LG SV-iS5 Series User manual

MODBUS-RTU
Option Board for
SV-iS5 Series
Read this manual carefully before using the MODBUS-RTU Option board
and follow the instructions exactly.
After reading this manual, keep it at handy for future reference.
LG Industrial Systems
User Manual

Thank you for purchase of LG Modbus-RTU Option Board!
SAFETY PRECAUTIONS
 Always follow safety precautions to prevent accidents and potential hazards from occurring.
 Safety precautions are classified into “WARNING” and “CAUTION” in this manual.
WARNING
CAUTION
 Throughout this manual we use the following two illustrations to make you aware of safety
considerations:
Identifies potential hazards (under certain conditions 삭제).
Read the message and follow the instructions carefully.
Identifies shock hazards(under certain conditions 삭제).
Particular attention should be directed because dangerous voltage may be present.
 Keep this manual at handy for quick reference.
CAUTION
 Do not touch the CMOS components unless the board is grounded.
ESD can cause break down of CMOS components.
 Do not change the communication cable with the inverter power is turned on.
Otherwise, there is a danger of connecting error and damage to the board.
 Make sure to precisely insert the connector of inverter and option board
Otherwise, there is a danger of connecting error and damage to the board.
 Check the parameter unit when setting the parameters.
Otherwise, there is a danger of connecting error and damage to the board.
Indicates a potentially hazardous situation which, if not avoided,
can result in serious injury or death.
Indicates a potentially hazardous situation which, if not avoided,
can result in minor to moderate injury, or serious damage to the
product.

1 modbus-rtu iS5 manual.doc
1. INTRODUCTION
By using a MODBUS-RTU Option board, SV-iS5 inverter can be connected to a MODBUS-RTU network.
1.1. When you use the MODBUS-RTU Option Card …
Inverter can be controlled and monitored by the sequence program of the PLC or other master module. The
card provides a terminal block for an RS-485 interface. Up to 32 drives or other Modbus slave devices may
be connected in a multi-drop fashion on the RS-485 Modbus network and may be monitored or controlled by
a single PLC or PC.
1.1.1 Interfacing type of RTU Reference:
- Allows the drive to communicate with any other computers.
- Allows connection of up to 31 drives with multi-drop link system.
- Ensure noise-resistant interface.
Users can use any kind of RS232-485 converters. However a converter that has built-in ‘automatic RTS
control’ is highly recommended. The specifications of converters depend on the manufacturers. Refer to the
converter manual for detailed converter specifications.
1.1.2 Before Installation
Before installation and operation, this manual should be read thoroughly. If not, it can cause personal injury
or damage other equipment.
2. SPECIFICATION
2.1. Performance specification
Items Specifications
Communication method RS485
Transmission form Bus method Multi-drop Link System
Applicable inverter IS5 series drive
Number of drives Maximum 31 drives connectable
Transmission distance Max. 1200m (Less than 700 m recommended)
Converter RS232-485, Use PC with RS232 card embedded
2.2. Hardware Specifications
Items Specifications
Installation CN2 connector on the inverter control board
Control B/D From inverter power supplyPower
Supply Comm. B/D From control board (insulated)

modbus-rtu iS5 manual.doc
2
2.3. Communication Specification
Items Specifications
Communication speed 1200 /2400/4800/9600/19200 bps Selectable
Control procedure Asynchronous communication system
Communication system Half duplex system
Character system Binary (8 bit)
Start/Stop bit 1 bit
Error check (CRC16) 2 byte
Parity check None
3. PRODUCT DETAIL
3.1. Layout and detail
Name Description
Connector CN2, Connector to inverter main PCB
P 485 signal - high
N 485 signal – low
G 485 Ground
S Shield
T1
Signal
connection
terminal
Communication
signal connection
terminal
T2
Short T1 and T2 to connect a
termination resistor
Figure 1. Layout

modbus-rtu iS5 manual.doc
3
3.2. Status LED
CPU LED Indicates normal operation of the board when blinking once per second.
RXD LED Receiving 485 signal
TXD LED Responding to 485 signal
On and Off intermittently Wrong DATA received (Normal operating)
Blinking with CPU LED at the same
time
DPRAM communication fault
ERR LED
Blinking with CPU LED in an
opposite way
Network Connection TimeOut <I/O-49>
elapsed
4. INSTALLATION
1. Connect the option board to the inverter control board using each connector on the board (See the
Figure 1).
2. Double check the board is firmly installed to the board and then apply the inverter power.
3. When power ON, CPU LED is blinking per second after all LEDs blink one after another.
4. If “CPU LED” is not blinking, turn off the inverter power swiftly (if not, inverter and the board may get
damaged.) and check for the proper installation of the board. If the problem persists, contact LG
distributor.
5. Check ModBus-RTU is displayed in <COM-01>.
6. Set the parameters as below when the above steps are all done.
Parameter code Display Setting Value
< COM-01 > Opt B/D MODBUS displayed automatically
< COM-02 > Opt mode Set the Command controlled via
communication
< I/O- 46 > Inv. number 1~31
(Verify the assigned number is not duplicated)
< I/O- 47 > Baud-rate 9600 bps (Factory default)
< I/O- 48 > Lost command (Note1) User setting
< I/O- 49> TimeOut (Note 1) 0.1 sec (Factory default)
Note 1) it is used for Emergency Stop when communication between inverter and master is not done
properly. It is activated when communication is not done even once for the set time. It means remote
controlling of inverter is not done. Set this value for safety
7. Turn off the inverter power for the connection of the Converter when step 6 is finished.
8. if the inverter is to be placed at the end of the network trunk line, install a jumper at JP1 on the
Modbus card to enable the termination resistor.

modbus-rtu iS5 manual.doc
4
5. TROUBLE SHOOTING
If communications cannot be established with the drive, there are four LEDs on the Modbus card to aid in
troubleshooting. The CPU LED should blink once per second to indicate that the modbus card is interfacing
with the inverter main PCB properly. The RXD LED should blink each time a properly formed Modbus
message is received that is addressed to the inverter. The RXD LED will not blink when messages are
received that are addressed to other inverters or devices. The TXD LED should blink each time the inverter
responds to a Modbus message. The ERR LED indicates either an invalid request was received or there is a
problem with the Modbus card itself. The ERR LED should never light.
5.1.1.CPU LED
State Indicates Corrective measures
Blinking Card is installed properly and working
normally
Card is not installed properly Verify that the card is installed
properly
Off
Inverter is not operating normally Verify that the inverter has power
5.1.2.RXD and TXD LEDs
State Indicates Corrective measures
Blinking Card is functioning normally and receiving and
sending messages
Incorrect Modbus connection to the card Verify that the Low signal is
connected to terminal N and the
High signal is connected to terminal
P
Master is not polling Verify that the master (PLC or PC) is
polling the inverter.
Incorrect baud rate setting Verify that the baud rate (I/O47) is
set to match the baud rate of the
inverter.
Off
Incorrect byte format The inverter communicates using 8
data bits, 1 stop bit and no parity
bits. Verify that the master is set to
the same.

modbus-rtu iS5 manual.doc
5
5.1.3.ERR LED
State Indicates Corrective measures
On/off from time
to time
The card is receiving invalid data such
as noise.
Normal
Blinking with CPU
LED at the same
time
Trouble with the Modbus card Cycle the Inverter power. If the
problem persists, contact LG
Blinking after CPU
LED one after
another
Network communication is not done
during TimeOut (I/O 49) setting.
Verify that the master is specifying
valid register addresses and valid
data.
Off The card is functioning normally and
receiving and sending messages
*See COM group for Frequency/Run command setting.

modbus-rtu iS5 manual.doc
6
2 PARAMETER CODE (HEX)
<Common> Area accessible regardless of inverter models (Note 3)
Parameter
Address Parameter Name Unit Read/Write Data Value (Hex)
0x0000 Drive model - R 4: SV-iS5
0x0001 Drive capacity - R
0: 0.75 1:1.5 2:2.2 3: 3.7
4: 5.5 5: 7.5 6: 11 7: 15
8: 18.5 9: 22 A: 30 B:37
C:45 D: 55 E: 75 F: 90
10: 110 11: 132 12: 160
13: 200 14:220 15:280
16:375 (Unit : kW)
0x0002 Drive Input Voltage - R 0: 220V 1: 440V
0x0003 S/W Version - R
0100: Ver. 1.00,
0101: Ver 1.01
0x0005 Frequency Reference 0.01Hz R/W
0x0006 Run Command - R/W
Bit 0: Stop
Bit 1: Forward Run
Bit 2: Reverse Run
Bit 3: Fault Reset
Bit 4: Emergency Stop
0x0007 Acceleration Time 0.1 sec R/W
0x0008 Deceleration Time 0.1 sec R/W
0x0009 Output Current 0.1 A R
0x000A Output Frequency 0.01 Hz R
0x000B Output Voltage 0.1 V R
0x000C DC Link Voltage 0.1 V R
0x000D Output Power 0.1 kW R
0x000E Sequence Monitor - R
BIT 0 : Stop
BIT 1 : Forward Run
BIT 2 : Reverse Run
BIT 3 : Fault (Trip)
BIT 4 : Accelerating
BIT 5 : Decelerating
BIT 6 : Output Frequency
Arrival

modbus-rtu iS5 manual.doc
7
Parameter
Address Parameter Name Unit Read/Write Data Value (Hex)
BIT 7 : DC Braking
BIT 8 : Stopping
BIT 9 :NotAvailable
BIT 10 : BrakeOpen
BIT11: Forward Run
Command
BIT 12 : Reverse Run
Command
0x000F Trip information - R
Bit 0:OCT1, Bit 1: OV, Bit 2:
EXT-A Bit 3: BX, Bit 4:OCT2,
Bit 5: GF, Bit 6: OH, Bit 7:
ETH, Bit 8: OLT, Bit 9: HW-
diag, Bit10:EXT-B, Bit11:FO
Bit12:OPT, Bit13:PO
Bit,14:IOLT, Bit15:LV
0x0010 Input Terminal Status - R
Bit 0: P1, Bit 1: P2, Bit 2: P3
Bit 3: P4, Bit 4: P5, Bit 5: P6,
Bit 6: RST, Bit 7: BX, Bit 8:
JOG, Bit 9: FX, Bit 10: RX
0x0011 Output Terminal
Status - R
Bit 0: Q1 (OC1), Bit 1: Q2
(OC2) Bit 2: Q3 (OC3), Bit 3:
AUX Bit 4: 30AC
0x0012 V1 - R 0 – FFC0
0x0013 V2 - R 0 – FFC0
0x0014 I - R 0 – FFC0
0x0015 RPM - R
(Note 3) The changed value in Common affects the current setting but returns to the previous setting when
power is cycled or Inverter is reset. However, changing value is immediately reflected in other parameter groups
even in the case of Reset or Power On/Off.
< DRV Group >
Address NO. Description Default Maximum Minimum Unit
5100 DRV#00 Cmd. freq 0 MaxFreq 0 0.01Hz
5101 DRV#01 Acc. Time 100 6000 0 0.1sec
5102 DRV#02 Dec. Time 200 6000 0 0.1sec
5103 DRV#03 Drive mode 1 2 0
5104 DRV#04 Freq. mode 0 4 0

modbus-rtu iS5 manual.doc
8
Address NO. Description Default Maximum Minimum Unit
5105 DRV#05 Step freq - 1 1000 MaxFreq startFreq 0.01Hz
5106 DRV#06 Step freq - 2 2000 MaxFreq startFreq 0.01Hz
5107 DRV#07 Step freq - 3 3000 MaxFreq startFreq 0.01Hz
5108 DRV#08 Current - - - 0.1A
5109 DRV#09 Speed - - - 1rpm
510A DRV#10 DC Link Voltage - - V
< FU1 Group >
Address NO. Description Default Maximum Minimum Unit
5203 FU1 #03 Run prohibit 0 2 0
5205 FU1 #05 Acc. pattern 0 4 0
5206 FU1 #06 Dec. pattern 0 4 0
5207 FU1 #07 Stop mode 0 2 0
5208 FU1 #08 DcBr freq. 500 6000 startFreq 0.01Hz
5209 FU1 #09 DcBlk time 10 6000 0 0.01sec
520A FU1 #10 DcBr value 50 200 0 %
520B FU1 #11 DcBr time 10 600 0 0.1sec
520C FU1 #12 DcSt value 50 200 0 %
520D FU1 #13 DcSt time 0 600 0 0.1sec
5214 FU1 #20 Max freq. 6000 40000 4000 0.01Hz
5215 FU1 #21 Base freq. 6000 maxFreq 3000 0.01Hz
5216 FU1 #22 Start freq. 50 6000 1 0.01Hz
5217 FU1 #23 Freq limit 0 1 0
5218 FU1 #24 F-limit Lo. 50 highFreq startFreq 0.01Hz
5219 FU1 #25 F-limit Hi. 6000 maxFreq lowFreq 0.01Hz
521A FU1 #26 Torque boost 0 1 0
521B FU1 #27 Fwd boost 20 150 0 0.1%
521C FU1 #28 Rev boost 20 150 0 0.1%
521D FU1 #29 V/F pattern 0 2 0
521E FU1 #30 User freq. 1 1500 maxFreq 0 0.01Hz
521F FU1 #31 User volt. 1 25 100 0 %
5220 FU1 #32 User freq. 2 3000 maxFreq 0 0.01Hz
5221 FU1 #33 User volt. 2 50 100 0 %
5222 FU1 #34 User freq. 3 4500 maxFreq 0 0.01Hz
5223 FU1 #35 User volt. 3 75 100 0 %
5224 FU1 #36 User freq. 4 6000 maxFreq 0 0.01Hz
5225 FU1 #37 User volt. 4 100 100 0 %
5226 FU1 #38 Volt control 1000 1100 400 0.1%

modbus-rtu iS5 manual.doc
9
Address NO. Description Default Maximum Minimum Unit
5227 FU1 #39 Energy save 0 30 0 %
5232 FU1 #50 ETH select 0 1 0
5233 FU1 #51 ETH 1min 180 200 ETH Cont %
5234 FU1 #52 ETH Cont 100 150 50 %
5235 FU1 #53 Motor type 0 1 0
5236 FU1 #54 OL level 150 150 30 %
5237 FU1 #55 OL time 100 300 0 0.1sec
5238 FU1 #56 OLT select 1 1 0
5239 FU1 #57 OLT level 180 200 30 %
523A FU1 #58 OLT time 600 600 0 0.1sec
523B FU1 #59 Stall prev. 0 7 0
523C FU1 #60 Stall level 180 250 30 %
< FU2 Group >
Address NO. Description Default Maximum Minimum Unit
5307 FU2 #07 Dwell freq 500 maxFreq StartFreq 0.01Hz
5308 FU1 #08 Dwell time 0 100 0 0.1sec
530A FU2 #10 Jump freq 0 1 0
530B FU2 #11 jump lo 1 1000 jump Hi 1 StartFreq 0.01Hz
530C FU2#12 jump Hi 1 1500 maxFreq jump Lo 1 0.01Hz
530D FU2 #13 jump lo 2 2000 jump Hi 2 StartFreq 0.01Hz
530E FU2 #14 jump Hi 2 2500 maxFreq jump Lo 2 0.01Hz
530F FU2 #15 jump lo 3 3000 jump Hi 3 startFreq 0.01Hz
5310 FU2 #16 jump Hi 3 3500 maxFreq jump Lo 3 0.01Hz
5311 FU2 #17 Start Curve 40 100 1 %
5312 FU2 #18 End Curve 40 100 1 %
5313 FU2 #19 Trip select 0 3 0 BIT
5314 FU2 #20 Power-on run 0 1 0
5315 FU2 #21 RST restart 0 1 0
5316 FU2 #22 Speed Search 0 15 0 BIT
5317 FU2 #23 SS Sup-Curr 100 200 80
5318 FU2 #24 SS P-gain 100 9999 0
5319 FU2 #25 SS I-gain 1000 9999 0
531A FU2 #26 Retry number 0 10 0
531B FU2 #27 Retry delay 10 600 0 0.1sec
531E FU2#30 Motor select 0 9 0
531F FU2#31 Pole number 4 12 2
5320 FU2 #32 Rated-Slip (Note4) 1000 0 0.01Hz

modbus-rtu iS5 manual.doc
10
Address NO. Description Default Maximum Minimum Unit
5321 FU2 #33 Rated-Curr (Note4) 2000 10 0.1A
5322 FU2 #34 Noload-Curr (Note4) 2000 5 0.1A
5324 FU2 #36 Efficiency (Note4) 100 70 %
5325 FU2 #37 Inertia rate 0 1 0
5327 FU2 #39 Carrier freq 50 150 10 0.1kHZ
5328 FU2 #40 Control mode 0 2 0
5329 FU2 #41 Auto tuning 0 1 0
532A FU2 #42 Rs (Note5) (Note4) 5000 0 0.001ohm
532B FU2 #43 Rr (Note6) (Note4) 5000 0 0.001ohm
532C FU2 #44 Lsigma (Note7) (Note4) MaxInduc 0 0.001mH
532D FU2 #45 SL P-gain 32767 32767 0
532E FU2 #46 SL I-gain 3276 32767 0
532F FU2 #47 proc PI mode 0 1 0
5330 FU2 #48 PID Ref 1 1 0
5331 FU2 #49 PID Ref Mode 0 5 0
5332 FU2 #50 PID Out Dir 1 1 0
5333 FU2 #51 PID F/B 0 2 0
5334 FU2 #52 PID P-gain 3000 9999 0 0.1%
5335 FU2 #53 PID I-time 300 320 0 0.1sec
5336 FU2 #54 PID D-time 0 9999 0 0.1msec
5337 FU2 #55 PID +limit 6000 maxFreq 0 0.01Hz
5338 FU2 #56 PID -limit 6000 maxFreq 0 0.01Hz
5339 FU2 #57 PID Out Inv 0 1 0
533A FU2 #58 PID OutScale 1000 9999 1 0.1%
533B FU2 #59 PID P2-gian 1000 9999 0 0.1%
533C FU2 #60 P-gain Scale 1000 1000 0 0.1%
5345 FU2 #69 Acc/Dec ch F 0 maxFreq 0 0.01Hz
5346 FU2 #70 Acc/Dec freq 0 1 0
5347 FU2 #71 Time scale 1 2 0
5348 FU2 #72 PowerOn disp 0 12 0
5349 FU2 #73 User disp 0 2 0
534A FU2 #74 RPM factor 100 1000 1 %
534B FU2 #75 DB mode 1 2 0
534C FU2 #76 DB %ED 10 30 0 %
5351 FU2 #81 2nd Acc time 50 6000 0 0.1sec
5352 FU2 #82 2nd Dec time 100 6000 0 0.1sec
5353 FU2 #83 2nd BaseFreq 6000 maxFreq 3000 0.01Hz
5354 FU2 #84 2nd V/F 0 2 0

modbus-rtu iS5 manual.doc
11
Address NO. Description Default Maximum Minimum Unit
5355 FU2 #85 2nd F-boost 20 150 0 0.1%
5356 FU2 #86 2nd R-boost 20 150 0 0.1%
5357 FU2 #87 2nd Stall 150 150 30 %
5358 FU2 #88 2nd ETH 1min 150 200 2nd ETH
Cont %
5359 FU2 #89 2nd ETH Cont. 100 2nd ETH
1min 50 %
535A FU2 #90 2nd R-Curr 36 2000 10 0.1A
535D FU2 #93 Para. Init 0 8 0
(Note 4, 5, 6, 7) Value depends on motor capacity.
< I/O Group >
Address NO. Description Default Maximum Minimum Unit
5401 I/O #01 V1 filter 10 9999 0 ms
5402 I/O #02 V1 volt x1 0 V1 vort x2 0 0.01V
5403 I/O #03 V1 freq y1 0 maxFreq 0 0.01Hz
5404 I/O #04 V1 volt x2 1000 1000 V1 volt x1 0.01V
5405 I/O #05 V1 freq y2 6000 maxFreq 0 0.01Hz
5406 I/O #06 I filter 10 9999 0 ms
5407 I/O #07 I curr x1 400 I curr x2 0 0.01mA
5408 I/O #08 I freq y1 0 maxFreq 0 0.01Hz
5409 I/O #09 I curr x2 2000 2000 I curr x1 0.01mA
540A I/O #10 I freq y2 6000 maxFreq 0 0.01Hz
540B I/O #11 Wire broken 0 2 0
540C I/O #12 P1 define 0 32 0
540D I/O #13 P2 define 1 32 0
540E I/O #14 P3 define 2 32 0
5411 I/O #17 Ti Filt Num 15 50 2
5414 I/O #20 Jog freq 1000 MaxFreq startFreq 0.01Hz
5415 I/O #21 Step freq - 4 4000 MaxFreq startFreq 0.01Hz
5416 I/O #22 Step freq - 5 5000 MaxFreq startFreq 0.01Hz
5417 I/O #23 Step freq - 6 4000 MaxFreq startFreq 0.01Hz
5418 I/O #24 Step freq - 7 3000 MaxFreq startFreq 0.01Hz
5419 I/O #25 Acc time– 1 200 6000 0 0.1sec
541A I/O #26 Dec time – 1 200 6000 0 0.1sec
541B I/O #27 Acc time – 2 300 6000 0 0.1sec
541C I/O #28 Dec time – 2 300 6000 0 0.1sec
541D I/O #29 Acc time – 3 400 6000 0 0.1sec

modbus-rtu iS5 manual.doc
12
Address NO. Description Default Maximum Minimum Unit
541E I/O #30 Dec time - 3 400 6000 0 0.1sec
541F I/O #31 Acc time – 4 500 6000 0 0.1sec
5420 I/O #32 Dec time – 4 500 6000 0 0.1sec
5421 I/O #33 Acc time – 5 400 6000 0 0.1sec
5422 I/O #34 Dec time – 5 400 6000 0 0.1sec
5423 I/O #35 Acc time – 6 300 6000 0 0.1sec
5424 I/O #36 Dec time – 6 300 6000 0 0.1sec
5425 I/O #37 Acc time – 7 200 6000 0 0.1sec
5426 I/O #38 Dec time – 7 200 6000 0 0.1sec
5428 I/O #40 FM mode 0 3 0
5429 I/O #41 FM adjust 100 200 10 %
542A I/O #42 FDT freq 3000 maxFreq 0 0.01Hz
542B I/O #43 FDT band 1000 maxFreq 0 0.01Hz
542C I/O #44 Aux mode 12 23 0
542D I/O #45 Relay mode 2 7 0 BIT3
542E I/O #46 Inv No. 1 31 1
542F I/O #47 Baud rate 3 4 0
5430 I/O #48 Lost command 0 2 0
5431 I/O #49 Time out 10 1200 1 0.1sec
<Note>
If you need to know specific parameter addresses for Auto Sequence Operation, please contact LG local
distributors.

modbus-rtu iS5 manual.doc
13
< EXT Group >
Address NO. Description Default Maximum Minimum Unit
5501 EXT #01 Sub B/D
5502 EXT #02 P4 define 3 32 0
5503 EXT #03 P5 define 4 32 0
5504 EXT #04 P6 define 5 32 0
5505 EXT #05 V2 mode 0 2 0
5506 EXT #06 V2 filter 10 9999 0 msec
5507 EXT #07 V2 volt x1 0 V2 volt x2 0 0.01V
5508 EXT #08 V2 freq y1 0 maxFreq 0 0.01Hz
5509 EXT #09 V2 volt x2 1000 1000 V2 volt x1 0.01V
550A EXT #10 V2 freq y2 6000 maxFreq 0 0.01Hz
550E EXT #14 F mode 0 2 0
550F EXT #15 F pulse set 0 1 0
5510 EXT #16 F pulse num 1024 4096 360
5511 EXT #17 F filter 10 9999 0 msec
5512 EXT #18 F pulse x1 0 F pulse
x2 0 0.1kHz
5513 EXT #19 F freq y1 0 maxFreq 0 0.01Hz
5514 EXT #20 F pulse x2 100 1000 F pulse x1 0.1kHz
5515 EXT #21 F freq y2 6000 maxFreq 0 0.01Hz
5516 EXT #22 PG P-gain 3000 9999 0
5517 EXT #23 PG I-gain 300 9999 0
5518 EXT #24 PG Slip Freq 100 200 0 %
551E EXT #30 Q1 define 0 23 0
551F EXT #31 Q2 define 1 23 0
5520 EXT #32 Q3 define 2 23 0
5522 EXT #34 LM mode 1 3 0
5523 EXT #35 LM adjust 100 200 10 %
5528 EXT #40 AM1 mode 0 3 0
5529 EXT #41 AM1 adjust 100 200 10 %
552A EXT #42 AM2 mode 3 3 0
552B EXT #43 AM2 adjust 100 200 10 %

modbus-rtu iS5 manual.doc
14
< COM Group >
Address NO. Description Default Maximum Minimum Unit
5601 COM #01 Opt B/D
5602 COM #02 Opt mode 0 3 0
5603 COM #03 Opt version 1.00
Note) Inverter Station # and Baud rate Setting: I/O-46, 47
 COM-01 [Opt B/D]
Indicates Option boards installed. This value is automatically set when the boards are installed.
 COM-02 [Opt Mode]
Determines whether Run/Stop/Reference Frequency is set via Communication.
Value Display Description
0 None Disabled
1 Command Run/Stop setting via Communication1
2 Freq Frequency setting via Communication2
3 Cmd + Freq Run/Stop/Reference Frequency via Communication
 COM-03 [Opt Version]
Displays version of Option Board.
< APP Group >
Address NO. Description Default Maximum Minimum Unit
5701 APP #01 APP mode 0 3 0
5702 APP #02 Trv. Amp [%] 0 200 0 0.1%
5703 APP #03 Trv. Scr 0 500 0 0.1%
5704 APP #04 Trv Acc Time 20 6000 1 0.1sec
5705 APP #05 Trv Dec Time 30 6000 1 0.1sec
5706 APP #06 Trv Off Hi 0 200 0 0.1%
5707 APP #07 Trv Off Lo 0 200 0 0.1%
5708 APP #08 Aux Mot Run 0 4 0
5709 APP #09 Starting Aux 1 4 1
570A APP #10 Auto Op Time 0 5940 0
570B APP #11 Start freq1 4999 maxFreq 0 0.01Hz
570C APP #12 Start freq2 4999 maxFreq 0 0.01Hz
570D APP #13 Start freq3 4999 maxFreq 0 0.01Hz
570E APP #14 Start freq4 4999 maxFreq 0 0.01Hz
570F APP #15 Stop freq1 1500 maxFreq 0 0.01Hz
1Run/Stop SettingAddress - Use 0x0006 in Common
2Freq Setting Address - Use 0x0005 in Common

LG
LG Industrial Systems Co., Ltd.
LGIS constantly endeavors to improve its product so that
information in this manual is subject to change without notice.
Visit Our Website: http://www.lgis.com/
August 8, 2002
Publication #: 10310000393
