LightSpeed Technologies DRQ User manual

Description Two-way speaker system
Driver Size 6.5” driver; 1” horn
Frequency Response 40 Hz–20 kHz
Impedance 8Ω
Power Handling 30 W
Dimensions 9.5” diameter; 5.5” deep
Weight 5.9 lbs.
Enclosure White ABS ceiling-mount
housing with metal grille;
UL listed fire-retardant ABS
back-enclosure
Tile Support 20-gauge metal tile bridge
DRQ™ ceiling speaker
DRQ™ ceiling speaker
LightSPEED’s DRQ ceiling speakers deliver high-quality, full-range
sound evenly throughout the classroom. With the supplied T-bridge and
integrated enclosure, the DRQ is easily installed into an acoustic ceiling
tile. When used with a LightSPEED Classroom Amplification System, four
DRQs project the teacher’s voice evenly throughout the classroom allow-
ing every child to hear every word. The speaker grille is flush mounted
to the ceiling tile, and wires are routed overhead, making for a clean and
unobtrusive installation.
Four DRQ speakers will cover classrooms
of up to 1600 square feet with 9 to
12 foot ceilings.
• Ideal option for rooms with
suspended ceilings
• Two-way speaker system produces
high-quality, full-range sound
• Integrated speaker enclosure
improves sound quality and reduces
bleed over
• Easy mounting makes for a
simple installation
• Stylish grille blends into classroom
surroundings
profile
room coverage
overview
www.lightspeed-tek.com
800.732.8999
LightSPEED Technologies imagine…
i
Top View of Room
Covers up to 1600 sq. ft.
(Example: 40 ft. x 40 ft.)
9.5” diameter
5.5”
8.125” Rough Opening
Front View
Side View
6.5” Speaker Size
