LG GR-P247STSL User manual

2
Entry
Basic safety precautions
Identification of parts
Where to install
Door removal
Door replacement
Feed water pipe installation
Height adjustment
Starting
djusting the temperatures and functions
djusting The Temperatures nd Display
Operating The Dispenser
Setting The Functions
Refreshment center
Shelf
Egg box
Nano charcoal deodorizer
Fresh compartment
Vacuum fresh compartment
Freezer/Fridge basket
Dairy corner
How to exchange the water purifier filter
Location of foods
Storing foods
General information
Cleaning
Trouble shooting
It is normal…
Table of contents
Introduction
Installation
Operation
Suggestion on
food storage
Care and
maintenance
3
3
11
12
13
14
14
15
17
18
19
20
24
25
25
25
26
27
28
28
29
30
31
32
32
33
38
17
This product is exclusive use at 240V/50Hz.
You should purchase transformer of more than 2.0KVA when you
want to use it at the 110V area.

Introduction
3
Entry
The model and serial numbers are found on the inner case or back of
refrigerator compartment of this unit. These numbers are unique to this unit
and not available to others. You should record requested information here
and retain this guide as a permanent record of your purchase. Staple your
receipt here.
Basic safety precautions
Date of purchase :
Dealer purchased from :
Dealer address :
Dealer phone no. :
Model no. :
Serial no. :
This guide contains many important safety messages.
lways read and obey all safety messages.
This is the safety alert symbol. It alerts you to safety messages that inform you
of hazards that can kill or hurt you or others or cause damage to the product. All
safety messages will be preceded by the safety alert symbol and the hazard signal
word DANGER, WARNING, or CAUTION. These words mean:
All safety messages will identify the hazard, tell you how to reduce the chance of
injury, and tell you what can happen if the instructions are not followed.
DANGER
You will be killed or seriously injured if you don’t follow
instructions.
WARNING
You can be killed or seriously injured if you don’t follow
instructions.
CAUTION
Indicates an imminently hazardous situation which, if not
avoided, may result in minor or moderate injury, or product
damage only.

4
Introduction
WARNING
To reduce the risk of fire, electric shock, or injury to persons when using your
product, basic safety precautions should be followed, including the following.
Read all instructions before using this appliance.
1. When connecting the power
The dedicated outlet should be used.
• Using several devices at one outlet may cause fire.
• The electric leakage breaker may damage food and the
dispenser may be leaked.
Prevent the power cord from being squeezed or imprinted if the refrigerator is
pushed in after the power plug is extracted during the installation.
When moving your appliance away from the wall, be careful not to roll over the
power cord or to damage it in any way.
It becomes the cause of fire or electric shock.
Do not allow the power cord bent or pressed by the heavy
object to be damaged.
It may damage the power cord to cause fire or electric shock.
Do not allow the power plug to face upward or to be
squeezed at the back of the refrigerator.
Water may be flown into or the plug may be damaged, which
causes fire or electric shock.
Do not extend or modify the length of the power plug.
It causes electric shock or fire by the electric damage of the
power cord or others.
Unplug the power plug when cleaning, handling or
replacing the interior lamp of the refrigerator.
• It may cause electric shock or injury.
• When replacing the interior lamp of the refrigerator, make
sure that the rubber ring for preventing the electric spark
within the socket is not taken off.

5
Introduction
Remove water or dust from the power plug and insert it
with the ends of the pins securely connected.
Dust, water or unstable connection may fire or electric shock.
Unplug the power cord from the power outlet for cleaning or other
requirements.
It may cause electric shock or injury.
Make sure of grounding.
Consult a qualified electrician or service person if the
grounding instructions are not completely understood,
or if you have doubts on whether the appliance is
properly grounded.
The incorrect grounding may cause breakdown and electric
shock.
Be sure to use grounded exclusive proper voltage consent for the power plug.
Be sure to use grounded extension consents when extension consents are used.
It becomes the cause of fire.
Ground
Wire
Copper
Flat
More than
30 inches
When the power cord or the power plug is damaged or
the holes of the outlet are loosed, do not use them.
It may cause electric shock or short circuit to make fire.
Wait for 5 minutes or longer when reconnecting the plug.
It may cause the operation of the freezer to fail.
After
5minutes
Pull out the power plug not by grasping the cord but the
plug of its end.
It may cause electric shock or short circuit to fire.
Do not pull out the cord or touch the power plug with wet
hands.
It may cause electric shock or injury.

6
Introduction
2. When using the refrigerator
Do not place the heavy object or the dangerous object
(container with liquid) on the refrigerator.
It may be dropped to cause injury, fire or electric shock when
opening or closing the door.
Do not install the refrigerator in the wet place or the place
which water or rain splashes.
Deterioration of insulation of electric parts may cause electric
leakage.
Do not cling to the door or the shelves of the door or the
home bar of the freezer or the cool chamber.
It may make the refrigerator fallen down or damage the hands.
Especially, do not allow the children to do the above.
Prevent children from entering the product.
It may endanger the life of a child if the child enters the
refrigerator.
Opening and closing the door of the refrigerator vigorously may cause the
stored food in the refrigerator basket to fall by shock and hurt the foot, so take
precautions.
Do not use or store inflammable materials ether,
benzene, alcohol, medicine, LP gas, spray or
cosmetics near or in the refrigerator.
It may cause explosion or fire.
Benzene
Ether
Thinner
Do not use drier to dry the inside, nor light a candle to
remove odor.
It may cause explosion or fire.
Do not store the medicine or the academic materials at
the refrigerator.
When the material with the strict temperature control is
stored, it may be deteriorated or it may make an
unexpected reaction to cause any risk.
The Academic
Medicine
The Medicine

7
Introduction
Do not put heavy things on the Home Bar.
(Only for the models with the Home Bar)
Falling objects may hurt people.
Use the submerged refrigerator after checking it.
It may cause electric shock or fire.
In case of thunder and lightning, or not in use for a long
period of time, detach the power plug.
There is a danger of electric shock or fire.
When gas is leaked, do not touch the refrigerator or
the outlet and ventilate the room immediately.
• The explosion by spark may cause fire or burn.
• Because this refrigerator uses natural gas (isobutene,
R600a) as the environment-friendly refrigerant, even a
small amount (80~90g) is combustible. When the gas is
leaked by the severe damage during delivering, installing
or using the refrigerator, any spark may cause fire or burn.
Do not place flower vase, cup, cosmetics, medicine or
any container with water on the refrigerator.
It may cause fire, electric shock or injury by dropping down.
Install in places away from the fire such as the place
where flammable gas is leaked.
It may cause fire.
Do not use the combustible spray near the refrigerator.
It may cause fire.

8
Introduction
Do not spray water at the outside or the inside of the
refrigerator or do not clean it with benzene or thinner.
Deterioration of insulation of electric parts may cause electric
shock or fire.
Thinner
When any strange smell or smoke is detected from the
refrigerator, disconnect the power plug immediately
and contact to the service center.
It may cause fire.
Service
center
Do not use the refrigerator for non-domestic purpose
(storing medicine or testing material, using at the ship,
etc.).
It may cause an unexpected risk such as fire, electric shock,
deterioration of stored material or chemical reaction.
When disposing the refrigerator, remove the packing
materials from the door or take off the doors but leave the
shelves in place so that children may not easily climb
inside.
It may cause to lock out the child.
This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the
appliance.
Install the refrigerator on the solid and level floor.
Installing it on the unstable place may cause death by falling
down the refrigerator when opening or closing the door.
Do not insert the hands or the metal stick into the exit
of cool air, the cover, the bottom of the refrigerator,
the heatproof grill (exhaust hole) at the backside.
It may cause electric shock or injury.
Do not allow any person except the qualified engineer
to disassemble, repair or alter the refrigerator.
It may cause injury, electric shock or fire.

9
Introduction
CAUTION
Violating this direction may cause injury or damage house or furniture.
Always be careful, please.
Do not insert the hands into the ice bucket or the ice
dispenser.
Operating the ice maker may cause injury.
This appliance contains a small amount of isobutane refrigerant (R600a),
natural gas with high environmental compatibility, but it is also combustible.
When transporting and installing the appliance, care should be taken to
ensure that no parts of the refrigerating circuit are damaged. Refrigerant
squirting out of the pipes could ignite or cause an eye injury. If a leak is
detected, avoid any naked flames or potential sources of ignition and air the
room in which the appliance is standing for several minutes.
In order to avoid the creation of a flammable gas air mixture if a leak in the
refrigerating circuit occurs, the size of the room in which the appliance may be
sited depends on the amount of refrigerant used. The room must be 1m2in size
for every 8g of R600a refrigerant inside the appliance. The amount of refrigerant in
your particular appliance is shown on the identification plate inside the appliance.
Never start up an appliance showing any signs of damage. If in doubt, consult your
dealer.
Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
Do not damage the refrigerant circuit.
Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
The refrigerant and insulation blowing gas used in the appliance require
special disposal procedures. When disposal, please consult with service
agent or a similarly qualified person.

10
Introduction
Do not touch food or containers at the freezer with wet
hands.
It may cause frostbite.
Do not put ice in thin crystal cup or ceramic ware.
It may break cup or ceramic ware to cause injury.
When the electricity is off, remove ice from the ice bucket
(only for the model with the dispenser).
The long-time power failure may thaw ice to damage the floor.
When the long-time power failure is expected, remove ice
from the ice bucket.
Supply the automatic ice maker with drinkable water
only (only for the model with the dispenser).
Otherwise, it may cause any risk.
Do not remove the cover of the automatic ice maker.
(Only for the models with automatic ice maker)
The operation mechanic parts of the ice maker may hurt people.
Do not place the food in disorder inside the refrigerator.
The food may fall during opening and closing the door of the refrigerator and hurt
people.
Drinkable
water
Do not put bottle in the freezer.
It may freeze the contents to break the bottle to cause injury.
Do not insert the hands into the bottom of the
refrigerator.
The iron plate of the bottom may cause injury.
Carry the refrigerator with the handle bar at the bottom
of the front and the top of the rear.
Otherwise, your hands may be slipped to cause injury.
Because the product is heavy, carrying it alone may hurt
people or accidents may occur.

11
Introduction
Identification of parts
•
Parts, features, and options vary by model. Your model may not include every option.
NOTE
Freezer
Compartment
Refrigerator
Compartment
Milk product corner
LED Lamp
Automatic
Icemaker
Shelf
Shelf
Shelf
Door rack
Drawer
Door rack
Lower cover
Shelf
Can Server
Refreshment center
Nano charcoal deodorizer
Egg Box
LED Lamp
Filter
Door Rack
Door Rack
Door Rack
Fresh compartment
Fresh compartment
Vacuum fresh
compartment
Because opening or closing the door or the home bar
of the refrigerator may cause injury to the person
around it, be careful, please.
Opening or closing the door may cause feet or hands to be
caught in the chink in door or the child to be get hurt by the
corner.
Do not put any living animal in the refrigerator.

12
Installation
1. Place your appliance where it is easy to
use.
2. Avoid placing the unit near heat sources,
direct sunlight or moisture.
3. To ensure proper air circulation around the
fridge -freezer, please maintain sufficient
space on both the sides as well as top and
maintain at least 2 inches (5 cm) from the
rear wall.
4. To avoid vibrations, the appliance must
be leveled.
5. Don't install the appliance below 5°C. It may cause affect the performance.
Select a good
location
Where to Install
Disposal of the
old appliance
This appliance contains fluid (refrigerant, lubricant)and is made of parts and materials
which are reusable and/or recyclable.
All the important materials should be sent to the collection center of waste material
and can be reused after rework (recycling). For take back, please contact with the
local agency.

13
Installation
Door removal
Electric Shock Hazard
Disconnect electrical supply to refrigerator
before installing. Failure to do so could result in
death or serious injury.
If your access door is too narrow for the
refrigerator to pass through, remove the refrigerator door and pass the
refrigerator laterally.
Remove the lower cover by lifting upward and then pull up the feed water tube
while pressing area shown in the figure to the right.
Remove lower
cover and
then feed water
tube
Remove the
freezer
compartment
door
Remove the
refrigerator
door
1) Removing the hinge cover by loosening
the screws. Separate all connection wires
except for the earth line after.
2) Remove the keeper by rotating it counter
clockwise () and then lifting the upper
hinge up ().
3) Remove the freezer compartment door by
lifting it upward. This time, the door should
be lifted enough for the feed water pipe tube
to be completely pulled out.
1) Loosen the hinge cover screws and
remove the cover. Remove connection
wire, if any, except for the earth line.
2) Remove keeper by rotating it clockwise
() and then remove the upper hinge
by lifting it up ().
3) Remove the refrigerator compartment
door by lifting it up.
•
If a tube end is deformed or abraded, cut the part away.
NOTE
•
When removing the upper hinge, be careful that the door does not fall forwards .
NOTE
•
Move the refrigerator compartment door passing through the access door and lay
it down, but be careful not to damage the feed water pipe tube.
NOTE
Lower cover
Lower hinge
Lower hinge
Keeper
Feed water tube
Connection
wires
Hinge
cover
Upper hinge
Keeper Upper hinge
Ground Line
Upper hinge
Connection
wires
WARNING

14
Installation
Door replacement
Feed water pipe installation
Pass the refrigerator laterally through the access
door as shown in the right figure.
Automatic ice maker operation needs water pressure of 147~834 kPa
(1.5~8.5 kgf/cm2) (That is, an instant paper cup (180 cc) will be fully filled
within 3 sec.).
If water pressure does not reach the rating 147 kPa (1.5 kgf/cm2) or below, it is
necessary to purchase a separate pressure pump for normal automatic icing and cool
water feed.
Keep the total length of the feed water pipe tube within 8 m and be careful for the
tube not be bent. If the tube is 8 m or longer it may cause trouble in water feed owing
to the drain water pressure.
Install the feed water pipe tube at a place free from heat.

Connect to potable water supply only.

Refer to instructions with water filter kit for installation.
Mount them in the reverse sequence of removal after they pass through the access
door.
Pass the
refrigerator
Before
installation
1
2
3
4
5
Max
FRZ
TEMP
REF
TEMP
Min 5
43
2
1Max
WARNING

15
Installation
Height adjustment
- When the height of the door may not be
leveled when the floor is not leveled.
When the freezer door is lower – 
Use the (-) driver or spanner to turn the
groove or nut of the height adjustment
screw on the left to the counterclockwise
direction to level the door.
When the fridge door is lower – 
Use the (-) driver or spanner to turn the
groove or nut of the height adjustment
screw on the right to the clockwise
direction to level the door.
The refrigerator doors will close smoothly by heightening the front side by adjusting
the height adjusting screw. If the doors do not close correctly, performance may be
affected.
When the floor is
not leveled
When the fridge door is lower than the freezer door while using the
refrigerator, level the doors.
1. Use the tool for adjustment on
the wide side to turn nut ( )
in the clockwise direction to loosen
the keeper nut.
2. Use the tool for adjustment on
the narrow side to turn the
adjustment hinge pin in
( )clockwise direction or
( ) counterclockwise direction
to adjust the height of the fridge
and freezer doors.
3. After aligning the height of the door, turn the keeper nut in counterclockwise
direction tightly.
When the fridge
door is lower than
the freezer door
After leveling the
door height
Keeper nut
Adjustment
hinge pin
Tool for
adjustment
Up
Down
Height difference
Height difference
When using
the driver
When using
the spanner
Next
1. Wipe off all dust accumulated during shipping and clean your appliance thoroughly.
2. Install accessories such as the ice cube box, cover evaporating tray, etc., in their
proper places. They are packed together to prevent possible damage during shipping.
3. Connect the power supply cord (or plug) to the outlet. Don't double up with other
appliances on the same outlet.
Do not force too hard to level the height. The hinge pin can be pulled out.
(Adjustable range of height is a maximum of 2" (5 cm))
CAUTION

16
Installation
To move the refrigerator through a house door, it may be necessary to remove the
refrigerator door handles.
HANDLE
REMOVAL
Place the handle on the door by aligning handle footprints to fit mounting fasteners
and tighten the set screws with a 2.5 mm (3/32") Allen wrench.
HANDLE
REINSTALLATION
•
Handle appearance may vary from illustrations on this page.
NOTE
Loosen the set screws with a 2.5 mm (3/32")
Allen wrench and remove the handle.
•
If the handle mounting fasteners need to be tightened or removed, use a 1/4"
Allen wrench.
NOTE
•
If the handle mounting fasteners need to be tightened or removed use a 1/4" Allen
wrench
NOTE
Mounting
Fasteners
Set Screw
Allen Wrench
Mounting
Fasteners

Operation
17
Refreshment Center
•Your model may not include every option.
NOTE
Starting
When your refrigerator is first installed, allow it to stabilize at normal operating
temperatures for 2-3 hours prior to filling it with fresh or frozen foods.
If operation is interrupted, wait 5 minutes before restarting.
DISPENSER SELECTION
INDICATOR
Shows Cubed ice or Crushed Ice
selection that will be dispensed
when the push switch is pressed.
FREEZER TEMPERATURE
Indicates the set temperature of the
freezer compartment in Celsius or
Fahrenheit.
REFRIGERATOR TEMPERATURE
Indicates the set temperature of the
refrigerator compartment in Celsius
or Fahrenheit.
EXPRESS FRZ.
When the EXPRESS FRZ. button is
pressed, the display will indicate the
selected function has been
activated.
DISPENSER LIGHT INDICATOR
When the LIGHT button is pressed,
the display will indicate the selected
function: The dispenser light is on,
this indicator will appear on the
display panel.
DOOR ALARM INDICATOR
This indicator shows that the door-
open warning alarm is activated.
WATER FILTER STATUS
This indicator shows the current
status for the water filter. See
Resetting the Filter Indicator.
LOCK STATUS
This indicator shows the current
status for the control panel functions
is set to LOCK.
Adjusting the temperatures and functions

18
Operation
Adjust Freezer
Temperature
Adjust Refrigerator
Temperature
Display Power-
Saving Mode
To adjust the temperature in the freezer compartment, press the FREEZER
button to cycle through the the range of available settings.
To adjust the temperature in the refrigerator compartment, press the
REFRIGERATOR button to cycle through the range of available settings.
This function places the display into the Power-Saving Mode.
• Simultaneously press the FREEZER and EXPRESS FRZ. buttons and hold
them for 5 seconds until a tone sounds.
• All LED lights will turn on and then off.
• When the Power-Saving Mode is activated, the display will remain off until
the next time the door is opened. The display will also turn on when any
button is pressed, and it will remain on for 20 seconds after the last door
opening or button selection.
• To deactivate the Power-Saving Mode, press the FREEZER and EXPRESS
FRZ. buttons simultaneously and hold them for 5 seconds until the tone
sounds.
Adjusting The Temperatures And Display
FREEZER
REFRIGERATOR
FREEZER
EXPRESS FRZ.
•The actual inner temperature varies depending on the food status, since the
indicated temperature setting is the target temperature and not the actual
temperature within the refrigerator.
Initially set the REFRIGERATOR CONTROL at
3 degrees C and the FREEZER CONTROL at
-19 degrees C. Leave them at these setting for 24 hours (one day) to stabilize. Then
adjust the compartment temperature as illustrated above.
NOTE

19
Operation
Dispensing
Crushed Ice
Dispensing Cubed
Ice
Controlling The
Dispenser Light
Press the ICE TYPE button to illuminate the Crushed Ice icon.
Press the push ice switch with a glass or other container and crushed ice will
be dispensed.
Press the ICE TYPE button to illuminate the Cubed Ice icon.
Press the push switch with a glass or other container and cubed ice will be
dispensed.
Press the LIGHT/FILTER button to turn the dispenser light on and off.
• When filling the container with a
small opening, use it near the
opening of the water or ice
dispenser as close as possible.
• Do not dispense ice into fine china
or crystal glasses. China or crystal
can break.
Operating The Dispenser
ICE TYPE
ICE TYPE
•Hold the glass or other container in place for a couple of seconds after dispensing
ice or water to catch the last few cubes or drops. The dispenser is designed to not
operate while either refrigerator door is open.
NOTE
LIGHT/FILTER
Water Switch
Ice Switch
Incorrect
Ice
Correct
CAUTION

20
Operation
Setting The
Dispenser Lock
Setting The Door
Alarm
Resetting The Filter
Indicator
Activating EXPRESS
FREEZING
Press the button for the desired function to view and select other settings.
Press and hold the ALARM/LOCK button for three seconds
to lock the dispenser and all of the other control panel
functions.
Press and hold again for 3 seconds to unlock.
The ALARM/LOCK button also controls the door alarm that
sounds three times in 30-second intervals when a
compartment door is left open for more than 60 seconds.
The alarm stops sounding when the door is closed.
Press the ALARM/LOCK button once to activate and deactivate the door alarm
function.
Press and hold the LIGHT/FILTER button for more than 3
seconds to reset the filter indicator after the water filter has
been replaced.
Press the EXPRESS FRZ. button once to activate the
EXPRESS FREEZING function. The EXPRESS FRZ. icon on
the display panel will illuminate when activated. The
EXPRESS FREEZING function runs the freezer compartment
at the coldest setting for a 24-hour period to increase
icemaking by up to about 20%, and then turns off
automatically.
Setting The Functions
•Contact your local service center if the alarm continues to sound after the doors are
closed.
NOTE
•It is recommended that you replace the filter when the water filter indicator light reaches 0 or
whenever the water or ice cube taste deteriorates noticeably.
NOTE
•
Press the button again to cancel the EXPRESS FREEZING function.
NOTE
ALARM / LOCK 3SECS
ALARM / LOCK 3SECS
LIGHT/FILTER
EXPRESS FRZ.
