●Install the earth wire to prevent short-circuit due to leaking current and electric shock.
●It is attached at the back of the washer. Connect it to the metal water pipe. If the water
pipe is made of plastic, it does not have the earth effect.
●Never connect the earth wire to the gas
pipe, lightning arrester, telephone
connector etc.
7
Connecting the earth wire
¬WARNING : This appliance must be earthed .
Other earthing method
●After connecting the
earth wire to the earth
copper plate, bury it at
least 75 cm deep under
the wet ground.
●Connect to the earthing-
only outlet.
●When installing it in an
area where earthing is
not possible, purchase a
short-circuit breaker
(15mA at operation,
7.5mA at idle) and
connect it to the outlet.
Connecting the power plug
●Insert the power plug into the outlet.
●Before connecting the power plug, check if the
voltage setting of the machine matches the outlet
voltage.
●If AC outlet with ground terminal is used,
grounding is not needed. If not, never forget
earthing (earthing method above).
Gas pipe
Earth
wire
123
456
789
0
Ground terminal
Short-circuit breaker
Earth
wire
Earth
wire
Earth copper plate
75cm
INSTALLATION
