LIMITLESS HEAT1100 User manual

Wall Mounted Glass TV Fire (HEAT1100)
Instruction Manual
HEAT1100_Instructions_Final.indd 3 22/06/2016 09:39:07

HEAT1100/V1-170516 -3-
-2-
Contents
1 Reading and storing the user manual
2 Explanation of symbols
1
6
3
8
11
13
2
7
10
4
5
9
12
Reading and Storing the User Manual .............................................
Explanation of Symbols ........................................................................
Intended Use ...........................................................................................
Safety Notes ............................................................................................
Overheating protection..........................................................................
Cleaning, Storage and Maintenance .................................................
Packaging and Appliance Disposal ....................................................
Appliance Parts and Features .............................................................
Assembly and Set Up ............................................................................
First Use and Operating Instrucitions ..............................................
Plug Wiring (Class I Appliance) ..........................................................
Technical Specication .........................................................................
Declaration of Compliance ..................................................................
Congratulations! With your purchase you have decided on a high-quality
product. Now please take time to familiarise yourself with the product prior
to assembly. It is important to read all of these instructions and safety tips
carefully before using the product.
To avoid any accidents or damage to the product, please follow all assembly
instructions, only use the product as instructed and only for its intended use.
Retain these instructions for future reference and if you are passing this
product to a third party, always make sure this documentation is included.
The following pictograms are used in these user manuals, on the appliance or on the
packaging:
WARNING! This symbol designates a hazard with moderate degree of risk
which may lead to death or severe injury if not avoided.
Avoid damaging the insulation on the lead; DO NOT trap the lead in the
cupboard doors or entry doors, pull it over hot surfaces or sharp edges.
CAUTION! Danger of electric shock! Hazardous electrical voltage.
Danger of death!
The appliance must not be used in the vicinity of deep water or in water
(e.g. washbasin, shower, bathtub, pond, water feature, pool). Risk of electric
shock.
DO NOT cover the appliance!
This appliance must only be used indoors!
2
2
3
3
6
6
6
7
8
9
11
11
11
HEAT1100_Instructions_Final.indd 4 22/06/2016 09:39:07

HEAT1100/V1-170516
-3-
-2-
3 Intended use
4 Safety notes
This appliance is suitable as an auxiliary heating for domestic, indoor spaces. It has been designed
for private home use and must not be used for commercial purposes. It is not suitable for heating
large spaces on its own.
When using this appliance, basic safety precautions should always be followed to protect you
against electric shock, re or personal injury. Please read all of the instructions carefully and
retain for future reference.
Ensure the appliance is switched OFF before connecting to the mains power supply.
Do not use this appliance if the cable or plug becomes damaged. Any repairs to the
appliance must be carried out by a person qualied to do so.
Do not open the housing of the appliance. There is a risk of receiving an electric shock if
voltage carrying connectors are touched or electrical and/or mechanical construction is
changed.
Do not remove the product from the mains power supply by pulling the cord. Switch OFF
and remove the plug by hand.
Never use the heater to dry textile materials or other objects on, above or in front of
the appliance. Never cover the heater with any objects.
Do not use the heater with a programming switch, a timer switch, a separate remote
control system or any other device that is capable of switching the radiator on
automatically, as there is a risk of re is the heater is covered, incorrectly set up or
malfunctions.
Do not leave the appliance switched on and unattended with heating elements turned on.
The above symbol warns against
covering the appliance. Covering the
appliance can cause build-up of heat and
lead to damage and result in re!
Do not touch the hot surface of the
appliance and heating elements when
in use and until it has cooled down
completely.
DANGER! Risk of electric shock. Improper handling of the appliance may result in
injury and damage to the property or this appliance.
DANGER! Fire Hazard! This appliance works at high temperatures. It is important
that you observe the following safety information before use to prevent re.
DO NOT COVER THE APPLIANCE! HOT SUFRACE!
HEAT1100_Instructions_Final.indd 5 22/06/2016 09:39:07

HEAT1100/V1-170516 -5-
-4-
4 Safety notes (continued)
Safety Instructions
DO NOT use the product for anything
other than its intended use mentioned
above.
Check that the voltage indicated on
the rating plate corresponds with your
mains voltage before connecting the
product to the mains power supply.
WARNING! DO NOT block the heat output
of the appliance. Place in an open, well
ventilated space. Ensure the area within
1m from each side of the heater is clear
of any objects.
The appliance can used by children aged
from 8 years and above and persons with
reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
Children aged 3 and over, who are
younger than 8 years old, may only
switch the device on and o, if they are
supervised or they have been instructed
in the device’s safe use and they have
understood the resulting dangers,
provided that the device is placed
or installed in its normal operating
position.
Children must not play with the
appliance. This is not a toy.
Children aged 3 and over, who are
younger than 8 years old, may not insert
the plug into the wall socket, adjust the
device, clean the device and/or carry out
any maintenance work, which the user
is required to carry out.
Children of less than 3 years should
be kept away unless continuously
supervised.
CAUTION! Some parts of this appliance
can become very hot and cause burns.
Particular attention has to be given
where children and vulnerable people
are present.
This appliance is intended for indoor,
domestic use only. Do not use the
appliance outdoors.
This appliance should not be operated
by means of an external timer or
separate remote control system, other
than supplied with the product.
Do not use this appliance in small rooms
whilst occupied by persons incapable of
leaving the room on their own, unless
constant supervision is provided.
This appliance contains no user
serviceable parts. If the appliance
stops working unexpectedly or appears
to malfunction, switch o the power
supply, unplug from the mains and stop
using immediately. Seek a qualied
electrician to rectify the fault or make
any repairs.
If the cable in this appliance is
damaged, it must be replaced by the
qualied electrician or a person with
similar qualications.
Always use the heater at a distance of
at least 1m away from walls, people and
objects such as curtains, bedding and
other ammable materials, etc.
HEAT1100_Instructions_Final.indd 6 22/06/2016 09:39:07

HEAT1100/V1-170516
-5-
-4-
4 Safety notes (continued)
Safety Instructions
DO NOT use the appliance for extended
periods of time.
This appliance is designed to be wall
mounted. Do not use this appliance near
curtains. It should be used on a rm
surface.
Do not position the appliance directly
below a power socket. The appliance
should be positioned so that the plug is
always accessible. When positioned near
the socket, the heat generated by the
appliance could damage the electrical
installation.
Avoid using this appliance with an
extension cord as this may overheat and
cause a risk of re. If necessary, ensure
that extension:
- is suited for appliance’s amperage (13A)
- cord is not creating tip hazard
- is not by any means damaged;
- no other appliances are plugged in
to the same extension or wall socket
otherwise it could overload the power
supply network.
Do not move, shake or touch the heater
when in use.
Never insert ngers and any objects
through the protective guards into the
appliance.
To avoid overheating and reduce the risk
of re - DO NOT COVER THE HEATER!
This appliance must not be used in
the immediate vicinity of a sink, bath,
shower or swimming pool.
The appliance must never be used
without be correctly xed to a wall.
Ensure the air can freely enter and
escape to avoid heat build-up inside the
appliance.
Never leave the switched on appliance
unattended.
When heater is being used for the
rst time there might be a temporary
presence of small amount of smoke
and odour because the appliance and
its heating elements are coated with a
thin lm of grease. This is not harmful
and will stop after a short while.
The prolonged presence of odour is
almost always an indication of damage.
If you notice any suspicious odours,
unplug from mains and have the
appliance inspected.
This appliance may only be used
when upright. Ensure the appliance is
assembled correctly with the handle on
top and power cable on the bottom.
Never insert ngers or other objects
through the protective guards into the
appliance.
Ensure the space underneath the heater
is clear and free of dust or loose debris.
The heat input is located underneath, if
blocked it can result in heat build-up,
malfunction and cause re.
HEAT1100_Instructions_Final.indd 7 22/06/2016 09:39:07

HEAT1100/V1-170516 -7-
-6-
5 Overheating protection
7 Disposal of packaging/appliance
Never cover the appliance or position too close to the wall and other objects so that it
can suciently distribute the heat generated. Ensure the safety grills are free from any
obstacle and they are not dusty. If the overheating protection stops the appliance on
more than two occasions, please refrain from using the appliance until it cooled down
completely.
RISK OF ELECTRIC SHOCK!
For safety reasons this heating appliance is tted with an overheating protector (thermal cut-out).
The heating element within this appliance switches itself o automatically when the appliance
become too hot internally. The heater will return to normal working operation when the appliance
has cooled down.
Never leave children unattended with the packaging material. Risk of suocation.
Your appliance is wrapped in packaging to protect it against transportation damage.
Dispose of the packaging in the most environmentally friendly way possible.
If possible, keep the appliance’s original packaging furing the warranty period so
that in the event of warranty claim, you can package the appliance safely for its
return.
This crossed-out wheeled bin symbol indicates that the item should not be disposed
of with household waste. The item should be handed in for recycling in accordance
with local enironmental regulations for waste disposal and in accordance with EC
Directive 2002/96/EEC - WEEE (Waste Electrical and Electronic Equipment). Dispose of
the unit at a suitable collection or recycling point. For more information or to locate
your nearest collection point, please contact the local authorities responsible for
waste disposal.
HEAT1100_Instructions_Final.indd 8 22/06/2016 09:39:07

HEAT1100/V1-170516
-7-
-6-
8 Appliance parts and features
Remove the appliance from the box and check all the parts listed below are included before
proceeding with the assembly. Remove all the packaging from the appliance and place it in the
box or dispose of safely. Please make sure children and pets are not present during unpacking
assembly - packaging foils and small parts are not toys!
Product Contents:
1. Fan heater
2. Glass panel
3. Top wall bracket/bottom wall bracket
4. 5x 4cm screw/5x wall plug
5. 2x small screw
6. Remote control
Product Features:
A. Illuminated ames/log
B. Operating switches
C. Heat output (top)
D. Heat input (back)
E. Glass panel
F. LED lighting (Inside-pre-tted)
E
B
A
F
D
C D
3
1
2
3
5
64
HEAT1100_Instructions_Final.indd 9 22/06/2016 09:39:09

-9-
HEAT1100/V1-170516
-8-
9 Assembly and set up
Ensure the heater is unplugged from mains power supply. Do not connect appliance until securely
xed and instruction manual is read in full.
WARNING! Wall mouning of this appliance requires minimum of two persons capable of lifting
heavy loads.
WARNING! Failure to install this appliance as instructed below may result in damage to the
equpiment or expose the user to the risk of re or serious injury.
Before proceeding with installation, ensure the glass panel is removed from the front of the
heater!
Install the bottom wall bracket following the instructions below.
Choose the location carefully. Have two people holding the main heater body against the wall
to ensure the position gives optimal viewing angle of the ame and does not create hazard or
obstruction. Take care.
min. 500mm
min. 500mm
min.
500mm
Position the wall bracket against the wall. Mark the 4 holes accordingly and remove the
bracket. Using a power drill make the holes. Insert wall plugs and replace the bracket. Secure
the bracket in place using the xings supplied.
1.
2.
3.
4.
HEAT1100_Instructions_Final.indd 10 22/06/2016 09:39:11

-9-
HEAT1100/V1-170516
-8-
Fireplace Eect Only Operation (NO HEAT)
Heater Fan Ventilator Operation with Fire Eect
10 First use and operation
Plug the heater into mains power supply.
Set the Operating Switch (B-1) to position 1 (ON).
Keep heat setting switches in OFF position (B-2; B-3)
To turn the heater o, turn the operating switch (B-1) to setting O.
Once the bracket is secure attach the heater by lifting it over and sliding it down onto the
bracket to secure in place.
Mark the hole located on the bottom bracket using pencil on the wall and remove the heater by
sliding it upwards away from the top bracket. Drill the hole and insert the wall plug.
Replace the heater following step 5 and insert the screw through the bottom bracket into the
wall.
Finally ensure that the heater is secure before leaving unattended.
5.
6.
7.
8.
Plug the heater into mains power supply.
Set the Operating Switch (B-1) to position 1 (ON) to activate the appliance.
Set the heat setting by pressing the operating switches (B-2) and (B-3) to desired heat setting.
Both, fan and re eect illumination should turn on.
To turn the fan heater o, turn the operating switch (B-1) to setting O.
Ensure the heater is unplugged from mains power supply. When correctly set up, plug the
appliance in to the mains power supply.
Operating Switch
The main operating switch features the following
three settings:
To operate the Fan Heater please use the operating
switch to select the desired setting.
- Appliance ON/OFF Switch
- Fire eect only Heater ON/OFF
- Low / High Heat Fan Settings
Never cover the appliance or position too close to the wall and other objects so that it can
suciently distribute the heat generated. Ensure the heater is positioned on at, stable
surface. It is not recommended to use the appliance during adverse weather conditions or
strong winds.
RISK OF FIRE!
1
13
3
B
2
2
HEAT1100_Instructions_Final.indd 11 22/06/2016 09:39:11

HEAT1100/V1-170516 -11-
-10-
6 Cleaning, maintenance and storage
Always wait for the heater to cool down completely and unplug it from the mains power
supply before cleaning or user maintenance. Do not allow the heating elements or other
electrical components to come into contact with water or cleaning solutions. Disconnect
the mains power plug if you do not intend to use the appliance for an extended period of
time.
RISK OF ELECTRIC SHOCK!
If necessary, clean external of the heater with a soft, slightly damp cloth with or without a mild
cleaning solution.
Polish dry with a soft, dry cloth. DO NOT use the appliance again until it has dried completely of if
you suspect internal parts might have come in contact with liquids. Remove dust deposits on the
protective screen with a vacuum cleaner.
Caution! Do not use abrasive or solvent cleaning products, as this could damage your appliance.
Caution! Always store this appliance in a safe, dry location out of foot trac to avoid a tripping
hazard and away from the reach of children.
Please follow the bulb replacement instructions on next page if bulb included with this product
stops working. Specication of the bulb can be found on page 10 within these instruction manual
in Technical Specication section.
HEAT1100_Instructions_Final.indd 12 22/06/2016 09:39:11

HEAT1100/V1-170516
-11-
-10-
11 Plug wiring (CLASS 1 Appliance)
12 Technical specication
13 Declaration of conformity
IMPORTANT! Should it be necessary to change the plug, please note that the wires in the mains
lead are coloured in accordance with the following code:
Green/Yellow - Earth
Blue - Neutral (N)
Brown - Live (L)
This appliance is tted with an approved BS 1363 13A 3 pin plug and a 13A BS 1362 fuse. In the event
of either requiring replacement, ensure that the equivalent rated and approved components are
used.
If your appliance has been tted with a NON-REWIREABLE MAINS PLUG: If you need to remove
the plug, disconnect from mains power supply and then cut it o the mains lead, immediately
dispose of it separately. NEVER attempt to reuse the plug or insert it into a socket outlet as there
is a danger of electric shock.
WARNING! - THIS APPLIANCE MUST BE EARTHED!
This product complies with all applicable European Directives and legally prescribed standards.
As the colours of the exible cord of
this appliance may not correspond
with the coloured markings identifying
terminals in your plug proceed as
follows: Earth wire
Fuse
Live wire
Cable grip
Outer Insulation
Neutral wire
Connect GREEN/YELLOW cord to
terminal marked with the letter
‘E’ or Earth symbol.
Connect BROWN wire to the
terminal marked with the letter
‘L’ or coloured RED.
Connect BLUE wire to the terminal
marked with the letter ‘N’ or
coloured BLACK.
Model No.
Power Supply
Power Consumption
Appliance Safety Class
Ingress Protection
HEAT1100
220-240V~50-60Hz
900W/1800W
CLASS 1 Appliance
Indoor use in dry locations
HEAT1100_Instructions_Final.indd 13 22/06/2016 09:39:12

If the below box doesn’t state the batch number, please copy it from the retail
packaging or rating plate. The batch number is located below the barcode on the back
of the box and on the rating label on the product.
If problems are encountered with this appliance, please quote your product code
(HEAT1100) and the above batch number every time you contact the manufacture,
distributer or retailer your purchase was made at.
IMPORTED AND DISTRIBUTED BY:
BONNINGTONS
GLAISDALE PARKWAY, NOTTINGHAM. NG8 4GP (UK)
BATCH NUMBER:
HEAT1100_Instructions_Final.indd 2 22/06/2016 09:39:12
