Epson 755c - PowerLite XGA LCD Projector User manual

With brilliant image quality, real-time wireless presentations,
convenient Instant Off™and other high performance features, the
Epson PowerLite 755c is the ultraportable that’s sure to impress. This
3.9 lb projector offers 2000 ANSI lumens and Epson 3LCD technology
for amazing color and detail. And, with 802.11g wireless capabilities,
it ensures fast transfer speeds for Keynote®and PowerPoint®
presentations.
2000 ANSI lumens from an outstanding
sub-4 lb projector!
• Offers incredible flexibility for great presentations anytime,
anywhere!
• Ideal for on-the-go presenters and those who require incredible
brightness from a small, lightweight projector that goes
virtually anywhere.
Superior image quality and performance
• 802.11g wireless performance included
• Epson 3LCD technology for greater color accuracy, rich color
saturation, and remarkable image quality
• XGA (1024 x 768) resolution for vibrant images with precision
color and detail
Easy setup and operation
• 7-second start-up for fast setup and convenient Instant Off™for
no cool down time.
• Power-on and -off beeps confirm user commands and avoid
confusing startups and shutdowns
• Source search function automatically displays the connected input
source(s) and switches instantly between various sources
• Automatic vertical keystone correction for square images even
when the projector is not centered
- +/-30˚ digital keystone correction that automatically engages
• 1.2x optical zoom lens to facilitate flexible placement and
positioning and still maintain image quality
• Full-featured remote control, with mouse emulation functions
and an electronic pointer for complete presentation control
• Password-protected security features, plus operation lock to
prevent theft or unauthorized usage
• Brightness control function can extend the lamp life and provide
more cost-effective operation (3000 hours in Low Brightness
mode, 2000 hours in High Brightness mode)
• Soft carrying case included
Wired* and wireless local networking capabilities
Epson EasyManagement™technology
• A wireless connection to remotely monitor and control projectors
over the network**
- Centralized monitoring and control
- Built-in remote access
- Simple Network Management Protocol (SNMP) for easy
network management and maintenance
- E-mail notification (via SMTP) to alert users to information
related to the temperature, fan and lamp
- Web control over multiple network projectors, each with a
different router address
Epson EasyMP™technology
• Wireless presentations to project images in real-time, without
cables; display on up to 4 projectors simultaneously!
- NS connection for PC and Macintosh systems (compatible
with Mac OS X 10.3 or later)
- 802.11g and Epson’s own algorithm ensure the fastest
transfer speeds for real-time PowerPoint and Apple®Keynote
(Mac OS X 10.3.x or later) presentations
- Broadest security protection — WEP, WPA, and Cisco LEAP
compatibility to safeguard the display screen, protect
confidential data, and ensure uninterrupted presentations
• Connect a memory device and start your presentation–all
without a PC
- USB or PCMCIA connectivity to show digital photos, stream
movies and MPEG2 videos
- Improved transfer speeds for PowerPoint and Apple Keynote
animations
Outstanding Epson service and support
(two-year limited warranty)
• 90-day lamp warranty for added dependability
• Epson Road Service program provides a replacement projector,
typically within 1 business day
• Epson PrivateLineSM dedicated toll-free support line available from
6 a.m. to 6 p.m. PST Monday - Friday
(Calls are answered live, typically in about a minute.)
• International warranty in over 45 countries
Projection System Epson original LCD technology
Projection Method Front/rear/ceiling mount
LCD
Driving method Epson High Temperature Poly-Silicon TFT
Pixel number 786,432 dots x 3 (1024 x 768) LCDs
Native resolution XGA
Aspect ratio 4:3 (supports 16:9, 5:4)
Pixel arrangement Stripe
Projection Lens
Type Manual: zoom / focus
F-number 1.58 – 1.76
f-number 23.7 – 28.5mm
Zoom ratio 1.0:1.2
Lamp
Type 170W UHE
Life* 2000H (High Brightness), 3000H (Low Brightness)
Screen Width Ratio (Distance/width) 1.58 to 1.64:1
Screen Size (Projected distance) 30" to 300" (2.9' to 34.4')
Keystone Correction Vertical: +/-30°
Auto Keystone Correction Vertical: +/-30°
Brightness (Typical) 2000 ANSI lumens (High Brightness)
1500 ANSI lumens (Low Brightness)
Contrast Ratio 400:1
Brightness Uniformity (Typical) 90%
Color Reproduction 24 bit; 16.7 mil
Audio Output 1W Monaural
Operating Temperature 41°F to 95°F (5°C to 35°C)
Power Supply Voltage 100-240VAC +/-10%, 50/60Hz
Power Consumption 240W/35W Network On at sleep mode
4W Network Off at sleep mode
Dimensions 7.6" x 10.8" x 2.7"
Weight 3.9lb
Fan Noise 40db (High Brightness),
35db (Low Brightness)
Effective Scanning Frequency Range
Pixel clock 13.5MHz to 162MHz
Horizontal 15KHz to 92KHz
Vertical 50Hz to 85Hz
Remote Control
Features Focus, zoom, keystone, source selection, power,
page up/page down, color mode, volume,
e-zoom, a/v mute, freeze, resize, menu, help,
auto, pointer
Operating Angle Right/Left +/- 30 degrees
Upper/Lower +/- 15 degrees
Operating Distance 20 ft (6m)
RGB
Analog RGB I/O
Display performance
Native 1024 x 768
Resize 1600 x 1200, 1280 x 1024, 800 x 600,
640 x 480
Input terminal
Video Mini D-sub 15 pin
Audio Stereo mini jack
Output terminal
Video N/A
Audio Stereo mini-jack
Video I/O
Display performance NTSC: 560 lines
PAL: 560 lines
(Depends on observation of the multi
burst pattern)
Input signal NTSC, NTSC4.43, PAL, M-PAL, N-PAL,
PAL60, SECAM
HDTV: 480i, 480p, 720p, 1080i
Input terminal
Video Composite Video: RCA (Yellow);
S-Video: Mini DIN;
Component Video: Mini D-sub 15pin
(in common with Analog RGB connector);
Video-RGB: Mini D-sub 15pin (in common
with Analog RGB connector)
Audio Stereo mini jack
Audio signal 500m Vrms/47Kohm
Control I/O
I/O terminal USB connector series A
(for DSC, USB memory, PCMCIA type I/II)
USB connector series B
(for mouse, keyboard)
Security Kensington®-style lock provision
Warranty
Two-year limited warranty, two-year international warranty, 90-day lamp
warranty, Epson Road Service Program and Epson PrivateLine dedicated
toll-free support (U.S. and Canada only)
Supplied Accessories
Power cable, remote control with battery, wireless 802.11g card, computer
cable, audio adapter cable, USB A/USB B cable, Owners Manual, EasyMP
Software CD-Rom, Start Here Kit, soft carrying case
Product/Accessory Part Numbers
Epson PowerLite 755c projector V11H200020
Replacement lamp V13H010L32
Air filter set V13H134A08
Samsonite wheeled soft case w/laptop ELPKS35-S
Samsonite soft shoulder case ELPKS43
ATA molded hardshell case ELPKS42
Ceiling mount ELPMBUNI
Suspension adapter ELPMBAPL
False ceiling plate ELPMBFCP
Security bracket/cabling for gyro lock mounts ELPMBSEC
Adjustable ceiling channel ELPMBACC
Component video cable ELPKC19
S-Video cable ELPSV01
Distribution Amplifier ELPDA01
Mac adapter set ELPAP01
50" portable screen ELPSC06
60" portable pop-up screen ELPSC07
80" portable pop-up screen ELPSC08
Classroom style pull-down screen (83.6") ELPSC09
High-Resolution Document Imager (ELPDC05) V12H162020
Kensington security lock ELPSL01
Support–The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
*Lamp life results will vary depending upon mode selected, environmental conditions, and usage.
SM
Epson PowerLite 755c Specifications
Epson PowerLite®755c
The lightweight, wireless wonder
that shines bright in any setting.
Printed on Recycled Paper
Specifications and terms are subject to change without notice. Epson and Exceed Your Vision are registered trademarks and Epson EasyManagement and Epson EasyMP are trademarks of Seiko Epson
Corporation. PowerLite is a registered trademark, and Epson Connection, PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are trademarks and/or
registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. © Copyright 2005 Epson America, Inc. CPD-20080 15K 7/05
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
USB type B USB type A
Back View
computer/component
Front View zoom lens
PCMCIA type I/II slot x1
audio in
video s-video
full-featured
IR remote control
* LAN card required
** Access point required
