ERV SERIES
INSTALLATION GUIDE
69-ERV-INSTALL 072717

Table of Contents
Location ...................................................................................................................................... 2
Pre-Installation Notes ................................................................................................................... 3
Hanging Straps .............................................................................................................................8
Grilles ..........................................................................................................................................9
Grille Fittings ..............................................................................................................................10
Lifebreath Weatherhood and Weatherhood Requirements ...............................................................11
Dual Hood ...................................................................................................................................12
Main Control Installation ..............................................................................................................13
Interlocking the ERV ...................................................................................................................17
Installation and Operation of Wireless 20/40/60 Minute Timer: 99-DET02 ........................................15
Installer Selectable High Speed Settings .......................................................................................17
Dimensional Model Drawings - 130ERV/130ERVR Models ................................................................19
Balancing the Airflows .................................................................................................................21
Determining the CFM ...................................................................................................................22
Balancing Collar Instructions ........................................................................................................22
Balancing the Airflows with a Pitot Tube .......................................................................................23
Troubleshooting ..........................................................................................................................24
Location - Installation Notes
Install the unit in a conditioned space that provides clearance for service access. A typical location
is in either a mechanical room or an area close to the outside wall within close proximity to where
the weatherhoods are mounted. If a basement area is inconvenient or non-existent, install the unit
in a utility room or laundry room.
If attic installation is necessary the unit must be situated in a conditioned space with access to service.
Leave sufficient clearance at the front of the access door for servicing the air filters and core. The
recommended clearance is a minimum of 25 in (635 mm) for opening and closing the door.
2
Simplified Installation (Return/Return Method) .................................................................................4
Partially Dedicated System .............................................................................................................5
Fully Dedicated System ..................................................................................................................6
Plug Installation - 130ERV/130ERVR.............................................................................................. 18
Selecting the Ventilation Rate ....................................................................................................... 14
Dimensional Model Drawings - 230ERV/230ERV/30ERV Models ........................................................20
Mounting the 30ERV ......................................................................................................................7
Installation and Pairing of Repeaters: 99-RX02 ..............................................................................16
Installation and Operation of 20/40/60 Minute Timer: 99-DET01 .....................................................18

Pre-Installation Notes
Read this notice before installing unit:
Disconnect the power from the unit before cleaning or servicing
To prevent electrical shock, it is extremely important to confirm the polarity of the power line that is switched by the
safety (disconnect) switch. The hot line (black) is the proper line for switching. Use either a voltmeter or test lamp
to confirm the absence of a voltage between the disconnect switch and ground (on the cabinet) while the door is
open. This procedure must be followed, as dwellings are occasionally wired improperly. Always ensure the proper
grounding of the unit.
Improper installation, adjustment, alteration, service or maintenance can cause property damage, personal injury or
loss of life. Installation and service must be performed by a qualified installer or service agency.
Warning
Do not apply electrical power to the unit until after the completion of the installation (including installation of low
voltage control wiring).
Ensure the installation and wiring is in accordance with CEC, NEC, and local electrical codes.
Plug the unit into a standard designated (120 VAC) electrical outlet with ground.
The use of an extension cord with this unit is not recommended. If the installation requires further wiring, have a
licensed electrician make all of the electrical connections. The recommended circuit is a separate 15 A/120 V circuit.
Attention
Before installation, careful consideration must be given to how this system will operate if connected to any other
piece of mechanical equipment, i.e. a forced air furnace or air handler, operating at a higher static. After
installation, the compatibility of the two pieces of equipment must be confirmed, by measuring the airflows of the
ERV, by using the balancing procedure found in this manual. Never install a ventilator in a situation where its
normal operation, lack of operation or partial failure may result in the backdrafting or improper functioning of
vented combustion equipment.
Unit must be installed level to ensure proper condensate drainage. Due to the broad range of installation and
operational conditions, consider the possibility of condensation forming on either the unit or connecting ducting.
Objects below the installation may be exposed to condensate.
Do not install control wiring alongside electrical wire.
Caution
Due to ongoing research and product development, specifications, ratings, and dimensions are subject to change
without notice. Refer to www.LIFEBREATH.com for the latest product information.
The plugs found in the manual bag, must be installed at the base of the 130ERV and 130ERV-R models before
the unit is operated. Refer to page 19 of this manual.
Note
3


Simplified Installation (Return/Return Method)
Installation Notes
The ERV must be balanced.
Unit should be balanced on high speed with the furnace
blower on.
It is mandatory that the furnace blower run continuously
or ERV operation be interlocked with the furnace blower.
The duct configuration may change depending on the
ERV model.
A backdraft damper is recommended in the exhaust air
duct to prevent outdoor air from entering the unit.
The airflow must be confirmed on site using the
balancing procedures found in this guide.
4
RETURN
AIR
DIRECT CONNECTION of both the ERV SUPPLY AIR STREAM and
EXHAUST AIR STREAM to the FURNACE COLD AIR RETURN
Stale Air
to Outside
Forced Air
Furnace
Fresh Air
from Outside
Dampers for balancing
air flows, if not in collars of unit
Spring-Loaded Backdraft Damper (Recommended)
There is a location for an optional Backdraft Damper with the leaf hinge vertical. The damper is
installed on the “Stale Air to Outside Collar”
Install backdraft damper
to ERV collar with leaf
hinge vertical
Check local codes/authority having jurisdiction for acceptance.
Applications such as greenhouses, atriums, swimming pools, saunas, etc. have unique ventilation requirements
which should be addressed with an isolated ventilation system.
Weatherhood arrangement is for drawing purposes only. Check local codes/authority having jurisdiction for
acceptance.
Backdraft dampers are recommended for the stale air to outside air duct. This damper prevents outdoor air from
entering the ERV during the operation of the furnace/air handler while the ERV is in standby, off, or recirculating.
Attention/Warning

Partially Dedicated System
Installation Notes
The ERV must be balanced.
Unit should be balanced on high speed with the furnace
blower on.
It is recommended that the furnace blower run
continuously or ERV operation be interlocked with the
furnace blower. Refer to building code.
The duct configuration may change depending on the
ERV model.
A backdraft damper is recommended in the exhaust air
duct to prevent outdoor air from entering the unit.
The airflow must be confirmed on site using the
balancing procedures found in this guide.
5
RETURN
AIR
DIRECT CONNECTION of the SUPPLY AIR STREAM to the FURNACE COLD AIR RETURN (Stale
air drawn from key areas of the home)
Stale Air to
Outside
Forced Air
Furnace
Fresh Air
from Outside
Dampers for balancing air flows,
if not in collars of unit
Exhaust Air from different
areas of the home
(bathrooms, kitchen)
Spring-Loaded Backdraft Damper (Recommended)
There is a location for an optional Backdraft Damper with the leaf hinge vertical. The damper is
installed on the “Stale Air to Outside Collar”
Install backdraft damper
to ERV collar with leaf
hinge vertical
Check local codes/authority having jurisdiction for acceptance.
Applications such as greenhouses, atriums, swimming pools, saunas, etc. have unique ventilation requirements
which should be addressed with an isolated ventilation system.
Weatherhood arrangement is for drawing purposes only. Check local codes/authority having jurisdiction for
acceptance.
Backdraft dampers are recommended for the stale air to outside air duct. This damper prevents outdoor air from
entering the ERV during the operation of the furnace/air handler while the ERV is in standby, off, or recirculating.
Attention/Warning

Fully Dedicated System
Installation Notes
The ERV must be balanced.
When balancing, all external exhaust systems should be
turned off (i.e. range hood, dryer exhaust, bathroom
vents).
All exhausting appliances should have their own make-up
air, as this is not an intended use of the ERV system.
The duct configuration may change depending on the ERV
model.
The airflow must be confirmed on site using the balancing
procedures found in this guide.
Spring-Loaded Backdraft Damper (Recommended)
There is a location for an optional Backdraft Damper with the leaf hinge vertical. The damper is
installed on the “Stale Air to Outside Collar”
6
Fresh air to house -main
living areas, bedrooms,
livingroom, recreation
room, etc.
Stale Air to
Outside
Fresh Air
from Outside
Dampers for balancing air flows,
if not in collars of unit
Stale Air from various
areas of the home
(bathrooms, kitchen)
Install backdraft damper
to ERV collar with leaf
hinge vertical
Check local codes/authority having jurisdiction for acceptance.
Applications such as greenhouses, atriums, swimming pools, saunas, etc. have unique ventilation requirements
which should be addressed with an isolated ventilation system.
Weatherhood arrangement is for drawing purposes only. Check local codes/authority having jurisdiction for
acceptance.
Backdraft dampers are recommended for the stale air to outside air duct. This damper prevents outdoor air from
entering the ERV during the operation of the furnace/air handler while the ERV is in standby, off, or recirculating.
Attention/Warning

Mounting the 30ERV
7
Four Mounting
Points
1. Begin by locating the four mounting tabs on the left
and right sides of the unit, at the front and back.
2. Using a flat / pan head screwdriver, bend out the four
tabs to approximately 45o.
3. Once the tabs have been all bent outwards, insert
the "S" hooks through the four holes on the tabs.
4. Continue with mounting the ERV usign the
instructions found on page 8.

Hanging Straps - Installation Notes
Use 4 screws and 4 washers (not provided) to attach the hanging straps to the floor joists. The
washer must be wider than the eyelet of the grommet on the hanging strap. The hanging straps
are designed to reduce the possibility of noise, resonance and harmonics.
Must push up on the bottom of the ERV when pulling the hanging straps.
Attention
Step 3: Hook the bottom grommets of the
straps through the “S” hooks. Pull down
vertically on the handle loops while lifting
the bottom of the unit.
Step 1: Insert the screws and washers
(not included) through the hanging strap
grommets and fasten to the joists.
Figure A
Step 4: Level the unit from right to left to right
and front to back. Adjust the unit up by pulling
down vertically on the hand loops while lifting up
on the bottom of the cabinet.
Step 5: Fold the hand loops in excess strap
and secure with a nylon tie (not included).
Figure B
Screws (not included)
Hand Loops
Hanging Strap Grommets
Washers (not included)Buckles
Hand Loops
Note: Pull down on the
hand loops while lifting
Screws
“S” Hooks
Note: This illustration of
the unit may vary from the
diagram shown.
Joist
Buckles
Figure C
Step 2: Unscrew the 4 machine screws located
on the upper side of the unit. Attach the “S”
hooks and reinsert the machine screws.
8

Adjustable grilles should be used to balance the flow rates into and out of various rooms. The
grilles should not be adjusted after balancing the unit.
Grilles or diffusers should be positioned high on the wall or in the ceiling. Kitchen exhaust should
never be connected to the range hood. They should be installed at least 4 ft (1.2 m) horizontally
away from the stove.
Field supplied balancing dampers should be installed external to the unit to balance the amount
of stale air being exhausted with the amount of fresh air being brought into the house. Refer to
airflow balancing section.
The Lifebreath Kitchen Grille includes a
removable grease filter. Most building codes
require that kitchen grilles are equipped
with washable filters.
The Lifebreath Kitchen Grille
(part# 99-10-002 6 in x 10 in)
The Lifebreath TechGrille
The TechGrille is a round, fully adjustable grille,
which provides quiet air distribution.
Grilles
4 in (100 mm) Part # 99-EAG4
5 in (125 mm) Part # 99-EAG5
6 in (150 mm) Part # 99-EAG6
8 in (200 mm) Part # 99-EAG8
Removable Filter
Airflow
Supply
Airflow
Exhaust
9

Do not mount exhaust grille within 4 ft (1.2 m) (horizontally) of a stove to prevent grease from entering the unit.
Caution
10
Grille Fittings
Stack Head Elbow (part # 99-WF4 / 99WF6)
Use this rough-in fitting before the drywall is installed. This
fitting is ideal for running ducting through 2 x 4 (min.)
studded walls.
Nail to stud.
Available sizes are 4 in and 6 in.
Nail stack head
elbow onto stud
2 x 4 Stud
1/2 in drywall
Stack Head
Elbow
Connect to ERV ducting
TechGrille
Suspended Ceiling Fitting (part # 99-CF6)
Use this fitting for ceiling tiles or finished/installed drywall.
Cut a hole through the ceiling tile, insert the fitting and use the
retaining ring to hold the fitting in place.
For finished/installed drywall, use caulking around the lip if you do
not have access to attach the retaining ring.
Available size: 6 in.
Connect to ERV ducting
Ceiling
Fitting
Retaining ring
Flush mount the lip of the
ceiling fitting to ceiling
TechGrille
Ceiling
Quick Mount Fitting
(part # 99-QM6)
Use this rough-in fitting before the drywall is
Installed.
Nail fitting onto the stud.
Available size: 6 in.
Connect to ERV ducting
2 x 4 Stud
Nail or screw quick
mount fitting to stud
TechGrille
1/2 in drywall
Quick Mount
Fitting
Terminator Fitting (part # 99-TM 4/5/6)
Use this rough-in fitting before the drywall is installed.
TechGrille
Connect to ERV ducting
Terminator
Fitting
Ceiling / wall
drywall
Nail / screw to
secure stud or
joist
Flush mount the lip
of the Terminator
fitting to the drywall
Nail or screw fitting onto the stud or joist.
Available sizes: 4 in, 5 in and 6 in.
Use this rough-in fitting before the drywall is installed.
Adapts to ridged and flex ducting
Strong attachment for grilles, either vertically or horizontally

11
Lifebreath Weatherhood
Fixed covered weatherhoods have a built-in bird screen with a 1/4 in (6 mm) mesh to prevent foreign
objects from entering the ductwork.
Installation Notes
The inner and outer liners of the flexible insulated duct must be clamped to the sleeve of the
weatherhoods (as close to the outside as possible) and the appropriate port on the ERV. It is very
important that the fresh air intake line be given special attention to make sure it is well sealed. A good
bead of high quality caulking (preferably acoustical sealant) will seal the inner flexible duct to both the
ERV port and the weatherhood prior to clamping.
The flexible insulated duct that connects the two outside weatherhoods to the ERV should be stretched
tightly and be as short as possible to minimize air flow restrictions.
Twisting or folding the duct will severely restrict airflow.
Hard (rigid) ducting which has been sealed and insulated should be used for runs over 10 ft
(3.3 m). Refer to your local building code.
Screen
(side view)
1/4 in (6 mm)
Screen
Exterior wall
Collar is supplied to
ensure vapor barrier is
100% sealed to wall plate
12 i n galvanized
pipe supplied
Weatherhood Requirements
Check local codes/authority having jurisdiction for acceptance and spacing
requirements for weatherhoods.
Do not locate in garage, attic or crawl space.
Intake:
Should be located upstream (if there are prevailing winds) from the exhaust outlet.
Not near dryer vents, furnace exhaust, driveways, oil fill pipes, gas meters, or garbage
containers.
Exhaust:
Not near a gas meter, electric meter or a walkway where fog or ice could create a hazard.
Contact your local building authority before installation of the Dual Hood to verify compliance with
local building codes.
Attention

12
Contact your local building authority before installation of the Dual Hood to verify compliance with
local building codes.
Caution:
Sealant must be applied as per instructions or leakage and condensation may occur.
Insulate the Fresh Air Supply and Stale Air Exhaust duct work back to the unit.
Attention/Caution
Dual Hood Part 99-190
With the Lifebreath Dual Hood, only one 6 in hole is required in the exterior wall to complete two
connections: fresh air intake and stale air exhaust.
13"
Top View
8.25" 6"
8.25"
25"
Side View
6" 5" 6"
21.5"
Stale Air
Exhaust
Fresh Air
Intake
SideView of Hood and Backplate
Tested by: National Research Council Canada
Program: Building Regulations for Market Access Report Number: A1-007793
Report Date: 15 February 2016
Found to comply with requirement as set in the NBC
Note

13
Main Control Installation
The Lifebreath Digital Control 99-DXPL02 is to be surface mounted onto a wall and the Lifebreath
Ventilation Control 99-BC04 may either be installed onto a flush mounted electrical switch box or
surface mounted onto a wall. Only one master control should be installed to a ventilation system (the
face plate on this illustration may not be exactly the same as yours).
1. For DXPL02 control, remove the operating
2.
3.
4.
5.
6.
7.
8.
9.
Operating
Instruction
Card
1 in hole for Wiring
wire opening. Terminals
10.
11.
12.
instructions card from the top of the control
(Figure A).
Separate the face plate from the back plate by
firmly pulling apart (Figures B or C). Be careful
not to damage face plate contact pins.
For DXPL02 control, place the back plate of
the control in the desired location on the wall
and pencil mark the wall with the right and left
screw holes (Figure D).
For BC04 control, place the screws and
anchors. back plate of the control in the
desired location on the wall and pencil mark
the top and bottom screw holes.
(Figure E or F).
For mounting the control without a Decora
plate, break off top and bottom tabs and refer
to Figure F for mounting. Remove the back
plate from the wall and mark the center hole
for the wires in the middle of the screw holes.
Refer to Figure D, E or F for dimensions.
Drill (two) 1/8 in holes for the screws and wall
anchors (Figure D, E or F). For DXPL02 control, vent openings clear Figure
D
drill
a 1 in hole in the center (Figure D). For
BC04 control, cut in a 3/4 in by 1 in oval hole
in the wall (Figure E or F).
Pull 3 wire 20 gauge (min.) 100 ft length
(max.), through the opening in the wall.
terminals located on the back plate (Figure D, E
supplied screws and anchors.
Attach the face plate to the back plate (Figure B
or C). Note: Be careful to correctly align the
face plate to avoid damaging the face plate
contact pins.
instructions card into the control (Figure A).
Connect the 3 wire 20 gauge (min.) 100 ft length (max.) to the terminal block located on ventilator (Red #3, Yellow #4
and Green #5).
Face
Plate Back
Plate
Pay special attention not to damage the contact pins when removing and detaching the face plate (Figures B and C).
Attention
Keep top / bottom
For DXPL02 control, insert the operating Figure
E
1.625"
Connect red, green, and yellow to the wiring 0.75"
or F). 1"
1.625"
1/8 in hole for
screw and
anchor
1 in x 3/4 in
for wire
opening
Wiring
Terminals
1/8 in hole
for screw and
anchor
oval hole
Break off tab
Alternate Wall Mount
1/8 in hole for
screw and
anchor
1 in x 3/4 in 0.75"
oval hole
1/8 in
for wire
hole for
opening
screw and
anchor
Wiring
Terminals
Break off tab
Figure F
Attach the back plate to the wall using two 1"
Wire hole
centered
between
screw
holes
Figure A
Figure B
Figure C
(Two) 1/8 in holes for screws
and anchors
Keep top / bottom
vent openings clear
Back
Plate
Face
Plate
1.5"1.5"

Disconnect the power from the unit before cleaning or servicing.
To prevent electrical shock, it is extremely important to confirm the polarity of the power line that is switched by
the safety (disconnect) switch. The hot line (black) is the proper line for switching. Use either a voltmeter or test
lamp to confirm the absence of a voltage between the disconnect switch and ground (on the cabinet) while the
door is open. This procedure must be followed, as dwellings are occasionally wired improperly. Always ensure the
proper grounding of the unit.
Warning
Due to ongoing research and product development, specifications, ratings, and dimensions are subject to change
without notice. Refer to www.LIFEBREATH.com for the latest product information.
Note
14
Selecting the Ventilation Rate That is Right for You
The modes of operation and speeds are used to adjust your indoor ventilation rate. Experiment with the
ventilation levels in your home to evaluate the ideal amount of ventilation to suit your home and
personal preferences. Operational modes available to you will depend on the main control that is installed.
Come features and modes may be unavailable to you.
Recirculation
Recirculates existing household air without introducing fresh air. Recirculation modes (II and V) are not
applicable if your ERV is connected to a forced air system, since your forced air system already circulates the
household air. Recirculation modes are unavailable on some models.
I. Continuous Ventilation
This mode of operation provides continuous ventilation within the home. You may, for example, select
Continuous Ventilation at low speed for normal operation and increase to high speed during increased
activity levels, such as cooking and showering, etc.
II. 20 Minutes On, 40 Minutes Recirculation 20/hr 40/hr
This mode ventilates for 20 minutes and recirculates the household air every 40 minutes each hour. This
mode is not applicable if your ERV is connected to a forced air system.
III.20 Minutes On, 40 Minutes Standby 20/hr 40/hr
This mode of operation provides 20 minutes of ventilation each hour. You can use this ventilation mode at
low speed for low household activity levels or when the home is unoccupied.
IV. 10 Minutes On, 50 Minutes Standby 10/hr 50/hr
This mode of operation provides 10 minutes of ventilation each hour. You can use this ventilation mode at
low speed for low household activity levels or when the home is unoccupied. This mode is useful when
20/40 mode is providing too much ventilation.
V. Continuous Recirculation or
This mode continuously recirculates your household air (no ventilation). This mode is not applicable if your
ERV is connected to a forced air system.
VI. Continuous Low Fan Speed LO
This mode will operate the fan in low speed continuously at the selected operating mode (Ventilation or
Recirculation).
VII. Continuous High Fan Speed HI
This mode will operate the fan in high speed continuously at the selected operating mode (Ventilation or
Recirculation). This mode is useful when occupancy in the home or activity is high for an extended period
of time.

15
Installation and Operation of Wireless 20/40/60 Minute Timer: 99-DET02
BC04
Control
NOTE: Your
control may look
different than the
one shown.
Press Simultaneously
to Initiate Pairing Mode
Figure A
Figure D
NOTE
Thewireless Timers and Repeaters must be matched to
the main wall control of the HRV / ERV. This process is
called "Pairing". Multiple Timers and Repeaters can be
paired to a single wall control.
Figure B
1/8 in hole for
screw and
anchor
1/8 in hole
for screw and
anchor
Break off tab
Alternate Wall Mount
1/8 in hole for
screw and anchor
Figure C
Back Plate
Face Plate
1/8 in
hole for
screw and
anchor
Break off tab
Figure F
Figure E
Press Simultaneously
to Initiate Pairing
Mode
DXPL02
Control
DET02 Timer
20/40/60 Minute
Status Lights
Select Button initiates
high speed ventilation
for 20, 40 or 60 min.
Battery Indicator
Removable
Backplate
The Timers may be installed onto a flush mounted electrical
switch box or it may be surface mounted onto a wall. Multiple
Timers may be installed in a ventilation system. To increase
the range of a wireless Timer, a RX02 Repeater should be used.
Pairing:
To pair additional DET02 Timers with the same wall control, or
if pairing was not successful, repeat steps 1-6.
When paired, the DET02 Timers can be moved and installed
elsewhere. Estimated range of the Timer is 40’ with no
obstructions. A RX02 Repeater may be installed to increase the
range of the Timers.
Test if pairing was successful by pressing the Select Button and
listen for the HRV / ERV to initiate HIGH fan speed Ventilation.
Un-pairing:
1. Turn on the main wall control by pressing the ON/OFF
button and remove the battery from Timer.
2.
DET02 with DXPL02 Controls: Press the left and right
buttons simultaneously on the main wall control
( and RESET buttons). The screen will go blank and the
wireless symbol will appear flashing on the bottom right
of the display. This indicates that the main control is now in
pairing mode. (Figure D)
3. DET02 with BC04 Control: Press the left and right
buttons simultaneously on the main wall control ( and
buttons). The bottom row of 3 LED's will begin flashing.
This indicates that the main control is now in pairing mode.
(Figure E)
4. Keep the Timer within 16” of the main wall control when
pairing.
5. Install the battery in the DET02 Timer. All four lights on
the Timer will immediately flash 5 times, then only the red
battery light will remain on for approximately 12 seconds
after which the "40" light flashes the rev code. 20, 40, 60
lights will flash until paired or will stop if not paired within
12 seconds. If pairing was not successful you now must
return to step 1 to restart the pairing process.
6. Press the button on the main wall control to exit pairing
mode when Timers have been successfully paired.
1. Remove the battery from the back of the DET02 Timer
2. Press and hold the Select Button on the front of the Timer
3. While holding the Select Button, reinsert the battery in the
Timer. Continue holding the select button until the LED
under "40" begins flashing. The DET02 Timer will now be
unpaired with the main wall control.
Installation:
1. Separate the face plate from the back plate by firmly
pulling apart (Figure A).
2. For mounting the control without a Decora plate, break off top and bottom tabs and refer to Figure C for mounting.
3.Place the back plate of the control in the desired location on the wall and pencil mark the top and bottom screw holes
(Figure B or C). Drill two 1/8" holes.
4. Attach the back plate to the wall using the 2 supplied screws and anchors.
5. Attach the face plate to the back plate (Figure A).

16
1. Turn on the main wall control by pressing the ON/OFF button .
2. RX02 with DXPL02 Controls: Press the left and right buttons simultaneously on the main wall
control ( and RESET buttons). The screen will go blank and the wireless symbol will appear
flashing on the bottom right of the display. This indicates that the main control is now in pairing
mode. RX02 with BC04 Control: Press the left and right buttons simultaneously on the main
wall control ( and buttons). The bottom row of 3 LED's will begin flashing. This indicates that
the main control is now in pairing mode.
3. The RX02 Repeater must be powered within 16” of the main wall control for pairing. If an outlet is
not available an extension cord should be used to power the repeater initially for pairing.
4. Plug the RX02 Repeater into the power outlet. The green light will flash after approximately 12
seconds indicating that the repeater is paired with the main wall control.
5. Press the ON/OFF button on the main wall control to exit pairing mode and the Repeater may
RX02
Repeater
Power
Plug
Installation and Pairing of Repeaters: 99-RX02
The RX02 Repeaters are to be plugged directly into a 120V power outlet
now be unplugged and moved to its permanent location.
To pair additional RX02 Repeaters with the same wall control, repeat steps
1-5 until all Repeaters have been paired.
When installed in its permanent location, the green LED will remain solid to
indicate the best location and the Repeater can be moved farther if
required. The green LED will flash to indicate it is in a good location. A red
light indicates the Repeater is out of range and needs to be moved closer to
the main wall control.

Interlocking the ERV to an Air Handler or Furnace Blower
ERV Terminal Block
Wire
Connector
Furnace
Terminal Strip
Furnace
Thermostat
Connecting the ERV as illustrated will ensure the
air handler/furnace blower motor is operating
whenever the ERV is venting.
The ERV must be interlocked to the furnace/air
handler with a simplified installation (return/
return installation).
Setting “Standby” When Using a Main Control
Timers mount in standard electrical boxes.
Use 3 wire 20 gauge (min.) 100 ft length (max.) low voltage wire and multiple timers individually wired back to the unit.
Caution:
Consideration should be given to competing airflows when connecting the ERV in conjunction with an air handler/
furnace blower system.
Building codes in some areas require “fully-off” functionality. Check with your local building authority before
modifying the unit to “standby-off”. Unintentional operation of the ERV by the end user may occur if the unit is
modified from “fully-off” to “standby-off”.
Attention/Caution
17
The ERV will be “fully-off” when the off position is selected
on the Main Control. Timers and/or other controls will not function when the ERV is in the off
position.The “fully-off” feature can be modified to “standby-off” by adding a jumper on the terminal
block between 2 (ON) and 3 (RED). “Standby” can also be achieved by setting the main control
to the ON position and selecting speed 0*. Timers and/or additional controls will initiate high speed
ventilation when activated.
*Speed 0 is not available on all controls.
Operating the ERV With Dry Contact Controls
A jumper must be in place between 2 (ON) and 3 (RED) on the terminal block to activate the ERV for
timers and/or dry contact controls.
Adding Dry Contact Controls
Low Speed: A jumper between 2 (ON) and 1 (LOW) initiates low speed ventilation.
High Speed: A jumper between 2 (ON) and 6 (HI) initiates high speed ventilation.
Dehumidistat: A dry contact for a Dehumidistat is connected between 2 (ON) and 10 (BLK)
Installer Selectable High Speed Settings
The circuit board on this unit has adjustable DIP switches for the selection of HIGH speed Hi1, Hi2 or
Hi3. The factory setting is Hi3, which is the highest speed possible H2 will result in a lower airflow
than H3, with H2 the lower of the high speeds. Refer to the specification page found online at;
www.lifebreath.com for the airflow rates on Hi1, Hi2 and Hi3.
Note: Low speed is not adjustable.
Description Switch 1 Switch 2 Switch 3 Switch 4
Hi 3 (factory default) Factory Setting “ON” Leave on factory setting ON ON
Hi 2 Factory Setting “ON” Leave on factory setting OFF ON
Hi 1 Factory Setting “ON” Leave on factory setting ON OFF

18
Installation and Operation 20/40/60 Minute Timer: 99-DET01
Operating your Lifebreath 20/40/60 Minute Fan Timer
Press and release the Select Button to activate a 20, 40 or 60 minute high
speed override cycle. The Light will illuminate and the unit will run on
high speed ventilation for the selected time. The Light will dim after 10
sec. for run time. The Light will flash during the last 5 min. of the cycle.
The timer connected to the unit will illuminate for the duration of the
override when the Select Button is pressed.
Lockout Mode
Lockout Mode is useful if you wish to disable the timers.
The timer can be set to lockout mode by pressing and holding the Select
Button for five seconds. After 5 sec., the Light will flash; release the Se-
lect Button. The timer is now in lockout mode. If the Select Button is
pressed during lockout mode the Light will momentarily illuminate but no
override will be initiated.
Status
Lights
Select Button
initiates high
speed ventilation
for 20, 40 0r 60 min.
Yellow
Red
Green
Red #3
Yellow #4
Green #5
If lockout mode is initiated when the timer is activated, the timer will
continue its timed sequence but will not allow any further overrides to be
initiated. Lockout mode can be unlocked by pressing and holding the Select
Button for 5 sec. After 5 sec. the Light will stop flashing. Release the Select
Button and the timer will now operate normally.
Plug Installation - 130ERV/130ERVR
The plugs are located in the ERV manual bag. The plugs will be installed into the 2 holes
located in the bottom tray of the ERV. They must be inserted from the inside of the unit to
ensure the holes are fully sealed, see detail below.
Ensure the plugs are firmly seated within the foam tray before operation.
Note
Core
Plug Plug
Foam Tray Pre-punch hole Pre-punch hole Foam Tray

19
Dimensional Drawing for 130ERV/130ERVR Models
Dimensional Drawing for Models 120ERV and (120ERVRX - in brackets)
Fresh Air
From Outside
Stale Air
From Inside
(Fresh Air
From Outside)
(Stale Air
From Inside)
Fresh Air
To Inside
Stale Air
To Outside
(Fresh Air
To Inside)
(Stale Air
To Outside)
Side View
Bottom View
28 5/8 in (727 mm)
Note: Bottom clearance of
25 in (635 mm) is
recommended for servicing
unit. All ducts use 5 in
(125 mm) connections.
16 1/2 in (419 mm) Core Balancing Damper
9 1/4 in (235 mm)
18 1/4 in (464 mm) 17 1/4 in (438 mm)
22 3/4 in (578 mm)
14 in (356 mm)
Front View
Top View
Fresh
Air From
Outside
Stale
Air To
Outside
Fresh
Air From Air To
Inside
Stale
Inside
Motorized
Impellers
Removable
Heat Recovery
Core
Recirculating
Defrost Damper
(For 130ERVR
Model Only)
Filters
Note: Front clearance of 25 in (635 mm)
is recommended for servicing unit. All
ducts use 5 in (125 mm) oval collars,
balancing dampers are located on all
collars.

20
Dimensional Drawing for 230ERV/230ERVR Models
19 in (483 mm)
14 3/4 in (375 mm)
33 5/8 in (850 mm)
FRONT VIEW TOP VIEW
Stale
Air To
Outside
Fresh
Air To
Inside
Fresh Stale
Air From Air From
Outside Inside
Motorized
Impeller
Core
Filter
Note: Front clearance of 25 in (635 mm) is
recommended for servicing unit. All ducts use
6 in (152 mm) round collars, balancing
dampers are located on two collars.
Recirculating
Damper
(For 230ERVR
Model Only)
Balancing
Dampers
Dimensional Drawing for 30ERV Model
Front View
Top View
18 3/4" (476 mm)
17 7/8" (454 mm)
19 1/4" (489 mm)
Note: Front clearance of 25 in (635 mm) is
recommended for servicing unit. All ducts
use 4 in (102 mm) round collars, balancing
dampers are located in each air stream.
Stale Air
From Inside Fresh Air
From Outside
Fresh Air
To Inside Fresh Air
To Outside
