Light4Me COB PIXEL BAR 10 RGB User manual

LIGHT4ME COB PIXEL BAR 10 RGB
User Manual
This pixel COB Par can make very nice and bright effect as an architectural wall wash or for performance stages
where traditional stage lighting emit a lot of heat onto performers. Please read the manual before operation.
A. SPECIFICATION
1. Voltage:AC 100V-240V, 50Hz/60Hz
2. Power consumption: 105W
3. LED: COB 10*Tri-9W RGB
4. Beam angle: 55 degree
5. DMX channels: 3, 5, 30 CH
6. Operation mode: LCD display
7. Working temperature: -10~40℃
8. Dimension: 900*182.5*111mm
9. Net weight: 7kgs
10. Power linking: 4pcs@110V, 8pcs@240V
11. Lumen:
R
227lux@2m
G
303lux@2m
B
296lux@2m
Full on
767lux@2m
B. OPERATION
This fixture has six working modes; press the “MODE” button can switch the modes.
Built-in programs
Auto running
DMX mode
Master/slave
Sound-active
Static color

1. Built-in Programs Mode
1) Press “MODE” button enter built-in programs mode “Program Mode”, Press “SETUP” button enter into
programs effect “Program：01”, press “UP” or “ DOWN” button to select “Program：01- Program：19”.
2) When select the programs effect “Program：01”
a. Press “SETUP” button could set the static color effect “1.R Flash000”, could set the static color “1.R”,
“2.RG”, “3.G”, “4.GB”, “5.B” ,“6.RB”,“7.RGB”,“8.OFF” via “UP” or “DOWN” buttons.
b. Press “SETUP” button could set the strobe manu “1.R Flash000”, could set the strobe value “Flash000 -
Flash100” via “UP” or “DOWN” button.
3) When select the programs effect “RUN PROGRAM:02 - RUN PROGRAM:19”
a. Press “SETUP” button could set the built-in programs speed “Speed092 Flash000”, could set the speed value
“Speed000 - Speed100” via “UP” or “DOWN” button.
b. Press “SETUP” button could set the strobe menu “Speed092 Flash000”, could set the strobe value “Flash001
- Flash100” via “UP” or “DOWN” button.
2. Auto Running Mode
1) Press “MODE” button enter built-in programs mode menu “Auto Mode”.
2) The first time, press “SETUP” button enter to set auto running time “Run Time：002”, could set the times “Run
Time：001- Run Time：100” via “UP” or “DOWN” button.
3) The second time, press “SETUP” button enter to set programs speed menu “Speed092Flash000”, could set the
speed value “Speed000 - Speed100” via “UP” or “DOWN” button.
4) The third time, press “SETUP” button enter to set strobe menu “Speed092 Flash000”, could set the strobe
value “Flash000 - Flash100” via “UP” or “DOWN” button.
3. DMX Mode
1) Press “MODE” button enter DMX control mode menu “DMX Mode”.
2) The first time, press “SETUP” button enter to set DMX address value “Addr：001 Chan：03”, could set address
value “Addr：001- Addr：512” via “UP” or “DOWN” button.
3) The second time, press “SETUP” button enter to set DMX working mode menu “Addr：001 Chan：03”, could
set DMX working mode “Chan：03, Chan：05, Chan：30” via “UP” or “DOWN” button.
DMX Mode 1：“Chan：03”
CH1
CH2
CH3
NO.
DMX
value
FUNCTION
SPEED
FLASH
1
0
OFF
NO USE
NO USE
2
1—12
PROGRAM02
SPEED
0--255
FLASH
0--255
3
13—25
PROGRAM03
4
26—38
PROGRAM04
5
39—51
PROGRAM05
6
52—64
PROGRAM06
7
65—77
PROGRAM07

8
78—90
PROGRAM08
9
91—103
PROGRAM09
10
104—116
PROGRAM10
11
117—129
PROGRAM11
SPEED
0--255
FLASH
0--255
12
130—142
PROGRAM12
13
143—155
PROGRAM13
14
156—168
PROGRAM14
15
169—181
PROGRAM15
16
182—194
PROGRAM16
17
195—207
PROGRAM17
18
208—220
PROGRAM18
19
221—233
PROGRAM19
20
234—255
SOUND
Sensitivity
0--255
NO USE
DMX Mode 2：“Chan：05”,
CH1
CH2
CH3
CH4
CH5
Red 0-255
Green 0-255
Blue 0-255
Dim 0-255
Flash 0-255
DMX Mode 3：“Chan：30”
CH1
CH2
CH3
CH4
CH5
CH6
Red 1
Green 1
Blue 1
Red 2
Green 2
Blue 2
CH7
CH8
CH9
CH10
CH11
CH12
Red 3
Green 3
Blue 3
Red 4
Green 4
Blue 4
CH13
CH14
CH15
CH16
CH17
CH18
Red 5
Green 5
Blue 5
Red 6
Green 6
Blue 6
CH19
CH20
CH21
CH22
CH23
CH24
Red 7
Green 7
Blue 7
Red 8
Green 8
Blue 8
CH25
CH26
CH27
CH28
CH29
CH30
Red 9
Green 9
Blue 9
Red 10
Green 10
Blue 10
4. Master/slave Mode
This mode is M/S Mode, press “MODE” button enter to M/S mode menu “Slave Mode”.
The salve fixtures will follow the programs after they were linked to the master fixture via DMX cables.
5. Sound-active Mode
1) Press “MODE” button enter to Sound-active mode menu “Sound Mode”.
2) Press “SETUP” button can enter into sensitivity settings “Sens-ty：31”, could set the sensitivity value “Sens-ty：
00-Sens-ty：31” via “UP” or “DOWN” button.
6. Static Color Mode
1) Press “MODE” button enter static color mode menu “Color Mode”.
2) Press “SETUP” button enter red brightness setting menu “Red 255 Green255”, could set the brightness

value “Red 000 -Red 255” via “UP” or “DOWN” button.
3) Press “SETUP” button enter green brightness setting menu “Red 255 Green255”, could set the brightness
value “Green000 - Green255” via “UP” or “DOWN” button.
4) Press “SETUP” button enter blue brightness setting menu “Blue 255”, could set the brightness value “Blue 000 -
Blue 255” via “UP” or “DOWN” button.
C. Restore Factory Settings
Press both “MODE” & “ENTER” button for two seconds when the light is unplugged, then power on and loose the
buttons.After restore factory setting, the fixture will be in auto running mode.
