada H9R 1E9orbytelephoneat1 800 405-5320.
CONNECTING TO OMNI / OMNIPRO
ConnectthereceivertotheOmniorOmniProcontrollerusing4-conductor,22-gaugeor
largerwireasfollows:
1. Connectthe"A"&"B"terminalsofthe42A00-2tothe"A"&"B"terminalsunderthe
sectionmarked“CONSOLE”onthecontroller.
2. Connectthe"+12"and"GND"terminalsofthe42A00-2tothe"12V"and"GND"
terminalsunderthesectionmarked"CONSOLE"onthecontroller.VerifythattheStatus
LEDonthereceiverisilluminated.
OMNI SETUP
A.Ataconsole,select"InstallerSetup"(press9,installercode,then#).Press2for
"Zones",andthenpress1#("WirelessReceiver?"Yes =1).
B.WhenconnectedtoOmni,Zones17-32arethewirelessreceiverzones.
C.WhenconnectedtoOmni,thereceiveraddressonthe42A00-2mustbesetto"A1"
andthenumberofaddressesmustbesetto"n1".
D.Omnicanhandleupto4transmittersperzone
Thechartbelowshowstherelationshipofeachwirelesstransmitteronthe42A00-2
WirelessReceivertoeachzoneontheOmni.
Zones on Omni Transmitter Numbers on Wireless Receiver
Zone17 1 17 33 49
Zone18 218 34 50
Zone19 319 35 51
Zone20 4 20 36 52
Zone21 5 21 37 53
Zone22 6 22 38 54
Zone23 7 23 39 55
Zone24 8 24 40 56
Zone25 9 25 41 57
Zone26 10 26 42 58
Zone27 11 27 43 59
Zone28 12 28 44 60
Zone29 13 29 45 61
Zone30 14 30 46 62
Zone31 15 31 47 63
Zone32 16 32 48 64
BLACK
GREEN
YELLOW
RED
Wireless Receiver
BGND+12V A
Controller
YELLOW
GREEN
RED
BLACK
OMNIPRO SETUP
A.WhenconnectedtoanOmniPro,the42A00-2isrecognizedasanExpansion
Enclosure.The42A00-2canhandleupto64wirelesszones,ingroupsof16.Each
groupof16zonesisconsidered1ExpansionEnclosure.
B.Ataconsole,select“InstallerSetup”(press9,installercode,then#).Press2for
"Zones".Pressthedownarrowonce,thenenterthenumberofexpansionenclosures
(groupsof16wirelesszones)beingused.
C.ThewirelesszonesontheOmniProstartonZone33(ifno17A00-1expansion
enclosuresareused).
D.The42A00-2addressissetat1(A1)(ifno17A00-1expansionenclosuresare used).
E.IftheOmniProhas117A00-1expansionenclosure,thewirelesszonesstartonZone
49.The42A00-2addressisthensetto2(A2).
F. IftheOmniProhas217A00-1expansionenclosures,thewirelesszonesstartonZone
65.The42A00-2addressisthensetto3(A3).
G.IftheOmniProhas317A00-1expansionenclosures,thewirelesszonesstartonZone
81.The42A00-2addressinthensetto4(A4).
Thechartbelowdescribeswhereeachgroupofwirelesstransmitters(groupsof16)on
the42A00-2WirelessReceiverrelatestoeachgroupofzones(groupsof16)onthe
OmniProinaccordancewiththe“numberofaddresses”assigned(n1-4).
Zones on OmniPro (in groups of 16)
Zones 33-48 Zones 49-64 Zones 65-80 Zones 81-96
n1 Transmitters:1-16,
17-32,33-48,and49-64
n2 Transmitters:
1-16and33-48
Transmitters:
17-32and49-64
n3 Transmitters:
1-16and49-64
Transmitters:
17-32
Transmitters:
33-48
n4 Transmitters:1-16 Transmitters:
17-32
Transmitters:
33-48
Transmitters:
49-64
CONNECTING TO OMNI II / OMNI IIe / OMNIPRO II / LUMINA / LUMINA PRO
ConnectthereceivertotheOmniII,OmniIIe,OmniProII,Lumina,orLuminaPro
controllerusing4-conductor,22-gaugeorlargerwireasfollows:
1. Connectthe"A"&"B"terminalsofthe42A00-2tothe"A"&"B"terminalsunderthe
sectionmarked"CONSOLE"onthecontroller.
2. Connectthe"+12"and"GND"terminalsofthe42A00-2tothe"12V"and"GND"
terminalsunderthesectionmarked“CONSOLE”onthecontroller.VerifythattheStatus
LEDonthereceiverisilluminated.
BLACK
GREEN
YELLOW
RED
Wireless Receiver
BGND+12V A
GREEN
YELLOW
BLACK
RED
Controller
OMNI II / OMNI IIe / LUMINA SETUP
A.Ataconsole,select"InstallerSetup"(press9,installercode,then#).Press2for
"Zones",andthenpress1#("WirelessReceiver?"Yes =1).
B.WhenconnectedtoOmniII,OmniIIe,orLumina,Zones33-48arethewireless
receiverzones.
C.Thereceiveraddressonthe42A00-2mustbesetto"A1"andthenumberofaddresses
mustbesetto"n1".
D.Thiscongurationcanhandleupto4transmittersperzone.
Thechartbelowshowstherelationshipofeachwirelesstransmitteronthe42A00-2
WirelessReceivertoeachzoneontheOmniII,OmniIIe,andLumina.
Zones on Omni IIe / Lumina Transmitter Numbers on Wireless Receiver
Zone33 1 17 33 49
Zone34 218 34 50
Zone35 319 35 51
Zone36 4 20 36 52
Zone37 5 21 37 53
Zone38 6 22 38 54
Zone39 7 23 39 55
Zone40 8 24 40 56
Zone41 9 25 41 57
Zone42 10 26 42 58
Zone43 11 27 43 59
Zone44 12 28 44 60
Zone45 13 29 45 61
Zone46 14 30 46 62
Zone47 15 31 47 63
Zone48 16 32 48 64
OMNIPRO II / LUMINA PRO SETUP
A.OmniProIIandLuminaProcanhavetwo42A00-2WirelessReceiversconnected.
WhenconnectedtoanOmniProIIorLuminaPro,the42A00-2isrecognizedasan
ExpansionEnclosure.Each42A00-2canhandleupto64wirelesszones,ingroups
of16.Eachgroupof16zonesisconsidered1ExpansionEnclosure(8Expansion
Enclosuresmaximum).
B.Ataconsole,select“InstallerSetup”(press9,installercode,then#).Press2for
"Zones".Pressthedownarrowonce,thenenterthenumberofexpansionenclosures
(groupsof16wirelesszones)beingused.
C.ThewirelesszonesontheOmniProIIandLuminaProstartonZone49(ifno17A00-1
expansionenclosuresareused).
D.The42A00-2addressissetat1(A1)(ifno17A00-1expansionenclosuresareused).
E.If117A00-1expansionenclosureisbeingused,thewirelesszonesstartonZone65.
The42A00-2addressisthensetto2(A2).
F. If217A00-1expansionenclosuresarebeingused,thewirelesszonesstartonZone
81.The42A00-2addressisthensetto3(A3).
G.If317A00-1expansionenclosuresarebeingused,thewirelesszonesstartonZone
97.The42A00-2addressinthensetto4(A4).
H.If417A00-1expansionenclosurearebeingused,thewirelesszonesstartonZone
113.The42A00-2addressisthensetto5(A5).
I. If517A00-1expansionenclosuresarebeingused,thewirelesszonesstartonZone
129.The42A00-2addressisthensetto6(A6).
J. If617A00-1expansionenclosuresarebeingused,thewirelesszonesstartonZone
145.The42A00-2addressinthensetto7(A7).
K.If717A00-1expansionenclosuresarebeingused,thewirelesszonesstartonZone
161.The42A00-2addressinthensetto8(A8).
NOTE:Iftwo42A00-2WirelessReceiversareconnected,therst42A00-2mustbe
addressedbetween1-4(A1-A4),andthesecondmustbeaddressedbetween5-8(A5-A8).
Thechartsbelowdescribewhereeachgroupofwirelesstransmitters(groupsof16)on
the42A00-2WirelessReceiverrelatestoeachgroupofzones(groupsof16)onthe
OmniProIIorLuminaProinaccordancewiththenumberofaddressesassigned(n1-4).
Zones on OmniPro II and Lumina Pro (in groups of 16) when 42A00-2 is set to address "A1"
Zones 49-64 Zones 65-80 Zones 81-96 Zones 97-112
n1 Transmitters:1-16,
17-32,33-48,and
49-64
n2 Transmitters:1-16
and33-48
Transmitters:
17-32and49-64
n3 Transmitters:1-16
and49-64
Transmitters:
17-32
Transmitters:
33-48
n4 Transmitters:1-16 Transmitters:
17-32
Transmitters:
33-48
Transmitters:
49-64
Zones on OmniPro II and Lumina Pro (in groups of 16) when 42A00-2 is set to address "A5"
Zones 113-128 Zones 129-144 Zones 145-160 Zones 161-176
n1 Transmitters:1-16,
17-32,33-48,and
49-64
n2 Transmitters:1-16
and33-48
Transmitters:
17-32and49-64
n3 Transmitters:1-16
and49-64
Transmitters:
17-32
Transmitters:
33-48
n4 Transmitters:1-16 Transmitters:
17-32
Transmitters:
33-48
Transmitters:
49-64
CONTROLLER INDICATIONS
Whentheconditionofatransmitterchangesstate,theconsolewilldisplaythatcondition
asfollows:
QUICK REFERENCE SETUP GUIDE
Transmitter Condition Console Display
Whenatransmitter(zone)isviolated ZoneName"NOTRDY"
Whenacoverisremovedfromatransmitter ZoneName"NOTRDY"
Whenasupervisoryfailureisreported ZoneName"TRBLNOW"
Whenabatterylowisreported ZoneName"HADTRBL"
FCC Compliance
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuant
topart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmful
interferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcanradiateradiofrequency
energyand,ifnotinstalledandusedinaccordancewiththeinstructions,maycauseharmfulinterference
toradiocommunications.However,thereisnoguaranteethatinterferencewillnotoccurinaparticular
installation.Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,which
canbedeterminedbyturningtheequipmentoffandon,theuserisencouragedtotrytocorrectthe
interferencebyoneormoreofthefollowingmeasures:
• Reorientorrelocatethereceivingantenna.
• Increasetheseparationbetweentheequipmentandreceiver.
• Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiveris
connected.
• Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ToenterSetupMode,pressandholdtheMode/Advanceswitchfor2seconds.
CharacteristicsofTransmitters:
Toresetmemory,pressandholdtheSetandMode/Advanceswitchestogetherfor2seconds.
LEVITON LIMITED WARRANTY
LevitonwarrantstotheoriginalconsumerpurchaserandnotforthebenetofanyoneelsethatproductsmanufacturedbyLevitonundertheLevitonbrandname(“Product”)willbefreefromdefectsinmaterialandworkmanshipforthetimeperiodsindicatedbelow,whicheverisshorter:• OmniPro II and Lumina Pro: three(3)yearsfrominstallationor42monthsfrommanufacturedate. • OmniLT, Omni IIe, and Lumina: two(2)years
frominstallationor30monthsfrommanufacturedate. • Thermostats, Accessories: two(2)yearsfrominstallationor30monthsfrommanufacturedate. • Batteries: Rechargeablebatteriesinproductsarewarrantedforninety(90)daysfromdateofpurchase.Note:Primary(non-rechargeable)batteriesshippedinproductsarenotwarranted.Products with Windows®Operating Systems:Duringthewarrantyperiod,Levitonwillrestore
corruptedoperatingsystemstofactorydefaultatnocharge,providedthattheproducthasbeenusedasoriginallyintended.Installationofnon-Levitonsoftwareormodicationoftheoperatingsystemvoidsthiswarranty.Leviton’s obligationunderthisLimitedWarrantyislimitedtotherepairorreplacement,atLeviton’soption,ofProductthatfailsduetodefectinmaterialorworkmanship.Levitonreservestherighttoreplaceproductunder
thisLimitedWarrantywithneworremanufacturedproduct.Leviton will not be responsible for labor costs of removal or reinstallation of Product.TherepairedorreplacedproductisthenwarrantedunderthetermsofthisLimitedWarrantyfortheremainderoftheLimitedWarrantytimeperiodorninety(90)days,whicheverislonger.ThisLimitedWarrantydoesnotcoverPC-basedsoftwareproducts.Leviton is not responsible
for conditions or applications beyond Leviton’s control. Leviton is not responsible for issues related to improper installation, including failure to follow written Installation and operation instructions, normal wear and tear, catastrophe, fault or negligence of the user or other problems external to the Product.To viewcompletewarrantyandinstructionsforreturningproduct,pleasevisitusatwww.leviton.com.
Copyright and Trademark Information
Thisdocumentandallitscontentshereinaresubjecttoandprotectedbyinternationalcopyrightand
otherintellectualpropertyrightsandarethepropertyofLevitonManufacturingCo.,Inc,itssubsidiaries,
afliatesand/orlicensors.©2013LevitonManufacturingCo.,Inc.Allrightsreserved.
Usehereinofthirdpartytrademarks,servicemarks,tradenames,brandnamesand/orproductnames
areforinformationalpurposesonly,are/maybethetrademarksoftheirrespectiveowners;suchuseis
notmeanttoimplyafliation,sponsorship,orendorsement.
Nopartofthisdocumentmaybereproduced,transmittedortranscribedwithouttheexpresswritten
permissionofLevitonManufacturingCo.,Inc.
DISPLAY DESCRIPTION SET SWITCH MODE/ADVANCE SWITCH
A | Enterthereceiver
address
Changesthecurrent
address(1-8)
Advancestothenextitem
n
| Enternumberof
addresses
Changesnumberof
addresses(1-4)
Advancestothenextitem
|Displaysthestatusof
transmitter1
Changescharacteristics
oftransmitter
Advancestothenexttransmitter
2Displaysthestatusof
transmitter2
Changescharacteristics
oftransmitter
Advancestothenexttransmitter
3Displaysthestatusof
transmitter3
Changescharacteristics
oftransmitter
Advancestothenexttransmitter
DISPLAY DESCRIPTION SET SWITCH
e e EraseEEPROM?(Reset
Memory)
PressandholdSet&Mode/Advanceswitches
togetherfor2seconds
DISPLAY MODE LED TYPE LED DESCRIPTION OF THE DISPLAY
|OFF OFF Notransmitterisprogrammedatthisaddress
|OFF BLINKS Thistransmitterisnotsupervisedanddoesn'tsend
restoretransmissions
|ON BLINKS Thistransmitterisnotsupervisedbutsendsrestore
transmissions
|OFF ON Thistransmitterissupervisedbutdoesn'tsend
restoretransmissions
|ON ON Thistransmitterissupervisedandsendsrestore
transmissions
*
*
•
•
•
•
WEB VERSION
Other Leviton Receiver manuals
