LG TRAINING MANUAL
LG TRAINING MANUAL
Fall 2013 Appliance Training
LFX31995ST
French Door Refigerator
w/Smart ThinQ™

LG Electronics Training Center, LGEAI, U.S.A.
SMART THINQ REFRIGERATOR
TRAINING MANUAL
LFX31995ST FRENCH DOOR
REFRIGERATOR

1
Contact Information
Technical Training Manager: John Ferguson
[email protected]
Training Center Manager: Joseph Stuart
jose[email protected]
Technical Knowledgebase Website
http://www.lgtechassist.com
Global Service Front System (GSFS) Website
http://gsfs-america.lge.com
Product Information Website
http://www.lg.com
LG Learning Center
http://www.lglearn.com
LFX31995ST Refrigerator

2
Specifications
Specifications/ Page 3 Service Manual
LFX31995ST Refrigerator

3
Specifications
Specifications/ Page 3 Service Manual
LFX31995ST Refrigerator

4
Parts Identification
Parts Identification/ Page 4 Service Manual
LFX31995ST Refrigerator

LG Electronics Training Center, LGEAI, U.S.A.
Warranty Statement

6
LG Limited Warranty Statement
LG Warranty Period
1 Year Coverage – Internal / Functional
Parts & Labor
7 Year Sealed System. Parts only.
Ten Years Linear Compressor. Part only.
See page 115 in the owners manual for
complete warranty statement.
Warranty Coverage / Page 115 Owner’s Manual
LFX31995ST Refrigerator

7
LG Warranty Does Not
Cover Items Listed
Highlights
Instruct customer
Damage due to a
corrosive atmosphere.
Acts of God
Misuse or abuse
Repairs when product
is used in other than
normal and household
use.
Improper installation
Incorrect current,
voltage or plumbing.
Limited Warranty / Page 116 Owner’s Manual
LG Limited Warranty Statement / Exclusions LFX31995ST Refrigerator

8
LG Warranty Does Not
Cover Items Listed
Highlights
Cosmetic or missing
parts to a display or
refurbished product.
Replacement of light
bulbs or filters.
Removal from the
home for repairs.
Removal or
reinstallation if
installed in an
inaccessible location.
Limited Warranty / Page 116 Owner’s Manual
LG Limited Warranty Statement / Exclusions LFX31995ST Refrigerator

LG Electronics Training Center, LGEAI, U.S.A.
LG SmartThinQ™Technology

10
Smart ThinQ™Technology Overview
Smart ThinQ Appliances

11
Smart ThinQ™Technology Overview
Smart ThinQ Network
Overview
Internet access via home Wi-Fi
Network
Product Registration
Connectivity via Smart Phone
or Tablet PC
Diagnostics
Download Custom Programs
Software Program Updates
Food Management – Smart
Refrigerators
Smart Grid Technology –
Lower energy costs to operate
appliances when utility costs
are lowest. (Smart Meter –
using Zigbee Technology
where available!)

12
Smart ThinQ™Technology
Member Registration Steps
Access the LG smart ThinQ website (http://us.smartthinQ.com
After Clicking the Sign Up Button, agree to the terms of use & privacy
statements by clicking “Confirm” on each.
Don’t forget the ID/Password entered. These will be used at the Product
Registration for each Smart ThinQ appliance.
Member registration is completed after the Email authentication.
Member Registration
User’s Guide Logo
http://us.smartthinq.com/web/guide/supportvideo.dev

13
Smart Refrigerator Display Screen Contents from
Owners Manual. Overview
44 Food Manager
45 Food Manager by Category
47 Food Manager using Keypad
49 Function Menu
51 Send Food List to Phone
53 Recipes
54 Recipe Search
55 Food In Refrigerator
56 LG Smart Range Recipes
57 Grocery List
57 Add New Food
59 Add Groceries using Keyboard
59 Add Groceries to Food Manager
60 Delete Groceries from List
63 Memo
64 Creating a Memo
67 Deleting a Memo
68 Save Memo to Home Screen.
69 Google Calendar
71 View Events
72 Photo Album
76 Save & Delete Photos
77 REF Manager
77 Smart Savings
77 Demand Response Functionality
80 Delay Defrost
81 Settings
81 REF Information
82 Smart Diagnosis
83 Wi-Fi
85 Date & Time
86 Brightness
86 Volume
87 Zigbee
88 Update
89 Edit Home Screen
89 Screen Saver
89 Freshness Tracker Alert
90 Log In
93 Using the Widgets
Contents from owners manual pg 3

LG Electronics Training Center, LGEAI, U.S.A.
Smart Refrigerator Phone App

15
LRE3027ST Electric Range
Smart Refrigerator app.
Smart ThinQ™Technology
Note Before Using
To use the connectivity features of the refrigerator, you must
create a user ID and password at: http://us.smarthinq.com
Registration of the Smart ThinQ refrigerator can only be
completed from the refrigerators display screen.
Registration and Wi-Fi is required to connect the refrigerator
to the range and smart phone.
.
Downloading the Smart Phone Application
Enable Wi-Fi on your phone.
Search and download the “LG Smart Refrigerator” app from
the Play Store with your smart phone. After the down load
is complete, install the application
Open App
Enter your Smart ThinQ user ID and password.
App will confirm.
Refrigerator must be connected to Wi-Fi and registered to
connect.

16
LG Smart Refrigerator App LFX31995ST Refrigerator
Smart Refrigerator App Capabilities.
Allows you to receive and transfer data and monitor refrigerator
settings. Recipes, Food Manager, and Grocery apps function
the same as the widgets on the refrigerator display. See next
page for Ref Manager app.
Photo Transfer allows you to transfer photos taken with your
smart phone to the Refrigerator Photo Album. See Pg 18
Smart Diagnosis allows both Wi-Fi and audible diagnosing with
the smart phone.
.
Smart Refrigerator app
Synchronizing Phone
Synchronizing LG Smart Refrigerator app to Smart Refrigerator
Synchronizing is an automatic feature of the app. After logging
in a prompt different than what is viewed to the left will briefly
appear to confirm you are connected to Smart Refrigerator.
When data is transferred to or from the refrigerator
synchronization must take place or data will be lost. Touch
Send or Receive to complete data transfer.
Error Message: Follow instructions on screen, Log In required
or check Wi-Fi connection on both phone and refrigerator.
.

17
LG Smart Refrigerator App LFX31995ST Refrigerator
Ref Manager app
REF Manager Monitor screen
Ref Manager App
Allows monitoring of refrigerator settings only. Adjustments can
not be done from phone. Multiple Smart Refrigerator apps can
be registered to same product this can create temperature
issues.
Monitoring of Refrigerator/Freezer temperature, Fresh Air Filter,
Water Filter, Ice Plus, Eco Friendly and Smart Saving (Zigbee).
Both phone and refrigerator must be connected to Wi-Fi and
logged in and registered.
Swipe screen right or left touch Ref Manager or select icon at
bottom of screen.
.

18
Smart Refrigerator app – Photo Transfer LFX31995ST Refrigerator
Uploading Pictures to the refrigerator from an
SD card or Smart Phone.
Pictures can be imported up to 300MB to the
Photo Album.
Imported pictures size is automatically
converted to the display resolution.
The refrigerator display allows photos to be
viewed as a slide show or saved to the
Home screen.
Uploading Photos to the Album by Smart
Phone.
Log in to Refrigerator app.
Touch Photo Album
Select photo
Touch Photo Transfer.
Touch Send to Refrigerator
Refrigerator display will prompt you to import
photos.
Uploading photos from phone/ Owners Manual pg 74
Sending Photos to
refrigerator.
If photo is already in
in refrigerator Photo
Alert pops up.
Uploading photos
Photo Alert
Note.
See Owners Manual pages 72 thru 76 for detailed information on
uploading from a SD card and managing the Photo Albums, Slide
Show, and saving photos to the Home screen.
.
