LG BH6440P User manual

TV Connection (HDMI OUT)
OPTICAL IN Connection
Wired Network Connection
Access Point
Cable Modem
aDisplays SmartShare menu.
bDisplays the Premium Home screen.
cDisplays LG Apps titles provided to the unit.
dDisplays the [My Apps] screen.
eChanges input mode.
fAdjusts the system settings.
Using HOME menu
Speaker Connection
Disc, Data Playback
cDisplays all linked devices.
Selects video, photo or audio content.
Displays the le or folder on linked device.
For the most Audio CD, BD-ROM and DVD-ROM discs, playback starts automatically.
,
Network Playback
SmartShare PC software Installation
Run the program, and set the share folder you want.
b
SmartShare Network Playback
aCheck the network connection and settings.
Router
www.lg.com
TV
TV
OPTICAL OUT
a
Initial Setup
Follow the directions for the initial setup displayed on the
screen.
Start the speaker test.
Stop the speaker test and select [Next].
Setup [TV Sound Connecting] and select [Next].
,
a
b
,
Devices that support MTP. aInstall SmartShare PC Software.
ENGLISH | SIMPLE MANUAL
An extended Owner’s Manual that contains information
on the advanced features is located on the CD-ROM
provided in an electronic version. To read these files, you
will need to use a Personal Computer (PC) equipped
with a CD-ROM drive.
3D Blu-ray™
/ DVD Home
Cinema System
BH6240S, BH6340H,
BH6440P, BH6540T
FRONT R
FRONT L
CENTER
REAR R
REAR L
WOOFER
Speaker design and connection method may be dierent according to models.
+
-
FM antenna
Speaker cables (Optional) b
a b c d e f
b c
BH6540T-DB_BGBRLLK_SIM_4434.indd 1 2014-09-02 �� 11:43:38

Safety Information
Specication
ENGLISH
Power requirements Refer to main label.
Power consumption Refer to main label.
Dimensions
(W x H x D)
Approx. 360 mm x 60.5 mm x 299
mm
Net Weight
(Approx.) 2.7 kg
Bus Power Supply
(USB) 5 V 0500 mA
Design and specications are subject to change without
notice.
Customer Support
You can update the Player using the latest software to
enhance the products operation and/or add new features.
To obtain the latest software for this player (if updates have
been made), proceed the software updates as above or
visit http://www.lg.com or contact LG Electronics customer
care centre.
Open source software notice
To obtain the corresponding source code under GPL,
LGPL and other open source licenses, please visit http://
opensource.lge.com. All referred license terms, warranty
disclaimers and copyright notices are available to
download with the source code.
Additional InformationEnjoying Private Sound Software Update
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK DO NOT
REMOVE COVER (OR BACK) NO USER-SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead symbol
within an equilateral triangle is intended to
alert the user to the presence of uninsulated
dangerous voltage within the product’s
enclosure that may be of sucient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK HAZARD, DO
NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
WARNING: Do not install this equipment in a conned space such
as a book case or similar unit.
CAUTION: Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
Slots and openings in the cabinet are provided for ventilation and
to ensure reliable operation of the product and to protect it from
over heating. The openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar surface. This product
shall not be placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
Use of controls, adjustments or the performance of procedures
other than those specied herein may result in hazardous radiation
exposure.
CAUTION concerning the Power Cord
To disconnect power from the mains, pull out the mains cord
plug. When installing the product, ensure that the plug is easily
accessible.
CAUTION: The apparatus shall not be exposed to water (dripping
or splashing) and no objects lled with liquids, such as vases, shall
be placed on the apparatus.
This device is equipped with a portable battery or accumulator.
Safety way to remove the battery or the battery from the
equipment: Remove the old battery or battery pack, follow the
steps in reverse order than the assembly.To prevent contamination
of the environment and bring on possible threat to human
and animal health, the old battery or the battery put it in the
appropriate container at designated collection points. Do not
dispose of batteries or battery together with other waste. It is
recommended that you use local, free reimbursement systems
batteries and accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
Disposal of your old appliance
1. When this crossed-out wheeled bin symbol is
attached to a product it means the product is
covered by the European Directive 2002/96/EC.
2. All electrical and electronic products should be
disposed of separately from the municipal waste
stream via designated collection facilities appointed
by the government or the local authorities.
3. The correct disposal of your old appliance will help
prevent potential negative consequences for the
environment and human health.
4. For more detailed information about disposal of
your old appliance, please contact your city oce,
waste disposal service or the shop where you
purchased the product.
Disposal of waste batteries/accumulators
1. When this crossed-out wheeled bin symbol is
attached to batteries/accumulators of Your product
it means they are covered by European Directive
2006/66/EC.
2. This symbol may be combined with chemical
symbols for mercury(Hg), cadmium(Cd) or lead(Pb)
if the battery Contains more that 0.0005% of mer-
cury,0.002% of cadmium or 0.004% of lead.
3. All batteries/accumulators should be disposed
separately from the municipal waste stream via
designated collection facilities appointed by the
government or the local authorities.
4. The correct disposal of Your old batteries/accu-
mulators will help to prevent potential negative
consequences for the environment, animal and
human health.
5. For more detailed information about disposal of
Your old batteries/accumulators, please contact
Your city oce, waste disposal service or the shop
where You purchased the product.
For Wireless product European Union Notice
LG Electronics hereby declares that this/these product(s) is/are in
compliance with the essential requirements and other relevant
provisions of Directive 1999/5/EC, 2004/108/EC, 2006/95/EC,
2009/125/EC and 2011/65/EU.
Please contact to the following address for obtaining a copy of the
DoC (Declaration of Conformity).
Contact oce for compliance of this product:
LG Electronics Inc.
EU Representative, Krijgsman 1,
1186 DM Amstelveen, The Netherlands
yPlease note that this is NOT a Customer Service contact
point. For Customer Service Information, see Warranty
Card or contact the dealer that you purchased this
product.
Indoor use only.
RF Radiation Exposure Statement
This equipment should be installed and operated with minimum
distance 20 cm between the radiator and your body.
,
b
a
c
Turn on the mobile device LG AV Remote
app is lnstalled and run LG AV Remote.
Make sure that your smartphone is connected to
the same Wi-Fi network as this player.
Router
Router
Smerovač
Router
Router
Not all modes support private sound and pairing multiple devices is not available.
a
c
b
d
Some of the content in this manual may dier from your player depending on the software of the player or your
service provider.
POWER: This unit operates on a mains supply of 200-240V~, 50/60Hz.
Wiring: This unit is supplied with a BS 1363 approved main plug. When replacing the fuse, always use of the same rating approved to BS
1362. Never use this plug with the fuse cover omitted. To obtain a replacement fuse cover contact your dealer. If the type of plug supplied
is not suitable for the mains sockets in your home, then the plug should be removed and a suitable type tted. Please refer to the wiring
instructions below:
Warning: A mains plug removed from the mains lead of this unit must be destroyed. A mains plug with bared wires is hazardous if inserted
in a mains socket. Do not connect either wire to the earth pin, marked with the letter E or with the earth symbol 6or coloured green or
green and yellow. If any other plug is tted, use same rating of fuse in the plug.
Important: The wires in this mains lead are coloured in accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE - As the colours of the wires in the mains lead of this unit may not correspond with the coloured marking
identifying the terminals in your plug, proceed as follows: The wire which is coloured blue must be connected to the terminal which is
marked with the letter N or coloured black. The wire which is coloured brown must be connected to the terminal which is marked with the
letter L or coloured red.
Technology with the human touch
GUARANTEE
• LG Electronics U.K. Ltd. will provide the following services in order to expedite this Guarantee.
1. All faulty components which fail due to defective manufacture will be replaced free of charge for a period of 12 months
from the original date of purchase.
2. The dealer (or his service agent) who sold the product will be reimbursed for any labour provided in the repair of this LG
equipment, for a period of 12 months from the original date of purchase. These claims must be made in accordance with
the published scale of service charges and relevant claims procedure.
PLEASE NOTE:
A. The dealer may restrict the guarantee to the original purchaser.
B. The dealer is not obliged to carry out service under guarantee if unauthorized modifications are made to the apparatus,
or if non standard components are used or if the serial number of the apparatus is removed, defaced, misused, or altered.
C. Any claims made under guarantee must be directed to the dealer from whom the equipment was originally purchased.
The dealer may, before carrying out service under guarantee, require a receipted account as evidence of the date of
purchase.
D. We respectfully point out that your dealer is not obligated to replace batteries if they become exhausted or worn in use.
E. Aerial alignment and consumer control adjustments are not covered by this guarantee.
This guarantee does not affect your statutory rights.
• REQUIREMENTS TO MAINTAIN WARRANTY COVERAGE:
RETAINYOUR RECEIPT TO PROVE DATE OF PURCHASE. A COPY OFYOUR RECEIPT MUST BE SURRENDERED AT THE TIME
GUARANTEE SERVICE IS PROVED.
• Product Registration Card :
It is helpful to complete at least your name, address, phone, model & serial numbers and return it. This will enable LG to
assist you in the future should you lose your receipt, your units be stolen, or should modifications be necessary.
• To obtain information or assistance:
Call UK: 0344 847 5454 IE: 01 686 9454
MODEL NO.* SERIAL NO.* DATE OF PURCHASE.*
In all cases of diculty - consult your LG dealer from whom the product was purchased
LGEUK Website : www.lg.com/uk
(Service website : www.lg.com/uk/support)
