LG MS-192W User manual

Instruction Manual
MS-192W

2
1
4
2
5
3
1. Front plate
2. Viewing window
3. Door seal
4. Sa ety lock system
5. Control panel
6. Glass tray
7. Roller rest
Oven Parts

3
Control Panel
Power selector
Allows selection o desired power.
Timer
permits selection o the desired cooking
time.

0123
4
5
6
7
8
9
10
20
30
40
50
60
MinMin
0.5
0.1
0.2
0.4
kg
0.3
MaxMax
90
360
600
WattWatt
DefrostDefrost

4
Installation
WARNIN : THIS APPLIANCE MUST BE EARTHED
The oven cannot be operated with the door open due to the sa ety interlocks built in the door mechanism
which switch o cooking unctions when the door is opened. Operating the oven with the door open could
result in harm ul exposure to microwave energy. It is important not to tamper with the door mechanism.
Do not place any object between the oven ront ace and the door or allow soil or cleaner residue
to accumulate on sealing sur aces.
Do not operate the oven i it is damaged. It is particularly important that the oven door closes
properly and that there is no damage to the (1) door (bent), (2) hinges and latches (broken or loosened), (3)
door seals and sealing sur aces.
The oven should not be adjusted or repaired by anyone except quali ied service personnel.
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENER Y
WARNIN
When heating liquids, e.g. soups, sauces and beverages in your microwave oven, delayed eruptive boiling can
occur without evidence o bubbling. This could result in a sudden boil over o the hot liquid. To prevent this
possibility the ollowing steps should be taken:
1. Avoid using straight-sided containers with narrow necks.
2. Do not overheat.
3. Stir the liquid be ore placing the container in the oven and again hal way through the heating time.
4. A ter heating, allow to stand in the oven or a short time. Stir or shake the contents (especially eeding
bottles and baby oods) and care ully check the temperature be ore use.
5. Clean the oven interior with a damp cloth a ter use.
6. Never operate the oven without Glass Tray & Roller rest/metal container as it may cause sparking.
1. Remove all packing materials and accessories.
2. Place the oven on a level sur ace a minimum o 85cm above the loor with at least 30cm above and 10cm rear
space to allow adequate ventilation. The side o the oven should be kept clear so there is air low or ventilation.
The ront o the oven should be at least 8cm rom the edge o the sur ace to prevent tipping.
An exhaust outlet is located on top or side o the oven. Blocking the outlet can damage the oven.
3. Plug your oven into a standard voltage household outlet.
NOTE: • This appliance should not be used for commercial catering purposes.
The wires in the mains lead are coloured in accordance with the ollowing code:
Blue - Neutral
Brown - Live
Green and Yellow - Earth
I the power cord is damaged, it must be replaced by the manu acturer or its service agent or a similarly
quali ied person in order to avoid hazard.

5
Important safety instructions
Read care ully and keep or uture re erence
• Do not operate the oven when empty. It is
best to leave a glass o water in the oven
when not in use. The water will sa ely
absorb all microwave energy i the oven
is accidentally started.
• Do not dry clothes in the microwave oven.
They may become carbonized or burned i
heated too long.
• Do not cook ood wrapped in paper towels,
unless your cook book contains instructions or
the ood you are cooking.
• Do not use the oven or drying kitchen towels
or paper products. They may burn.
• Do not use wooden containers. They may
heat up and char.
• Do not use recycled paper products since
they may contain impurities which may
cause sparks and/or ires when used in
cooking.
• Allow the turntable to cool be ore cleaning.
• Small amounts o ood require shorter
cooking or heating time. I normal times
are allowed they may overheat and burn.
• Be ore cooking, pierce the skin o ruit and
vegetables.
• Do not cook eggs in their shell.
Pressure will build up inside the egg
which will burst.
• Do not attempt deep at rying in your
oven.
• Remove the plastic wrapping rom ood
be ore cooking or de rosting. Note
though that in some cases ood should
be covered with plastic ilm, or heating
or cooking, as detailed in microwave
cook books.
• I smoke is observed, switch o or disconnect
the oven rom the power supply and keep the
oven door closed in order to sti le any lames.
• When ood is heated or cooked in disposable
containers o plastic, paper or other
combustible materials, check the oven
requently due to the possibility o ignition.
- WARNIN : Liquids or other oods must not be heated in sealed containers since they
are liable to explode.
- WARNIN : Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in a
sa e way and understands the hazards o improper use.
- WARNIN : I the oven door and door seal are damaged, the oven must not be
operated until it has been repaired by a quali ied service technician.
- WARNIN : Do not attempt to tamper with, or make any adjustments or repairs to the
door, control panel, sa ety interlock switches or any other part o the oven.
It is hazardous or anyone to carry out any service or repair operation
which involves the removal o any cover which gives protection against
exposure to microwave energy. Repair should only be undertaken by a
quali ied service technician.

6
Cooking Utensils
COOKIN UTENSILS
Utensils should be checked to ensure that they are suitable or use in the microwave oven.
The ollowing chart summarises the proper use o cooking utensils in your oven:
Cooking utensils Microwave
Heat resistant glass, glass ceramic yes
Ceramic, china yes
(Do not use china with
gold or silver trim.)
Metal cookware no
Non-heat resistant glass no
Microwave plastic yes
Plastic wrap yes
Paper (cup, plates, towels) yes
Straw, wicker and wood no
Microwave
1. Most glass, glass ceramic, and heat resistant
glassware utensils are excellent. Those with
metal trim should not be used in a microwave
oven.
2. Paper napkins, towels, plates, cups, cartons,
and cardboard can be used in the microwave
oven. Do not use recycled paper products
since they may contain impurities which may
cause sparks and/or ires when used in
cooking.
(Consult your cookbook or correct use o
these products.)
3. Plastic dishes, cups, reezer bags, and plastic
wraps may be used in the microwave oven.
Follow the manu acturer’s instructions or the
in ormation given in the cookbook when using
plastics in the microwave oven.
4. Metal utensils and utensils with metallic trim
should not be used in the microwave oven.
For more in ormation on the proper use o
metal in your oven, please read the
introduction section in the cookbook. I the
use o aluminum oil, skewers, or utensils
containing metal in the oven is speci ied in the
recipe, allow at least 2.5cm clearance
between the metal object and the interior
oven wall. I arcing (sparks) occurs, remove
immediately.
Note:
Consult your cookbook, individual recipes, and
charts or correct use o cooking containers,
products, and other use ul in ormation.
Notes:
• Care should be taken when removing utensils
or the glass turntable, as they may become
hot during cooking.
• Only use a thermometer that is designed or
recommended or use in the microwave oven.
• Ensure the turntable is in place when you
operate the oven.

7
Other Helpful Instructions
Cleaning and Care
For best results and more enjoyable cooking,
please read these comments thoroughly.
For Best Results:
1. When determining the time or a particular ood,
begin by using minimum time and checking con-
dition occasionally. It is easy to overcook ood
because microwaves cook very quickly.
2. Small quantities o ood, or oods with low water
content may dry out and become hard i
cooked too long.
Defrosting Frozen Foods:
1. Foods that have been rozen can be placed
directly in the oven or thawing. (Be certain
to remove any metallic ties or wraps.)
2. De rost according to the De rosting Tips ound in
this Manual.
3. For areas o the ood thawing aster than others,
cover with small pieces o aluminium oil. This
helps slow down or stop the de rosting process.
4. Some oods should not be completely thawed
be ore cooking. For example, ish cooks so
quickly that it is sometimes better to begin
cooking while still slightly rozen.
5. It may be necessary to increase or decrease the
cooking time in some recipes, depending
on the starting temperature o the oods.
NOTE:
Air rom the vent may become warm during
cooking.
Browning:
There are a ew oods which are not cooked long
enough in the microwave oven to brown and may
need additional colour.
Coatings such as paprika, and browning agents
such as Worcestershire sauce may be used on
chops, meat patties or chicken pieces.
Roasts, poultry or ham, cooked or 10-15 minutes or
longer, will brown without extra additives.
BE SURE THE OVEN IS TURNED OFF BEFORE
CLEANIN .
Keep the oven interior sur aces clean and dry.
As a general rule clean a ter each use.
INTERIOR WALLS
Remove any crumbs and ood remains between the
door and oven using a damp cloth. This area has
to be particularly well cleaned to ensure the door
will close properly. Remove any grease splashes
with a soapy cloth then rinse and dry. Do not use
abrasives which may scratch and damage the
painted sur ace o the oven.
NEVER POUR WATER INTO THE OVEN
ROLLER REST
The roller rest should be removed and cleaned in
hot soapy water at least once a week to prevent
grease restricting the rotation o the wheels.
DOOR
The door and door seals should be kept clean at
all times. Use only warm, soapy water to rinse then
dry thoroughly.
DO NOT USE ABRASIVE MATERIALS, SUCH AS
CLEANING POWDERS OR STEEL AND PLASTIC
PADS.
Metal parts will be easier to maintain i wiped
requently with a damp cloth.
EXTERIOR
Clean with mild soap and warm water, rinse and
dry with a so t cloth. Do not use abrasive materials.
Do not spill water in the vents. I the power lead
becomes soiled wipe it with a damp cloth.

8
MICROWAVE COOKIN
See page 3.
1. Open the oven door, place the ood on the
turntable in the oven, and close the oven
door.
2. Set the power selector () to the desired power
level. There are ive power levels rom 90 Watts
to max. The power selector can be set to any
one o these positions.
3. Set the timer () to the desired cooking
time. The turntable begins to rotate and
cooking starts. At the end o cooking time the
bell will ring, and the lamp is turned o .
Note:
• Each number on the scale represents one
minute. To ensure accurate timing, it is
advisable to turn the timer knob slightly past
the desired cooking time and then back to
the proposed setting.
• Press the door opener to check the cooking
condition during oven operation. Opening the
door during cooking automatically turns o
the oven and stops the timer. I cooking is to
continue, close the door - the oven will turn
on and the timer will resume counting.
• The turntable may rotate in either direction.
WEI HT DEFROST COOKIN
See page 3.
De rosting rozen ood is one o the bene its o a
microwave oven. De rosting using a microwave
oven is much aster than in the re rigerator and
sa er than at room temperature, as it does not
promote the growth o harm ul bacteria.
It is important to remember that de rosting takes
longer than normal cooking. Check the ood,
turning it over at least once during de rosting.
1. Turn the power select knob () to set
the de rosting mode. ( )
2. Turn the timer knob () clockwise to set the
weight (kg) o ood.
NOTE: The oven starts working as soon as the
timer knob is turned. Each number on the scale
represents one kg.
MS-192W
(Watt)
• Max
• 600
• 360
• De rost
• 90
Operating Procedure

9
Heating or Reheating uide
To heat or reheat success ully in the microwave, it is important to ollow several guidelines. Measure the amount o
ood in order to determine the time needed to reheat. Arrange the ood in a circular pattern or best results. Room
temperature ood will heat aster than re rigerated ood. Canned oods should be taken out o the can and placed in a
microwavable container. The ood will be heated more evenly i covered with a microwavable lid or vented plastic
wrap. Remove cover care ully to prevent steam burns. Use the ollowing chart as a guide or reheating cooked ood.
Sliced meat 11⁄2~21⁄2minutes Place sliced meat on microwavable plate.
3 slices (0.5cm thick) Cover with plastic wrap and vent.
• Note: Gravy or sauce helps to keep meat juicy.
Chicken pieces
1 breast 2~31⁄2minutes Place chicken pieces on microwavable plate.
1 leg and thigh 11⁄2~21⁄2minutes Cover with plastic wrap and vent.
Fish illet 1~21⁄2minutes Place ish on microwavable plate.
(170-230g) Cover with plastic wrap and vent.
Lasagne Place lasagne on microwavable plate.
1 serving (300g) 41⁄2~7 minutes Cover with plastic wrap and vent.
Casserole
1 cup 11⁄2~31⁄2minutes COOK covered in microwavable casserole dish.
4 cups 5~71⁄2minutes Stir once hal way through cooking.
Casserole
cream or cheese
1 cup 11⁄2~3 minutes COOK covered in microwavable casserole dish.
4 cups 4~61⁄2minutes Stir once hal way through cooking.
Sloppy Joe or
Barbecued bee Reheat illing and bun separately.
1 sandwich 1~3 minutes Cook illing covered in microwavable casserole dish.
(1/2 cup meat illing) Stir once. Heat bun as directed in chart below.
without bun
Mashed potatoes
1 cup 2~31⁄2minutes COOK covered in microwavable casserole dish.
4 cups 6~81⁄2minutes Stir once hal way through cooking.
Baked beans COOK covered in microwavable casserole dish.
1 cup 2~31⁄2minutes Stir once hal way through cooking.
Ravioli or pasta in sauce
1 cup 3~41⁄2minutes COOK covered in microwavable casserole dish.
4 cups 8~111⁄2minutes Stir once hal way through cooking.
Rice
1 cup 11⁄2~2 minutes COOK covered in microwavable casserole dish.
4 cups 4~6 minutes Stir once hal way through cooking.
Sandwich roll or bun
1 roll 20~35 seconds Wrap in paper towel and place on glass tray.
Vegetables
1 cup 11⁄2~3 minutes COOK covered in microwavable casserole dish.
4 cups 4~6 minutes Stir once hal way through cooking.
Soup COOK covered in microwavable casserole dish.
1 serving (8 oz.) 2~3 minutes Stir once hal way through cooking.
Item Cook time Special Instructions
(at HI H)

10
Fresh Vegetable Chart
Artichokes 2 medium 5~8 Trim. Add 2 tsp water and 2 tsp juice. 2-3 minutes
(230g each) 4 medium 11~13 Cover.
Asparagus, 450g 3~7 Add 1⁄2cup water. Cover. 2-3 minutes
Fresh, Spears
Green Beans 450g 8~12 Add 1⁄2cup water in 1.5 litre casserole 2-3 minutes
dish. Stir hal way through cooking.
Beets, Fresh 450g 13~18 Add 1⁄2cup water in 1.5 litre covered casserole 2-3 minutes
dish. Rearrange hal way through cooking.
Broccoli, Fresh, 450g 5~9 Place broccoli in baking dish. 2-3 minutes
Spears Add 1⁄2cup water.
Cabbage, Fresh, 450g 6~8 Add 1⁄2cup water in 1.5 litre covered casserole 2-3 minutes
Chopped dish. Stir hal way through cooking.
Carrots, Fresh, 200g 3~6 Add 1⁄4cup water in 1 litre covered casserole 2-3 minutes
Sliced dish. Stir hal way through cooking.
Cauli lower, 450g 8~10 Trim. Add 1⁄4cup water in 1 litre covered 2-3 minutes
Fresh, Whole casserole dish. Stir hal way through cooking.
Fresh, Flowerettes 2 cups 3~6 Slice. Add 1⁄2cup water in 1.5 litre covered 2-3 minutes
Celery, Fresh, 4 cups 8~10 casserole dish. Stir hal way through cooking.
Sliced
Corn, Fresh 2 ears 5~9 Husk. Add 2 tbsp water in 1.5 litre baking dish. 2-3 minutes
Cover.
Mushrooms, 230g 2~3 Place mushrooms in 1.5 litre covered 2-3 minutes
Fresh, Sliced casserole dish. Stir hal way through cooking.
Parsnips, Fresh, 450g 4~8 Add 1⁄2cup water in 1.5 litre covered 2-3 minutes
Sliced casserole dish. Stir hal way through cooking.
Peas, Green, 4 cups 7~10 Add 1⁄2cup water in 1.5 litre covered 2-3 minutes
Fresh casserole dish. Stir hal way through cooking.
Sweet Potatoes 2 medium 5~10 Pierce potatoes several times with ork. 2-3 minutes
Whole Baking 4 medium 7~13 Place on 2 paper towels. 2-3 minutes
(170~230g each) Turn over hal way through cooking.
White potatoes, 2 potatoes 6~8 Pierce potatoes several times with ork. 2-3 minutes
Whole Baking 4 potatoes 10~15 Place on 2 paper towels. 2-3 minutes
(170~230g each) Turn over hal way through cooking.
Spinach, Fresh, 450g 5~8 Add 1⁄2cup water in 2 litre covered casserole dish. 2-3 minutes
Lea
Courgette, Fresh, 450g 5~8 Add 1⁄2cup water in 1.5 litre covered casserole 2-3 minutes
Sliced dish. Stir hal way through cooking.
Courgette, Fresh, 450g 7~10 Pierce. Place on 2 paper towels. 2-3 minutes
Whole Turn courgette over and rearrange hal way
through cooking.
Vegetable Amount Cook time
(at HI H) Instructions Standing Time

VEAL
chop 450g 9-10 10
minced 450g 4-5 10
steak 450g 6-8 10
PORK
chop (1⁄2 ”/1.2cm thick) 700g 10-15 10
cubes 700g 8-10 10
minced 450g 5-6 10
roast, loin (boneless) 2-2.3kg 28-34 20
spareribs 1.5kg 12-17 15
steak shoulder 1.2kg 12-15 10
tenderloin 1kg 10-12 10
LAMB
roast, leg or shoulder 2-2.3kg 28-33 15
CHICKEN
whole 1.2-1.5kg 26-30 20
parts 1.2-1.5kg 14-17 15
breasts (with bone) 1-1.5kg 10-14 20
drumsticks 450g 9-10 10
thighs 450g 9-10 10
wings 700g 8-12 10
TURKEY
parts 1-1.5kg 14-16 15
breast (with bone) 2-2.5kg 18-22 20
DUCKLIN
whole 2-2.5kg 30-40 25
11
Meat Weight Defrosting time Standing time
(minutes) (minutes)
Defrosting Tips
Defrosting meats tips & techniques
“WARNIN : Do not use aluminium foil during cooking cycle.”
• You can de rost meats in their original wrapping as long as no metal is present. Remove any metal rings,
twist ties, wire or oil.
• Place meat in a shallow baking dish to catch juices.
• De rost meats only as long as necesssary. Separate items like chops, sausages and bacon as soon as
possible. Remove de rosted portions and continue to de rost remaining pieces.
• Whole pieces o meat are ready or standing time as soon as a ork can be pushed into the centre o the
meat using moderate pressure. The centre will still be icy. Allow to stand until completely thawed.
• De rost meat on de rost mode.
MEAT & POULTRY DEFROSTIN TABLE

12
Questions and Answers
Q. What’s wrong when the oven light will not
glow?
A. ■Light bulb has blown.
■Door is not closed.
Q. Why is steam coming out o the air exhaust
vent and/or why is water dripping rom the
bottom o the door?
A. Steam is normally produced during cooking
operations. The microwave has been made
to vent this steam out o the side vent,
occasionally this steam condenses on the
door and water then drips out at the bottom
o the door. This is quite normal and sa e.
Q. Does microwave energy pass through the
viewing screen in the door?
A. No. The metal screen re lects the energy to
the oven cavity. The holes, or ports are
made to allow light to pass; they do not let
microwave energy through.
Q. Will the microwave oven be damaged i it
operates while empty?
A. Yes. Never run it empty.
Q. Why do eggs sometimes pop?
A. When baking or poaching eggs, the yolk
may pop due to steam build-up inside the yolk
membrane. To prevent this, simply pierce the
yolk with a toothpick be ore cooking.
Never cook eggs witthout piercing their shells.
Q. Why is standing time recommended a ter the
cooking operation has been completed?
A. Standing time is very important.
With microwave cooking, the heat is in the
ood, not in the oven.
Many oods build up enough internal heat to
allow the cooking process to continue, even
a ter the ood is removed rom the oven.
Standing time or joints o meat, large
vegetables and cakes is to allow the inside to
cook completely, without overcooking the outside.
Q. Why does my oven not always cook as ast
as the microwave cooking guide says?
A. Check your cooking guide again, to make
sure you’ve ollowed directions exactly;
and to see what might cause variations in
cooking time. Cooking guide times and heat
settings are suggestions, to help prevent
over-cooking . . . the most common problem
in getting used to a microwave oven.
Variations in the size, shape and weights and
dimensions could require longer cooking time.
Use your own judgement along with the
cooking guide suggestions to check
whether the ood has been properly cooked
just as you would do with a conventional
cooker.
Q. Why do sparks and crackling (arcing) occur
in the oven?
A. There may be several reasons why sparks
and crackling (arcing) within cavity happens.
■You are using dishes with metal parts or trim
(silver or gold).
■You have le t a ork or other metal utensil in
the oven.
■You are using a large amount o metal oil.
■You are using a metal twist-tie.

13
Technical Specifications
MS-192W
Power Input 230 V AC, 50 Hz
Output (IEC 60705 RATING STANDARD) 800 Watts
Microwave Frequency 2,450 MHz
Outside Dimensions (W x H x D mm) 455 x 281 x 325
Power Consumption 1,200 Watts
Wiring
The wires in this mains lead are coloured in accordance with the ollowing codes
BLUE ~Neutral
BROWN ~Live
GREEN & YELLOW ~Earth
As the colours o the wires in the mains lead o this appliance may not correspond with the
coloured markings on the terminals in your plug proceed as ollows.
The wire which is coloured BLUE must be connected to the terminal which is marked with the
letter N or Coloured BLACK.
The wire which is coloured BROWN must be connected to the terminal which is marked with
the letter L or coloured RED.
The wire which is coloured GREEN & YELLOW or GREEN must be connected to the terminal
which is marked with the leter E or
You must use a 13 Amp plug (BS 1363) and it a 13 Amp use (BS 1362). I any other o type o plug
is used a 13 Amp use must be itted either in the plug adapter or at the distribution board. Never use
this plug with the use cover omitted. To obtain a replacement use cover contact your supplying
dealer or LG Electronics.

PARTNo. 3828W5A3984
