Light speaker E2 Operating instructions
1
Tech Support: 1-800-268-1172
OWNER’S MANUAL
and installation instructions
State-of-the-Art Wireless SubWoofer
Installs in 5 minutes or less!
NOTE: This SubWoofer can only be used with the e² wireless LightSpeaker® transmitter. It
cannot be used or operated without the LightSpeaker® transmitter.
e2 Sub Manual English.indd 1 10-07-28 11:36 AM
2
Tech Support: 1-800-268-1172
EU Compliance Information
Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive 73/23/EEC and
2006/95/EC; Conforms to European Union EMC Directives 89/336/EEC and 2004/108/EC.
WEEE Notice
Note: This mark applies only to countries within the European Union (EU) and Norway.
This application is labeled in accordance with European Directive 2002/96/EC
concerning waste electrical and electronic equipment (WEEE). This label indicates
that this product should not be disposed of with household waste. It should be
deposited at an appropriate facility to enable recovery and recycling.
The exclamation point, within an equilateral triangle, is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
The lightning ash with arrowhead symbol within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufcient magnitude to constitute a risk of
electrical shock to persons.
WARNING: To reduce the risk of re or electrical shock, do not expose this apparatus to rain
or moisture.
WARNING: No naked ame sources – such as candles – should be placed on the product.
WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to
life. No user-serviceable parts inside. Refer all servicing to qualied service personnel.
Place the equipment near a main power supply outlet and make sure that you can easily access
the power breaker switch.
WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the
back panel or included power supply of the product. Operation from other voltages other than
those indicated may cause irreversible damage to the product and void the product’s warranty.
The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into
voltages in which the product was not designed to operate. If the product is equipped with a
detachable power cord, use only the type provided with your product or by your local distributor
and/or retailer. If you are unsure of the correct operational voltage, please contact your local
distributor and/or retailer.
AMPLIFIER REQUIREMENTS
Due to the high output levels these speakers are capable of reproducing, exercise
caution with the volume control. Excessive volume over long periods of time can
permanently damage your hearing. Overdriving your amplier could also damage
your speakers. Check with your dealer to make sure your particular amplier is best
suited to your application. We want you listening for a lifetime.
CARE AND CLEANING
Your speakers have a durable nish that should only require dry dusting. Avoid use of abrasive or
solvent-based cleaners and harsh detergents. The brush attachment of your vacuum or a damp
cloth should remove any dust from your speaker grilles.
The exclamation point, within an equilateral triangle, is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the literature
accompanying the product.
The lightening ash with arrowhead symbol within an equilateral triangle, is intended to alert
the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufcient magnitude to constitute a risk of electrical shock to persons.
WARNING: To reduce the risk of re or electrical shock, do not expose this apparatus to rain or
moisture.
WARNING No naked ame sources - such as candles - should be placed on the product.
WARNING - Do not open! Risk of electrical shock voltages in this equipment are hazardous to life. No
user-serviceable parts inside. Refer all servicing to qualied service personnel.
Place the equipment near a main power supply outlet and make sure that you can easily access the
power breaker switch.
WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the back
panel or included power supply of the product. Operation from other voltages other than those
indicated may cause irreversible damage to the product and void the product’s warranty. The use
of AC Plug Adapters is cautioned because it can allow the product to be plugged with a detachable
power cord, use only the type provided with your product or by your local distributor and/or retailer. If
you are unsure of the correct operational voltage, please contact your local distributor and/or retailer.
AMPLIFIER REQUIREMENTS
Due to the high output levels these speakers are capable of reproducing, exercise caution with the
volume control. Excessive volume over long periods of time can permanently damage your hearing.
Overdriving your amplier could also damage your speakers. Check with your dealer to make sure
your particular amplier is best suited to your application. We want you listening for a lifetime.
CARE AND CLEANING
Your speakers have a durable nish that should only require dry dusting. Avoid use of abrasive or
solvent-based cleaners and harsh detergents. The brush attachment of your vacuum or a damp cloth
should remove any dust from your speaker grilles.
EU Compliance Information
Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive 73/23/EEC and
2006/95/EC; Conforms to European Union EMC Directive 89/336/EEC and 2004/108/EC.
WEEE Notice
Note: This mark applies only to countries within the European Union (EU) and Norway.
This application is labeled in accordance with European Directive 2002/96EC
concerning waste electrical and electronic equipment (WEEE). This label
indicates that this product should not be disposed of with household waste. It
should be deposited at an appropriate facility to enable recovery and recycling.
EU Compliance Information
Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive 73/23/EEC and
2006/95/EC; Conforms to European Union EMC Directives 89/336/EEC and 2004/108/EC.
WEEE Notice
Note: This mark applies only to countries within the European Union (EU) and Norway.
This application is labeled in accordance with European Directive 2002/96/EC
concerning waste electrical and electronic equipment (WEEE). This label indicates
that this product should not be disposed of with household waste. It should be
deposited at an appropriate facility to enable recovery and recycling.
The exclamation point, within an equilateral triangle, is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
The lightning ash with arrowhead symbol within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufcient magnitude to constitute a risk of
electrical shock to persons.
WARNING: To reduce the risk of re or electrical shock, do not expose this apparatus to rain
or moisture.
WARNING: No naked ame sources – such as candles – should be placed on the product.
WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to
life. No user-serviceable parts inside. Refer all servicing to qualied service personnel.
Place the equipment near a main power supply outlet and make sure that you can easily access
the power breaker switch.
WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the
back panel or included power supply of the product. Operation from other voltages other than
those indicated may cause irreversible damage to the product and void the product’s warranty.
The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into
voltages in which the product was not designed to operate. If the product is equipped with a
detachable power cord, use only the type provided with your product or by your local distributor
and/or retailer. If you are unsure of the correct operational voltage, please contact your local
distributor and/or retailer.
AMPLIFIER REQUIREMENTS
Due to the high output levels these speakers are capable of reproducing, exercise
caution with the volume control. Excessive volume over long periods of time can
permanently damage your hearing. Overdriving your amplier could also damage
your speakers. Check with your dealer to make sure your particular amplier is best
suited to your application. We want you listening for a lifetime.
CARE AND CLEANING
Your speakers have a durable nish that should only require dry dusting. Avoid use of abrasive or
solvent-based cleaners and harsh detergents. The brush attachment of your vacuum or a damp
cloth should remove any dust from your speaker grilles.
EU Compliance Information
Eligible to bear the CE mark, Conforms to European Union Low Voltage Directive 73/23/EEC and
2006/95/EC; Conforms to European Union EMC Directives 89/336/EEC and 2004/108/EC.
WEEE Notice
Note: This mark applies only to countries within the European Union (EU) and Norway.
This application is labeled in accordance with European Directive 2002/96/EC
concerning waste electrical and electronic equipment (WEEE). This label indicates
that this product should not be disposed of with household waste. It should be
deposited at an appropriate facility to enable recovery and recycling.
The exclamation point, within an equilateral triangle, is intended to alert the user to
the presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.
The lightning ash with arrowhead symbol within an equilateral triangle, is intended
to alert the user to the presence of uninsulated “dangerous voltage” within the
product’s enclosure that may be of sufcient magnitude to constitute a risk of
electrical shock to persons.
WARNING: To reduce the risk of re or electrical shock, do not expose this apparatus to rain
or moisture.
WARNING: No naked ame sources – such as candles – should be placed on the product.
WARNING: Do Not Open! Risk of Electrical Shock. Voltages in this equipment are hazardous to
life. No user-serviceable parts inside. Refer all servicing to qualied service personnel.
Place the equipment near a main power supply outlet and make sure that you can easily access
the power breaker switch.
WARNING: This product is intended to be operated ONLY from the AC Voltages listed on the
back panel or included power supply of the product. Operation from other voltages other than
those indicated may cause irreversible damage to the product and void the product’s warranty.
The use of AC Plug Adapters is cautioned because it can allow the product to be plugged into
voltages in which the product was not designed to operate. If the product is equipped with a
detachable power cord, use only the type provided with your product or by your local distributor
and/or retailer. If you are unsure of the correct operational voltage, please contact your local
distributor and/or retailer.
AMPLIFIER REQUIREMENTS
Due to the high output levels these speakers are capable of reproducing, exercise
caution with the volume control. Excessive volume over long periods of time can
permanently damage your hearing. Overdriving your amplier could also damage
your speakers. Check with your dealer to make sure your particular amplier is best
suited to your application. We want you listening for a lifetime.
CARE AND CLEANING
Your speakers have a durable nish that should only require dry dusting. Avoid use of abrasive or
solvent-based cleaners and harsh detergents. The brush attachment of your vacuum or a damp
cloth should remove any dust from your speaker grilles.
e2 Sub Manual English.indd 2 10-07-28 11:36 AM
3
Tech Support: 1-800-268-1172
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions – All the safety and operating instructions should be read before
this product is operated.
2. Keep these instructions – The safety and operating instructions should be retained for
future reference.
3. Heed all warnings – All warnings on the appliance and in the operating instructions
should be adhered to.
4. Follow all instructions – All operating and use instructions should be followed.
5. Do not use this apparatus near water – The appliance should not be used near water
or moisture – for example, in a wet basement or near a swimming pool, and the like.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacture’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding plug. A polarized plug
has two blades with one wider than the other. A grounding plug has two blades and a
third grounding prong. The wide blade or the third prong is provided for your safety.
If the provided plug does not fit into your outlet, consult an electrician for replacement
of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at the plugs,
convenience receptacles, and at the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart or rack is used, use caution when moving the cart/
apparatus combination to avoid injury from tip-over.
13. Unplug the apparatus during lightning storms or when unused for long periods of time.
14. Refer all servicing to qualified personnel. Servicing is required when the apparatus
has been damaged in any way, such as power supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus has been exposed to rain or moisture,
does not operate normally, or has been dropped.
15. WARNING - to reduce the risk of fire or electric shock, do not expose this apparatus
to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that
objects filled with liquids, such as vases, shall not be placed on the apparatus.
16. WARNING: The mains plug/appliance coupler is used as disconnect device, the
disconnect device shall remain readily operable.
17. This equipment is a Class II or double insulated electrical appliance. It has been
designed in such a way that it does not require a safety connection to electrical earth.
e2 Sub Manual English.indd 3 10-07-28 11:36 AM
4
Tech Support: 1-800-268-1172
Congratulations
Thank you for your purchase of the e² SubWoofer! Everything
about this SubWoofer has been designed to work perfectly with
your e² LightSpeaker
®
system; from the small, inconspicuous
shape to state-of-the-art wireless technology, this subwoofer
will virtually disappear in your room while delivering rich, deep
bass. Place it in a corner or behind a couch, or favorite chair
— plug in to the closest electrical outlet. There are no wires to
run and no special tuning required. Just plug and play! Use the
second zone capability so that others in different rooms can
listen to a second music source at the same time. Or switch
between the sources to listen to the music you like best in one
room or all rooms. To learn more about the capabilities of your
e² LightSpeaker
®
system visit us at: www.lightspeaker.ca.
SubWoofer Overview
e2 Sub Manual English.indd 4 10-07-28 11:36 AM
5
Tech Support: 1-800-268-1172
Table of Contents
SubWoofer Overview............................................................................6
What is in this Box?................................................................................7
Installation Considerations................................................................8
Installation Instructions.......................................................................9
Specifications......................................................................15
Warranty...............................................................................................16
FCC Declaration...................................................................................17
Technical Support Information...................................Back Cover
e2 Sub Manual English.indd 5 10-07-28 11:36 AM
6
Tech Support: 1-800-268-1172
SubWoofer Overview
This wireless SubWoofer is
intended to install in just a few
minutes. The system can use
up to 4 wireless SubWoofers
(when used with a
e²
LightSpeaker
®
transmitter)
to provide bass to your entire
living area.
Additionally, the system can
be expanded by adding our patented LightSpeakers
®
.
These LightSpeakers
®
install in minutes and fit into 5” and
6” recessed ceiling cans as well as table lamps, hanging
lamps or any standard Edison socket. They can provide
“green” lighting and outstanding sound throughout your
home. The LightSpeakers
®
are available from your retailer
or at www.lightspeaker.ca.
The entire system provides even greater flexibility to you
as the owner since you can take it with you if you move. It
leaves no trace that the system was ever installed or used.
e2 Sub Manual English.indd 6 10-07-28 11:36 AM
7
Tech Support: 1-800-268-1172
NOTE: This SubWoofer can only be used with the
e²
wireless LightSpeaker
®
transmitter. It cannot be used or
operated without the LightSpeaker
®
transmitter.
What’s in this Box
Wireless SubWoofer
Owner’s Manual
Power Cord
Remote and transmitter also sold separately.
e2 Sub Manual English.indd 7 10-07-28 11:36 AM
8
Tech Support: 1-800-268-1172
Installation Considerations
Your
e²
Wireless SubWoofer can be placed in any area or
zone where you would like additional bass to your existing
LightSpeaker
®
distributed audio system. The only wiring
required is to plug it into a standard electrical outlet.
This SubWoofer will perform perfectly adding rich, deep
bass from wherever it is placed in your room, however,
it will provide the most bass if it is placed in or close to a
room corner. Ideal positioning would be to place it in a
room corner and not further then 4 feet or not less than
7 feet from one of your LightSpeakers
®
or AudioRocks.
Distances between 4 and 7 feet may require the PHASE
switch to be changed from 0° to 180°. Please see Page
11 of the manual for instructions on how to do this. Your
e²
wireless SubWoofer will operate up to 50 feet (in any
direction) away from your LightSpeaker
®
transmitter.
Please take a few minutes to read this manual. Following
simple setup instructions, will ensure you get the most
from your LightSpeaker
®
SubWoofer.
e2 Sub Manual English.indd 8 10-07-28 11:36 AM
9
Tech Support: 1-800-268-1172
Installation Instructions
Step 1: Please read all safety instructions at the start of this
manual.
Step 2: Decide where you would like to add additional bass
to your LightSpeakers
®
and note the zone in which those
LightSpeakers
®
are located.
Step 3:
Attach the power cord to the back of your SubWoofer
and plug it into the nearest electrical outlet. Be certain the power
switch on the rear of your SubWoofer is set to the “OFF” position.
Step 4: Pairing your SubWoofer to the LightSpeaker
®
System.
Pairing is the process of “teaching” your transmitter to
recognize your SubWoofer as part of the LightSpeaker
®
system. It’s essential and only takes a couple of minutes.
A) Determine which zone your SubWoofer will be placed into
(See “Setting Up Zones” in your LightSpeaker
®
owner’s manual).
B) Set the zone switch on the back of your SubWoofer to either
Zone 1 or Zone 2 depending on which zone it is to be located in.
+
+
+
+
110 - 240 V AC 50/60Hz
CONFORMS TO
UL STD. 1993
CERTIFIED TO
CAN/CSA
STD. E968
CONFORMS
TO ANSI/UL
STD. 60065
CERTIFIED TO
CAN/CSA STD.
C22.2 No. 60065
CAUTION:
RISK OF ELECTRICAL SHOCK
USE IN DRY LOCATIONS ONLY
ATTENTION:
RISQUE DE CHOC ÉLECTRIQUE
Utiliser Seulement Dans des
Endroits Secs
SUBWOOFER 6.2.0
Model W 6.2.0
Designed in USA
Manufactured in China
XXXXXXX
Low Pass Crossover
80 Hz 100 Hz 120 Hz
Phase Zone
0° 180° 1 2
Volume
Pairing
ON
OFF
POWER
Status
e2 Sub Manual English.indd 9 10-07-28 11:36 AM
10
Tech Support: 1-800-268-1172
C) On your LightSpeaker
®
transmitter, find and press the
“PAIRING Button” located on the back of the transmitter. The
status lights on the front of the transmitter will begin to flash.
Note:
When these lights are flashing, your transmitter is in pairing
mode; and you have approximately 30 seconds to complete the
next two steps. If you are unable to complete these steps, simply
push the pairing button on the transmitter again.
D) Set the Power switch, located on the back panel of your
subwoofer, to “ON”. While the lights are still flashing on the
transmitter, push the “pairing button” on the back panel of your
e²
Wireless SubWoofer. When the “STATUS” LED turns from
Red to Green the pairing is complete.
+
+
+
+
+
110 - 240 V AC 50/60Hz
CONFORMS TO
UL STD. 1993
CERTIFIED TO
CAN/CSA
STD. E968
CONFORMS
TO ANSI/UL
STD. 60065
CERTIFIED TO
CAN/CSA STD.
C22.2 No. 60065
CAUTION:
RISK OF ELECTRICAL SHOCK
USE IN DRY LOCATIONS ONLY
ATTENTION:
RISQUE DE CHOC ÉLECTRIQUE
Utiliser Seulement Dans des
Endroits Secs
SUBWOOFER 6.2.0
Model W 6.2.0
Designed in USA
Manufactured in China
XXXXXXX
Low Pass Crossover
80 Hz 100 Hz 120 Hz
Phase Zone
0° 180° 1 2
Volume
Pairing
ON
OFF
POWER
Status
+
+
+
+
+
110 - 240 V AC 50/60Hz
CONFORMS TO
UL STD. 1993
CERTIFIED TO
CAN/CSA
STD. E968
CONFORMS
TO ANSI/UL
STD. 60065
CERTIFIED TO
CAN/CSA STD.
C22.2 No. 60065
CAUTION:
RISK OF ELECTRICAL SHOCK
USE IN DRY LOCATIONS ONLY
ATTENTION:
RISQUE DE CHOC ÉLECTRIQUE
Utiliser Seulement Dans des
Endroits Secs
SUBWOOFER 6.2.0
Model W 6.2.0
Designed in USA
Manufactured in China
XXXXXXX
Low Pass Crossover
80 Hz 100 Hz 120 Hz
Phase Zone
0° 180° 1 2
Volume
Pairing
ON
OFF
POWER
Status
e2 Sub Manual English.indd 10 10-07-28 11:36 AM
11
Tech Support: 1-800-268-1172
Step 5: Setting the Phase Switch.
This will ensure that your
e²
SubWoofer sounds it’s very best in
your favorite listening position. It is easiest to do with two people:
One at the listening position and the other at the SubWoofer.
A) Your
e²
Wireless SubWoofer is set up and ready to play. Play
a favorite piece of music, ideally one with a lot of bass to ensure
it’s functioning properly.
B) With one person at the listening position or some convenient
position not too close to the subwoofer (6 ft. to 10 ft. back is fine)
and the other person operating the phase, switch on the back of
the SubWoofer.
+
+
+
+
110 - 240 V AC 50/60Hz
CONFORMS TO
UL STD. 1993
CERTIFIED TO
CAN/CSA
STD. E968
CONFORMS
TO ANSI/UL
STD. 60065
CERTIFIED TO
CAN/CSA STD.
C22.2 No. 60065
CAUTION:
RISK OF ELECTRICAL SHOCK
USE IN DRY LOCATIONS ONLY
ATTENTION:
RISQUE DE CHOC ÉLECTRIQUE
Utiliser Seulement Dans des
Endroits Secs
SUBWOOFER 6.2.0
Model W 6.2.0
Designed in USA
Manufactured in China
XXXXXXX
Low Pass Crossover
80 Hz 100 Hz 120 Hz
Phase Zone
0° 180° 1 2
Volume
Pairing
ON
OFF
POWER
Status
e2 Sub Manual English.indd 11 10-07-28 11:36 AM
12
Tech Support: 1-800-268-1172
C) While listening to the deepest bass notes in the music, flip the
phase switch back and forth while the listener determines which
setting produces the most bass. Leave the switch in the position
with the most bass.
D) Keep in mind there is no wrong position for this switch, and if
you can’t reliably hear a difference in either position then it will not
matter which position the switch is left at.
Step 6: Setting the Crossover Frequency.
There are three possible crossover frequencies to choose from:
80Hz, 100Hz and 120Hz. The one you choose will depend on
where your SubWoofer is located and your personal taste.
Remember, if you find one setting you like better than another,
then leave it at the setting you like best. The closer your
e²
Wireless SubWoofer is to the corner, the LOWER the crossover
will be set. There is a lot of variability in rooms so choose the
crossover frequency that sounds right to you. If you cannot hear
a difference then the frequency you choose will not make any
difference.
110 - 240 V AC 50/60Hz
CONFORMS TO
UL STD. 1993
CERTIFIED TO
CAN/CSA
STD. E968
CONFORMS
TO ANSI/UL
STD. 60065
CERTIFIED TO
CAN/CSA STD.
C22.2 No. 60065
CAUTION:
RISK OF ELECTRICAL SHOCK
USE IN DRY LOCATIONS ONLY
ATTENTION:
RISQUE DE CHOC ÉLECTRIQUE
Utiliser Seulement Dans des
Endroits Secs
SUBWOOFER 6.2.0
Model W 6.2.0
Designed in USA
Manufactured in China
XXXXXXX
Low Pass Crossover
80 Hz 100 Hz 120 Hz
Phase Zone
0° 180° 1 2
Volume
Pairing
ON
OFF
POWER
Status
+
+
+
+
e2 Sub Manual English.indd 12 10-07-28 11:36 AM
13
Tech Support: 1-800-268-1172
A) As in the case with the phase switch this step is easier to
perform with two people. Sit or stand in your preferred listening
position while another person pushes the button immediately
below the LEDs that mark the three different crossover
frequencies. Each time the button is pushed the crossover will
cycle to the next frequency first 80Hz (LED will light up), then
100Hz, and finally 120Hz. The next push of the button will light
the 80Hz frequency again.
B) Choose the setting that sounds the best and leave the
crossover set to this frequency. This can be changed at any
time in the future and will not affect the operation of either your
SubWoofer or your LightSpeaker
®
system.
Step 7: Setting the volume control.
Your
e²
Wireless SubWoofer has a built in volume control so it
can be matched to different numbers of LightSpeakers
®
. The
more LightSpeakers
®
in the listening area, the higher the volume
should be set.
+
+
+
+
+
+
110 - 240 V AC 50/60Hz
CONFORMS TO
UL STD. 1993
CERTIFIED TO
CAN/CSA
STD. E968
CONFORMS
TO ANSI/UL
STD. 60065
CERTIFIED TO
CAN/CSA STD.
C22.2 No. 60065
CAUTION:
RISK OF ELECTRICAL SHOCK
USE IN DRY LOCATIONS ONLY
ATTENTION:
RISQUE DE CHOC ÉLECTRIQUE
Utiliser Seulement Dans des
Endroits Secs
SUBWOOFER 6.2.0
Model W 6.2.0
Designed in USA
Manufactured in China
XXXXXXX
Low Pass Crossover
80 Hz 100 Hz 120 Hz
Phase Zone
0° 180° 1 2
Volume
Pairing
ON
OFF
POWER
Status
e2 Sub Manual English.indd 13 10-07-28 11:36 AM
14
Tech Support: 1-800-268-1172
A) While listening to your LightSpeakers
®
, cycle the volume
control up and down, stopping at the point where it sounds best.
You may want to test this with several types of music to find the
setting that sounds best to you.
B) When the volume reaches the maximum available, the pairing
LED will begin to flash.
Your
e²
Wireless SubWoofer is now ready to use!
+
+
+
+
+
110 - 240 V AC 50/60Hz
CONFORMS TO
UL STD. 1993
CERTIFIED TO
CAN/CSA
STD. E968
CONFORMS
TO ANSI/UL
STD. 60065
CERTIFIED TO
CAN/CSA STD.
C22.2 No. 60065
CAUTION:
RISK OF ELECTRICAL SHOCK
USE IN DRY LOCATIONS ONLY
ATTENTION:
RISQUE DE CHOC ÉLECTRIQUE
Utiliser Seulement Dans des
Endroits Secs
SUBWOOFER 6.2.0
Model W 6.2.0
Designed in USA
Manufactured in China
XXXXXXX
Low Pass Crossover
80 Hz 100 Hz 120 Hz
Phase Zone
0° 180° 1 2
Volume
Pairing
ON
OFF
POWER
Status
e2 Sub Manual English.indd 14 10-07-28 11:36 AM
15
Tech Support: 1-800-268-1172
SubWoofer Specifications:
Driver
• 6.5” diameter, microcellulose fiber cone body with natural
rubber surround
Voice Coil Diameter
• 25.4 mm (1.0”)
Enclosure
• Type - Ported; Front-firing driver with Rear-firing port
• Material - Medium Density Fiberboard
• Finish - Matte black, with black cloth grill
Amplifier
• Type - Digital
• Power - 65 W average sine power
• Features
0-180 degree phase switch
Three position variable low pass filter:
Settings at 80 Hz, 100 Hz, 120 Hz
Digitial volume control gain profile precisely matches
subwoofer SPL to LightSpeaker
®
satellite SPL
at all volume settings
Frequency Response (-3 dB)
• 43 Hz - 120 Hz
Max SPL
• 102 dB - Output will match up to four LightSpeakers
®
Transmitter
• Frequncy 2.4 Ghz proprietary
• Range - up to 50 feet from the transmitter
• AC Input - 120 Vac - 230 Vac
RF Remote Range - Up to 100 feet
Dimensions
• Enclosure - 9.0” H x 9.0” W x 12.0” D + 0.625” for feet
• Transmitter - 8.0” L x 7.0” W x 2.5” H
• Remote - 3.2” L x 1.6” W x 0.8” H
e2 Sub Manual English.indd 15 10-07-28 11:36 AM
16
Tech Support: 1-800-268-1172
Warranty - Home and Commercial Audio (CANADA)
The Warranty below is valid only for sales to consumers in the Canada.
THE PRIESTMAN ELECTRONICS CORPORATION (“PRIESTMAN
ELECTRONICS”)
warrants this product to be free from defects in materials
and workmanship (subject to the terms set forth below) for a period of one
(1) year from the date of purchase. During the Warranty period,
PRIESTMAN
ELECTRONICS
will repair or replace (at
PRIESTMAN ELECTRONICS
option)
this product or any defective parts (excluding electronics and amplifiers). For
products that have electronics or amplifiers, the Warranty on those parts is
for a period of one (1) year from the date of purchase.
To obtain Warranty service, please contact the
PRIESTMAN ELECTRONICS
authorized dealer from which you purchased this product. If your dealer is not
equipped to perform the repair of your
PRIESTMAN ELECTRONICS
product, it
can be returned, freight paid, to
PRIESTMAN ELECTRONICS
for repair. Please
call
PRIESTMAN ELECTRONICS
at 1-800-
268-1172
for instructions. You will
need to ship this product in either its original packaging or packaging affording
an equal degree of protection.
Proof of purchase in the form of a bill of sale or receipted invoice from an
authorized dealer, which is evidence that this product is within the Warranty
period, must be presented or included to obtain Warranty service.
This Warranty is invalid if (a) the factory-applied serial number has been
altered or removed from this product or (b) this product was not purchased
from a
PRIESTMAN ELECTRONICS
authorized dealer. You may call 1-800-
268-1172 to confirm that you have an unaltered serial number and/or you
purchased from a
PRIESTMAN ELECTRONICS
authorized dealer.
This Warranty is only valid for the original purchaser and will automatically
terminate prior to expiration if this product is sold or otherwise transferred
to another party.
This Warranty does not cover cosmetic damage or damage due to misuse,
abuse, negligence, acts of God, accident, commercial use or modification of,
or to any part of, the product. This Warranty does not cover damage due to
improper operation, maintenance or installation, or attempted repair by anyone
other than
PRIESTMAN ELECTRONICS
or a
PRIESTMAN ELECTRONICS
dealer which is authorized to do
PRIESTMAN ELECTRONICS
warranty work.
Any unauthorized repairs will void this Warranty. This Warranty does not
cover product sold AS IS or WITH ALL FAULTS.
e2 Sub Manual English.indd 16 10-07-28 11:36 AM
17
Tech Support: 1-800-268-1172
REPAIRS OR REPLACEMENTS AS PROVIDED UNDER THIS WARRANTY ARE
THE EXCLUSIVE REMEDY OF THE CONSUMER.
PRIESTMAN ELECTRONICS
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES FOR BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON
THIS PRODUCT. EXCEPT TO THE EXTENT PROHIBITED BY LAW, THIS
WARRANTY IS EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESS AND
IMPLIED WARRANTIES WHATSOEVER, INCLUDING BUT NOT LIMITED TO,
THE WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PRACTICAL
PURPOSE.
Some states do not allow the exclusion or limitation of incidental or
consequential damages or implied warranties so the above exclusions may
not apply to you. This Warranty gives you specific legal rights, and you may
have other rights, which vary from state to state.
OUTSIDE THE UNITED STATES AND CANADA
The warranty on this product if it is sold to a consumer outside of the
United States or Canada shall comply with applicable law and shall be the
sole responsibility of the distributor that supplied this product. To obtain
any applicable warranty service, please contact the dealer from which you
purchased this product, or the distributor that supplied this product.
Questions? Call us!
Have a question about your
e²
speakers? Talk to the people who know
them best! We’re waiting to hear from you!
1-800-268-1172
Email us!
If you prefer, your questions and comments can be submitted by email,
too; you can count on rapid response and clear, concise answers.
WRITE THE PART NUMBER AND SERIAL NUMBER FROM YOUR
PRODUCT BOX HERE AND RETAIN FOR PRODUCT REGISTRATION
Part Number:______________________________________________
Serial Number:_____________________________________________
Register your product online
at www.lightspeaker.ca/register.
e2 Sub Manual English.indd 17 10-07-28 11:36 AM
18
Tech Support: 1-800-268-1172
THIS DEVICE COMPLIES WITH FCC RULES PART 15.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference and
(2) This device must accept any interference received including that which may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
CAUTION:
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment
e2 Sub Manual English.indd 18 10-07-28 11:36 AM
20
Tech Support: 1-800-268-1172
If you want to expand your light and sound system to
additional rooms, replace existing lights with LED lights
only or enjoy the same music outdoors as well as
indoors, visit www.lightspeaker.ca
For more detailed installation instructions go to
www.lightspeaker.ca
e² Technical Support
Toll Free: 1-800-268-1172
E-mail: [email protected]
Date: 7/12/10
Precor Consumer Electronics
107 Connie Crescent,
Concord, Ontario L4K 1L3
CM
Intertek
xxxxxxx
US
C
e2 Sub Manual English.indd 20 10-07-28 11:36 AM
Table of contents
