LG AMNQ09GSJA0 Quick start guide

MFL63260122
Rev.00_052821
Copyright © 2021 LG Electronics Inc. All Rights Reserved.
www.lg.com
OWNER’S &
INSTALLATION MANUAL
AIR
CONDITIONER
Original instruction
This manual is the simplified version of original manual.
You can obtain the original manual from www.lg.com.
Please read this installation manual completely before installing the product.
Installation work must be performed in accordance with the national wiring standards
by authorized personnel only.
Please retain this installation manual for future reference after reading it thoroughly.
ENGLISH
BAHASA INDONESIA
*MFL63260122*
AMNQ09GSJA0 AMNQ12GSJA0 AMNQ18GSKA0 AMNQ24GSKA0
AMNQ09GSJB0 AMNQ12GSJB0 AMNQ18GSKB0 AMNQ24GSKB0
AMNQ09GL1A0 AMNQ12GL2A0 AMNQ18GL2A0 AMNQ24GL3A0
AMNQ09GTUA0 AMNQ12GTUA0 AMNQ18GTTA0 AMNQ24GTTA0 IMKG.1077.05.2021

2SAFETY INSTRUCTIONS
ENGLISH
Limiting concentration is the limit of Freon gas
concentration where immediate measures can
be taken without hurting human body when
refrigerant leaks in the air. The limiting
concentration shall be described in the unit of
kg/m3(Freon gas weight per unit air volume)
for facilitating calculation.
The A-weighted sound pressure emitted by
this product is below 70 dB.
** The noise level can vary depending on the
site.
The figures quoted are emission level and are
not necessarily safe working levels.
Whilst there is a correlation between the
emission and exposure levels, this cannot be
used reliably to determine whether or not
further precautions are required.
Factor that influence the actual level of
exposure of the workforce include the
characteristics of the work room and the other
sources of noise, i.e. the number of
equipment and other adjacent processes and
the length of time for which an operator
exposed to the noise. Also, the permissible
exposure level can vary from country to
country.
This information, however, will enable the
user of the equipment to make a better
evaluation of the hazard and risk.
Total amount of replenished
refrigerant in refrigerant facility (kg)
Capacity of smallest room where
indoor unit is installed (m3)
Refrigerant
concentration
(kg/m3)
=
Limiting concentration: 0.44 kg/m3 (R410A)
Airborne Noise Emission Limiting concentration

SAFETY INSTRUCTIONS 3
ENGLISH
WARNING
• Installation or repairs made by unqualified persons can result in hazards to you and others.
• Installation work must be performed in accordance with the National Electric Code by qualified
and authorized personnel only.
• The information contained in the manual is intended for use by a qualified service technician
familiar with safety procedures and equipped with the proper tools and test instruments.
• Failure to carefully read and follow all instructions in this manual can result in equipment
malfunction, property damage, personal injury and/or death.
• Ducts connected to an appliance shall not contain an ignition source. (for R32)
• This equipment shall be provided with a supply conductor complying with the national
regulation.
Installation
• Do not use a defective or underrated circuit breaker. Use the correctly rated breaker and fuse.
- There is risk of fire or electric shock.
• For electrical work, contact the dealer, seller, a qualified electrician, or an Authorized Service
Center. Do not disassemble or repair the product by yourself.
- There is risk of fire or electric shock.
!
WARNING
This indicates that the failure to follow the instructions can cause serious injury or death.
CAUTION
This indicates that the failure to follow the instructions can cause the minor injury or damage to
the product.
This symbol is displayed to indicate matters and operations that can cause risk.
Read the part with this symbol carefully and follow the instructions in order to avoid risk.
!
!
!
SAFETY INSTRUCTIONS
The following symbols are displayed on indoor and outdoor units.
The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe
or incorrect operation of the appliance.
The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below.
Read the precautions in this manual
carefully before operating the unit.
This appliance is filled with
flammable refrigerant (for R32)
This symbol indicates that the
Operation Manual should be read
carefully.
This symbol indicates that a service
personnel should be handling this
equipment with reference to the
Installation Manual.

4SAFETY INSTRUCTIONS
ENGLISH
• Always ground the product as per the wiring diagram. Do not connect the ground wire to gas or
water pipes lightening rod or telephone ground wire.
- There is risk of fire or electric shock.
• Install the panel and the cover of control box securely.
- There is risk of fire or electric shock due to dust, water etc.
• Use the correctly rated breaker or fuse.
- There is risk of fire or electric shock.
• Do not modify or extend the power cable. If the power cable or cord has scratches or skin
peeled off or deteriorated then it must be replaced.
- There is risk of fire or electric shock.
• For installation, removal or reinstall, always contact the dealer or an Authorized Service Center.
- There is risk of fire, electric shock, explosion, or injury.
• Do not install the product on a defective installation stand. Be sure that the installation area
does not deteriorate with age.
- It may cause product to fall.
• Never install the outdoor unit on a moving base or a place from where it can fall down.
- The falling outdoor unit can cause damage or injury or even death of a person.
• In outdoor unit the step-up capacitor supplies high voltage electricity to the electrical
components. Be sure to discharge the capacitor completely before conducting the repair work.
- An charged capacitor can cause electrical shock.
• When installing the unit, use the installation kit provided with the product.
- Otherwise the unit may fall and cause severe injury.
• Indoor/outdoor wiring connections must be secured tightly and the cable should be routed
properly so that there is no force pulling the cable from the connection terminals.
- Improper or loose connections can cause heat generation or fire.
• Safely dispose off the packing materials. Like screws, nails, batteries, broken things etc after
installation or svc and then tear away and throw away the plastic packaging bags.
- Children may play with them and cause injury.
• Be sure to check the refrigerant to be used. Please read the label on the product.
- Incorrect refrigerant used can prevent the normal operation of the unit.
• Do not touch refrigerant pipe and water pipe or any internal parts while the unit is operating or
immediately after operation.
- It can cause a burn or frostbite.
Operation
• When the product is soaked (flooded or submerged) in water , contact an Authorized Service
Center for repair before using it again.
- There is risk of fire or electric shock.
• Be sure to use only those parts which are listed in the svc parts list. Never attempt to modify
the equipment.
- The use of inappropriate parts can cause an electrical shock, excessive heat generation or fire.
• Do not touch , operate, or repair the product with wet hands. Hold the plug by hand when
taking out.
- There is risk of electric shock or fire.

SAFETY INSTRUCTIONS
• Do not place a heater or other heating appliances near the power cable.
- There is risk of fire and electric shock.
• Do not allow water to run into electric parts. Install the unit away from water sources.
- There is risk of fire, failure of the product, or electric shock.
• Do not store or use or even allow flammable gas or combustibles near the product.
- There is risk of fire.
• Do not use the product in a tightly closed space for a long time. Perform ventilation regularly.
- Oxygen deficiency could occur and hence harm your health.
• Do not open the front grille of the product during operation. (Do not touch the electrostatic
filter, if the unit is so equipped.)
- There is risk of physical injury, electric shock, or product failure.
• If strange sound, smell or smoke comes from product. Immediately turn the breaker off or
disconnect the power supply cable.
- There is risk of electric shock or fire.
• Ventilate the product room from time to time when operating it together with a stove, or
heating element etc.
- Oxygen deficiency can occur and hence harm your health.
• When the product is not to be used for a long time, disconnect the power supply plug or turn
off the breaker.
- There is risk of product damage or failure, or unintended operation.
• Take care to ensure that nobody especially kids could step on or fall onto the outdoor unit.
- This could result in personal injury and product damage.
• Take care to ensure that power cable could not be pulled out or damaged during operation.
- There is risk of fire or electric shock.
• Do not place anything on the power cable.
- There is risk of fire or electric shock.
• When flammable gas leaks, turn off the gas and open a window for ventilation before turning
on the product. Do not use the telephone or turn switches on or off.
- There is risk of explosion or fire.
• Make sure to ventilate sufficiently when this air conditioner and a heating appliance such as a
heater are used simultaneously.
- Failure to do so may result in fire, serious injury, or product failure.
• If the supply cord is damaged, it must be replaced by a special cord or assembly available from
the manufacturer of its service agent.
CAUTION
Installation
• Two or more people must lift and transport the product.
- Avoid personal injury.
• Do not install the product where it will be exposed to sea wind (salt spray) directly.
- It may cause corrosion on the product.
!
5
ENGLISH

SAFETY INSTRUCTIONS
6
ENGLISH
• Install the drain hose to ensure that the condensed water is drained away properly.
- A bad connection may cause water leakage.
• Keep level even when installing the product.
- To avoid vibration or noise.
• Do not install the product where the noise or hot air from the outdoor unit could damage or
disturb the neighborhoods.
- It may cause a problem for your neighbors and hence dispute.
• Always check for gas (refrigerant) leakage after installation or repair of product.
- Low refrigerant levels may cause failure of product.
• Pipe-work shall be protected from physical damage.
• Use the deoxidized copper as piping materials to install.
• If anyone other than a licensed Professional installs, repairs, or alters LG Electronics Air
Conditioning Products, the warranty is voided.
- All costs associated with repair are then the full responsibility of the owner.
• Do not insert a drain hose in drain or soil pipe.
- Bad smells can occur and it results in a corrosion of a heat exchanger or pipe.
• Do not install the unit in potentially explosive atmospheres.
Operation
• Do not use the product for special purposes, such as preserving foods, works of art, etc. It is a
consumer air conditioner, not a precision refrigeration system.
- There is risk of damage or loss of property.
• Means for disconnection must be incorporated in the fixed wiring in accordance with the wiring
rules.
• Appliance shall be disconnected from its power source during service and when replacing
parts.
• Do not block the inlet or outlet of air flow.
- It may cause product failure.
• Use a soft cloth to clean. Do not use harsh detergents, solvents or splashing water etc.
- There is risk of fire, electric shock, or damage to the plastic parts of the product.
• Do not touch the metal parts of the product when removing the air filter.
- There is risk of personal injury.
• Do not step on or put anything on the product. (outdoor units)
- There is risk of personal injury and failure of product.
• Always insert the filter securely after cleaning. Clean the filter every two weeks or more often if
necessary.
- A dirty filter reduces the efficiency.
• Do not insert hands or other objects through the air inlet or outlet while the product is
operating.
- There are sharp and moving parts that could cause personal injury.
• Be cautious when unpacking and installing the product.
- Sharp edges could cause injury.

7
SAFETY INSTRUCTIONS
ENGLISH
• If the refrigerant gas leaks during the repair, do not touch the leaking refrigerant gas.
- The refrigerant gas can cause frostbite (cold burn).
• Do not tilt the unit when removing or uninstalling it.
- The condensed water inside can spill.
• Do not mix air or gas other than the specified refrigerant used in the system.
- If air enters the refrigerant system, an excessively high pressure results, causing equipment
damage or injury.
• If the refrigerant gas leaks during the installation, ventilate the area immediately.
- Otherwise it can be harmful for your health.
• Dismantling the unit, treatment of the refrigerant oil and eventual parts should be done in
accordance with local and national standards.
• Replace the all batteries in the remote control with new ones of the same type. Do not mix old
and new batteries or different types of batteries.
- There is risk of fire or product failure.
• Do not recharge or disassemble the batteries. Do not dispose off batteries in a fire.
- They may burn or explode.
• If the liquid from the batteries gets onto your skin or clothes, wash it well with clean water. Do
not use the remote if the batteries have leaked.
- The chemicals in batteries could cause burns or other health hazards.
• If you swallow the battery fluid from a leak, wash out the inside of your mouth thoroughly and
then consult a doctor.
- Failure to do so may result in serious health complications.
• Do not let the air conditioner run for a long time when the humidity is very high and a door or a
window is left open.
- Moisture may condense and wet or damage furniture.
• Do not expose your skin or kids or plants to the cool or hot air draft.
- This could harm to your health.
• Do not drink the water drained from the product.
- It is not sanitary and could cause serious health issues.
• Use a firm stool or ladder when cleaning, maintaining or repairing the product at an height.
- Be careful and avoid personal injury.
• This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. Children should be supervised to ensure that they do not play with the appliance.
• This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.

8INSTALLATION MANUAL
ENGLISH
INSTALLATION PLACES
- There should not be any heat source or steam near
the unit.
- There should not be any obstacles to prevent the
air circulation.
- A place where air circulation in the room will be
good.
- A place where drainage can be easily obtained.
- A place where noise prevention is taken into
consideration.
- Do not install the unit near the door way.
- Ensure the spaces indicated by arrows from the
wall, ceiling, or other obstacles.
- The indoor unit must keep the maintenance space.
- The basic installation for the round type should be
in an exposed area. Do not install at a non exposed
installation site such as areas with ceiling texture.
More than A
More than B
More than
C
More than
B
(Unit : mm)
Unit : mm
Ceiling
Ceiling Board Ceiling Board
H
1 000
or more
500 or
more
300 or less
At least 1 800
H or less
10 or
more
500 or
more
Type A B C
Wall mounted 200 100 2 300
ART COOL 200 500 1 500
ART COOL Mirror 200 100 2 300
Console 300 300 250 or less
More than
300
More than
300
More than
300
More than
200
More than 50
More than
200
R
More than 700
More than 700
More than 300
More than 200
More than 100
More than 100
(Unit : mm)
Unit : mm
Ceiling
Above 2 500
4 000 or less
1 000
or more
500 or
more
10 or more
500 or
more
300 or less
FloorFloorFloor
Chassis H
TU/TT 3 300
TQ/TR/TP 3 600
TN/TM 4 200
Flat washer for M10
(accessory)
Flat washer for M10
(accessory)
Hanging bolt
(W3/8 or M10)
Nut
(W3/8 or M10)
Nut
(W3/8 or M10)
Spring washer
(M10)

INSTALLATION MANUAL 9
ENGLISH
• Suitable dimension "H" is necessary to get a
slope to drain as shown in the figure.
• The feature may be changed according to
the type of model.
H = 20 or more
(Unit: mm)
M10 Nut
M10 SP. washer
M10 washer
X4
X4
(Local supply)
X4
M10 Nut
M10 SP. washer
M10 washer
X4
X4
X4
SSide view
- The appliance shall be installed, operated and stored in a room with a floor area larger than the
minimum area.
- Use the graph of table to determine the minimum area.
- m : Total refrigerant amount in the system
- Total refrigerant amount : factory refrigerant charge + additional refrigerant amount
- Amin : minimum area for installation
Minimum floor area (for R32)
0
100
200
300
400
500
600
Amin (m
2
)
m (kg)
0 1.224 2 3 4 5 6 7 8
Floor standing
Wall mounted
Ceiling mounted
Floor location
m (kg) Amin (m2)
< 1.224 -
1.224 12.9
1.4 16.82
1.6 21.97
1.8 27.80
2 34.32
2.2 41.53
2.4 49.42
2.6 58.00
2.8 67.27
3 77.22
3.2 87.86
3.4 99.19
3.6 111.20
3.8 123.90
4 137.29
4.2 151.36
4.4 166.12
Floor location
m (kg) Amin (m2)
4.6 181.56
4.8 197.70
5 214.51
5.2 232.02
5.4 250.21
5.6 269.09
5.8 288.65
6 308.90
6.2 329.84
6.4 351.46
6.6 373.77
6.8 396.76
7 420.45
7.2 444.81
7.4 469.87
7.6 495.61
7.8 522.04
Wall mounted
m (kg) Amin (m2)
< 1.224 -
1.224 1.43
1.4 1.87
1.6 2.44
1.8 3.09
2 3.81
2.2 4.61
2.4 5.49
2.6 6.44
2.8 7.47
3 8.58
3.2 9.76
3.4 11.02
3.6 12.36
3.8 13.77
4 15.25
4.2 16.82
4.4 18.46
Wall mounted
m (kg) Amin (m2)
4.6 20.17
4.8 21.97
5 23.83
5.2 25.78
5.4 27.80
5.6 29.90
5.8 32.07
6 34.32
6.2 36.65
6.4 39.05
6.6 41.53
6.8 44.08
7 46.72
7.2 49.42
7.4 52.21
7.6 55.07
7.8 58.00
Ceiling Mounted
m (kg) Amin (m2)
< 1.224 -
1.224 0.956
1.4 1.25
1.6 1.63
1.8 2.07
2 2.55
2.2 3.09
2.4 3.68
2.6 4.31
2.8 5.00
3 5.74
3.2 6.54
3.4 7.38
3.6 8.27
3.8 9.22
4 10.21
4.2 11.26
4.4 12.36
Ceiling Mounted
m (kg) Amin (m2)
4.6 13.50
4.8 14.70
5 15.96
5.2 17.26
5.4 18.61
5.6 20.01
5.8 21.47
6 22.98
6.2 24.53
6.4 26.14
6.6 27.80
6.8 29.51
7 31.27
7.2 33.09
7.4 34.95
7.6 36.86
7.8 38.83
Front
Inspection hole 600x600
Control box
More than
1 000
Air outlet
vents
Air inlet vents
600
More
than
More than
600
(unit: mm)
TTop view

10 INSTALLATION MANUAL
ENGLISH
General instructions
- All field supplied parts and materials, electric
works must conform to local codes. Use
copper wire only.
- Follow the "WIRING DIAGRAM” attached to
the unit body to wire the outdoor unit, indoor
units and the remote controller.
- All wiring must be performed by an
authorized electrician.
Wiring Connection
Connect the wires to the terminals on the
control board individually according to the
out door unit connection.
Ensure that the color of the wires of outdoor
unit and the terminal No. are the same as
those of indoor unit respectively.
ELECTRIC WIRING WORK
• Supply and communication cable of
appliances shall not be lighter than
polychloroprene sheathed. (code
designation 60245 IEC 57)
Using the remote controller
You can operate the air conditioner more
conveniently with the remote controller.
You will find the buttons for the additional
functions under the cover of the remote control.
1(L) 2(N) 3
Connected to outdoor unit
or B.D. unit.
• The connecting cable connected to the
indoor and outdoor unit should be
complied with the following
specifications (Rubber insulation, type
H05RN-F approved by HAR or SAA).
20 mm
GN/YL
NORMAL
CROSS-SECTIONAL
AREA 0.75 mm2
CAUTION
!
Rated current of
appliance A.
Nominal
cross-sectional area
mm2
≤0.2
> 0.2 and ≤3
> 3 and ≤6
> 6 and ≤10
> 10 and ≤16
> 16 and ≤25
> 25 and ≤32
> 32 and ≤40
> 40 and ≤63
Tinsel cord
0.5
0.75
1.0 (0.75)
1.5 (1.0)
2.5
4
6
10
NNOTE For ssupply cords supplied with
multi-phase appliances, the nominal
cross-sectional area of the conductors is
based on the maximum cross-sectional area
of the conductors per phase at the ssupply
cord connection to the appliance terminals.
• The feature may be changed according to
the type of model.

OWNER'S MANUAL 11
ENGLISH
Clean the product regularly to maintain
optimal performance and to prevent possible
breakdown.
Operation Tips!
• Do not overcool the room.
This is not good for the health and wastes
electricity.
• Keep blinds or curtains closed.
Do not let direct sunshine enter the room
when the air conditioner is in operation.
• Keep the room temperature uniform.
Adjust the vertical and horizontal airflow
direction to ensure a uniform temperature in
the room.
• Make sure that the doors and windows are
shut tight.
Avoid opening doors and windows as much
as possible to keep the cool air in the room.
• Clean the air filter regularly.
Blockages in the air filter reduce the airflow
and lower cooling and dehumidifying effects.
Clean at least once every two weeks.
• Ventilate the room occasionally.
Since windows are kept closed, it is a good
idea to open them and ventilate the room
now and then.
When the air conditioner is not
going....
When air conditioner is not going to be used
for a long time.
1Operate the air conditioner at the following
settings for 2 to 3 hours.
• Type of operation: Fan operation
mode.(Refer to page "Fan Mode")
• This will dry out the internal mechanisms.
2Turn off the breaker.
3Remove the batteries from the Remote
Controller.
Helpful information
The air filters and your electric bill.
If the air filters become clogged with dust, the
cooling capacity will drop, and 6 % of the
electricity used to operate the air conditioner
will be wasted.
When the air conditioner is to be
used again.
1Clean the air filter and install it in the indoor
unit. (Refer to page "Maintenance and
Service")
2Check that the air inlet and outlet of the
indoor/outdoor unit are not blocked.
3Check that the ground wire is connected
correctly. It may be connect to the indoor
unit side.
MAINTENANCE
CAUTION
!
• Turn off the power and unplug the
power cord before you perform any
maintenance; otherwise it may cause
electric shock.
• Never use water that is hotter than
40 °C when you clean the filters. It may
cause deformation or discoloration.
• Never use volatile substances when you
clean the filters. They may damage the
surface of the product.
Turn off the breaker when the air
conditioner is not going to be used for a
long time. Dirt may collect and may cause
a fire.
CAUTION
!

12 OWNER'S MANUAL
ENGLISH
Troubleshooting Tips! Save time and money!
Check the following points before requesting repairs or service.... If the malfunction persist,
please contact your dealer.
Call the service immediately in the following situations
1Anything abnormal such as burning smell, loud noise etc. happen. Stop the unit and turn the
breaker off. Never try to repair by yourself or restart the system in such cases.
2Main power cord is too hot or damaged.
3Error code is generated by self diagnosis.
4 Water leaks from indoor unit even if the humidity is low.
5Any switch, breaker (safety, earth) or fuse fails to work properly.
User must carry routine checkup & cleaning to avoid unit’s poor performance. In case of special
situation, the job must be carried out by service person only.
Case Explanation
The air conditioner does not
operate.
• Have you made a mistake in timer operation?
• Has the fuse blown or has the circuit breaker been tripped?
The room has a peculiar odor. • Check that this is not a damp smell exuded by the walls,
carpet, furniture or cloth items in the room.
It seems that condensation is
leaking from the air
conditioner.
• Condensation occurs when the airflow from the air
conditioner cools the warm room air.
Air conditioner does not
operate for about 3 minutes
when restart.
• This is the protector of the mechanism.
• Wait about three minutes and operation will begin.
Does not cool or heat
effectively.
• Is the air filter dirty? See air filter cleaning instructions.
• The room may have been very hot when the room air
conditioner was first turned on. Allow time for it to cool down.
• Has the setting temperature been set incorrectly?
• Are the indoor unit's air inlet or outlet vents obstructed?
The air conditioner operation
is noisy.
• For a noise that sounds like water flowing.
- This is the sound of freon flowing inside the air conditioner
unit.
• For a noise that sounds like the compressed air releasing into
atmosphere.
- This is the sound of the dehumidifying water being
processed inside the air conditioning unit.
Crack sound is heard. • This sound is generated by the expansion/contraction of the
inlet grille, etc. due to changes of temperature.
Remote control display is
faint, or no display at all.
• Has the circuit breaker been tripped?
• Are the batteries inserted in the opposite (+) and (-)
directions?
The error code is occurred
after lightning struck
• This product has been applied to the over current protection
circuit. Error can occur, but it is normal behavior. After few
minutes, It will operate normally.

13
ENGLISH

14
ENGLISH

Petunjuk asli
Panduan ini adalah versi sederhana dari panduan asli.
Anda dapat memperoleh panduan asli di www.lg.com.
AMNQ09GSJA0 AMNQ12GSJA0 AMNQ18GSKA0 AMNQ24GSKA0
AMNQ09GSJB0 AMNQ12GSJB0 AMNQ18GSKB0 AMNQ24GSKB0
AMNQ09GL1A0 AMNQ12GL2A0 AMNQ18GL2A0 AMNQ24GL3A0
AMNQ09GTUA0 AMNQ12GTUA0 AMNQ18GTTA0 AMNQ24GTTA0
Hak cipta © 2021 LG Elektronik. Semua hak cipta di lindungi
Silakan baca buku panduan pemasangan ini seluruhnya sebelum memasang produk.
Pekerjaan pemasangan harus dilakukan sesuai dengan standar pengabelan nasional
oleh petugas resmi saja.
Silakan simpan buku panduan pemasangan ini untuk referensi di masa mendatang
setelah membaca seluruhnya.
www.lg.com
BUKU PANDUAN PEMILIK &
PEMASANGAN
PENDINGIN
RUANGAN (AC)
BAHASA INDONESIA
IMKG.1077.05.2021

2
BAHASA INDONESIA
Batas konsentrasi adalah batas konsentrasi
gas Freon di mana tindakan segera dapat
diambil tanpa melukai tubuh manusia saat zat
pendingin bocor ke udara. Batas konsentrasi
disebutkan dalam satuan kg/m3(Berat gas
Freon per satuan volume udara) untuk
memudahkan perhitungan.
Tekanan suara berbobot A yang dikeluarkan
oleh produk ini di bawah 70 dB.
** Tingkat kebisingan dapat berbeda-beda
tergantung lokasi.
Angka yang dikutip adalah tingkat emisi dan
belum tentu merupakan tingkat kerja yang
aman.
Meskipun ada korelasi antara emisi dan
tingkat paparan, informasi ini tidak dapat
diandalkan untuk menentukan apakah
pencegahan lebih lanjut diperlukan atau tidak.
Faktor yang memengaruhi tingkat paparan
tenaga kerja yang sebenarnya termasuk
karakteristik ruang kerja dan sumber
kebisingan lainnya, misalnya jumlah peralatan
dan proses lain yang berdekatan dan lama
waktu operator terkena kebisingan tersebut.
Tingkat paparan yang diperbolehkan juga
dapat berbeda dari satu negara ke negara lain.
Akan tetapi informasi ini akan memungkinkan
pengguna peralatan untuk mengevaluasi
bahaya dan risiko dengan lebih baik.
Jumlah total zat pendingin yang
diisikan ulang pada fasilitas zat
pendingin (kg)
Kapasitas ruangan terkecil tempat
unit dalam ruangan dipasang (m3)
Konsentrasi
zat pendingin
(kg/m3)
=
Batas konsentrasi: 0,44 kg/m3(R410A)
Emisi Kebisingan Udara Batas konsentrasi

PETUNJUK KESELAMATAN 3
BAHASA INDONESIA
PERINGATAN
• Pemasangan atau perbaikan yang dilakukan oleh orang yang tidak berkualifikasi dapat
mengakibatkan bahaya bagi diri Anda dan orang lain.
• Pekerjaan pemasangan harus dilakukan sesuai dengan Kode Listrik nasional oleh petugas resmi
yang berkualifikasi saja.
• Informasi yang terdapat dalam buku panduan ini dimaksudkan untuk digunakan oleh teknisi
servis berkualifikasi yang terbiasa dengan prosedur keselamatan dan dilengkapi dengan
peralatan dan alat uji yang sesuai.
• Jika Anda tidak membaca dengan cermat dan mengikuti semua petunjuk dalam buku panduan
ini, itu dapat mengakibatkan kesalahan fungsi peralatan, kerusakan properti, cedera pribadi
dan/atau kematian.
• Saluran yang tersambung ke alat tidak boleh mengandung sumber pengapian. (untuk R32)
• Peralatan ini akan dilengkapi dengan konduktor pasokan yang sesuai dengan peraturan nasional.
Pemasangan
• Jangan menggunakan pemutus arus listrik yang cacat atau di bawah spesifikasi yang
diperlukan. Gunakan pemutus arus listrik dan sekring dengan kapasitas yang benar.
- Ada risiko kebakaran atau sengatan listrik.
!
PERINGATAN
Ini menunjukkan bahwa kegagalan mengikuti petunjuk dapat mengakibatkan cedera serius
bahkan kematian.
PERHATIAN
Ini menunjukkan bahwa kegagalan mengikuti petunjuk dapat mengakibatkan cedera ringan
atau kerusakan produk.
Simbol yang ditampilkan menunjukkan masalah dan pengoperasian yang berisiko. Baca
bagian dengan simbol ini dengan cermat dan ikuti petunjuk guna menghindari risiko.
!
!
!
PETUNJUK KESELAMATAN
Panduan keselamatan berikut ditujukan untuk mencegah risiko tak terduga atau kerusakan akibat
pengoperasian produk yang salah atau tidak aman. Panduan ini dibagi menjadi 'PERINGATAN'
dan 'PERHATIAN' seperti yang dijelaskan di bawah.
Simbol-simbol berikut ditampilkan pada unit dalam ruangan dan luar ruangan.
Baca tindakan pencegahan dalam
buku panduan ini dengan cermat
sebelum mengoperasikan unit.
Alat ini berisi refrigeran yang mudah
terbakar. (untuk R32)
Simbol ini menunjukkan bahwa Buku
Panduan Pengoperasian harus dibaca
dengan cermat.
Simbol ini menunjukkan bahwa
petugas servis harus menangani
peralatan ini dengan mengacu pada
Buku Panduan Pemasangan.

4PETUNJUK KESELAMATAN
BAHASA INDONESIA
• Untuk pekerjaan listrik, hubungi dealer, penjual, teknisi listrik yang memenuhi syarat, atau Pusat
Layanan Resmi. Jangan membongkar atau memasang produk sendiri.
- Ada risiko kebakaran atau sengatan listrik.
• Selalu bumikan produk sesuai diagram kabel. Jangan menyambungkan kabel tanah ke pipa gas
atau air, penangkal petir atau kabel tanah telepon.
- Ada risiko kebakaran atau sengatan listrik.
• Pasang panel dan tutup kotak kontrol dengan erat.
- Ada risiko kebakaran atau sengatan listrik karena debu, air, dsb.
• Gunakan pemutus arus listrik atau sekring dengan kapasitas yang benar.
- Ada risiko kebakaran atau sengatan listrik.
• Jangan mengubah atau memperpanjang kabel daya. Jika kabel daya tergores atau kulitnya
mengelupas atau memburuk maka kabel harus diganti.
- Ada risiko kebakaran atau sengatan listrik.
• Untuk pemasangan, pelepasan atau pemasangan ulang, selalu hubungi dealer atau Pusat
Layanan Resmi.
- Ada risiko kebakaran, sengatan listrik, ledakan, atau cedera.
• Jangan memasang produk pada tempat pemasangan yang cacat. Pastikan area pemasangan
tidak menjadi lapuk seiring berjalannya waktu.
- Hal itu dapat menyebabkan produk jatuh.
• Jangan pernah memasang unit luar ruangan di dasar yang bergerak atau tempat di mana unit
dapat jatuh.
- Unit luar ruangan yang jatuh dapat menyebabkan kerusakan atau cedera atau bahkan kematian
seseorang.
• Pada unit luar ruangan, kapasitor penaik tegangan memasok listrik bertegangan tinggi ke
komponen listrik. Pastikan untuk mengosongkan kapasitor sepenuhnya sebelum melakukan
pekerjaan perbaikan.
- Kapasitor yang bermuatan dapat menyebabkan sengatan listrik.
• Saat memasang unit, gunakan kit pemasangan yang disediakan bersama produk.
- Jika tidak unit dapat jatuh dan menyebabkan cedera serius.
• Sambungan kabel dalam ruangan/luar ruangan harus tersambung dengan kencang dan kabel
harus diarahkan dengan benar agar tidak ada gaya yang menarik kabel dari terminal sambungan.
- Sambungan yang tidak benar atau longgar dapat menyebabkan panas atau kebakaran.
• Buang bahan kemasan dengan aman. Seperti sekrup, paku, baterai, barang yang rusak, dsb
setelah pemasangan atau servis dan kemudian robek dan buang tas kemasan plastiknya.
- Anak-anak dapat bermain dengannya dan menyebabkan cedera.
• Pastikan untuk memeriksa refrigeran yang akan digunakan. Silakan baca label pada produk.
- Menggunakan zat pendingin yang salah dapat mencegah pengoperasian normal unit.
• Jangan menyentuh pipa zat pendingin dan pipa air atau bagian internal apa pun selama unit
beroperasi atau segera setelah beroperasi.
- Hal itu dapat menyebabkan luka bakar atau radang dingin.
Pengoperasian
• Saat produk basah (terkena banjir atau terendam), hubungi Pusat Layanan Resmi untuk
perbaikan sebelum menggunakannya lagi.
- Ada risiko kebakaran atau sengatan listrik.
• Pastikan untuk hanya menggunakan komponen yang tercantum di daftar komponen servis.
Jangan pernah mencoba untuk memodifikasi peralatan.
- Penggunaan komponen yang tidak tepat dapat menyebabkan sengatan listrik, panas berlebih
atau kebakaran.

PETUNJUK KESELAMATAN
• Jangan menyentuh, mengoperasikan, atau memperbaiki produk dengan tangan basah. Pegang
steker dengan tangan saat mencabutnya.
- Ada risiko sengatan listrik atau kebakaran.
• Jangan meletakkan pemanas atau alat pemanas lainnya di dekat kabel daya.
- Ada risiko kebakaran dan sengatan listrik.
• Jangan biarkan air mengalir ke komponen listrik. Pasang unit jauh dari sumber air.
- Ada risiko kebakaran, kerusakan produk, atau sengatan listrik.
• Jangan menyimpan atau menggunakan atau bahkan membiarkan gas yang mudah menyala atau
terbakar di dekat produk.
- Ada risiko kebakaran.
• Jangan menggunakan produk di ruangan yang tertutup rapat untuk waktu yang lama. Lakukan
ventilasi secara teratur.
- Kekurangan oksigen dapat terjadi dan membahayakan kesehatan Anda.
• Jangan membuka kisi-kisi depan produk selama pengoperasian. (Jangan menyentuh filter
elektrostatik, jika unit dilengkapi dengan filter tersebut.)
- Ada risiko cedera fisik, sengatan listrik, atau kerusakan produk.
• Jika ada bunyi yang aneh, bau atau asap keluar dari produk, segera matikan pemutus arus listrik
atau cabut kabel sumber daya.
- Ada risiko sengatan listrik atau kebakaran.
• Alirkan udara ke ruangan produk dari waktu ke waktu saat produk dioperasikan bersamaan
dengan kompor, atau elemen pemanas, dsb.
- Kekurangan oksigen dapat terjadi dan membahayakan kesehatan Anda.
•
Saat produk tidak digunakan untuk waktu yang lama, cabut steker atau matikan pemutus arus listrik.
- Ada risiko kerusakan atau kegagalan produk, atau pengoperasian yang tidak diinginkan.
• Berhati-hatilah untuk memastikan tidak ada orang terutama anak-anak yang dapat menginjak
atau jatuh ke unit luar ruangan.
- Hal ini dapat menyebabkan cedera pribadi dan kerusakan produk.
• Berhati-hatilah jangan sampai kabel listrik tertarik atau rusak selama pengoperasian.
- Ada risiko kebakaran atau sengatan listrik.
• Jangan meletakkan APA PUN di atas kabel daya.
- Ada risiko kebakaran atau sengatan listrik.
• Jika terjadi kebocoran gas yang mudah terbakar, matikan gas dan buka jendela untuk ventilasi
sebelum menyalakan produk. Jangan menggunakan telepon atau menyalakan atau mematikan
sakelar.
- Ada risiko ledakan atau kebakaran.
• Pastikan untuk mengalirkan udara dengan cukup saat pendingin ruangan ini dan alat pemanas
seperti pemanas digunakan secara bersamaan.
- Bila tidak itu dapat menyebabkan kebakaran, cedera serius, atau kerusakan produk.
• Jika kabel yang disediakan rusak, kabel harus diganti dengan kabel atau rakitan khusus yang
tersedia dari produsen agen layanannya.
PERHATIAN
Pemasangan
• Dua orang atau lebih harus mengangkat dan mengangkut produk.
- Hindari cedera pribadi.
!
5
BAHASA INDONESIA

PETUNJUK KESELAMATAN
6
BAHASA INDONESIA
• Jangan memasang produk di mana produk akan terkena angin laut (semprotan garam) secara
langsung.
- Hal itu dapat menyebabkan korosi pada produk.
• Pasang selang pembuangan untuk memastikan air kondensasi dibuang dengan baik.
- Sambungan yang buruk dapat menyebabkan kebocoran air.
• Pastikan produk rata saat memasang produk.
- Untuk menghindari getaran atau kebisingan.
• Jangan memasang produk di mana kebisingan atau udara panas dari unit luar ruangan dapat
merusak atau mengganggu lingkungan sekitar.
- Hal itu dapat menyebabkan masalah bagi tetangga Anda dan perselisihan.
• Selalu cek apakah terjadi kebocoran gas (zat pendingin) setelah pemasangan atau perbaikan
produk.
- Tingkat zat pendingin yang rendah dapat menyebabkan kerusakan produk.
• Pekerjaan pipa harus dilindungi dari kerusakan fisik.
• Gunakan tembaga deoksidasi sebagai bahan pipa yang akan dipasang.
• Jika ada orang lain selain Profesional berlisensi yang memasang, memperbaiki atau mengubah
Produk Pendingin Ruangan LG Electronics, garansi akan dibatalkan.
- Semua biaya terkait perbaikan menjadi tanggung jawab penuh pemilik.
• Jangan masukkan selang pembuangan ke dalam pipa pembuangan atau tanah.
- Bau yang tidak sedap dapat terjadi dan menyebabkan korosi pada penukar atau pipa panas.
• Jangan pasang unit ini di lingkungan yang berpotensi ledakan.
Pengoperasian
• Jangan menggunakan produk untuk tujuan khusus, seperti mengawetkan makanan, karya seni,
dll. Ini adalah pendingin ruangan konsumen, bukan sistem pendinginan presisi.
- Ada risiko kerusakan atau hilangnya properti.
•
Sarana pemutusan harus disertakan dalam pemasangan kabel sesuai dengan peraturan pengabelan.
• Alat harus dicabut dari sumber dayanya selama servis dan saat mengganti komponen.
• Jangan menghalangi saluran masuk atau keluar udara.
- Hal itu dapat menyebabkan kerusakan produk.
• Gunakan kain lembut untuk membersihkan. Jangan menggunakan detergen yang keras, pelarut
atau percikan air dsb.
- Ada risiko kebakaran, sengatan listrik, atau kerusakan bagian produk yang terbuat dari plastik.
• Jangan menyentuh bagian logam produk saat melepas filter udara.
- Ada risiko cedera pribadi.
• Jangan menginjak atau menaruh apa pun di atas produk. (unit luar ruangan)
- Ada risiko cedera pribadi dan kerusakan produk.
• Selalu masukkan filter dengan kencang setelah membersihkan. Bersihkan filter setiap dua
minggu sekali atau lebih sering jika perlu.
- Filter yang kotor mengurangi efisiensi.
• Jangan memasukkan tangan atau benda lain melalui saluran masuk atau keluar udara saat
produk dioperasikan.
- Ada bagian yang tajam dan bergerak yang dapat menyebabkan cedera pribadi.
• Berhati-hatilah saat mengeluarkan dan memasang produk.
- Tepi yang tajam dapat menyebabkan cedera.
•
Jika gas zat pendingin bocor selama perbaikan, jangan menyentuh gas zat pendingin yang bocor.
- Gas zat pendingin dapat menyebabkan radang dingin.
