Lightware L-1020 Projector User’s Guide
Thischapterwillexplaintheset-upandconnectionproceduresforyour
projector, including information pertainingtobasicadjustmentsand
interfacingwithperipheralequipment.
Getting Started
Insert the power cord into the AC input socket of your projector, as
shown in Figure 1. Connect the other end of the power cord to an AC
outlet.
Upon connecting to power, the projector will enter the Live State* the
Lamp Age LED, the Lamp Status LED and the Power On/Standby LED
will flash on then off then on again. The fan will turn on and the lamp
will light. During this time the projector keypad and the remote control
will be inactive. After approximately 12 seconds the remote control
and the projector keypad will become active and all projector functions
will become accessible.
*For an explanation of the projectors operational states see page A-4 in
theappendix.
Powering Up The Projector
Figure1:PowerConnection

2Lightware L-1020 Projector User’s Guide
Set the resolution of your computer display to XGA (1024x768) or
lower.
DisconnectthePCmonitorcablefrom the computer monitor output
connectionon yourcomputer.
Connect the supplied 15 pinVGA signal cable to your projector
ComputerIn connectoras shown in figure 2.
Connect the other end of the cable to the monitor output connection of
yourcomputer.
Note: If you wish to view your computer and projected images
simultaneously,usethe 15-pin HD gender changer toconnect
the computer monitor cable to the projector Monitor Out
connector.
Connecting to an IBM Compatible Desktop PC.
GettingStarted
Figure2:PC Desktop Connection
Monitor Loop Through
Connector
ComputerIn

3
Lightware L-1020 Projector User’s Guide
Connecting to an IBM Compatible Laptop PC
Set the resolution of your laptop display to XGA (1024x768) or lower.
Connect the supplied 15 pinVGA signal cable to your projector
Computer In asshowninfigure3.
Connect the other end of the cable to the external monitor output
connectorofyourcomputer.
Activate the laptop’s external monitor (VGA) port. This is usually
accomplished using the Fn key in conjunction with one of the function
keys (Fn+F4 for example).
Note: See page A-15 in the appendix for a list of laptop manufacturers
and the methods they use to activate the laptop’s external
monitorport.
Figure3: PC LaptopConnection
ComputerIn

4Lightware L-1020 Projector User’s Guide
GettingStarted
Connecting to a Mac Desktop Computer
If your Mac has a separateVGA output port, connect the supplied 15
pinVGA cable to that output port and connect the other end of the
VGA cable to the Monitor In connector on the projector.
In the Mac O/S control panel, set the mirroring option to ON and
designate the external monitor as the active monitor. For more
informationonthe mirroring function see page A-13intheappendix.
If your Mac does not have a separateVGA output port, then discon-
nect the monitor cable from the computer monitor output connector
andconnectthe Mac adapter (available upon request)tothemonitor
output connector on the computer as shown in figure 4. Connect the
suppliedVGA cable to the output side of the Mac adapter. Set the dip
switches on the Mac adapter to match the output requirements of your
Mac. See page A-11 in the appendix for help in setting the dip
switches.
Note: If you wish to view your computer and projected images simulta-
neously,youcan use the built-inmonitor loop-through connec-
tion of the projector to connect to your Mac monitor.Connect
theMac loop-through adapter (availableuponrequest) to the
projector MonitorOut connector. Connect yourMac monitor
cableto the output side of the loop-through adapter.
Figure4:Mac Desktop Connection
Monitor Out Connector
ComputerIn

5
Lightware L-1020 Projector User’s Guide
Connectthe Mac adapter (availableuponrequest*) to the laptop
external monitor output port. Connect the suppliedVGA cable to the
output side of the Mac adapter shown in figure 5. Connect the other
end of theVGA cable to the L-1020 Monitor In connector.Set the dip
switches on the Mac adapter to match the output requirements of
your Mac. See page A-11 in the appendix for help in setting the dip
switches.
Differentmodelsof Mac Computers havedifferentrequirementsfor
using an external monitor. For more information on connecting to an
externalmonitoror projector see page A13 intheappendix.
Connecting to a Mac Laptop Computer
*To request a Mac adapter, call Lightware technical support at
1-800-445-9396.
ComputerIn
Figure5:Mac Laptop Connection

6Lightware L-1020 Projector User’s Guide
GettingStarted
Thereareseparate audioinputconnections forcomputer andVCRon
yourLightwareL-1020.
To connect to your computer audio output, plug one end of the sup-
pliedstereo-audio cable (3.5mm maleconnectorson each end) into
the audio output jack of your desktop computer or the speaker output
jack of your laptop. Connect the other end of the stereo audio cable to
the computer Audio In jack of the Lightware L-1020 as shown in figure
6.
TheL-1020has the capability of providing anaudiosignalto powered
external speakers via the 3.5mm Audio Out jack.
Connecting to Computer Audio
Figure6:Audio Connection
Audio in
Audio Out

7
Lightware L-1020 Projector User’s Guide
The L-1020 accepts both composite video and S-video inputs from a
video player as well as stereo audio inputs.
Usethe three wire compositevideo/stereo-audiocable, shipped with
your projector, to connect to your video player video and audio outputs
as shown in figure 7. The color coded red and white connectors are for
audioandthe yellow connector isforcompositevideo.
If you are using an S-video source instead of composite, the compos-
itevideocablewillremainunused,asshowninfigure8.
Connecting to a Video Player
Figure 7:Audio /Video Connections
Figure8: S-videoConnection
S-Video Cable
Unused Video Cable

8Lightware L-1020 Projector User’s Guide
Connecting the Remote Mouse
To control yourcomputermousefromtheprojector’sremotecontrol,
usethe followingprocedure:
1. Turn off your computer.
2. Disconnect the standard mouse from the mouse port on your
computer.
3. Connect the remote mouse interface cable between the 9 pin DIN
oftheprojector and the appropriate mouse connector(serial,PS2,
ADB) on your computer, as shown in figure 9.
4. Make sure that your projector is connected to power and then
powerup yourcomputer.
For most applications the above procedure is all that is required. If
youareencountering difficulty, please referto ConfiguringYour
RemoteMouse onpageA-8 in the appendix.
Note:ADB adapters for Macintoshcomputersare available upon
requestat no charge. Contact yourdealeror Lightware at 1-800-
445-9396.
Figure9: Remote MouseConnection
GettingStarted

9
Lightware L-1020 Projector User’s Guide
Powering up the Projector
Besuretheprojectorisproperlyconnectedtopowerandtheprojector
is in the Sleep state *.
Press the Power On/Standby button and the projector will enter the
Live state * with the lamp on and the fan at high speed. (The lamp
takes approximately 30 seconds to reach full brightness.)
The projector uses a group of default settings at startup. These
default settings can be modified through choices made in the menus.
Seepage17 Menus.
Thedefault settingsprovidean on-screenStartuplogo forthefirst five
seconds and then select the data input source. If no data source is
present the projector will select a video player input source. If no
input source is detected, the image projected will default to the Startup
logo. If no Startup logo was selected in the features menu then the
screen will be blank.
Caution: Ultra High Pressure lamps need to be in a stable condition
prior to turning them on or off. To protect the lamp and the
projector,Lightware has designed protective delays into the
power up and power down circuitry. After first turning on the
lamp, a 30 second timer prevents prematurely turning it off. After
turning off the lamp, a 60 second timer prevents turning it on
prematurely. Please do not attempt to bypass these delays.
*for more information on the operational states of the L-1020, see
OperationalStates onpageA-4 in the appendix.
Tip:
If you are connected to a laptop and are not projecting an image you
may have not properly activated the external video output port. See
Laptop External Video Port Activation on page A-15 in the appen-
dix .
This chapter describes how to operate your projector. It includes informa-
tion on how to adjust the projector, use the remote control, and how to
access and use the on-screen menus.
Operating the Projector

10 Lightware L-1020 Projector User’s Guide
OperatingtheProjector
Adjusting Focus
To adjust focus, rotate the focus ring, as shown in figure 10, until the
image is clear.
Adjusting Image Size
To adjust the size of the projected image, move the zoom ring tab,
shown in figure 11, until the image is the desired size. For a chart
showing distance to screen vs image size refer to page A-21 in the
appendix.
Figure 10: Focus Adjust
Figure 11: Image Size Adjust
Zoom Ring Tab
Focus Ring

11
Lightware L-1020 Projector User’s Guide
Adjusting Height
To adjust the level of the projector, Lightware has provided an adjust-
able elevator foot on each rear corner. To set the level, rotate the foot
oftheappropriaterearcorner,as showninfigure 13, until the projected
image is level.
Adjusting Level
Figure13:ProjectorLevelAdjust
Leveling Foot
Elevator Foot Release
Figure 12:Front Elevator Foot Adjust
To adjust the height of the front of the projector, Lightware has pro-
vided a quick-release elevator foot under the front center of the
projector. Tosettheappropriate projector height, presstherelease
mechanism shown in figure 12, and lift the front of the projector.Once
the appropriate height is reached, let go of the release mechanism to
lock the elevator foot in place.

12 Lightware L-1020 Projector User’s Guide
OperatingtheProjector
The wireless remote control is similar to those used forTV's and
VCR's. It allows you to set up and adjust the projector image and to
conductinteractive presentations.
The projector control buttons on the remote control give you instant
access to all projector functions.
The built in joystick and mouse buttons allow remote control of the
computer mouse with all of the functionality of your standard computer
mouse.
Configuringyour remote mouse withappropriatedrivers and the useof
simultaneousremotemouse and laptop pointerarediscussedin
ConfiguringYourRemoteMouse onpage A-8 in theappendix.
On/Standby
Source
4Directional
Select Keys
OnScreen
Menus
ComputerMouse
Control
Left Mouse
Button
Curtain
Freeze
ZoomOut
Pointer
AudioControls
Drag&Drop
Right Mouse Button &
RemoteBacklight
ZoomIn
Remote Control
Figure14: RemoteControl

13
Lightware L-1020 Projector User’s Guide
Remote Functions
Thefollowingdescribes the various projector functions availablefrom
the remote control. Those functions also available from the projector
keypadare noted.
On/Standby
Press the On/Standby button, on the remote control or
the projector keypad, to cause the projector to change the
fan speed to high and turn the lamp on ( Live* state). If the
projector lamp has been on for more than 30 seconds,
pressing it again will slow the fan speed to standby and
turn off the lamp ( Standby* state). If the lamp has been
on for less than 30 seconds the projector will enter the
StandbyPending* stateandthe PowerOn/Standby button
on the projector keypad will flash pending transition to the
Live state.
*For more information on the operational states of the projector
see Operational States on page A-4 in the appendix.
Source
Press the Source button on the remote control or the
projector keypad to toggle the input to the projector
through the available input sources i.e.computer, com-
posite video and S-video. If there are no other active
inputsourcesconnected an error messagewillappearfor
5 seconds indicating the lack of an additional signal
source and the source selection will remain where it is.
Directional Select Keys
The Directional Select Keys on the remote control or the
projectorkeypad provide thefollowingfunctions:
l Menunavigationandselection
l Projectedimagepositioning
l Panaroundazoomedorcropped image.
l Pointermovement
l Slide control adjust
l Curtainoperation

14 Lightware L-1020 Projector User’s Guide
OperatingtheProjector
Freeze
Press the Freeze button on the remote control to freeze
the projected image. Press the Freeze button again or
transition to another source to return the projector to
normaldisplay operation.
Tip:You can use the Freeze button to hold an image on the projected
screen while you are making changes to your presentation or checking
your notes on your computer screen. Once the adjustments are
made, simply press the freeze button again to return to your presenta-
tion.
Zoom
Press the Zoom In key on the remote control to cause the
display to zoom in on the center of the projected image.
Zoom will magnify the image up to 8 times in 19 steps.
Continued pressing of the Zoom Out key will return the
display to the normal size.
While in the zoom mode use the Directional Keys to move
thezoomwindow around the full screen.
Menu
Press the Menu key on the remote control or the projector
keypad to activate the on-screen main menu. Pushing it
oncemorewill de-activate the on-screen main menu.
Curtain
Press the Curtain key on the remote control to overlay a
curtain on the entire projected display. You can then
reveal portions of the display by using the arrow keys to
slide the curtain down, up, right, or left.
Remote Functions (continued)

15
Lightware L-1020 Projector User’s Guide
RemoteBacklight
Press and hold the Right Mouse button on the remote
control for several seconds to activate the backlight for
the remote control buttons.
Computer Mouse Control
Use the Joystick on the remote control to control the
computer mouse in a manner similar to the standard
mouse control used on most computers.
Right Mouse Button
The Right Mouse button on the remote control functions
in a manner similar to the standard right mouse button
control on most computers.
LeftMouse Button
The Left Mouse button on the remote control functions in
a manner similar to the standard left mouse button control
on most computers.
Pointer
Press the Pointer key on the remote control to produce an
arrow shaped pointer in the center of the screen. The
Directional Select keys are used to move the pointer
aroundthe screen.
Audio Controls
Press the +key on the remote control to increase the
volume of the audio. Press the - key on the remote
control to decrease the volume of the audio. Press the
Mute key to mute the audio.

16 Lightware L-1020 Projector User’s Guide
Projector Control Panel
Figure 15 shows the layout of the L-1020 keypad controls.
The Lamp Age LED and the Lamp Status LED provide information on
the condition of the High Intensity Discharge Lamp.
The lamp conditions indicated by the LED’s are as follows:
Lamp Status LED
Green - No Fault
Red - Lamp Failed
LampAge LED
Green - Less than 100% of Lamp Life
Amber - 100% of Lamp Life
Red - 150% of Lamp Life
Figure 15:L-1020 Keypad
Power On/Standby
Directional Arrows
Menu Source Lamp Age LED
Lamp Status LED
OperatingtheProjector

17
Lightware L-1020 Projector User’s Guide
Menus
Press the Menu button on the remote control or on the projector’s
controlpanelto bring up theon-screenmainmenu and the sub-menu
for the highlighted selection. Each main menu item has an associated
sub-menu. Press the Up or Down arrow keys on the remote control to
highlight a menu item. Highlighting the menu item brings up the sub-
menu for that selection. Use the Right arrow key to move to the sub-
menu.
The sub-menus provide all of the choices that relate to the main menu
selection. Press the Up or Down keys to highlight your choice and
then press the Right arrow key to bring up either a slide control that
will adjust the level or value of that choice or a second sub-menu that
will provide the final selections. A typical example of each is shown
below.
Any changes or adjustments made are saved when the projector is
powereddown. TheL-1020 will remembertheconfigurationsettings
for the last ten signal sources used with the projector and recall those
settingswhenever one ofthosedevices is detected.
Menu Operation
MainMenu SlideControl
SubMenu
Help
Audio
Source
Features
Custom Modes
Service
Reset
4
4
4
4
4
Picture 4
4
4
Tracking
Contrast
Brightness
Sharpness
Room Light
Color
Tint
Reset
Frequency 4
4
4
4
4
4
4
4
4
Frequency
0
+
-

18 Lightware L-1020 Projector User’s Guide
OperatingtheProjector
For those menus with a reset function, highlight Reset and use the
right arrow to move to the Reset sub-menu. While in the Reset sub-
menu press the down arrow to reset the functions in that menu.
Select Reset in the Main menu to reset values in the Main menu as
follows:
lAudio - Resets all values in the audio menu.
lPicture - Resets all values in the picture menu.
lSource - Resets to Computer as first choice.
lFeatures -ResetsCompression, Ceiling Mount, RearProjec-
tion, it does not reset Language, Startup Logo and Curtain.
lCustom Modes - Reset clears any saved custom modes.
lService - No Service menu items are reset.

19
Lightware L-1020 Projector User’s Guide
To access the Audio menu from the Main menu, use the Up or Down
arrows on the remote control or projector to highlight Audio in the Main
menu. Use the Right arrow to move to the sub-menu for the selection.
In the Audio menu, use the Up or Down arrows to highlight the function
that you wish to select. For Volume, Bass, Treble and Balance a Slide
Rule will appear as shown below. For theStereo Mode, Mute and
Reset functions, sub-menus will appear.
Audio Menu
Volume
ChooseVolume toproduce aSlideRule control.
lPress the Up arrow key to increase the volume level.
lPress the Down arrow key to decreas the volume
level.
Help
Source
Features
Custom Modes
Service
Reset
4
4
4
Audio 4
4
4
4
4
Bass
Treble
Stereo Mode
Mute
Balance
Reset
4
4
4
Volume 4Volume
3
+
-

20 Lightware L-1020 Projector User’s Guide
Treble
Choose Treble to produce a Slide Rule control.
lPress the Up arrow key to increase the treble level.
lPress the Down arrow key to decrease the treble
level.
Stereo Mode
Choose Stereo Mode to produce a menu with the following
choices. Use the Up or Down arrow keys to select one of
thefollowing.
lMono: Mixes contents of right and left channels.
lLinear Stereo: Normal stereo without any extra
processing.
lPseudo Stereo: Creates “like stereo” effect from
monosource.
lSpatial Stereo: Simulates “3D space” feeling from
stereosource.
Bass
ChooseBass toproducea Slide Rule control.
lPress the Up arrow key to increase the bass level.
lPress the Down arrow key to decrease the bass
level.
OperatingtheProjector
