Lexus LX570 2017 User instructions

LX 570
Lexus Personalized Settings
Your vehicle includes a variety of electronic features that can be programmed to your
preferences. Programming of these features is performed once at no charge by your
Lexus Dealer provided you obtain the service at the 6-month/5,000-mile scheduled
maintenance service.
It is also possible to customize certain vehicle features yourself using the navigation
system screen.
Settings that can be customized by:
Using the
Navigation System Dealer
LPS options were correct at time of development. All options are subject to change without prior notice.
Vehicles with Navigation System:
Press the button.
Highlight then
push knob to select.
STEP 1
STEP 4
Select category and scroll to specific
customization setting.
STEP 5
MENU
Vehicle must be in “ON” mode to
program personalized settings.
Please refer to the 2017 LX 570
Quick Guide or Navigation
Owner’s Manual for more
information on Remote Touch
operations.
Door Lock Settings
1. Automatic Door Lock
The automatic door locks can be programmed as follows:
□The doors automatically lock when the vehicle speed is 12 mph or higher = By speed
  □The doors automatically lock when the vehicle is taken out of Park and shifted into another
range (Standard) = By shift from P
□The doors will not automatically lock = Off
2. Automatic Door Unlock
The automatic door locks can be programmed as follows:
□The doors automatically unlock when the vehicle is shifted into Park (Standard) =
By shift to P
□All the doors automatically unlock when the driver door is opened = By driver door
□The doors will not automatically unlock = Off
3. Remote 2-Press Unlock
When using the electronic key to unlock the doors:
□Pressing the unlock button one time unlocks the driver’s door and two times unlocks all
doors (Standard) = On
□Pressing the unlock button one time unlocks all doors = Off
Menu
Vehicle Settings
Setup
Climate Nav
Navigation
Data Services
Settings
Vehicle
Scroll to Page 2. Highlight then
push knob to select.
STEP 3
Phone LEXUS
App Suite
Display
LEXUS App Suite Info
Radio Media Phone Setup
Setup
Page2
LEXUS Park Assist
Maintenance
Vehicle Customization
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
MENU
Highlight using the Remote
Touch, then push knob to select.
STEP 2
4. Select Doors to Unlock
When using Smart Access to unlock the doors:
□Gripping the driver door handle will unlock all doors = All doors
□Gripping the driver door handle will unlock the driver’s door (Standard) = Driver’s door

Settings that can be customized by:
Using the
Navigation System Dealer
2
5. Auto Relock Timer
When the doors are unlocked and not opened:
□They will automatically re-lock in 120 seconds
  □They will automatically re-lock in 60 seconds (Standard)
□They will automatically re-lock in 30 seconds
□They will not re-lock = Off
6. Lock/Unlock Feedback - Lights
When the lock or unlock button on the electronic key is pressed:
□Lock button makes lights flash once/Unlock button makes lights flash twice (Standard) =
On
  □Lights will not flash = Off
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Climate Settings
8. Auto Seat Temperature FR L (Front Left)
Sensitivity level for climate controlled (AC, heater) driver seat:
9. Auto Seat Temp. FR R (Front Right)
Sensitivity level for climate controlled (AC, heater) front passenger seat:
Very High Normal
(Standard)
High Low Very Low
Very High Normal
(Standard)
High Low Very Low
7. Lock/Unlock Feedback - Tone
When the lock button is pressed on the electronic key, the system volume can be
programmed as follows:
o volume 2volume 1 volume 3 volume 4 volume 5
(standard)
volume 6 volume 7
12. Smog Sensor Sensitivity
When in AUTO recirculation mode, the sensor will determine when to switch from outside
air to recirculated air based on outside air quality:
lowest
sensitivity
highest
sensitivity
sensitivity 2 sensitivity 3 sensitivity 5 sensitivity 6 normal
(Standard)
Door Lock Settings (cont’d)
10. Auto Heated Steering Wheel*
Operates automatically according to the outside and cabin temperatures when the engine
switch is turned to IG-ON:
□On (Standard)
□Off
*If equipped
11. Auto Heated Steering Wheel Time*
Adjust the time when the heated steering wheel automatically turns off:
*If equipped
Very Short Normal
(Standard)
Short Long Very Long
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings

Settings that can be customized by:
Using the
Navigation System Dealer
3
Vehicle Customization
Other Vehicle Settings
Lights Settings
Climate Settings
Door Lock Settings
very dark dark normal
(Standard)
light very light
Vehicle Customization
Other Vehicle Settings
Light Settings
Climate Settings
Door Lock Settings
Lights Settings
13. Headlamps-On Sensitivity
The front headlights can be programmed to turn On under varying degrees of ambient light
conditions (headlight switch must be in AUTO mode):
14. Headlights Auto-Off Timer
When the ignition is turned off and all the doors are closed (headlight switch must be in ON
or AUTO mode):
□The headlights will turn off in 90 seconds
□The headlights will turn off in 60 seconds
□The headlights will turn off in 30 seconds (Standard)
□The headlights will turn off immediately when the vehicle is turned off and the driver door
is opened
15. Daytime Running Lights
Illumination of daytime running lights:
□On (Standard)
□Off
16. Interior Lights Off Timer
The interior lights can be adjusted to stay on after closing the door as follows:
□30 seconds
□15 seconds (Standard)
□7.5 seconds
  □Off
17. Exterior Lights Off Timer
The exterior lights can be adjusted to stay on after closing the door as follows:
□30 seconds
□15 seconds (Standard)
□7.5 seconds
  □Off
Other Vehicle Settings
18. Driver’s Seat Easy Exit*
When the vehicle is placed in park and the ignition turned off, the driver seat can be set as
follows:
  □Automatically move fully away from the steering wheel (Standard) = Full
 □Automatically move partially away from the steering wheel = Partial
 □Remain in the current position, as set by the driver = Off
* If equipped
Vehicle Customization
Other Vehicle Settings
Lights Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Lights Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Lights Settings
Climate Settings
Door Lock Settings
Vehicle Customization
Other Vehicle Settings
Lights Settings
Climate Settings
Door Lock Settings
Programmable by Dealer Only
19. Unlock on Second Key Turn
When using the mechanical key to unlock the doors:
□ Turning the key one time will unlock all doors = Off
  □Turning the key one time unlocks the driver door, and two times unlocks all doors
(Standard) = On
Dealer
only

Settings that can be customized by:
Using the
Navigation System Dealer
4
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
20.Access System with Electronic Key
Unlock the doors with:
□Electronic key unlock button (deactivates Smart Access) = Off
□Smart Access (touch door handle) or electronic key (Standard) = On
21. Panic Mode
When pressing the panic button on the electronic key:
□The alarm will not sound and the vehicle lights will not flash = Off
□The alarm will sound intermittently and the vehicle lights will flash (Standard) = On
22. Door Lock Buzzer
When the lock button on the electronic key is pressed and a door is not fully closed:
□The buzzer will not sound = Off
  □The buzzer will sound (Standard) = On
23.Wireless Remote Window Operation Buzzer
When option #27 is on, and the wireless remote is used to open windows:
□The buzzer will not sound = Off
  □The buzzer will sound (Standard) = On Dealer
only
24. Open Moon Roof Buzzer
When the lock button on the electronic key is pressed and the moon roof is not fully closed:
□The buzzer will not sound = Off
  □The buzzer will sound (Standard) = On
25.Close Windows and Moon Roof with Mechanical Key
When using the mechanical key to operate windows and moon roof:
□Turning the key right and holding the position for 2 seconds will not close the windows
and moon roof (Standard) = Off
□Turning the key right and holding the position for 2 seconds will close the windows
and moon roof = On
26. Open Windows and Moon Roof with Mechanical Key
When using the mechanical key to operate windows and moon roof:
□Turning the key left and holding the position for 2 seconds will not open the windows and
moon roof (Standard) = Off
□Turning the key left and holding the position for 2 seconds will open the windows and
moon roof = On
28. Slide/Tilt Moon Roof with Mechanical Key
When option #26 is on, the moon roof can be programmed to:
□Slide (Standard)
□Tilt
27. Open Windows and Moon Roof with Electronic Key
When pressing the unlock button on the electronic key for 3 seconds:
□The windows and moon roof will not open (Standard) = Off
□All the windows and moon roof will open = On
29. Slide/Tilt Moon Roof with Electronic Key
When option #27 is on, the moon roof can be programmed to:
□Slide (Standard)
□Tilt
Programmable by Dealer Only (cont’d)

Settings that can be customized by:
Using the
Navigation System Dealer
5
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
30.Interior Light
The interior light will illuminate when POWER is switched to Off:
□Off
  □On (Standard)
31. Illumination of the Interior Cabin Light when Unlocking Door
When using the electronic or mechanical key to unlock the door:
□The cabin light will not illuminate = Off
  □The cabin light will illuminate (Standard) = On
32.Illumination of the Interior Cabin Light when Approaching the Vehicle
When approaching the vehicle with the electronic key:
□The cabin light will not illuminate = Off
  □The cabin light will illuminate (Standard) = On
33. Center Console Spotlight
The center console spotlight will illuminate when POWER is in Accessory mode:
□Off
  □On (Standard)
34. Illumination of the Outer Foot Lights when Approaching the Vehicle
When approaching the vehicle with the electronic key:
□The outer foot lights will not illuminate = Off
 □The outer foot lights will illuminate (Standard) = On
35. Illumination of the Outer Foot Lights when a Door is Opened
When a door is opened:
□The foot lights will not illuminate = Off
□The foot lights will illuminate (Standard) = On
39. Instrument Dimming Sensitivity
Level of light at which the instrument panel lights will dim:
very dark dark normal
(Standard)
light very light
Programmable by Dealer Only (cont’d)
38.Lane Change Signal Flashes
Push turn signal lever partway to signal a lane change. Signal will flash:
□Off
□3 times (Standard)
□4 times
  □5 times
□6 times
  □7 times
36. Reverse-Linked Rear Wiper
When the vehicle is placed into reverse, the rear window wiper will:
□Operate automatically (Standard) = On
□Not operate automatically = Off
37. Reverse-Linked Rear Wiper Operation
When option #36 is on, the rear window wiper will:
□Sweep once (Standard) = On
□Sweep continuously = Off
Dealer
only

Repair Order Number ( Dealer only) Vehicle Identification Number ( Dealer only)
Date Customer Signature
Settings that can be customized by:
Using the
Navigation System Dealer
Dealer
only
6
41. Tilt Away of Steering Wheel
When vehicle is shifted into Park and ignition turned off, steering wheel can be set as follows:
□Automatically move up and away from the driver position setting (Standard) = On
□Remain in the current position, as set by the driver = Off
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
Dealer
only
44.Efficient Ventilation Mode
When the front defogger is activated:
□It will automatically engage the air conditioner compressor to blow air onto the
windshield (Standard) = On
  □It will automatically blow air onto the windshield without engaging the air conditioner
compressor = Off
45. Linking Seat Position Memory with Door Unlock*
When using Smart Access to unlock the doors, seat position memory recall can be
programmed as follows:
□The driver seat will move to memory position when the driver door is unlocked (Standard)
□The driver seat will move to memory position when any door is unlocked
* If equipped
Programmable by Dealer Only (cont’d)
40. Instrument Restore Sensitivity
Level of light at which the instrument panel lights will brighten:
very light light normal
(Standard)
dark very dark
48. Power Back Door Electronic Key Operation
The button on the electronic key can be programmed as follows:
□Press and hold the button to open the back door (Standard)
 □Unlock the rear door, then press the button to open the back door
46. Power Back Door Switch Operation
The back door opener button can be programmed as follows:
□Press button one time to open back door
□Press and hold the button for 0.8 seconds to open the back door (Standard)
Dealer
only
47. Back Door Chime
The chime that sounds when opening the back door can be programmed as follows:
□Start buzzer On; in-operation buzzer Off (Standard)
□Start buzzer Off; in-operation buzzer On
Dealer
only
42. Moon Roof Switch - Auto Operation
Pressing the open/close switch will automatically open or close the moon roof in one motion:
□Off
  □On (Standard)
43. Auto A/C Mode
When Auto A/C is selected:
□It will automatically engage the air conditioner compressor to reach the set temperature
(Standard) = On
  □It will automatically achieve a set temperature, warm or cool, without engaging the air
conditioner compressor*= Off
*The A/C compressor will be engaged when the Auto A/C button is pressed a second time
