lifelong Inferno User manual
7-Preset
Cooking Modes
Safety
Sensor
Anti Skid
feet
Pan Sensor
Technology
1 YEAR
WARRANTY
Lifelong
Inferno
Induction
Cooktop
2000W
Consumer Warranty Card
Dear Customer,
Thank you for choosing a Lifelong consumer product. All Lifelong Consumer
products are designed and manufactured to the highest standards to deliver high
quality performance, as well as easy installation and use. At Lifelong, we believe in
providing not only service, but adding value to your purchase. The warranty has
therefore been designed especially for you with your interest at heart.
Warranty Service
All Lifelong consumer products are covered against manufacturing defects from
them date of purchase.
Name of the product:
Model:
Warranty coverage: 1 year
Please note: Purchase receipt is necessary for warranty verification.
Customer Details
Name:
Address:
Home Number:
Office Number:
E-mail Address:
Product Details
Model No.:
Serial No.:
Purchase Date:
Invoice Number:
Online Site:
Please log onto to www.lifelongindiaonline.com and complete the online warranty form with your
personal and product details within 14 days.
2
FEATURES Inferno Induction
Reliable Tact Switch operation Yes
Auto Detection Yes
Auto Cool Function Yes
Under Voltage & Over
voltage protection Yes
Anti Magnetic Glass plate Yes
Variable Heat level for
customized Indian cooking 7 levels
Intelligent preset functions Yes
Digital Timer Display Yes
Input Voltage Display Yes
Electricity Reading Yes
PRODUCT FEATURES
PRODUCT FEATURES
1) Air Vent
2) Power Cord
3) Glass Top
4) Cooking area
5) Control panel
6) 7 segment display
1
2
3
4
5
6
Terms and Conditions:
1.This warranty is void if:
a. The completely filled warranty card is not presented
at the time of servicing the product.
b. The product is not operated according to the
instructions given under the user manual.
C. Damages are caused by lightning, abnormal
voltage, water or other liquid intrusion, fire, flood,
accident, negligence or improper handling.
d. Product has been damaged due to installation,
repairs, alterations or modifications by unauthorized
service organizations or persons.
e. Product label specifying the model number, serial
number and production code has been removed
and altered.
f. Defects or parts requiring replacement due to
ordinary wear and tear, corrosion, rust or stains,
scratches, dents on the casing or paintwork of the
product.
g. Claims damaged and/or missing parts
(accessories) after 7 days from the original date of
goods received.
h. Defects or faults in product which have been used
for commercial/industrial purposes or which have
been rented/leased or have been otherwise subject
to non-household/non-domestic use.
2. Repairs or replacements will be carried out by
authorized service provider.
3. During the limited warranty period, Lifelong or its
authorized service provider will repair without charge
the defective unit inclusive of labor and parts and
restore the unit to its optimum working condition. All
defective parts used for the warranty repair should be
surrendered to Lifelong and/or its authorised servicer.
4. All expenses incurred in collecting the unit (s) or
part(s) thereof from authorised service provider as will
as any other expenses and incidentals will be borne
by the consumer.
5. Lifelong obligations are limited to the repair and
replacement of the defective product. Except as set
forth above, there are no other express or implied
warranty and all warrantied, conditions or other terms
implied by statute or common law (including any
warranty of satisfactory quality, merchantability or
fitness for a particular purpose) are excluded to the
fullest extent permitted by the lass.
6. Lifelong total liability for damages relating to or arising
out of the purchase or use of the product regardless of
the type or cause of such damage of the form of
characterization of the claim asserted (e.g. contract or
tort) shall not exceed the original purchase price paid
for the product.
7. However in no event shall Lifelong and Lifelong
authorized distributors be liable for any punitive, special
incidental, indirect or consequential losses or damages
whatsoever (including without limitation, damages for
the loss of revenue, business, profits, goodwill, or
contracts, business interruptions, loss of business
information or any other pecuniary loss.) Whether or
not Lifelong has been advised of the possibility of such
damages.These limitations shall apply not with
standing the failure of the essential purpose of any
limited warranty. This limited warranty does not affect
consumer's statutory rights under the law.
8. No carrier, dealer or employee is thereof authorized to
make modifications to this warranty and you should not
reply on any such representation. Lifelong reserves the
right to amend the terms and conditions if necessary.
Manufactured for & Marketed by :
Lifelong Online Retail Private Limited
Made in China
For queries and complaints:
www.lifelongindiaonline.com
3
COLOURS BLUE GREY
Rated Power (W) 2000 W 2000 W
Voltage/ Frequency 220-240 VAC / 50 Hz 220-240 VAC / 50 Hz
NOTE: DESIGNS & SPECIFICATIONS ARE SUBJECTED TO
CHANGE WITHOUT PRIOR NOTICE.
KNOW YOUR INDUCTION
ATTENTION: Before use, please check for the plug and socket are in good
condition. Before positioning the pot, please clear off marks/dirt from pot
surface & glass panel. Put pot at the centre& never put empty pot on glass
panel.
POWER & FUNCTION SELECTION
•Plug in induction cooktop into power supply into supply and switch on. Short
sound is heard & Mains voltage is displayed as eg U 230. This is standby
mode.
•Press "ON/OFF" switch and unit will switch on to "MANUAL" mode by
default. Press "MENU" switch repeatedly for desired cooking options. Once
desired cooking function is selected unit will start to operate on set cooking
functions.
In use, never leave it unattended for a long time. If leaving
is necessary, make sure that water inside the pot can
prevent dry-burning due to excessively little water from
damage to the pot.
Never use the induction cooktop in narrow space, and do
not have foreign objects to block the air entry and air vent,
as this may affect radiation.
12
PRODUCT DISPOSAL GUIDELINES
For the purpose of recycling to facilitate effective utilization of resourc-
es, please return this product to a nearby authorized collection center
/ registered dismantler or recycler while disposing off this product. In
case of further assistance, you may contact nearest authorized
service center.
4
•If, after selection of a function, to adjust power, press " + " or " - " key.
•Individual function may be & limited in power adjustment because of
effect on cooking.
•For some functions, the induction cooktop can, during heating, control its
temperature automatically based on cooking effect.
TEMPERATURE/POWER ADJUSTMENT
•If no timing is conducted or there is no such function the induction
cooktop will heat based on default cooking time.(for detailed time duration,
refer to "Cooking mode instructions")
• To adjust the cooking time press "Time/Preset" switch, after the numbers
on the display screen flash, press switch to carry out the timing
adjustment.
• When adjustment is finished, the number on the display will be shown
after blinking for 5 secs.The induction cooktop will start counting down.
• After work time elapses, the cooktop will shut down automatically. To
shut down ahead of time; press "ON/OFF" switch.
TIMER ADJUSTMENT
• After work time elapses, the cooktop will shut down automatically. To shut
down ahead of time; press "ON/OFF" switch. Preset time adjustment
When the unit is connected to main supply, a short audible signal is heard
and led for "ON/OFF" switch glows.
• For the purpose of delay start, press "timer/preset" switch "0000" will start
blinking.
TEMPERATURE AND TIME CAN BE ADJUSTED
SPECIAL ATTENTION
During and after using the induction cooktop, keep it clean.
Prevent the machine from insects, dust and damp and
stop black beetles from entering and causing short circuit;
when not in use for a long time, it is recommended to be
stored in a plastic bag after cleaning.
Never splash water or soup into the induction cooktop to
prevent the circuit board from shorting.
After using, unplug the unit to avoid damage to electronic
elements or even fire due to long-term on-position. After
the ceramic panel cools, clean it with soft cloth dipped with
little detergent rather than water.
It is recommended to use a high-power socket rather than
a defective one. Do not share a socket with high-power
appliances such as air conditioners and electric stoves to
avoid over-current from causing fire.
Never use this induction cooktop on a table or bottom plate
made of iron or stainless steel, as this may cause burning
of the unit.
Because the bearing of the ceramic panel for the induction
cooktop is limited, never put too heavy objects on the
ceramic panel, as this may cause damage to the plastic lid
and ceramic panel.
11
5
• Press "" or "" switch to adjust timings. Timing can be adjusted from 1Min
to 23Hrs 59Min.
• After the adjustment of desired timing, set timing will blink for 5sec & the
time will be registered. •After the time adjustment, default manual mode
is selected. To change, press desired cooking function to be used as per
requirement. After the countdown time elapses the induction cooker will
resume heating automatically.
MAINTENANCE
1. Clean after every use Before cleaning, disconnect Plug and wait till the
cooktop cools down completely.
2. Clean the outside body of cooktop and the control panel with a damp cloth.
3. Do not wash or immerse Cooktop in water
4. Use clean Pots Nessels to avoid discolouration or stains on the ceramic
Plate.
5. To Clean the ceramic plate, first wipe it with a wet cloth or sponge using
water & mild detergent Finally wipe it dry with a soft damp cloth.
6. When not in use for a long time, please unplug the unit and protect
against dust & insects.
COOKWARE KNOWLEDGE
Use the Recommended Cookware for efficient cooking.
Stainless Steel Pots Enamelled SS Kettles Iron Kettles Iron Pans
with magnetic base with magnetic base.
•Min Diameter of Pan/Pot - 120 mm, Max Diameter of Pan/Pot - 200 mm.
•Material - Iron, SUS304,SUS430 10
Never have a child to operate
this unit alone so as to avoid
any dangers such as scalding.
A person wearing a heart
pacemaker shall consult a
doctor before using this product.
Avoid using great force to
strike the ceramic panel as this
may cause damage. In the event
of damage, please stop using,
and send it to a service facility for
repair.
IMPORTANT SAFEGUARDS
Do not use this unit on a carpet, table cloth or tissue, as this may
block the air entry and air vent and affect radiation caution from the
cavity.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction. concerning use of the appliance by a
person responsible for their safety.
The adult should supervise the children in order to make surethe
children can Warning not play with the appliance.
Metal objects such as knife, fork, spoon and lid should not be placed
on the surface of glass panel, because they may Warning become
hot.
This appliance is intended to be used in household and similar
applications such as: -staff kitchen areas in shops, offices Warning
and other working environments; -farm houses;-by clients in hotels,
motels and other residential type environments; bed and breakfast
type environments.
If the supply cord is damaged, it must be replaced by a special cord
or assembly Warning available from the manufacture or its service
agent.
6
Do not use
Convex bottom Pots Pots with stands Aluminum /Copper Pots Heat-resistant Glass Pots
OPERATION FUNCTIONS
FUNCTION PROCEDURE
MANUAL (Default
Function)
FRY
ROTI/DOSA
CURRY/SABJI
When "Manual" is selected, "1600" indicating the
wattage is displayed. Wattage adjustment can be
done from 200W to 2000W by using M or' key.
Cooking time can be adjusted from 1 min to
3Hr.Default cooking time is 2Hr.
When the "Fry" function is selected, "270°C"
indicating the wattage is displayed. Temperature
adjustment can be done from "60°C" to "270°C".
Cooking time can be adjusted from 1 minute to
3Hr.Default cooking time is 2Hr.
When the "Roti/Dosa" function is selected,
"200°C" indicating the temperature is
displayed.Temperature adjustment can be done
from "60°C" to "270°C". Cooking time can be
adjusted from 1 minute to 3Hr.Default cooking time
is 2Hr.
When the "Curry/Sabji" function is selected,
"2000" indicating the wattage is displayed.
Wattage adjustment can be done from "200W" to
"2000W". Cooking time can be adjusted from
9
Please use an individual socket
of more than 10A, and never
use a universal socket or share a
socket with other appliances.
During the use, the induction
cooker shall be placed horizon-
tally, with at least 10 cm from its
sides and back to the wall.
Never use the induction cooker
in high temperature environ-
ments such as near a gas stove
or kerosene stove.
Never directly wash the
induction cooker with water so
as to avoid dangers.
Be sure not to insert foreign
objects such as an iron wire or
block the air vent and air entry so
as to avoid dangers.
Never heat the iron piece on
the ceramic plate so as to avoid
any dangers due to high temper-
ature.
For sealed foods such as
canned goods, please do not
heat them before opening their
covers so as to avoid any
dangers of explosion due to
heating expansion.
Never use the induction cooker
on a gas stove (magnetic force
lines may heat iron parts of the
gas stove) to avoid accidents.
Never contact the control panel
with a sharp article to prevent
from any damage such as crack
to the control panel.
Never place the induction
cooker on any metal (iron,
aluminum, etc.) platform, includ-
ing a non-metal cushion less than
10cm on the upper pad.
Never have the induction
cooker to work without food
inside, otherwise its operational
performance may be affected
and even danger may happen.
The induction cooker shall be
cleaned regularly to prevent
foreign objects from entering the
fan. This can influence the
normal work.
Never touch the ceramic panel
when it is in use.
If the power cord is damaged,
it must be replaced by a special
one.
ATTENTION
7
NOODLES
MILK/TEA
from 1 min to 3Hrs.Delayed timer setting can be
done for 1,in to 23:59Hrs. Default cooking time is
25min continue,95min ON/OFF.
When the "Noodles" function is selected, "1800"
indicating the wattage is displayed. Wattage
adjustment can be done from "200W" to
"2000W".Cooking time can be adjusted from 1
minute to 3Hrs.Default cooking time is 15min.
When the "Milk/Tea" function is selected, "1600"
indicating the wattage is displayed. Wattage
adjustment can be done from "200W" to
"2000W".Cooking time can be adjusted from 1 min
to 3Hrs.Default cooking time is 12min
continue,23min ON/OFF.
SYMPTOM
Vessel size is not suitable or no vessel
Input voltage is low (125±10V)
Input voltage is high (270±10V)
Temperature under the glass is high
IGBT temperature is high
Sensor under IGBT is open / short
Sensor under glass is open / short
TROUBLE SHOOTING
ERROR
E0
E1
E2
E3
E4
E5
E6
8
Possible cause
• Please check if pot is kept on cooktop or
Non induction compatible pot is placed
or Pot is placed at centre of cooktop plate
• Please check if surrounding
temperature is very high.
• Check if the air inlet/outlet is covered.
• Set time/default time has lapsed.
• Please check if plug is properly plugged.
• Please check if noise is from cooling
fan.
Problem
There is audible signal &
display shows "EO" blinking
Stops heating during use
No response from switch/key
Abnormal noise during use
The above are indicators of common failures. If the problem persists call
customer care. Please do not disassemble the unit to avoid any danger
and damage to the induction cooktop.
IMPORTANT SAFEGUARDS
Read the Instruction Manual carefully before use.
Close supervision is necessary when appliances are near children.
• Operate carefully in accordance with the requirements.
• Such operation is not allowed.
• Be sure to operate like this.
IMPORTANT SAFEGUARDS
Table of contents
Other lifelong Cooktop manuals
