LG GA-419 User manual

ХОЛОДИЛЬНИК С
МОРОЗИЛЬНЫМ
ОТДЕЛЕНИЕМ
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ
ПЕРЕД ВКЛЮЧЕНИЕМ ХОЛОДИЛЬНИКА
ВНИМАТЕЛЬНО ПРОЧИТАЙТЕ ДАННУЮ
ИНСТРУКЦИЮ И ВСЕГДА ДЕРЖИТЕ ЕЕ ПОД РУКОЙ.
REFRIGERATOR-
FREEZER
OWNER'S MANUAL
PLEASE
READ THIS OWNER'S MANUAL THOROUGHLY
BEFORE OPERATING AND KEEP IT HANDY FOR
REFERENCE AT ALL TIMES.
Downloaded from Fridge-Manual.com Manuals

25
Introduction
Installation
Operation
Suggestion On
Food storage
Care and
Maintenance
Trouble Shooting
Table of Contents
Registration
Important Safety Instruction
Identification of Parts
Installation
Starting
Temperature Control
Display Panel For Temperature Control
Opti Fresh Zone
Super Freezer
Vacation
Self Test
Lock
Door Alarm
Ice Making
Defrosting
Half Shelf
Wine Rack
Storing Food
General Information
Lamp Replacement
To Reverse the Doors
Cleaning
Trouble Shooting
26
26
31
32
32
33
33
35
36
36
37
37
38
38
38
39
39
40
42
43
43
44
45
Downloaded from Fridge-Manual.com Manuals

Introduction
Introduction
Registration
The model and serial number are found on the rear of
this unit. This number is unique to this unit and not
available to others. You should record requested
information here and retain this guide as a permanent
record of your purchase. Staple your receipt here.
Date of Purchase :
Dealer Purchased From :
Dealer Address :
Dealer Phone No. :
Model No. :
Serial No. :
Important Safety Instruction
To avoid any risk of personal injury, material
damage or incorrect use of the appliance, be sure to
observe the following safety precautions. (After
reading these owner’s instructions, please keep
them in a safe place for reference). Remember to
hand them over to any subsequent owner.
Indicates that
a danger of
death or
serious injury
exists
Warning
ww
26
Indicates that
a risk of
personal
injury or
material
damage exists
Caution
ww
The working life of this set is 7 years since the date of
delivery to consumer.
Downloaded from Fridge-Manual.com Manuals

27
Introduction
Important Safety Instruction
wwWarning
Precaution •This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
•Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
•When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
•After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
•Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
•Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
•Do not insert the power plug with wet hands.
You may receive an electric shock.
•Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
•Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
Important Safety Instruction
wwWarning wwKeep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
wwDo not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
wwDo not damage the refrigerant circuit.
wwDo not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
wwThe refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Identification of Parts
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
Downloaded from Fridge-Manual.com Manuals
33
Operation
Temperature Control
Display Panel For
Temperature Control
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
• Press the ON/OFF button over 3 seconds to switch the
appliance.

Introduction
28
Important Safety Instruction
•Do not disassemble, repair or alter the appliance.
It may cause fire or abnormal operations, which may
lead to injury.
•Pull the power plug out of the socket before
replacing the interior light in the refrigerator.
Otherwise, there is a risk of electric shock.
•If possible, connect the fridge-freezer to its own
individual electrical outlet to prevent it and other
appliances or household lights from causing an
overload.
The supply plug of the refrigerator-freezer should be
placed in easy accessible position for quick disconnection
in emergency.
Accessibility of
Supply Plug
It will cause electric shock or fire.
Do not modify or
extend the Power
Cord length
If the supply cord is damaged, it must be replaced by the
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
Don't store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance.
In the event of an electric short circuit, grounding
(earthing) reduces the risk of electric shock by providing
an escape wire for the electric current. In order to
prevent possible electric shock, this appliance must be
grounded. Improper use of the grounding plug can result
in an electric shock. Consult a qualified electrician or
service person if the grounding instructions are not
completely understood, or if you have doubts on
whether the appliance is properly grounded.
Risk of child entrapment.
Before you throw away your old refrigerator or freezer:
Take off the doors.
Leave the shelves in place so that children may not
easily climb inside.
Supply Cord
Replacement
Danger
Don't store
Grounding
(Earthing)
Downloaded from Fridge-Manual.com Manuals

27
Introduction
Important Safety Instruction
wwWarning
Precaution This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
You may receive an electric shock.
Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
Important Safety Instruction
wwWarning wwKeep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
wwDo not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
wwDo not damage the refrigerant circuit.
wwDo not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
wwThe refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Identification of Parts
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
Downloaded from Fridge-Manual.com Manuals
33
Operation
Temperature Control
Display Panel For
Temperature Control
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
• Press the ON/OFF button over 3 seconds to switch the
appliance.

Introduction
Important Safety Instruction
wwCaution •If the wall socket is loose, do not insert the power
plug.
It may cause electric shock or fire.
•Never unplug your refrigerator by pulling on the
power cord. Always grip plug firmly and pull it
straight out from the outlet. You may disconnect a
wire and cause a short circuit.
•Do not use a wet or damp cloth when cleaning the
plug. Remove any foreign matter from the power
plug pins.
Otherwise, there is a risk of fire.
•Do not put your hands into the bottom area of
the appliance.
Any Sharp edges may cause personal injury..
•After unplugging the appliance, wait for at least
five minutes before plugging it again to the wall
socket.
Abnormal operation of the freezer may cause material
damage.
•If the appliance is not to be used for a long time,
pull out the power plug.
Any deterioration in the insulation may cause fire.
•Do not let children touch or play with the control
panel on the front of the appliance.
•The refrigerant used in fridge/freezer and the
gases in the insulation material require special
disposal procedures. Ensure that none of the pipes
on the back of the appliances are damaged prior
to disposal.
30
Downloaded from Fridge-Manual.com Manuals

27
Introduction
Important Safety Instruction
Warning
Precaution This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
You may receive an electric shock.
Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
Important Safety Instruction
Warning Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Identification of Parts
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
 
 
 
 
 

 

 
 
 
 
!"
# $%
!"
&' (
& 
!  )
!"

!"
  
!"
*% 
!"
*% + !"
$ 
& $%
 (
$,' 
, %(
-
 
 
 
Downloaded from Fridge-Manual.com Manuals
33
Operation
Temperature Control
Display Panel For
Temperature Control
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
• Press the ON/OFF button over 3 seconds to switch the
appliance.

Installation
Installation
Starting
1. Select a good location.
Place your fridge-freezer where it is easy to use.
2. Avoid placing the unit near heat sources, direct
sunlight or moisture.
3. To ensure proper air circulation around the
fridge -freezer, please maintain sufficient space on
both the sides as well as top and maintain at least
2 inches (5 cm) from the rear wall.
4. To avoid vibration, the unit must be leveled. If
required, adjust the leveling screws to compensate for
the uneven floor.
The front should be slightly higher than the rear to
aid in door closing.
Leveling screws can be turned easily by tipping the
cabinet slightly.
Turn the leveling screws counterclockwise( ) to
raise the unit, clockwise( ) to lower it.
5. Clean your fridge-freezer thoroughly and wipe off all
dust accumulated during shipping.
6. Install accessories such as ice cube box, etc., in their
proper places. They are packed together to prevent
possible damage during shipment.
7. Connect the power supply cord (or plug) to the
outlet. Don't double up with other appliances on the
same outlet.
When your fridge-freezer is installed, allow it 2-3 hours
to stabilize at normal operating temperature prior to
filling it with fresh or frozen foods.
If power plug is disconnected, allow 5 minutes delay
before restarting.
Your fridge-freezer is now ready for use.
32
Downloaded from Fridge-Manual.com Manuals

27
Introduction
Important Safety Instruction
Warning
Precaution This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
You may receive an electric shock.
Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
Important Safety Instruction
Warning Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Identification of Parts
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
Downloaded from Fridge-Manual.com Manuals
33
Operation
Temperature Control
Display Panel For
Temperature Control
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
Temperature Adjustment Button for
Refrigerator Compartment
Temperature Adjustment Button for
Opti Fresh Zone Compartment
ON/OFF Power Button
Temperature Adjustment Button
for Freezer Compartment
Super Freezer Button
Vacation Button
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
MinMin MaxMax
MinMin MaxMax
Temperature Adjustment Button for
Refrigerator Compartment
Lock Button
ON/OFF Power Button
Temperature Adjustment Button
for Freezer Compartment
Super Freezer Button
Vacation Button
ON/OFF Power Button Temperature Adjustment Button for
Refrigerator Compartment
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
• Press the ON/OFF button over 3 seconds to switch the
appliance.
In selecting
"Lock ON"
In selecting
"Lock OFF"

• The initial Temperature of the Freezer and Refrigerator
Compartment is -21°C and 4°C respectively. You can now
adjust the temperature of the compartments as you want.
Operation
34
Note The actual inner temperature varies depending on the
food status, as the indicated setting temperature is a
target temperature, not actual temperature within
refrigerator. Refrigeration function is weak in the
initial time. Please adjust temperature as above after
using refrigerator for minimum 2~3 days.
< Exterior Type 2 >
Min Max
< Interior Type>
Min Max
< Exterior Type 1 >
• When you press the temperature control button,
the temperature of the Freezer or Refrigerator
part is change by 1 degree.
▶
• When you press the temperature control
buttons, the temperature of Refrigerator and
Freezer compartment is repeated in the following
order. Refrigeration
Compartment :
3 →4 →5 →1 →2
Freezer Compartment :
3 →4 →5 →1 →2
• Lower number means higher temperature setting
in each compartment
• The initial temperature of freezer and refrigerator
compartment is 3 and 3 respectively.
▶
• When you press the temperature control
buttons, the temperature of Refrigerator
and Freezer compartment is repeated in
the following order.
Refrigeration Compartment :
3 →4 →5 →1 →2
▶
How to adjust the
temperature in the
refrigerator and
freezer compartment
Downloaded from Fridge-Manual.com Manuals

27
Introduction
Warning
Precaution This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
You may receive an electric shock.
Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
Warning Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
Downloaded from Fridge-Manual.com Manuals
33
Operation
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
Method to use
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
Exterior Type 2
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
Switching on and off the appliance
Switch off
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
Switch on
• Press the ON/OFF button over 3 seconds to switch the
appliance.

Operation
Super Feezer
Vacation
• Please select this function for prompt freezer.
• This function is used when you want to freeze the
foods quickly. Press the SUPER FRZ (Super Freezer)
button once, and then the quick freeze operation starts
with the lamp it.
• The Super Freeze operation takes about 3 hours.
When its operation ends, it automatically returns to the
previous temperature setting. If you want to stop the
quick freeze operation, press the SUPER FRZ button
once more, the lamp goes out, and the Super Freeze
operation stops and the refrigerator returns to the
previous temperature setting.
• The arrow mark graphic remains at the On status after
flickering for 4times when selecting Super Freezer is
turned “On”.
36
In selecting
"Super Feezer ON"
In selecting
"Super Feezer OFF"
In selecting
"Vacation ON"
In selecting
"Vacation OFF"
Note When the Vacation mode is “ON”, the other buttons
will not operate. When you come back from
vacations, press the vacation mode off so that other
buttons work and the refrigerator returns to previous
temperature setting.
• This function makes the fridge-freezer work in a power
saving mode which is useful for when you are away on
holiday, by reducing energy consumption as much as
possible.
Pressing ‘VACATION’ starts operation with lamp ON
and pressing it again stops the operation.
Downloaded from Fridge-Manual.com Manuals

27
Introduction
Warning
Precaution This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
You may receive an electric shock.
Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
Warning Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
Downloaded from Fridge-Manual.com Manuals
33
Operation
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
Temperature Adjustment Button for
Refrigerator Compartment
Temperature Adjustment Button for
Opti Fresh Zone Compartment
ON/OFF Power Button
Temperature Adjustment Button
for Freezer Compartment
Super Freezer Button
Vacation Button
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
MinMin MaxMax
MinMin MaxMax
Temperature Adjustment Button for
Refrigerator Compartment
Lock Button
ON/OFF Power Button
Temperature Adjustment Button
for Freezer Compartment
Super Freezer Button
Vacation Button
ON/OFF Power Button Temperature Adjustment Button for
Refrigerator Compartment
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
Method to use
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
Exterior Type 2
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
Switching on and off the appliance
Switch off
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
Switch on
• Press the ON/OFF button over 3 seconds to switch the
appliance.
In selecting
"Lock ON"
In selecting
"Lock OFF"

Operation
Door Alarm •
When the door of the fridge is left opened for a while, the
alarm sounds. Please contact with the local service center if
warning continue to sound even after closing the door.
Ice Making
• Fill water in ice making box of the ice making corner. If
water is fully filled the ice will not be separated well and
water can be dropped to make ice lumped.
• Ice will be dropped into the ice storage bin by rotating ice
separation handle of ice making compartment.
38
Note • Rotating the ice separation handle before ice is fully
frozen may cause the remaining water drop into the
ice storage bin to lump the ice together.
Defrosting
• The refrigerator uses an automatic defrosting system.
Frost, forming on the back wall of the compartment
melts, when the Cyclically working compressor is
switched off, and turns to water drops. Melt water runs
down to the drain tray, gets to the container in the
compressor through the tube. It is necessary (at least once
in 3 months) clean the drain hole to ensure unobstructed
drainage of melt water to the container.
• To defrost and clean the freezing compartment,
unplugging the refrigerator or selecting ‘On/Off’ switch
and removing products from the freezing compartment.
Open the door of the freezing compartment for 1 hour,
collect melt water with a sponge and wash the
compartment and rub it dry.
It is prohibited to scrape the surface of an freezing
evaporator with metal and sharp objects for snow layer
removal.
wwCaution
Tip • To remove ice
cubes easily, run
water on the tray
before twisting.
Downloaded from Fridge-Manual.com Manuals

27
Introduction
Warning
Precaution This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
You may receive an electric shock.
Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
Warning Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
Downloaded from Fridge-Manual.com Manuals
33
Operation
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
• Press the ON/OFF button over 3 seconds to switch the
appliance.

Suggestions on food storage
wwCaution
Storing Food
• Do not store food which goes bad easily at low
temperature, such as banana, and melon.
• Allow hot food to cool prior to storing. Placing hot
food in the fridge-freezer could spoil other food, and
lead to higher electric bills.
• When storing the food, use a container with a lid. This
prevents moisture from evaporating, and helps food to
keep its taste and nutrients.
• Do not block air vents with food. Smooth circulation of
cold air keeps fridge-freezer temperature even.
• Do not open the door frequently. Opening the door
lets warm air enter the fridge-freezer, and cause
temperature to rise.
• Never keep too many foods in door rack, as this may
stop the door from fully closing.
• Do not store bottles in the freezer compartment - they
may break when frozen.
• Do not refreeze food that has been thawed. This
causes loss of taste and nutrition.
• Do not store pharmaceutical products, scientific
materials or other temperature sensitive products in the
refrigerator.
Products that require strict temperature controls must
not be stored in the refrigerator.
40
Downloaded from Fridge-Manual.com Manuals

27
Introduction
Warning
Precaution This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
You may receive an electric shock.
Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
Warning Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
Downloaded from Fridge-Manual.com Manuals
33
Operation
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
• Press the ON/OFF button over 3 seconds to switch the
appliance.

Care and Maintenance
Power Failure
General Information
• 1~2 hour power failure does no harm to the foods
stores. Try to avoid opening and closing the door too
frequently.
If You Move
Anti
Condensation
Pipe
• Take out foods from the fridge-freezer and firmly fix
the loose items with tape.
• Turn the leveling screws until they stop before moving
the fridge-freezer. Otherwise the screw may scratch
the floor or the fridge-freezer cannot move.
• The Anti-Condensation pipe is
installed around the front side
of fridge-freezer as well as on
the partition between fridge
compartment and freezer
compartment to prevent
dewing.
• Especially after installation or
when ambient temperature is
high, the fridge-freezer may feel
hot, which is quite normal.
42
Anti-Condensation
Pipe
Downloaded from Fridge-Manual.com Manuals

27
Introduction
wwWarning
Precaution This fridge-freezer must be properly installed and
located in accordance with the Installation
Instruction before it is used.
Never unplug your fridge-freezer by pulling on
the power cord. Always grip plug firmly and pull
straight out from the outlet.
When moving your appliance away from the wall,
be careful not to roll over or damage the power
cord.
After your fridge-freezer is in operation, do not
touch the cold surfaces in the freezer
compartment, particularly when hands are damp
or wet. Skin may adhere to these extremely cold
surfaces.
Pull out the power plug prior to cleaning the fridge-
freezer. Never damage, serverely bend, pull out, or
twist the power cord because power cord damage may
cause a fire or electronic shock. Never place glass
products in the freezer because they may be broken
when their inner contents are frozen.
Do not directly spray water inside or outside the
fridge/freezer.
There is a risk of explosion or fire.
Do not insert the power plug with wet hands.
You may receive an electric shock.
Do not put a container filled with water on top of
the appliance.
If the water spills on to any electrical parts, it may lead
to fire or electric shock.
Do not install the fridge/freezer in a damp place,
where it could be splashed with water.
Incorrect insulation of the electrical parts may cause an
electric shock or file.
Downloaded from Fridge-Manual.com Manuals
29
Introduction
wwWarning wwKeep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
wwDo not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
wwDo not damage the refrigerant circuit.
wwDo not use electrical appliances inside the food
storage compartments of the appliance, unless they
are of the type recommended by the manufacturer.
wwThe refrigerant and insulation blowing gas used in
the appliance require special disposal procedures.
When disposal, please consult with service agent or a
similarly qualified person.
This appliance contains a small amount of isobutane
refrigerant (R600a), natural gas with high
environmental compatibility, but it is also
combustible. When transporting and installing the
appliance, care should be taken to ensure that no
parts of the refrigerating circuit are damaged.
Refrigerant squirting out of the pipes could ignite
or cause an eye injury. If a leak is detected, avoid
any naked flames or potential sources of ignition
and air the room in which the appliance is standing
for several minutes.
In order to avoid the creation of a flammable gas air
mixture if a leak in the refrigerating circuit occurs, the
size of the room in which the appliance may be sited
depends on the amount of refrigerant used. The room
must be 1m2in size for every 8g of R600a refrigerant
inside the appliance. The amount of refrigerant in your
particular appliance is shown on the identification plate
inside the appliance.
Never start up an appliance showing any signs of
damage. If in doubt, consult your dealer.
Downloaded from Fridge-Manual.com Manuals
31
Introduction
Note If you find some parts missing from your unit, they
may be parts only used in other models. (i.e. the
“Miracle Zone” is not included in all models)
Downloaded from Fridge-Manual.com Manuals
33
Operation
Your fridge-freezer has controls that let you regulate the
temperature in the fridge and freezer compartments.
< Exterior Type 1 >
< Exterior Type 2 >
< Interior Type>
Adjusting the
temperatures and
functions
Downloaded from Fridge-Manual.com Manuals
35
Operation
Opti Fresh Zone
Temperature
Transition Corner
(Optional)
• By pressing the button, store meat (at relatively low
conservation temperature) or other types of food to be
defrosted ,raw fish,etc...
The temperature of the Opti fresh zone’s compartment
is always okay.
• Pressing “OPTI ZONE” button start operation with lamp
ON and pressing it again stops the operation.
< Exterior Type 1 >
< In selecting "Opti Fresh Zone ON" >
< In selecting "Opti Fresh Zone OFF" >
Downloaded from Fridge-Manual.com Manuals
37
Operation
Self Test
Lock
ON / OFF
FUNCTION
• This function automatically detects failure when failure
is found in product during the use of refrigerator.
• If the failure occurs at product and it does not operate
by pressing any button and normal indication is not
done, do not turn the power off and immediately
contact with the local service center.
• A lot of time is needed for service engineer to detect
the failed part by turning it off.
• Pressing this button stops operation of other buttons.
• ”Locking” or “Un-Locking” is repeated whenever
pressing the LOCK button. (For “Locking” or “Un-
Locking” press the “LOCK” button for 3 secs.)
• When ‘LOCK’ is activated, pressing the other buttons
would not work.
• Press the ON/OFF button over 3 seconds to switch for
defrosting, cleaning and no use of long term.
• The outside lamp(display) is turned off.
• The inside lamp is ON, When open the door.
• Press the ON/OFF button over 3 seconds to switch the
appliance.
