LG WD-16330FD User manual

P/No.: 3828ER3033M

Washing Machine
OWNER’S MANUAL
WD(M)-16330(5)FD
WD(M)-16331(6)FD
WD(M)-14330(5)FD
WD(M)-14331(6)FD
WD(M)-12330(5)FD
WD(M)-12331(6)FD
Thank you for buying a
LG Fully Au oma ic Washing machine.
Please read your owner's manual carefully, i provides
ins ruc ions on safe ins alla ion, use and main enance.
Re ain i for fu ure reference.
Record he model and serial numbers of your washing machine.

2
roduct Features
P
ontents
C
Warnings....................................................................................3
Specifica ions.............................................................................4
Ins alla ion..................................................................................5
Care before washing................................................................11
Adding de ergen .....................................................................12
Func ion ...................................................................................13
How o use washer ..................................................................14
Main enance ............................................................................21
Troubleshoo ing guide .............................................................24
Terms of Warran y ...................................................................27
■ Jumbo drum
LG’s jumbo drum can wash abou 40% more load han conven ional washing
machines. A bigger drum improves he wash performance.
■ More economical by Intelligent Wash System
In elligen Wash Sys em de ec s he amoun of load and wa er empera ure, and
hen de ermines he op imum wa er level and washing ime o minimize energy and
wa er consump ion.
■ Child-Lock
The child-lock sys em is o be used for preven ing children from pressing any
bu on o change he program during opera ion.
■ Low noise speed control system
By sensing he amoun of load and balance, i evenly dis ribu es load o minimize
he spinning noise level.
■ Auto Restart
Au o Res ar allows he program o res ar all by i self in case of power failure.
I does from he s age where i s opped.
■ Direct Drive System
The advanced Brushless DC mo or ro a es he drum direc ly wi hou bel and pulley.
■ Safety device (Aqua lock) [WD(M)-16330(5)FD/14330(5)FD/12330(5)FD]
Aqua lock Sys em is designed for de ec ing wa er leak during opera ion o preven
wa er from flooding over he floor.
■ Water circulation
Spray de ergen solu ion and wa er on o he load over and over. Clo hes are
soaked more quickly and horoughly during wash cycle. The de ergen suds can be
removed more easily by he wa er shower during rinse cycle. The wa er circula ion
sys em uses bo h wa er and de ergen more efficien ly.

3
arnings
W
For your safety, the information in this manual must be followed to minimize
the risk of fire or explosion, electric shock, or to prevent property damage,
personal injury, or loss of life.
!
READ ALL INSTRUCTIONS AND EXPLANATION OF THE INSTALLATION BEFORE USE
WARNING!
❊ Do not push down the door excessively, when washer door open.
This could topple over the washer.
• Before ins alla ion, check ex erior damages. If i has,
do no ins all.
• Do no ins all or s ore he washer where i will
be exposed o he wea her.
• Do no amper wi h con rols.
• Do no repair or replace any par of he washer
or a emp any servicing unless specifically
recommended in he user-main enance ins ruc ions
or published user-repair ins ruc ions ha you
unders and and have he skills o carry ou .
• Keep he area undernea h and around your
appliances free of combus ible ma erials such as
lin , paper, rags, chemicals, e c.
• Close supervision is necessary if his appliance is
used by or near children. Do no allow children o
play on, wi h, or inside his or any o her appliance.
• Keep small animals away from he appliance.
• Do no leave he washer door open.
An open door could en ice children o hang on he
door or crawl inside he washer.
• Never reach in o washer while i is moving. Wai
un il he drum has comple ely s opped.
• The laundry process can reduce he flame re ardan
of fabrics.
• To avoid such a resul , carefully follow he garmen
manufac urer’s wash and care ins ruc ions.
• Do no wash or dry ar icles ha have been cleaned
in, washed in, soaked in, or spo ed wi h
combus ible or explosive subs ances (such as wax,
oil, pain , gasoline, degreasers, dry-cleaning
solven s, kerosene, e c.) which may igni e or
explode.
• Do no slam he washer door closed or ry o force
he door open when locked. This could resul in
damage o he washer.
• When he machine runs high empera ure, he fron
door may be very ho . Don’ ouch i .
• To minimize he possibili y of elec ric shock, unplug
his appliance from he power supply or disconnec
he washer a he household dis ribu ion panel by
removing he fuse or swi ching off he circui breaker
before a emp ing any main enance or cleaning.
• When unplugging power cord, do no pull ou by
grasping he cord. O herwise, he power cord may
be damaged.
• Never a emp o opera e his appliance if i is
damaged, malfunc ioning, par ially disassembled, or
has missing or broken par s, including a damaged
cord or plug.
• Before discarding an old machine unplug i . Render
he plug useless. Cu off he cable direc ly behind
he appliance o preven misuse.
GROUNDING INSTRUCTIONS
This appliance mus be grounded. In he even of malfunc ion or breakdown, grounding will reduce he risk of elec ric shock by providing a pa h
of leas resis ance for elec ric curren . This appliance is equipped wi h a cord having an equipmen -grounding conduc or and grounding plug.
The plug mus be plugged in o an appropria e ou le ha is properly ins alled and grounded in accordance wi h all local codes and ordinance.
• Do no use an adap er or o herwise defea he grounding plug.
• If you don’ have he proper ou le , consul an elec rician.
IMPORTANT SAFETY INSTRUCTIONS
WARNING :To reduce he risk of fire, elec ric shock, or injury o persons when using
he washer, follow basic precau ions, including he following:
SAVE THESE INSTRUCTIONS
WARNING : Improper connec ion of he equipmen -grounding conduc or can resul in risk of elec ric shock. Check wi h
a qualified elec rician or serviceman if you are in doub as o whe her he appliance is properly grounded. Do no modify
he plug provided wi h he appliance - if i does no fi he ou le , have a proper ou le ins alled by a qualified elec rician.

Spanner
Op ion : Ho /Cold(2EA)Inle hose(1EA)
■ Accessories
4
pecifications
S
Name : Fron loading washing machine
Power supply : 220-240 V~, 50 Hz
Size : 600mm(W) x 600mm(D) x 850mm(H)
Weigh / Max.Wa : 65 kg / 2100 W
Wash capaci y : 7 kg
Wa er consump ion : 49ℓ(7ℓ/ kg)
Permissible wa er pressure : 0.3-10 kgf/cm
2
(30-1000 kPa)
Spin speed : No spin/400/600/800/1000/1200/1400/1600
[WD(M)-16330(5)FD / WD(M)-16331(6)FD]
No spin/400/600/800/1000/1200/1400
[WD(M)-14330(5)FD / WD(M)-14331(6)FD]
No spin/400/600/800/1000/1200
[WD(M)-12330(5)FD / WD(M)-12331(6)FD]
❋The appearance and specifica ions may be varied wi hou no ice o raise he uni s quali y.

5
nstallation
I
1. To preven in ernal damage during
ranspor , he special 4 bol s are
locked. Before opera ing he washer,
remove
he bol s along wi h he rubber bungs.
• If hey are no removed, i may cause
heavy vibra ion, noise and malfunc ion.
3. Take ou he 4 bol s along wi h he
rubber bungs by sligh ly wis ing he
bung. Keep he 4 bol s and he
spanner for fu ure use.
• Whenever he appliance is ranspor ed,
he ransi bol s mus be refi ed.
The appliance is fi ed wi h ransi bol s o preven in ernal damage during ranspor .
• Packing and all transit bolts must
be removed before using the
washer.
󳢹When unpacking the base, be
sure to remove the additional
packing support in the middle
of the base packing.
2. Unscrew he 4 bol s wi h
he spanner supplied.
4. Close he holes wi h he caps supplied.
 Transit bolts
Install or store where it will not be ex osed to tem eratures below freezing or ex osed to the weather.
Pro erly ground washer to conform with all governing codes and ordinances.
The base o ening must not be obstructed by car eting when the washing machine is installed on a
car eted floor.
In countries where there are areas which may be subject to infestation by cockroaches or other vermin,
ay articular attention to kee ing the a liance and its surroundings in clean condition at all times.
Any damage which may be cause by cockroaches or other vermin will not be covered by the a liance
guarantee.
 Removing transit bolts
Base Packing
Washer
Packing Suppor
(Packing suppor may no
be used depending on
models.)

6
nstallation
I
Level floor :
Allowable slope under en ire washer is 1˚
Power outlet :
Mus be wi hin 1.5 me ers of ei her side of
loca ion of washer. Do no overload he ou le
wi h more han one appliance.
Additional Clearance :
For wall, door and floor modeling is required.
(10cm : rear /2cm:righ & lef side)
Do no place or s ore laundry produc s on op of
washer a any imes.
They can damage he finish or con rols.
 Installation place requirement
Laundry
Tub
Washer
approx.
2cm
Drain Hose
650
850
600
 Positioning
Ins all he washer on a fla hard floor.
Make sure ha air circula ion around he washer is no impeded by carpe s,rug e c.
• Never ry o correc any unevenness in he floor wi h pieces of wood, cardboard or similar
ma erials under he washer.
• If i is impossible o avoid posi ioning he washer nex o a gas cooker or coal burning
s ove,an insula ing(85x60cm) covered wi h aluminum foil on he side facing he cooker or
s ove,mus be inser ed be ween he wo appliance.
• The washer mus no be ins alled in rooms where he empera ure can drop below 0°C.
• Please ensure ha when he washer is ins alled, i is easily accessible for he engineer in
he even of a breakdown.
• Wi h he washer ins alled adjus all four fee using he ransi bol spanner provided
ensuring he appliance is s able, and a clearance of approxima ely 20mm is lef be ween
he op of he washer and he underside of he work- op.

7
nstallation
I
Rubber seal
Hose connec or
Rubber seal
Hose connec or
[WD(M)-16330(5)FD/14330(5)FD/12330(5)FD]
▶ Water supply pressure must be between 30kPa and 1000kPa
(0.3~10kgf/cm2)
▶ D n’t strip r cr ssthread when c nnecting Inlet h se t the valve.
▶ If the water supply pressure is m re than 1000kPa, a dec mpressi n device
sh uld be installed.
• Two rubber seals are supplied wi h he wa er inle hoses hese are in
order o preven wa er leaks.
• Check wa er igh ness of washing machine connec ions by urning he
ap comple ely on.
• Periodically check he condi ion of he hose and replace he hose if
necessary.
• Make sure ha here is no kink on he hose and ha i is no crushed.
▶ When y ur washer has tw valves,
• The Inle hose which has red connec or is for he ho wa er ap.
• If he washer has wo valves, he energy is saved by using ho valve.
 Washing Machine is to be connected to the water mains using new hose-sets and that old
hose-sets should not be used.
 Connecting water supply hose
1. Do no use an ex ension cord or double adap er.
2. If he supply cord is damaged, i mus be replaced by he manufac urer or i s service agen s or
similarly qualified person in order o avoid a hazard.
3. Always unplug he machine and urn off he wa er supply af er use.
4. Connec he machine o an ear hed socke in accordance wi h curren wiring regula ions.
5. The appliance mus be posi ioned so ha he plug is easily accessible.
• Repairs o he washing machine mus only be carried ou qualified personnel. Repairs carried ou by
inexperienced persons may cause injury or serious malfunc ioning. Con ac your local service cen er
• Do no ins all your washing machine in rooms where empera ures below freezing may occur. Frozen hoses
may burs under pressure. The reliabili y of he elec ronic con rol uni may be impaired a empera ures below
freezing poin .
• If he appliance is delivered in he win er mon hs and empera ures are below freezing : S ore he washing
machine a room empera ure for a few hours before pu ing i in o opera ion.
 Electrical connection
CAUTION concerning the Power Cord
Mos appliances recommend hey be placed upon a dedica ed circui ; ha is, a single ou le circui
which powers only ha appliance and has no addi ional ou le s or branch circui s. Check he
specifica ion page of his owner's manual o be cer ain.
Do no overload wall ou le s. Overloaded wall ou le s, loose or damaged wall ou le s, ex ension cords,
frayed power cords, or damaged or cracked wire insula ion are dangerous. Any of hese condi ions
could resul in elec ric shock or fire. Periodically examine he cord of your appliance, and if i s
appearance indica es damage or de eriora ion, unplug i , discon inue use of he appliance, and have
he cord replaced wi h an exac replacemen par by an au horized servicer.
Pro ec he power cord from physical or mechanical abuse, such as being wis ed, kinked, pinched,
closed in a door, or walked upon. Pay par icular a en ion o plugs, wall ou le s, and he poin where
he cord exi s he appliance.
CAUTION

8
nstallation
I
 Normal Tap without thread & screw type inlet hose
 Normal Tap without thread & one touch type inlet hose
1.Unscrew he fixing screw o
a ach he ap.
2.Push he connec or up ill he
rubber packing is in igh con ac
wi h he ap. Then igh en he 4
screws.
3.Push he wa er supply hose
ver ically upwards so ha he
rubber packing wi hin in he
hose can adhere comple ely o
he ap and hen igh en i by
screwing i o he righ .
1.Un igh en he upper connec or
screw.
2.Push he upper connec or up ill
he rubber packing is in igh
con ac wi h he ap. Then
igh en he 4 screws.
3. Connec he wa er supply hose
o he middle connec or,
pushing he pla e down.
• Your machine comes wi h only
cold wa er connec ion.
• Make sure ha here are no
kinks in he hose and ha i is
no crushed.
• Make sure ha he rubber seal
is inside he hose connec or.
Upper
Connec or Rubber
packing
Middle
connec or
Fixing screw
Guide pla e
Connec or
Rubber seal
Hose connec or
Used the horizontal tap
Horizon al ap
Ex ension ap
Square ap
Rubber packing
Upper
Connec or
Middle
connec or
Pla e
Upper
Connec or
Wa er supply
hose
• In case he diame er of he ap is
large remove he guide pla e.
• Turn he middle connec or no
o have wa er leaked.
• To separa e he wa er supply
hose from he middle connec or
shu off he ap. Then pull he
inle hose down, pushing he
pla e down.

9
nstallation
I
 Installation of drain hose
• The drain hose should no be placed
higher han 100 cm above he floor.
• Proper securing of he drain hose will
pro ec he floor from damage due o
wa er leakage.
• When he drain hose is oo long, do
no force back in o he washer. This
will cause abnormal noise.
• When ins alling he drain hose sink,
secure i igh ly wi h a s ring.
• Proper securing of he drain hose will
pro ec he floor from damage due o
wa er leakage.
This equipmen is no designed for mari ime use or for use mobile ins alla ions such as
caravans, aircraf e c.
Turn off he s opcock if he machine is o be lef for any leng h of ime (e.g. holiday),
especially if here is no floor drain(gully) in he immedia e vicini y.
When disposing of he appliance, cu off he mains cable, and des roy he plug Disable he
door lock o preven young children being rapped inside.
Packaging ma erial (e.g. Films, S yrofoam) can be dangerous for children. There is a risk
of suffoca ion !
Keep all packaging well away from children

10
nstallation
I
 Level adjustment
1. Adjus ing he washing machine level properly preven s excessive
noise and vibra ion.
Ins all he appliance on a solid and level floor surface, preferably
in a corner of he room.
2. If he floor is uneven, adjus he adjus able fee as required.
(do no inser pieces of wood e c. under he fee )
Make sure ha all four fee are s able and res ing on he floor and
hen check ha he appliance is perfec ly level. (use a spiri level)
※※
After the washer is level, tighten the lock nuts up towards of the base
of the washer. All lock nuts must be tightened.
❊ Diagonal Check
When pushing down the edges of the washing machine top plate
diagonally, the machine should not move up and down at all.
(Please, check both of two directions
If machine rocks when pushing the machine top plate diagonally,
adjust the feet again.
Rubber Cup
NOTE
Timber or suspended type flooring may contribute to
excessive vibration or load balance errors.
NOTE
In the case that the washing machine is installed on a raised
platform, it must be securely fastened in order
to eliminate the risk that it might fall off.

Concrete floors

Wooden floors (Suspended floors)
• The installation surface must be clean, dry and level.
• Install washer on a flat hard floor.

Tile floors (Slippery floors)
• Position each foot on the Tread Mate and level the machine to suit. (Cut Tread Mate into 70x70 mm
sections and stick the pieces on to the dry tile where machine is to be placed.)
※※
Tread Mate is a self adhesive material used on ladders & steps that prevents slipping.
• Wooden floors are particularly susceptible to vibration.
• To prevent vibration we recommend you place rubber cups under each foot,
at least 15mm thick under the washer, secured to at least 2 floor beams with screws.
• If possible install the washer in one of the corners of the room, where the floor is more stable.
※※
Insert the rubber cups to reduce vibration.
※※
You can obtain the rubber cups (p/no.4620ER4002B from the LG spares dept.
Important!
• Proper placement and levelling of the washer ensure long,regular and reliable operation.
• The washer must be absolutely horizontal and stand firmly in position.
• It must not “Seesaw” across corners under load.
• The installation surface must be clean, free from floor wax and other lubricant coatings.
• Do not let the feet of the washer get wet. If feet of the washer get wet, slipping may occur.

11
are before washing
C
1. Care Labels
Look for a care label on your clothes. This will tell you about the fabric content of your
garment and how it should be washed.
2. Sorting
To get the best results, Sort clothes into loads that can be washed with the same wash cycle.
Water temperature and spin speed and different fabrics need to be washed in different ways.
Always sort dark colors from pale colors and whites. Wash separately as dye and lint
transfer can occur causing discoloration of white etc. If possible, do not wash heavily
soiled items with lightly soiled one.
Soil Heavy, Normal, Light) Separate clothes according to amount of soil.
Color White, Lights, Darks) Separate white fabrics from colored fabrics.
Lint Lint producers, Collectors) Wash lint producers and lint collectors
separately.
3. Caring before loading
 Caring before washing
 Before the first washing
 Combine large and small items in a load. Load large items first. Large items should not be more
than half the total wash load.
Do not wash single items. This may cause an out-of-balance load. Add one or two similar items.
• Check all pockets to make sure
that they are empty. Items such as
nails, hair clip, matches, pens,
coins and keys can damage both
your washer and your clothes.
• Close zippers, hooks and strings to
make sure that these items don’t
snag on other clothes.
• Pre treat dirt and stains by brushing
a little detergent dissolved in water
onto stains like collars and cuffs to
help shift dirt.
Select a cycle COTTON 60°C, add a half load of detergent) allow the unit to wash
without clothing.
This will remove residues from the drum that may have been left during manufacturing.

12
dding detergent
A
• Main wash only ➔
• Pre Wash + Main Wash ➔
• Do not exceed the maximum fill line.
Overfilling can cause early dispensing
of the fabric softener which could stain
clothes.
• Do not leave the fabric softener in the
detergent drawer for more than days.
(Fabric softener could harden)
• Softener will automatically be added
during the last rinse cycle.
• Do not open the drawer when water is
supplied.
• Solvents(benzene, etc) are not
allowable.
1. The Dispenser Drawer
2. Adding Fabric Softener
■ Adding detergent and fabric softener
MAX
max
( )
125 ml
MAX MAX
125 ml
NOTE
Do not pour fabric softener
directly on the clothes
• The detergent should be used according to the
instruction of the detergent manufacture.
• If too much detergent is used more than the
recommended amount, too many suds can
occur and this will decrease the washing result
or cause heavy load to the motor. (Causing a
malfunction)
• Use powder detergent only for the front
loading washer.
• Detergent usage may need to be adjusted
for water temperature, water hardness,
size and soil level of the load. For best
results, avoid oversudsing.
4. Water softener
• A water softener, such as Calgon can be
used to cut down on the use of detergent
in extremely hard water areas. Dispense
according to the amount specified on the
packaging. First add detergent and then
the water softener.
• Use a quantity of detergent as for soft
water.
❋ Tips
Full load : according to
manufacturer’s recommendation.
Part load : 3/4 of the normal amount.
Minimum load : 1/2 of full load.
• Detergent is flushed from the dispenser at
the beginning of the cycle.
3. Detergent dosage

13
unction
F
■ Recommended courses according to the laundry types
※( ) : WD(M)-14330(5)FD / WD(M)-14331(6)FD / WD(M)-12330(5)FD / WD(M)-12331(6)FD
❋Intensive : If the laundr is heavil soiled “Intensive” option is effective.
❋Program setting with “Intensive” option for test in accordance or in conformit with EN60456 and IEC 60456.
❋ Rinse+: Used to introduce an additional rinse, which ma assist in removing traces of detergent residue.
❋ Pre Wash : If the laundr is heavil soiled, “Pre Wash” course is recommended. Pre Wash is available in Cotton
and S nthetic Program.
❋ Crease Care : If ou want to prevent crease, select Crease Care button.
Fabric Proper Maximum Energy Time
Program Option in in
Type Temp. Load kWh Minutes
Cotton
S nthetic
Delicate
Wool/Silk
Hand
Wash
Quick 30
First check if laundr
is machine washable.
(white cotton, linen
towel and sheets...)
Color fast gaments
(shirts, night dresses,
pajamas...)and lightl
soiled white
cotton(underwear...)
Pol amide, Acr ic,
Pol ester
Delicate laundr easil
damaged
Machine washable
woolens with pure
new wool or silk onl
“Hand Wash” marked
delicate and wool
laundr
Colored Laundr which
is lightl soiled fast.
95˚C
60˚C
(30˚C,
40˚C,
60˚C-Eco)
40˚C
(30˚C,
60˚C)
30˚C
(40˚C,
Cold)
30˚C
(40˚C,
Cold)
Cold
(30˚C)
30˚C
Rinse Hold
Intensive
Rinse+
Pre Wash
Crease Care
Rinse Hold
Intensive
Rinse+
Pre Wash
Crease Care
Rinse Hold
Intensive
Rinse+
Pre Wash
Crease Care
Rinse Hold
Intensive
Rinse+
Crease Care
Rinse Hold
Intensive
Rinse+
Crease Care
Rinse Hold
Intensive
Rinse+
Crease Care
Rinse Hold
Rinse+
Crease Care
Rating
Rating
Less than
3.5 kg
Less than
3.0 kg
Less than
2.0 kg
Less than
2.0 kg
Less than
2.0 kg
2.74
1.09
0.45
0.41
0.28
0.03
0.35
123
(117)
106
(100)
80
52
50
44
30

14
ow to use washer
H
• Press he Power( ) bu on o s ar .
• Press he Start/Pause( ) bu on.
• Ini ial condi ions
- Wash : main wash
- Rinse : 3 times
- Spin : 1600 rpm
[WD(M -16330(5 FD / WD(M -16331(6 FD]
1400 rpm
[WD(M -14330(5 FD / WD(M -14331(6 FD]
1200 rpm
[WD(M -12330(5 FD / WD(M -12331(6 FD]
- Water temperature : 60˚C
- Program : Cotton
• Press he Power( ) bu on o s ar .
• Selec he condi ions which you wan o
use, by urning he program dial and
pressing each bu on.
For selecting the each conditions, please
refer to the page15~page20
• Press he Start/Pause( ) bu on.
1. Cotton automatically
selected upon power on.
2. Manual Selecting

15
ow to use washer
H
(1) Dial : Program
(2) Bu on : S ar / Pause
(3) Bu on : In ensive
(4) Bu on : Rinse Hold
(5) Bu on : Rinse+
(6) Bu on : Pre Wash
(7) Bu on : Crease Care
(8) Bu on : Child Lock
(9) Bu on : Power
(10) Bu on : Spin
(11) Bu on : Time Delay
3. Rinse+
Option
• By pressing he
Op ion bu on, all
Op ion func ions
may be selec ed.
- Intensive
- Rinse Hold
- Rinse+
- Pre Wash
- Crease Care
• For addi ional rinse which may assis in
removing races of de ergen residue.
• By selec ing Rinse+func ion, he rinse
ime and he rinse wa er are increased.
4. Pre Wash
• If he laundry is heavily soiled,
“Pre Wash” course is effec ive.
• Pre Wash is available in Co on and
Syn he ic.
The required lamp will light up for identification.
2. Rinse Hold
• Is selec ed by pressing he Rinse Hold
bu on his func ion leaves clo hes in he
machine; suspended in he wa er af er a
rinse wi hou en ering in o spin.
• To proceed hrough o a drain or spin, once
he rinse hold func ion is comple ed using o
program dial scroll o he required program.
5. Crease Care
• If you wan o preven crease, selec his
bu on wi h spin speed.
1. Intensive
• If he laundry is heavily soiled “In ensive”
op ion is effec ive.
• By selec ing he In ensive op ion, he wash
ime may be ex ended, depending on he
program selec ed.
• This Op ion is no available wi h Quick 30
program.

16
ow to use washer
H
2. No spin
Spin
• By pressing he Spin bu on, he spin speed can be chosen.
• If no spin is selec ed, he washer s ops
af er draining wa er.
[WD(M)-12330(5)FD / WD(M)-12331(6)FD]
[WD(M)-16330(5)FD / WD(M)-16331(6)FD]
[WD(M)-14330(5)FD / WD(M)-14331(6)FD]
1. Spin selection
• Spin Speed is available according o
he program as follows.
•
WD(M)-16330(5)FD / WD(M)-16331(6)FD
- Co on, Rinse+Spin, Quick 30
No Spin - 400 - 600 -
800 - 1000 - 1200 - 1400 - 1600
- Syn he ic, Wool/Silk, Hand Wash
No Spin
- 400 - 600 - 800 - 1000
- Delica e
No Spin
- 400 - 600 - 800
•
WD(M)-14330(5)FD / WD(M)-14331(6)FD
- Co on, Rinse+Spin, Quick 30
No Spin - 400 - 600 -
800 - 1000 - 1200 - 1400
- Syn he ic, Wool/Silk, Hand Wash
No Spin
- 400 - 600 - 800 - 1000
- Delica e
No Spin
- 400 - 600 - 800
• WD(M)-12330(5)FD / WD(M)-12331(6)FD
- Co on, Rinse+Spin, Quick 30
No Spin - 400 - 600 - 800 - 1000 - 1200
- Syn he ic, Wool/Silk, Hand Wash
No Spin
- 400 - 600 - 800 - 1000
- Delica e
No Spin
- 400 - 600 - 800
Spin only:
1. Press he Power bu on.
2. Se he desired spin speed by pressing
he Spin bu on.
3. Press he Start/Pause bu on.

17
ow to use washer
H
Water Temp.
• By urning he Program Dial, he wa er
empera ure can be selec ed.
- Cold
- 30˚C / 40˚C / 60˚C / 95˚C
• Wa er empera ure can be selec ed
according o he program.
The required temperature lamp will light up
for identification.
For the more detailed information, please
refer to the page13.
Child Lock
If you choose o lock
he bu ons on he
con rol assembly o
preven ampering his
func ion may be
selec ed.
• Child Lock can be se by pressing he
Rinse+bu on and Pre Wash bu on
simul aneously. (Abou hree seconds)
• When child l ck is set, all butt ns are l cked
except f r p wer butt n.
•
To deac iva e Child Lock sys em, press
Rinse+and Pre Wash bu ons
simul aneously again. (Abou hree seconds)
• To change o he desired program, whils
in child lock mode.
1.
Press bo h Rinse+and Pre Wash oge her
once again. (Abou hree seconds)
2. Press he Start/Pause bu on.
3. Selec he desired program and press he
Start/Pause bu on again.
• The child lock can be se a any ime and
i is au oma ically canceled when
opera ional errors occur. Also Child Lock
works when power is off.
1. Child Lock

18
Program
• 8 programs are available according to the
laundry type.
• Lamp will light up to indicate selected
program.
• When Start/Pause button is pressed,
the Cotton program is automatically
selected.
- By turning the Program dial, the
program is selected in order of
Cotton
- Delicate - Quick 30 -
Rinse+Spin - Drain - Hand Wash -
Wool/Silk - Synthetic”.
Regarding to the laundry type for each
program Please refer to the page13.
ow to use washer
H
Time Delay
1. Time Delay
Preparing washing before starting
“Time Delay”
- Turn on the water tap.
- Load laundry and close the door.
- Place the detergent and fabric softener
in the drawer.
• How to set Time Delay”
- Press Power button.
- Turn the Program dial to select
the program you require.
- Press Time Delay button and set the
desired time.
- Press the Start/Pause button.
( :” blinks.)
• If Time Delay button is pressed, 3:00”
is displayed. The maximum delayed time
is 19 hours and the minimum time is
3 hours.
• Each pressing of the button advances
on time delay by one hour.
• To cancel the time delay, press the
Power button.
• Time Delay is ‘expected time’ from the
present to the completion of washing
cycle or selected process (Wash, Rinse,
Spin).
• ccording to the condition of water supply
and temperature, the delayed time and the
actual washing time may vary.

19
ow to use washer
H
Start/Pause
• This Start/Pause button is used to start
wash cycle or pause the wash cycle.
• If temporary stop of wash cycle is
needed, press the Start/Pause button.
• When in Pause, the power is turned off
automatically after 4 minutes.
• NB. The door will not open before 1 to 2
minutes when Pause is selected,
or at the end of the wash cycle.
1. Start
2. Pause
3. Door Lock
1. Power
2. Initial Program
Power
• Press the Power button to turn power on
and off
• To cancel the Time Delay function, the
power button should be pressed.
• When the Power button is pressed, the
washer is ready for otton program.
And the other initial conditions as
follows.
• So, if you want to advance into the
washing cycle without changing the
program, just press the Start/Pause
button and then the washer will proceed.
Initial program
[WD(M)-16330(5)FD / WD(M)-16331(6)FD]
- Cotton Program / Main was /
Normal Rinse / 1600 rpm / 60˚C
[WD(M)-14330(5)FD / WD(M)-14331(6)FD]
- Cotton Program / Main was /
Normal Rinse / 1400 rpm / 60˚C
[WD(M)-12330(5)FD / WD(M)-12331(6)FD]
- Cotton Program / Main was /
Normal Rinse / 1200 rpm / 60˚C
• Lights whenever the door of the washer is
locked.
• The door can be unlocked by pressing the
Start/Pause button to stop the washer.
• The door can be opened after a short delay.
• While the "Detecting" is shown in the display
the machine rotates slowly and detects how
many laundries are loaded in the drum. It will
take a few seconds.
• Available in otton, otton-Eco.
4. Detecting
