Lidl Service SOKL 1920 B2 User manual
IAN 289836
WI-FI SURVEILLANCE CAMERA
SOKL 1920 B2
WI-FI SURVEILLANCE CAMERA
Quick Start Guide
GB/IE/NI Quick Start Guide Page 3
3GB/IE/NI
Quick Start Guide
NOTE: Get your camera up and running with this Quick Start Guide; however, before using
the product read the complete instruction manual. Especially the safety notices must be read before
mounting and initiating the camera.
Scope of delivery
RJ45
φ6mm 1/4”
φ6mm 1/4”φ6mm 1/4”
φ16mm 5/8”
1618
20 22
15 19
23
21 24
Camera
observation /
Kameraüber-
wachung
11 x Wi-Fi Surveillance Camera
61 x Antenna
15 1 x PoE adaptor cable (Power over Ethernet)
18 1 x Power adaptor
19 1 x Wall mounting template / drill pattern
20 3 x Screws
21 1 x Quick start guide and instruction manual
22 3 x Wall plugs
23 1 x CD with assembly, operating and safety
instructions
24 1 x Under surveillance sticker
Camera overview
Antenna
Camera connection cable
Lens IR LEDs
PIR motion detector
4 GB/IE/NI
Installing the camera
You will need:
Ethernet cable
Wi-Fi router (2.4 GHz 802.11b/g/n)
microSD card (up to 128 GB)
iOS device with iOS 7.0 or above or Android
device with Android 4.4X or above
Tools:
Electric drill
Cross-head screwdriver
Ø 6 mm (1/4”) masonry drill bit
Ø 16 mm (5/8”) masonry drill bit
Sealing compound e.g. silicone
A1 A2 A3
x3
22
19 19
Stick the wall mounting template19 on the wall, eave or ceiling using the duct tape (not provided)
in the desired mounting position.
Drill 3 mounting holes (Ø 6 mm, 1/4”) (Fig.A1). Drill 1 hole (Ø 16 mm, 5/8”) in the wall for use
as a cable guide (Fig.A2).
Insert the wall plugs 22 into the mounting holes (Fig.A3).
A4
5
Pull the camera connection cable 5through the cable hole (Fig. A4).
5GB/IE/NI
A5
x3 8
20
Fix the wall mounting 8to the mounting surface using the screws20 provided (Fig.A5).
Connecting the cables
Antenna
RJ45
Router (not included)
Ethernet slot
Power socket
Camera
Power adaptor
Configuring the camera
Download and install the "Silvercrest IP Cam S-K 1920"
application on your smart device. The application is
available in the App Store®for iOS devices and in the
Google Play™store for Android devices. Alternatively scan
the appropriate QR code for your smart device operating
system.
Tap icon to add the camera and follow the on-screen
instructions. We advise you to go through the 1-minute demo
before configuring the camera.
NOTE: The view varies depending on the operating system in use. For more information, refer to
the full manual of this product.
6 GB/IE/NI
Connecting to Wi-Fi
For the first time setup to connect camera with Wi-Fi network, follow the detailed steps in the App
during setup.
If you want to update the Wi-Fi setting, follow below steps for advanced setup.
Tap "Edit Settings" and then "Settings".
Tap "Advanced" and type in the admin password set during the configuration process.
Tap (Wi-Fi) to go to the "Wi-Fi Settings". Choose the Wi-Fi network and type in the password.
NOTE: The Wi-Fi router's default password is usually labelled at the back of router. If you have
changed default password to a custom one, make sure the password is correct before you setup the
camera.
Live View
Tap to enter the Live View mode. Depending on the network speed and/or connection status, it may
take a while to load the live view.
Snapshot Tap to take a screenshot. The pictures are saved in your smart device
gallery.
Mute/Unmute Tap to mute/unmute audio in live view mode. Make sure the smart
device itself is not muted.
Record Tap to record approx. 1 minute video on the microSD card. The
recording cannot be stopped manually.
Night View
Auto / Off Tap to enable/disable automatic infra-red for black & white vision.
Arm /
Disarm
Arm the camera to start detecting/recording/sending push notifications
when you are away. Disarm the function when you do not want the
camera to mail data to you.
IAN 289836
OWIM GmbH & Co. KG
Stiftsbergstraße 1
DE-74167 Neckarsulm
GERMANY
Model No.: HG03329A-BS, HG03329B-BS
Version: 09/2017
