Lifeline LL-12V100-24 User manual

Maintenance
•When in storage for an extended period of time, discharge the battery to 40-
50% State of Charge. Use the Life ine B uetooth app to verify State of Charge
(SOC%)
•Keep batteries stored in coo , dry, and venti ated areas.
Troubleshooting
If the battery shows 0 vo ts at the termina , the battery has gone into protection mode.
P ease refer to the fo owing instructions or contact us for assistance.
•If the battery becomes over-discharged and reads 0 Vo ts at the termina ,
disconnect the battery from a e ectrica oads and connect to compatib e
ithium charger and charge separate y at 14.4 - 14.6 Vo ts to reset the BMS.
•If the battery temperature becomes too high or too ow during operation and
triggers the battery temperature protection, p ease disconnect the battery
from the charging source and et the battery coo down or remove battery
from co d conditions and a ow to heat up to operating temperatures and the
BMS wi automatica y reset.
•If too high of a current passes through the battery and triggers the
charge/discharge overcurrent protection, disconnect the battery from a
e ectrica oads and the BMS wi automatica y reset.
•If the battery termina s sti show 0 vo tage after fo owing these suggestions, the
interna battery fuses or sensors may have been damaged due to severe
conditions. P ease contact us for assistance.
Warranty
•Limited Lifetime Warranty: This warranty is extended to the origina purchaser or
end user and covers defects in materia s and workmanship.
•Life ine Lithium batteries are covered by a 5 Year Pro-rated warranty.
•RV & Marine app ications: Within the 1
st
12 months of the warranty period,
subject to the exc usions isted be ow, the battery wi be rep aced at no cost.
•The warranty is inva idated if any of the fo owing occurs, and is not imited to:
oFai ure to fo ow the recommendations in this Owner’s Manua
oAccidenta or unreasonab e use, misuse, over charging or over
oading, or norma wear.
oExtended storage without recharging
oProduct that has been opened, modified or tampered with
oProduct that was used for app ications other than which it was
designed and intended for, inc uding engine starting.
•The warranty does not cover shipping, or any other incidenta costs not re ated
to the battery.
•For a other app ications or technica assistance, p ease contact our Technica
Support team at 1-800-527-3224.
•A shipping costs for returns are the responsibi ity of the owner of the product
and are non-refundab e.
Lifeline Batteries
292 E Arrow Highway  San Dimas, CA 91773
1-800-527-3224
www. ife inebatteries.com

Low Temperature Models
LL-12V100-2 | 12.8V 100 Ah Group Size 2
LL-12V100-27 | 12.8V 100 Ah Group Size 27
P ease read this manua prior to insta ation and
operation.
Congratu ations on the purchase of a new Life ine Lithium Battery! Life ine has
been the eading name in advanced battery techno ogy inc uding AGM
(Absorbed G ass Mat) batteries since 1993.
This manua is intended to be used for quick reference on y.
For the fu content of Life ine’s technica recommendations, cautions and
other important information, p ease refer to the “Life ine Lithium Owner’s
Manua ” avai ab e for down oad at www. ife inebatteries.com. If you do not
have web access, p ease contact Life ine Customer Service Dept. by ca ing
1-800-527-3224 or [phone] to receive a copy by mai .
Attentions and Warnings:
Per US regulation, Lifeline Lithium batteries are shipped in a 60% State of
Charge. Please charge batteries to 100% SOC before installation and use.
Download the Bluetooth app available for iOs and Android.
•This product is intended for Para e connections on y. DO NOT
connect in Series for 24, 36, or 48 Vo t systems.
•DO NOT open, disassemb e, modify, or repair the battery.
•DO NOT puncture, drop, crush, burn, penetrate, shake, or strike the
battery.
•DO NOT use a bad y damaged battery or operate it with damaged
cab es or charging adaptors.
•DO NOT permit the battery to freeze. Never charge a frozen battery.
•DO NOT submerge in water. This product is IP65 water resistant which
protects against ow water pressure on y.
•This product contains ithium-on batteries. When it is worn out, dispose
of it proper y using oca aws and regu ations.
•In case of skin or eye contact with damaged or exposed battery
chemica s, rinse immediate y with c ean water and seek medica
attention.
The following specifications are recommended for maximum battery life for all
Lifeline Lithium Low Temperature models only.
Specifications
Ce Type LiFePO4
Nomina Vo tage 12.8V
Technica Rated Capacity 100 Ah
Cyc e Life (0.2C, 77°F, 25°C) 3500 Cyc es (80% DOD)
Termina Bo t Size M8
Certifications UN38.3, CE, UL1642, IEC62133
Shipping C assification UN3480, C ass 9
Model LL-12V100-2 10.2 x 6.6 x 8.6 | 27.8 bs
Model LL-12V100-27 12.1 x 6.6 x 8.7 | 28.2 bs
Charging
Recommended Charging Current 20A
Maximum Charging Current 100A
Recommended Charge Vo tage 14.4V – 14.6V
BMS Charge Cut-Off Vo tage 15.4V
BMS Reset Vo tage 14.4V – 14.6V
Ba ancing Vo tage 14.4V - 14.6V
F oat Vo tage 13.4V -13.8V
Equa ization Vo tage 14.4V or Disabled
Temperature Compensation 0 or Disabled
Discharging
Maximum Continuous Discharge Current
100A
Peak Discharge Current
200A
BMS Discharge Cut-Off Current
300A
Low Vo tage Disconnect
11.0V
BMS Discharge Cut-Off Vo tage
8.0V
Reconnect Vo tage
>10.0V
Temperature
Discharge Temperature -4 ~ 131° F (-20 ~ 55° C)
Charging Temperature -4 ~ 131° F (-20 ~ 55° C)
Storage Temperature 23 ~ 95° F (-5 ~ 35° C)
BMS High Temperature Cut-Off 149° F (65° C)
Reconnect Temperature 131° F
