LILYGO T3 V1.6.1 User manual

!
Version 1.0
Copyright © 2022
T3 V1.6.1
User Guide

About This Guide
This document is intended to help users set up the basic software development
environment for developing applications using hardware based on the T3 V1.6.1
Through a simple example, this document illustrates how to use Arduino, including the
menu based configuration wizard, compiling the Arduino and firmware download to the
ESP32 module.
Release Notes
Date
Version
Release notes
2022.07V1.0 First release.

T3 V1.6.1 Board PINMAP

Main Chip ESP32 Pin Layout

Table of Contents
1. Introduction!1".............................................................................................................................
1.1. T3 V1.6.1.................................................................................................................................1!
1.2.
Arduino
1".....................................................................................................................................
1.3. Preparation!1".................................................................................................................................
2. Get Started!2".............................................................................................................................
2.1. Download the Arduino Software !...............................................................................................2!
2.1.1. Install Prerequisites
! .......................................................................................................2!
2.1.2. Toolchain Setup!
............................................................................................................2!
2.2. Install the Arduino Software! ......................................................................................................3!
2.3. Set up Path!
................................................................................................................................3!
!................................................................................................................................4!
!5"..................................................................................................................................
! ...........................................................................................................................6"
3. Configure
4. Connect
5. Test Demo
6. Upload Sketch
!7".......................................................................................................................
6.1. Build and Flash!7"..........................................................................................................................
6.2. Monitor!8".......................................................................................................................................
7. SSC Command Reference!9".....................................................................................................
7.1. op!9"...............................................................................................................................................
7.2. sta!9"..............................................................................................................................................
7.3. ap!10".............................................................................................................................................
7.4. mac!10"..........................................................................................................................................
7.5. dhcp!11".........................................................................................................................................
7.6. ip!11"..............................................................................................................................................
7.7. reboot!12".......................................................................................................................................
7.8. ram!12...........................................................................................................................................

!
1. Introduction
1. Introduction
1.1. T3 V1.6.1
T3 V1.6.1 is a development board. It can work independently
It consists of ESP32 MCU supporting Wi-Fi + BT+ BLE communication protocol and a
screen. The screen is 0.96 inch OLED SSD1306.The LoRa chip model is SX1276.
For applications ranging from low-power sensor networks to the most demanding tasks.
The MCU of this board is the ESP32-PICO-D4 chip.
ESP32 integrates Wi-Fi (2.4 GHz band) and Bluetooth 4.2 solutions on a single chip,
along with dual high performance cores and many other versatile peripherals. Powered
by 40 nm technology, ESP32 provides a robust, highly integrated platform to meet the
continuous demands for efficient power usage, compact design, security, high
performance, and reliability.
Xinyuan provides the basic hardware and software resources that empowers application
developers to build their ideas around the ESP32 series hardware. The software
development framework provided by Xinyuan is intended for rapidly developing Internet-
of-Things (IoT) applications, with Wi-Fi, Bluetooth, flexible power management and other
advanced system features.
The T3 V1.6.1 manufacturer is Shenzhen Xin Yuan Electronic Technology Co., Ltd.
1.2. Arduino
A set of cross-platform applications written in Java. The Arduino Software IDE is
derived from the Processing programming language and the integrated development
environment of the Wiring program. Users can develop applications in Windows/Linux/
MacOS based on Arduino. It is recommended to use Windows 10. Windows OS has
been used as an example in this document for illustration purposes.
1.3. Preparation
To develop applications for ESP32 you need:
•PC loaded with either Windows, Linux or Mac operating system
•Toolchain to build the Application for ESP32
•Arduino that essentially contains API for ESP32 and scripts to operate the Toolchain
•CH9102 serial port driver
•The ESP32 board itself and a USB cable to connect it to the PC
Xinyuan 1/132022.07

!
2. Get Started
2. Get Started
2.1. Download the Arduino Software
The quickest how to install the Arduino Software (IDE) on Windows machines
2.1.1. Quick Start Guide
The website provides a quick start tutorial
•Windows:
https://www.arduino.cc/en/Guide/Windows
•Linux:
https://www.arduino.cc/en/Guide/Linux
•Mac OS X:
https://www.arduino.cc/en/Guide/MacOSX
2.1.2. Installation steps for Windows platform Arduino
Xinyuan
Enter the download interface, select Windows installer to install directly
2/132022.07

!
2. Get Started
2.2. Install the Arduino Software
Xinyuan
Wait for installation
3/132022.07

!
3. Start a Project
3. Configure
Download the installation package Git.exe
Xinyuan
3.1. Download Git
3.2. Pre-build configuration
Click Arduino icon, then right click and select ``Open folder where ``
Select hardware ->
Mouse ** Right click ** ->
Click Git Bash Here
3.3. Cloning a remote repository
$ mkdir espressif
$ cd espressif
$ git clone --recursive https://github.com/espressif/arduino-esp32.git esp32
4/132022.07

!
4. Connect
4. Connect
You are almost there. To be able to proceed further, connect ESP32 board to PC, check
under what serial port the board is visible and verify if serial communication works.
Xinyuan 5/132022.07

!
4. Configure
5.
Test Demo
Select File>>Example>>WiFi>>WiFiScan
!
Xinyuan 6/132022.07

!
5. Build and Flash
6. Upload Sketch
6.1. Select Board
Tools<<Board<<ESP32 Dev Module
Xinyuan
6.2. Upload
Sketch << Upload
7/132022.07

!
5. Build and Flash
6.2. Serial Monitor
Tools << Serial Monitor
Xinyuan 8/132022.07

!
6. SSC Command Reference
7. SSC Command Reference
Here lists some common Wi-Fi commands for you to test the module.
7.1. op
Description
op commands are used to set and query the Wi-Fi mode of the system.
Example
op󰲧-Q󰲧
op󰲧-S󰲧-o󰲧wmode
Parameter
7.2. sta
Description
sta commands are used to scan the STA network interface, connect or disconnect AP, and
query the connecting status of STA network interface.
Example
sta󰲧-S󰲧[-s󰲧ssid]󰲧[-b󰲧bssid]󰲧[-n󰲧channel]󰲧[-h]
sta󰲧-Q
sta󰲧-C󰲧[-s󰲧ssid]󰲧[-p󰲧password]
sta󰲧-D
Parameter
Table 6-1. op Command Parameter
Parameter
Description
-Q
Query Wi-Fi mode.
-S
Set Wi-Fi mode.
wmode
There are 3 Wi-Fi modes:
•mode = 1: STA mode
•mode = 2: AP mode
•mode = 3: STA+AP mode
Table 6-2. sta Command Parameter
Parameter
Description
-S scan
Scan Access Points.
Xinyuan 9/132022.07

!
6. SSC Command Reference
7.3. ap
Description
ap commands are used to set the parameter of AP network interface.
Example
ap󰲧-S󰲧[-s󰲧ssid]󰲧[-p󰲧password]󰲧[-t󰲧encrypt]󰲧[-n󰲧channel]󰲧[-h]󰲧[-m󰲧max_sta]
ap󰲧–Q
ap󰲧–L
Parameter
7.4. mac
Description
mac commands are used to query the MAC address of the network interface.
Example
mac󰲧-Q󰲧[-o󰲧mode]
-s ssid
Scan or connect Access Points with the ssid.
-b bssid
Scan the Access Points with the bssid.
-n channel
Scan the channel.
-h
Show scan results with hidden ssid Access Points.
-Q
Show STA connect stutus.
-D
Disconnected with current Access Points.
Parameter
Description
Table 6-3. ap Command Parameter
Parameter
Description
-S
Set AP mode.
-s ssid
Set AP ssid.
-p password
Set AP password.
-t encrypt
Set AP encrypt mode.
-h
Hide ssid.
-m max_sta
Set AP max connections.
-Q
Show AP parameters.
-L
Show MAC Address and IP Address of the connected station.
Xinyuan 10/132022.07

!
6. SSC Command Reference
Parameter
7.5. dhcp
Description
dhcp commands are used to enable or disable dhcp server/client.
Example
dchp󰲧-S󰲧[-o󰲧mode]
dhcp󰲧-E󰲧[-o󰲧mode]
dhcp󰲧-Q󰲧[-o󰲧mode]
Parameter
7.6. ip
Description
ip command are used to set and query the IP address of the network interface.
Example
ip󰲧-Q󰲧[-o󰲧mode]
ip󰲧-S󰲧[-i󰲧ip]󰲧[-o󰲧mode]󰲧[-m󰲧mask]󰲧[-g󰲧gateway]
Table 6-4. mac Command Parameter
Parameter
Description
-Q
Show MAC address.
-o mode
•mode = 1: MAC address in STA mode.
•mode = 2: MAC address in AP mode.
Table 6-5. dhcp Command Parameter
Parameter
Description
-S
Start DHCP (Client/Server).
-E
End DHCP (Client/Server).
-Q
show DHCP status.
-o mode
•mode = 1 : DHCP client of STA interface.
•mode = 2 : DHCP server of AP interface.
•mode = 3 : both.
Xinyuan 11/132022.07

!
6. SSC Command Reference
Parameter
7.7. reboot
Description
reboot command is used to reboot the board.
Example
reboot
7.8. ram
ram command is used to query the size of the remaining heap in the system.
Example
ram
Table 6-6. ip Command Parameter
Parameter
Description
-Q
Show IP address.
-o mode
•mode = 1 : IP address of interface STA.
•mode = 2 : IP address of interface AP.
•mode = 3 : both
-S
Set IP address.
-i ip
IP address.
-m mask
Subnet address mask.
-g gateway
Default gateway.
Xinyuan 12/132022.07
