Lightwave Technology PKE-AL(PS)-UNI User manual

PassiveorActiveKeylessentrysystem
UserGuide
8
Lightwave Technology
400 Wright Street
Montreal, QC, Canada, H4N1M6
Website: www.lightwavetechnology.com
Passive Keyless Entry System

Doc#140109 Rev: 1.0 ©2014 -1W-AM-2BTN-PKE-A- Canada
OWNERS MANUAL
PKE-AL(PS)-UNI
WARNING!
It is the responsibility of the vehicle operator to
ensure that their vehicle is parked in a safe and
responsible manner.
A note concerning the battery inside the transmitter:
Depending on your usage of the transmitter, the battery can last anywhere between
2 to 3 years. Although we recommend to replace the battery inside the transmitter
every year to get the best performances from your system.
INDUSTRY CANADA USER NOTICE:
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (EIRP) is not more than that
required for successful communication.
NOTE: The manufacturer is not responsible for any radio or TV interference caused by
unauthorized modifications to this equipment. Such modifications could void the user's
authority to operate the equipment.

PassiveorActiveKeylessentrysystem
UserGuide
2
Table of Contents
Government regulations…………………………………………………………………….…… 3
Using the transmitter and ADB………………………………………………………….…… 4
Doorlock Access Chart……………………………………………………………………….…… 5
Trunk / Hatch Release……………………………………………………………………….…… 6
Valet Mode………………………………………………………………………………….…………… 6
Parking Light Flash Table………………………………………………………………………… 7
PassiveorActiveKeylessentrysystem
UserGuide
7
Diagnostics - Parking lights Flash Table
Parking
Lights
Flashes Description
1 Flash - Door Lock
2 Flashes - Door Unlock
3 Flashes - Valet Mode
5 Flashes - Please see your retailer
6 Flashes - Please see your retailer
7 Flashes -Door Locking command using ADB while RFID
transmitter is inside vehicle (Active Mode Only)
8 Flashes - Please see your retailer

PassiveorActiveKeylessentrysystem
UserGuide
6
Trunk/Hatch Release or Motorized liftgate
With RFID
transmitter
Press & Release
Button 1 & 2
on RFDI
transmitter
-Parking lights will blink 2 times
-Trunk will pop open or Motorized
hatch will open or Close

Valet Mode Enabled/Disabled
Use factory
key in
ignition
cylinder
Cycle Key in
ignition cylinder
5x On/Off
-Valet On = Parking lights will blink
3 times
-Valet Off = Parking lights will blink
2 times














PassiveorActiveKeylessentrysystem
UserGuide
3
Government regulations
This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions: (1) This device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates and can radiate
radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with the Industry Canada Radio Standards
Specification RSS 210. Its use is authorized only on a no-interference, no-
protection basis; in other words, this device must not be used if it is
determined that it causes harmful interferences to services authorized by
IC. In addition, the user of this device must accept any radio interface that
may be received, even if this interfere-ence could affect the operation of
the device.
Warning! Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate this
device.

PassiveorActiveKeylessentrysystem
UserGuide

4
Using the Transmitter and ADB
Your Passive Keyless system is equipped with a 2 button RFDI remote
control. This transmitter is capable of allowing access to your vehicle
without pressing any button on it.
LOCK
Locks the doors and arms the
Starter Kill (if installed)
UNLOCK
Unlocks the doors and disarms
the Starter Kill (if installed)
TRUNK
Opens the Trunk, Hatch or
Power liftgate
(if option installed)
The Active Doorlock Button (ADB) is an
optional part installed at the entry doors
and can control the Locking and Unlocking
of the doors simply by pressing on it.
NOTE: The RFID transmitter must be
present for the doorlocks to react to the
ADB.







PassiveorActiveKeylessentrysystem
UserGuide
5
Doorlock Access Chart
The Doorlock mode is configured by your installer at the time of installation.
There are three (3) different doorlock mode. Passive mode does not require
any action from user and is the default method to use. Active mode requires
a physical action from user in order to Lock / Unlock the doors. The ADB
(Part#: XXXXXXX) is required for Active mode and is sold separately. Hybrid
mode requires to use the ADB in active mode but will lock the doors
automatically after 90 seconds if doors are left unlocked inadvertently and
RFID transmitter is not in range.
With Passive
Doorlocking
With RFID
transmitter
Walk away from
the vehicle
(more than 10 feet)
-Vehicle doorlocks will Lock / Arm
-Parking lights will blink 1 time
-Horn will honk 1 times (if connected)
With RFID
transmitter
Walk close to
the vehicle
(within 10 feet)
-Vehicle doorlocks will Unlock /
Disarm
-Parking lights will blink 2 time
-Horn will honk 2 times (if connected)
With Active
Doorlocking
(ADB)
With RFID
transmitter in
range (within 10
feet of the vehicle)
Press & Release
ADB button
-Vehicle doorlocks will Lock / Arm
-Parking lights will blink 1 time
-Horn will honk 1 times (if
connected)
With RFID
transmitter in
range (within 10
feet of the vehicle)
Press & Release
ADB button
-Vehicle doorlocks will Unlock /
Disarm
-Parking lights will blink 2 time
-Horn will honk 2 times (if
connected)
With Hybrid
Doorlocking
(ADB) +
Passive
mode
With RFID
transmitter
Walk away from
the vehicle
(more than 10 feet)
-After 90 seconds, Vehicle
doorlocks will Lock / Arm
-Parking lights will blink 1 time
-Horn will honk 1 times (if connected)
With RFID
transmitter in
range (within 10
feet of the vehicle)
Press & Release
ADB button
-Vehicle doorlocks will Unlock /
Disarm
-Parking lights will blink 2 time
-Horn will honk 2 times (if connected)
With RFID
transmitter in
range (within 10
feet of the vehicle)
Press & Release
ADB button
-Vehicle doorlocks will Lock / Arm
-Parking lights will blink 1 time
-Horn will honk 1 times (if
connected)

