LG GSA-4167B Guide

4.7GB SCSI-2 DVD-RAM Drive
Installation and Using Guide
SA23-1246-00

First Edition (April 2001)
Before using this information and the product it supports, read the information in “Safety Information” on page v an
“Appendix B. Notices” on page 25.
A reader’s comment form is provided at the back of this publication. If the form has been removed, address comments
to Publications Department, Internal Zip 9561, 11400 Burnet Road, Austin, Texas 78758-3493. To send comments
electronically, use this commercial internet address: [email protected]. Any information that you supply may be
used without incurring any obligation to you.
©International Business Machines Corporation 2001. All rights reserved.
Note to U.S. Government Users - Documentation related to restricted rights - Use, duplication, or disclosure is subject
to the restrictions set forth in the GSA ADP Schedule Contract with IBM Corp..
Note
Before you install this product and use this information, be sure to read the product warranties and
notices information included with the system unit in which you are installing the product.

Contents
Safety Information.......................v
Laser Safety Information .....................v
Laser Compliance ......................v
Handling the 4.7GB SCSI-2 DVD-RAM Drive .............vii
Electrostatic Discharge Protection..................vii
About This Book .......................ix
ISO 9000 ..........................ix
Related Publications ......................ix
Trademarks and Acknowledgments .................ix
Chapter 1. Overview ......................1
Front View of DVD-RAM Drive ...................1
Rear View of DVD-RAM Drive ...................2
Chapter 2. Preparing to Install the 4.7GB SCSI-2 DVD-RAM Drive ......3
Verifying Your Hardware Requirements ................3
Verifying Your Software Requirements ................3
Checking Your Package .....................3
Gathering Tools and Documentation .................4
Planning Your SCSI Device Layout .................4
Determining Your SCSI Device Address ................4
Setting the SCSI Address.....................5
Rear View and Jumper Pin Positions on the 4.7GB SCSI-2 DVD-RAM Drive....7
Chapter 3. Installing the 4.7GB SCSI-2 DVD-RAM Drive..........9
Installing and Connecting the 4.7GB SCSI-2 DVD-RAM Drive.........9
Configuring the 4.7GB SCSI-2 DVD-RAM Drive .............10
Verifying the Installation .....................10
Chapter 4. Installing Device Drivers ................11
Installing Device Drivers on an AIX System ..............11
Chapter 5. Using the 4.7GB SCSI-2 DVD-RAM Drive ..........13
Understanding the Status Lights ..................13
Maintaining the DVD-RAM Drive ..................14
Other Handling Considerations ..................14
Handling Compact Discs ....................14
Handling DVD-RAM Cartridges ..................15
Loading a Compact Disc Horizontally ................16
Loading a Compact Disc Vertically .................17
Loading a DVD-RAM Cartridge Horizontally ..............18
Loading a DVD-RAM Cartridge Vertically ...............19
Opening the Tray Manually....................19
Playing an Audio CD ......................20
iii

Appendix A. Communications Statements ..............21
Federal Communications Commission (FCC) Statement ..........21
European Union (EU) Statement ..................22
International Electrotechnical Commission (IEC) Statement .........22
United Kingdom Telecommunications Safety Requirements .........22
Avis de conformité aux normes du ministère des Communications du Canada. . . 22
Canadian Department of Communications Compliance Statement .......22
VCCI Statement .......................23
Radio Protection for Germany ...................23
Appendix B. Notices .....................25
iv 4.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide

Safety Information
DANGER
An electrical outlet that is not correctly wired could place hazardous voltage
on metal parts of the system or the devices that attach to the system. It is the
responsibility of the customer to ensure that the outlet is correctly wired and
grounded to prevent an electrical shock.
Before installing or removing signal cables, ensure that the power cables for
the system unit and all attached devices are unplugged.
When adding or removing any additional devices to or from the system,
ensure that the power cables for those devices are unplugged before the
signal cables are connected. If possible, disconnect all power cables from the
existing system before you add a device.
Use one hand, when possible, to connect or disconnect signal cables to
prevent a possible shock from touching two surfaces with different electrical
potentials.
During an electrical storm, do not connect cables for display stations, printers,
telephones, or station protectors for communications lines.
Laser Safety Information
CAUTION:
This product may contain a CD-ROM which is a class 1 laser product.
Laser Compliance
All Lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR
Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in
compliance with the IEC 825 (first edition 1984) as a class 1 laser product. Consult the
label on each part for laser certification numbers and approval information.
CAUTION:
All IBM laser modules are designed so that there is never any human access to
laser radiation above a class 1 level during normal operation, user maintenance,
or prescribed service conditions. Data processing environments can contain
equipment transmitting on system links with laser modules that operate at
greater than class 1 power levels. For this reason, never look into the end of an
optical fiber cable or open receptacle. Only trained service personnel should
perform the inspection or repair of optical fiber cable assemblies and receptacles.
v

vi 4.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide

Handling the 4.7GB SCSI-2 DVD-RAM Drive
Attention: Static electricity can damage your equipment. Leave the 4.7GB SCSI-2
DVD-RAM Drive in its bag until you are ready to install it in your system unit.
Electrostatic Discharge Protection
Take the following precautions whenever you handle the 4.7GB SCSI-2 DVD-RAM
Drive or other static-sensitive devices:
vUse an anti-static wrist strap if you have one.
vLimit your movement. Movement can cause static electricity to build up around you.
vHold the drive carefully by its frame or edges. Avoid touching solder joints, pins, or
other printed circuitry.
vDo not place the drive on the system unit cover or on a metal table. If you must set it
aside, put it back into its bag.
vBe very careful when you handle the drive during cold weather, as low humidity and
heating increase static electricity.
vii

viii 4.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide

About This Book
This book provides information about the 4.7GB SCSI-2 DVD-RAM Drive, and how to
plan your SCSI device layout, set the SCSI address (also called a SCSI ID), as well as
install and use the DVD-RAM drive. Use this book along with your specific system unit
and operating system documentation.
ISO 9000
ISO 9000 registered quality systems were used in the development and manufacturing
of this product.
Related Publications
Refer to your system unit and operating system documentation for information specific
to your hardware and software configuration.
Trademarks and Acknowledgments
The following terms are trademarks of International Business Machines Corporation in
the United States, other countries, or both:
vAIX
vIBM
vRS/6000
Other company, product, and service names may be trademarks or service marks of
others.
ix

x4.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide

Chapter 1. Overview
This chapter describes the features of the 4.7GB SCSI-2 DVD-RAM Drive. The
DVD-RAM is a half-high, 5.25-inch, 8-bit, single-ended, tray-loading drive. Its distinctive
features include the following:
vSCSI-2 interface supports both synchronous and asynchronous data transfer
vDVD-RAM high-speed data transfer rate of 3600KB per second (24X) max at outer
diameter due to constant RPM spin rate
vDVD-RAM high-speed data transfer rate of 2705KB per second (2X DVD)
vHigh-speed synchronous burst rate of 10MB per second
vAverage random access time of 100ms for CD-ROM and 155ms for DVD-RAM
vCan be installed in either a vertical or horizontal orientation
vLoading tray accommodates 8cm discs (in the horizontal orientation only), 12cm
discs (CD-ROM), and 4.7GB DVD cartridges
vReads multi-session discs
vReads CD-recordable discs
vReads CD-RW discs
vReads/writes 2.6GB, 4.7GB, and 9.4GB (double sided) DVD media
vSupports major CD-ROM formats: Mode 1, Mode 2 Form 1, and XA
vContains headphone output and line output for audio
Front View of DVD-RAM Drive
1 2
56
43
1CD/DVD Tray
2Emergency Eject Hole
3Headphone Jack
4Volume Control
5Status Light
6Load/Unload Button
1

Rear View of DVD-RAM Drive
1 2 34
1Audio Line Out Connector
2Jumper Block and Pins
350-pin SCSI Interface Connector
4Power Connector
24.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide

Chapter 2. Preparing to Install the 4.7GB SCSI-2 DVD-RAM Drive
This chapter covers all the things you need to do before you install your 4.7GB SCSI-2
DVD-RAM Drive. Preparing to install the drive involves the following tasks:
vVerifying your hardware requirements
vVerifying your software requirements
vMaking sure your package is complete
vGathering tools and documentation
vPlanning your SCSI device layout
vDetermining your SCSI device address
vSetting the SCSI address
Verifying Your Hardware Requirements
The 4.7GB SCSI-2 DVD-RAM Drive requires the following hardware:
vAn available bay large enough to hold a 5-1/4 inch half-high device
vA SCSI-2 adapter, which is either
built into or on a separate adapter card inside your
system unit
vA SCSI interface cable
vA 50- to 68-pin interposer
Verifying Your Software Requirements
The 4.7GB SCSI-2 DVD-RAM Drive is supported on AIX 4.3.3 operating system or later.
Ensure that your operating system supports this DVD-RAM drive before you install it.
Contact your support representative for assistance.
Checking Your Package
Check that your package contains the following items:
vThe 4.7GB SCSI-2 DVD-RAM Drive
vMounting screws
vA CD-ROM test disc
vA DVD-RAM test disc
vA 50- to 68-pin interposer
vA registration card
v7 jumpers (included on the jumper block)
vCleaning Kit
Contact the place of purchase if an item is missing or damaged.
Important: Be sure to retain your proof of purchase because it might be required to
receive warranty service.
3

Gathering Tools and Documentation
To install the drive, you need the following items:
vA flat-blade screwdriver
vYour system unit documentation, including any service documentation
vYour operating system documentation
Planning Your SCSI Device Layout
SCSI devices include such hardware as disk drives, tape drives, CD-ROM drives,
DVD-RAM drives, scanners, and printers. Some SCSI devices can be connected to or
installed inside your system unit, while others can be installed externally. The devices
are attached, in a daisy-chain configuration, to a SCSI adapter installed inside the
system unit.
Each device in the chain has a unique SCSI address (also called a SCSI ID). When
you connect more than one SCSI device, it is important that you plan the location and
address of each device in the chain. You must also be sure to connect a terminator at
each end of the chain. If you are using an internally connected device, the SCSI
adapter provides the termination for that end. The last attached device must terminate
the other end of the chain.
If your configuration includes both internal and external devices, you must connect a
terminator to the last external device and terminate the internal SCSI cable. The
adapter terminates one end of the chain, and the last device terminates the other end.
Determining Your SCSI Device Address
Before you install the 4.7GB SCSI-2 DVD-RAM Drive, you must set the SCSI address
on the drive. First, you must determine which SCSI addresses are available to use.
Then you choose an address and install jumpers on the drive to set the selected
address. You can use any available SCSI address as long as no two SCSI devices on
the same chain use the same address. No device can use address 7, which is reserved
for the SCSI adapter.
SCSI addresses are in sequential order from highest to lowest priority. Refer to Table 1
below for the priority associated with each SCSI address. For optimum performance,
choose the highest unused SCSI address between 6 and 0.
Note: Use only SCSI addresses 6 through 0 for this device.
Table 1. Data Access Priorities for SCSI Addresses
Priority SCSI Address SCSI Device Name
Highest Priority 7 Adapter
↓6
↓5
↓4
44.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide

Table 1. Data Access Priorities for SCSI Addresses (continued)
Priority SCSI Address SCSI Device Name
↓3
↓2
↓1
Lowest Priority 0
To find an available SCSI address on an AIX system, do the following:
1. At a system prompt, type:
lsdev -Cs scsi
Press Enter. Information similar to the following displays:
hdisk1 Available 00-01-00-1,0 1.0 GB SCSI Disk Drive
This information is interpreted as follows:
Column 1: device name (hdisk1)
Column 2: device status (Available)
Column 3: SCSI information (00-01-00-1,0)
Column 4: device type (1.0 GB SCSI Disk Drive)
In this example, the SCSI address for the device name (
hdisk1 ) is 1 as shown in
the 1,0 portion of the string in column 3. The 0in the 1,0 portion of the string is the
SCSI bus number for that device.
2. Find an available SCSI address for the DVD-RAM drive and choose the
highest-priority unused address for yours. On Table 1, record the address you chose
for your DVD-RAM drive, as well as the names and addresses of any other installed
SCSI devices. Save this information for future reference.
Setting the SCSI Address
After you choose an available SCSI address for your DVD-RAM drive, you can install
the jumpers on the drive to match the selected address. The SCSI address can be set
from 0 to 6. Address 7 is reserved for the adapter. The 4.7GB SCSI-2 DVD-RAM Drive
SCSI address is factory-set at 4. Refer to “Determining Your SCSI Device Address” on
page 4 if you need instructions for selecting another SCSI address.
To set a SCSI address, you install jumpers onto pin positions 2, 3, and/or 4, located on
the jumper block, to set each position to
On or Off . (See Table 2 on page 6 below.) To
set a position to On, insert a jumper onto both the top and bottom pins. To set a
position to Off, insert the jumper onto the top pin only.
Note: Jumpers are also installed in other positions on the jumper block to enable or
disable other functions.
Refer to the figure on page 7 and to Table 2 on page 6 below as you go through the
following steps to set the SCSI address on this drive:
Chapter 2. Preparing to Install the 4.7GB SCSI-2 DVD-RAM Drive 5

Attention: Be sure to read “Handling the 4.7GB SCSI-2 DVD-RAM Drive” on page vii
before you begin.
1. Remove the drive from its bag.
2. Place the drive on top of the bag on a flat surface.
3. Refer to the figure on page 7. Locate pin positions 2,3, and 4on the drive. They
are the first three positions on the left side of the jumper block as you view the drive
from the back. The SCSI address is factory-set to 4.
4. Using Table 2 below as your guide, install jumpers in the correct positions to set the
SCSI address you previously chose.
Table 2. SCSI Address Settings
SCSI Address Position 2 Position 3 Position 4
0 Off Off Off
1OnOffOff
2 Off On Off
3OnOnOff
4OffOffOn
5OnOffOn
6 Off On On
5. Make sure the jumper on position 1is set to Off. This position does not enable or
disable any function, and can be used as a spare jumper.
6. The jumper in position 5should be set to Off. This position does not enable or
disable any function, and can be used as a spare jumper.
7. Make sure the jumper in position 6is set to Off. This disables the drive’s internal
terminator power. Terminator power is provided by the system through the SCSI
cable.
8. The jumper in position 7should be set to Off. This position does not enable or
disable any function, and can be used as a spare jumper.
You can remove spare jumpers and store them in a safe place or install them in the Off
position on any unused pin position.
64.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide

Rear View and Jumper Pin Positions on the 4.7GB SCSI-2 DVD-RAM Drive
The following figure shows the jumpers as they are set at the factory.
1 2 34
1234567
1Audio Line Out Connector
2Jumper Block and Jumper Pins
350-pin SCSI Interface Connector
4Power Connector
Chapter 2. Preparing to Install the 4.7GB SCSI-2 DVD-RAM Drive 7

84.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide

Chapter 3. Installing the 4.7GB SCSI-2 DVD-RAM Drive
This chapter takes you through the steps of installing your 4.7GB SCSI-2 DVD-RAM
Drive, which involves the following tasks:
Note: Make sure you have set the SCSI address. For more information, see “Setting
the SCSI Address” on page 5.
vInstalling the drive in your system unit
vConnecting the DVD-RAM drive
vConfiguring the device driver software
vVerifying a successful installation
Installing and Connecting the 4.7GB SCSI-2 DVD-RAM Drive
After you set the SCSI address on your drive, you can install the drive into your system
unit. The 4.7GB SCSI-2 DVD-RAM Drive must be installed into an available system unit
bay and connected to a SCSI cable and power cable. Refer to “Rear View and Jumper
Pin Positions on the 4.7GB SCSI-2 DVD-RAM Drive” on page 7 as you go through the
following steps to install and connect the drive:
1. Follow your operating system instructions for shutting down your system, then turn
off the power to your system unit. On an AIX system, type:
shutdown -F
at the system prompt, then press Enter. When halt completed displays, turn off
the system unit power and unplug the power cord from the wall outlet.
2. Remove the covers of your system unit. Follow the instructions provided in your
system unit documentation.
3. Install the drive in an available bay in your system unit. See the instructions in your
system unit documentation for installing an internal device.
Note: Be sure to use the screws provided with this drive. Using the wrong size
screws might cause damage to the drive.
4. Plug the 50- to 68-pin interposer into the SCSI interface connector located on the
back of the drive.
5. Plug the SCSI interface cable into the 50- to 68-pin interposer located on the back
of the drive.
6. Plug the power cable into the power connector located on the back of the drive.
7. If an audio card is installed in your system unit, plug the audio cable into the audio
connector located on the back of the drive.
8. Follow the directions provided in your system unit documentation to reinstall the
covers of your system unit.
9. Plug the power cord back into the wall outlet.
10. Turn on the power to your system unit so that the operating system can update the
system configuration.
9

Save this book and store any extra parts in a safe place in case you ever change your
configuration.
Configuring the 4.7GB SCSI-2 DVD-RAM Drive
To configure the DVD-RAM drive after installation, reboot your system unit. Device
drivers are provided in AIX and other operating systems that support the 4.7GB SCSI-2
DVD-RAM Drive. Your operating system should recognize the drive and should
automatically update your system unit configuration.
Verifying the Installation
See the instructions provided in your system unit documentation for verifying the
successful installation of the drive. To verify the installation on an AIX system, type:
lsdev -Cs scsi
at the system prompt, then press Enter. A list of SCSI devices displays. An
Available
status indicates that the drive is installed and ready to use.
10 4.7GB SCSI-2 DVD-RAM Drive Installation and Using Guide
