GSA-5169D
16x External Super Multi DVD/CD ReWriter
with “One Touch” AV Capture Function
GSA-5169D
PRODUCT INFO
The L3200TF from LG Electronics runs double-duty as both a PC LCD
Monitor and also as an HDTV-ready LCD TV. It boasts a 16:9 Widescreen
display capable of a resolution of 1366 x 768 at a brightness and
contrast that you need to see to believe. The L3200TF is great as a
stand-alone HDTV for your home or as an informational display at a
public venue. The Ultra Fast 8ms Response Time also makes the L3200TF
ideal as a platform for gaming consoles. KEY FEATURES
•Easily transfer your home movies and video cassettes into DVD
with ”One-Touch” AV Capture Function with Audio/Video Inputs
•Reads/Write all CD/DVD formats
•Max. 16x DVD+-R Write Speed
•Max. 48x CD Write Speed
•Supports Double Layer DVD+R, Dual Layer -R Discs (8.5GB)
•2MB Buffer with SuperLink Buffer Underrun Error Protection
•Windows® ME/2000/XP Compatible
•All-In-One DVD Writing Software & Cables Included
•USB 2.0 Port for Fast Data Transfer
BUILT IN
TV
TUNER
BUILT-IN
SPEAKERS
S-VIDEO
INPUT
COMPLETE SOLUTION
With S-Video and RCA Video and Audio inputs, the GSA-5169D optical
drive by LG makes it easy to archive your video cassettes and home movies
into DVD. With an incredible 16x max DVD burn speed, and 5x DVD-RAM,
you’ll never have to worry about compatibility because this drive is
compatible with all DVD formats. Double Layer DVD+R (8.5GB) and dual
layer DVD-R (8.5GB) recording is also supported. Burn Fast, Burn Right
with the LG GSA-5169D.
• AV CAPTURE
The One Touch button on the front faceplate and audio/video inputs in
the rear allow for easy access to connect your VCR or camcorder. The
included One-Touch Capture Software enables seamless transfer of your
analog content in to digital DVD form.
• BURN YOUR MOVIES
The bundled Ahead NeroTM software gives you all the tools you need to
transfer your home movies onto high-quality MPEG-2/DVD Video
• BACKUP YOUR DATA
With PC security becoming an ever important issue, it is important to
backup your valuable PC data. A double layer DVD+R disc holds 8.5GB of
data so you can have all of it on one disc. For even greater flexibility,
DVD-RAM media can be used to write, erase and rewrite up to 100,000
times!
INCLUDES
All-in-One Software
Nero Express, Nero BackItUp, InCD
PowerDVD, PowerProducer Gold
4x
DVD-R DL
Max Write
8x
DVD+R DL
Max Write
Available by Firmware Flashing
LightScribeTM is a laser printing technology that provides a complete
convenient, cost-effective system for labeling optical discs. Simply
“burn” the data to a LightScribeTM disc, flip the disc over, place it back
in the drive and “burn” the label.
DVD
DVD-R
Write

GSA-5169D
16x Super Multi External DVD ReWriter with “One Touch” AV Capture Function
RETAIL PACKAGING INCLUDES:
(1) Power Cord
(1) Signal Cable (15-Pin D-SUB)
(1) Stereo Cable (Audio)
(1) Main Remote Control
(2) AAA battery
(1) Install Disk
(1) Manual Book
(1) Manual Paper
(1) Warranty Card
FRONT REAR
PLUG AND PLAY!
•Watch your favorite DVD Movies!
•Watch your favorite TV Shows!
•Connect to your Digital Camcorder or Digital Camera!
•Connect to your favorite Game Consoles!
SIDE
• For More Information, please visit www.LGUSA.com
• Resellers, please visit www.LGSuperSeller.com
• Phone: [phone]
• Email: lgsupersellert[email protected]
Type: 32.0” (32.0” VIS) WXGA Active Matrix TFT Screen
Size: 27.47” (698mm) horizontal x 15.44” (393mm) vertical
Colors: 16.7 Million (8-bit)
Pixel Pitch: 0.170mm x 0.511mm
Maximum Resolution: 1366 x 768
Brightness: 500 cd/m
2
Contrast Ratio: 1000 : 1 (AI) 500 : 1 (Typical)
Response Time: 8ms (GTG)
Horizontal Viewing Angle: 178 degrees
Vertical Viewing Angle: 178 degrees
Interface: LVDS
Surface Treatment: Anti-glare, Hard coating (3H)
PC Input: (1) 15 Pin D-SUB, (1) DVI-D, (1) PC Audio In
TV Tuner: (1) Built-In
Video Input: (1) Composite, (1) S-Video, (2) Component Video
Audio Input: (1) Standard A/V (Left & Right)
Audio Output: (1) Headphone Output
RS-232C Control: (1) 9-Pin D-SUB
Monitor Communications: DDC 2B
Power Voltage: AC 90~264 V (47~63Hz, auto-switch)
Type: Built in Power
Switch Type: Touch Sense Type
Normal Usage: 160W
Stand-by Usage: Under 5W
31.3W) X 19.4(H) X 3.9(D) in / Set(w/o stand) (803x493x100mm)
31.3(W) X 21.3(H) X 4.1(D) in / Set(w/stand) (803x540x104mm)
38.0(W) X 21.3(H) X 4.1(D) in / Set(w/stand, speakers)
(964x540x104mm)
36.1(W) X 27.7(H) X 13.1(D) in / Box (917x704x332mm)
42.5 lb (19.3kg) (Set, w/o speakers)
57.3 lb (26.0kg) (Shipping Weight)
Cableless, Detachable Side Speakers (1 Pair)
10W x 2 (Output)
Power, Source, Menu, Adjust (Left/Right/Up/Down),
Auto/Select
Advanced PIP, Image Zoom Function, RS-232C Control Jack,
SRS WOW Audio Enhancement Technology, Discrete IR
Codes, Matching Speakers, Anti-Theft Lock Port
UL, FCC(ClassB), EPA Energy Star, CE, SEMKO, CSA, VCCI-2,
CCC, GOST, TUV-GS
(1) Remote Control, (1) Power Cord, (1) A/V Cable, (1) 15-Pin
D-SUB Cable, (1) PC Audio Cable, (1) DVI-D Cable, (1) 19-Pin
Cable, (1) S-VHS Cable, (2) AAA Batteries, User’s Manual
Standard VESA Mounting, 200mm x 200mm Screw Spacing
719192178854
719192179714
DISPLAY
USER INTERFACE
POWER
MECHANICAL
(WxHxD)
Weight
SPEAKER
SPECIAL FUNCTIONS
SAFETY/ REGULATORY
ACCESSORIES
VESA MOUNTING
UPC#
L C D
M o n i t o r s
O p t i c a l
D r i v e s
M e m o r y
P r o d u c t s
L G I T P r o d u c t s w w w . L G u s a . c o m
TYPE
TRANSFER RATES
WRITE
TRANSFER RATES
READ
ACCESS TIME
SUSTAINED RATE
External DVD-RW/CD-RW Drive
[DVD+R] 2.4x, 4x, 8x, 12x, 16x
[DVD+RW] 2.4x, 4x, 8x
[DVD+R Double Layer] 2.4x, 4x, 6x, 8x
[DVD-R Dual Layer] 4x
[DVD-R] 2x, 4x, 8x, 12x, 16x
[DVD-RW] 1x, 2x, 4x, 6x
[DVD-RAM] 2x, 3x, 5x(Ver 2.2)
[CD-R] 16x, 24x, 40x, 48x
[CD-RW] 4x, 10x, 16x, 24x, 32x
[DVD-R/-RW/-ROM] 16x / 8x / 16x Max
[DVD+R/+RW/+R Double Layer] 16x / 8x / 8x Max
[DVD-R Dual Layer] 4x
[CD-ROM/CD-R] 48x Max
[CD-RW] 32x Max
[DVD-RAM] 2x, 3x, 5x Max
DVD-ROM(SL/DL) : 140/175ms
DVD-RAM : 250ms
CD-ROM : 120ms
DVD-ROM : 22.16MB/sec (16x Max.)
CD-ROM : 7,200 kB/sec (48x Max.)
BURST TRANSFER
RATE
WRITING METHOD
AV CAPTURE
HOST INTERFACE
DIMENSIONS
(WxHxD)
WEIGHT
UPC#
UltraDMA Mode4 (66.6MB/sec Max)
Multi Word DMA Mode2 (16.6MB/sec Max)
PIO Mode4 (16.6MB/sec Max)
DVD-R/RW : Disc at Once, Incremental Recording,
Restricted Overwrite (DVD-RW only)
DVD+R: Sequential Recording
DVD+RW/RAM: Random Write
DVD+R/-R DL: Sequential Recording
CD-R/RW: Disc at Once (DAO), Session at Once (SAO),
Track at Once (TAO), Packet Writing
Input Video : S-Video/RCA
Input Audio : Analog
Video Encoding Standard : MPEG-2, MPEG-1
Data Multiplexing: MPEG-2 (ISO/IEC 13818-1)
Audio Compression : Read: MPEG-1, MPEG-2, AC3
Write: MPEG-1, Layer-2
Video Type : NTSC/PAL
Video Format : VCD/SVCD/DVD/AVI
Supported Capture Recording Disc : CD-R/CD-RW
(VCD/SVCD/AVI)/ DVD+-R/DVD+-RW/DVD+-R DL (DVD/AVI)
USB 1.1/USB 2.0
External Dimensions 6.3”x 1.9”x 9.0” (160 x 50 x 230mm)
Front Bezel 6.5” x 2.0” x 0.2” (164.8 x 51.8 x 5mm)
3.1 lbs (1.4 kg)
048231294478
SPECIFICATIONS
CONTACT US
www.LGSuperSeller.com
www.LGusa.com
www.LGErewards.com
FRONT BACK SIDE
• 1-Year Warranty on Optical Drives
• 48 Hour Swap Program
• Call Toll-Free 1-800-243-000 (24 Hours 7 Days a Week)
WARRANTY
SOFTWARE
FRONT BACK SIDE REAR PORTS (ANALOG/DIGITAL/POWER) HEAT-SENSITIVE POWER BUTTON AUTO-MIRROR FUNCTION
INCLUDES
All-in-One Software
Nero Express, Nero BackItUp, InCD
PowerDVD, PowerProducer Gold
• Nero Recording
Nero Express, InCD
• Cyberlink’s Authoring & Playback Software
PowerProducer Gold, PowerDVD
• One Touch DVD (AV Capture Software)
One Touch Easy Wizard Mode, Advanced Mode
The GSA-5169D features the “One
Touch” Video to Disc Recording feature
which enables seamless transfer of
videocasettes and home videos to DVD.
The rear audio and video ports allow
for easy connection to your A/V
devices.
One Touch DVD button
(1) S-Video, (1) Compsite Inputs (Audio/Video)
