Lincoln Impinger II 1100 Series User manual

Impinger® II Express
easyTouch & Digital
Series 1100 Series Conveyor Oven
Domestic / International Service Manual
GAS AND ELECTRIC OVENS FOR USA AND NON-USA COUNTRIES
Consistency You Can Count On
Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Original Document

2 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
THIS PAGE INTENTIONALLY LEFT BLANK

Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 3
Safety Notices
DEFINITIONS
DANGER
Indicates a hazardous situation that, if not avoided, will
result in death or serious injury. This applies to the most
extreme situations.
nWarning
Indicates a hazardous situation that, if not avoided,
could result in death or serious injury.
,Caution
Indicates a hazardous situation that, if not avoided,
could result in minor or moderate injury.
Notice
Indicates information considered important, but not
hazard-related (e.g. messages relating to property
damage).
NOTE: Indicates useful, extra information about the
procedure you are performing.
Read These Before Proceeding:
DANGER
Do not install or operate equipment that has been
misused, abused, neglected, damaged, or altered/
modified from that of original manufactured
specifications.
Important
Read these instructions for use carefully so as to
familiarize yourself with the appliance before connecting
it to its gas container. Keep these instrucions for future
reference.
nWarning
Improper installation adjustment, alteration, service
or maintenance can cause property damage, injury or
death. Read the installation, operating and maintenance
instructions thoroughly before installing or servicing
this equipment.
nWarning
Authorized Service Representatives are obligated to
follow industry standard safety procedures, including,
but not limited to, local/national regulations for
disconnection / lock out / tag out procedures for all
utilities including electric, gas, water and steam.
nWarning
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
concerning use of the appliance by a person responsible
for their safety. Do not allow children to play with this
appliance.
nWarning
This equipment is intended for indoor use only. Do not
install or operate this equipment in outdoor areas.
nWarning
Do not use electrical appliances or accessories other
than those supplied by the manufacturer.
FOR YOUR SAFETY
Do Not Store Or Use Gasoline Or Other Flammable
Vapors Or Liquids In The Vicinity Of This Or Any Other
Appliance.
nWarning
Never use a high-pressure water jet for cleaning or hose
down or flood interior or exterior of units with water. Do
not use power cleaning equipment, steel wool, scrapers
or wire brushes on stainless steel or painted surfaces.
,Caution
Maintenance and servicing work other than cleaning as
described in this manual must be done by authorized
service personnel.
,Caution
Improper cleaning of oven could damage catalyst(s) in
ventless models and will void unit warranty.
NOTE: Proper installation, care and maintenance are essential
for maximum performance and trouble-free operation of
your equipment. Visit our website www.wbtkitchencare.com
for manual updates, translations, or contact information for
service agents in your area.

4 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Table of Contents (continued)
THIS PAGE INTENTIONALLY LEFT BLANK

Table of Contents
Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 5
Section 1: General Information...........................................................................................................6
Section 2: Operation ........................................................................................................................... 9
Temperature Calibration..................................................................................................22
Conveyor Speed Calibration............................................................................................22
Section 3: Troubleshooting ...............................................................................................................23
Section 4: Component Replacement Procedures ........................................................................... 61
Section 5: Schematics ........................................................................................................................72
Lincoln Start-Up Form ......................................................................................................................... 92
Lincoln Equipment Limited Warranty .................................................................................................94

6 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Model Number Key
Example: 1133-005-E-K1801
11 33 005–––EK1801
OVEN PLATFORM SIZE
(i.e. Impinger III)
INDICATES CHANGE TO BASE ASSEMBLY
(i.e. Natural Gas, 230V, 1 phase, 50 Hz)
LANGUAGE CODE
CUSTOM CONFIGURATION CODE
(i.e. General Market)
AGENCY CODE
PANEL SETUP CODE
Language Code
Code Language Country
0 English Dom. & Int. Default
B French CE – France/Luxembourg
C German CE – Germany
D Italian CE – Italy
E Spanish CE – Spain
F English CE – UK/India/Africa/Hungary
G Spanish Mexico/Latin America
H Portuguese CE – Portugal
I Not Used ---
J Danish CE – Denmark
K Dutch & French CE – Belgium
L Dutch CE – Netherlands
M Greek CE – Greece
N Finnish CE – Finland
O Restricted ---
P Norwegian CE – Norway
Q English Japan
R Swedish CE – Sweden
S English Australia
T Mandarin China
U Restricted ---
V English Pacific Rim/Korea
W English Middle East/Africa
X Not Used ---
Y Not Used ---
Z Not Used ---
Agency Code
Code Agency
N No agency
E CE & RoHS compliance combined
U US & Canada compliance only
A Advantage style oven
B Australia AGA
OLD MODEL NUMBERS EXAMPLES
Please note that the model numbering system changed
March 2007. The chart below shows the old model
numbering system and its matching new model number.
Please see Page 3 for complete list.
Old Model Number "New Model Number
1116-080-A (or A1) "1116-00z-U-Kxxxx
1132-080-A (or A1) "1132-00z-U-Kxxxx
1161-080-A "1131-00z-U-Kxxxx
1154-080-EA "1154-z00-U-Kxxxx
1164-000-EA "1164-z00-U-Kxxxx
Section 1
General Information

Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 7
Section 1 General Information
Old Model Current Model Input Rate Voltage Current Phase Hz #, Supply Wires
1116-080-A
1116-062-A
1116-023-A
"1116-xxx-U N
a
t
u
r
a
l40,000 BTU/Hr.
11.7 kW/42.2
120 7 1 60 3, 1 Pole+N+G
1116-080-A1 "1116-037-U 7 1 3, 1 Pole+N+G
1154-000-EA
1154-080-EA "1154-xxx-E 230 2 1 50 3, 2 Pole+G
1154-V80-EA "1157-xxx-N 220 2 1 60 3, 2 Pole+G
N/A 1178-xxx-U 120 7 1 60 3, 1 Pole+N+G
1117-080-A
1117-023-A "1117-xxx-U
L
P
120 7 1 60 3, 1 Pole+N+G
1117-080-A1 "1117-037-U 7 1 3, 1 Pole+N+G
1155-000-EA
1155-080-EA "1155-xxx-E 230 2 1 50 3, 2 Pole+G
1155-V80-EA "1158-xxx-N 220 1 60 3, 2 Pole+G
1130-080-A
1130-080-A1 "1130-xxx-U
E
l
e
c
t
r
i
c
10kW
208 48 1 60 3, 2 Pole+G
1130-08H-A N/A 48 1 3, 2 Pole+G
1131-080-A
1161-080-A "1131-xxx-U
240
42 1
60
3, 2 Pole+G
1131-080-A1 "1131-037-U 42 1 3, 2 Pole+G
1131-08H-A N/A 42 1 3, 2 Pole+G
1132-080-A
1132-023-A
1162-080-A
"1132-xxx-U
208
28 3
60
4, 3 Pole+G
1132-080-A1 "1132-037-U 28 3 4, 3 Pole+G
1132-08H-A "1172-xxx-U 28 3 4, 3 Pole+G
1132-002-A "1174-xxx-U 28 3 4, 3 Pole+G
1133-080-A
1133-080-A1 "1133-xxx-U 240 25 3 60 4, 3 Pole+G
1133-08H-A "1173-xxx-U 25 3 4, 3 Pole+G
N/A 1134-xxx-N 380/208 16 3 50 5, 3 Pole+N+G
N/A 1135-xxx-U 480 15 3 60 4, 3 Pole+G
1164-000-EA
1164-080-EA "1164-xxx-E 400/230 15 3 50 5, 3 Pole+N+G
Gas Pressure Conversion
Inches of Water
Column
kPa m-Bar Millimeters of
Water Column
3.5 0.87 8.70 88.9
4.5 1.12 11.2 114.3
7 1.74 17.40 177.8
8 1.99 19.90 203.2
9.2 2.29 22.90 233.7
10 2.48 24.87 254.0
10.5 2.61 26.11 266.7
11 2.73 27.36 279.4
14 3.48 34.81 355.6
14.5 3.61 36.05 368.3
1100 Series Model Number

8 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
General Information Section 1
Utility Service Layout – Models 1116 & 1117
Gas and electrical services for the Models 1116 and 1117 should be located as shown below. If flexible services are provided,
they must meet code requirements for such installation.
Purchaser’s Responsibility:
It is the responsibility of the purchaser:
1. To see that the gas and electric services for the oven are installed on site in accordance with the
manufacturer’sspecification.
2. To unload, uncrate, and install the oven in its proper location; in accordance with this service manual.
3. To see that the gas and electric services are connected properly by a qualified installer of your choice. For installation
in the State of Massachusetts: Installation of this oven must be performed by a licensed plumber or gas fitter. All such
connections must be in accordance with applicable code requirements.
4. Arrange for inspection and operation check-out by an Authorized Service Technician. Do not attempt to operate
the oven until connection of utility service has been fully inspected by a Factory Authorized Servicer or a Lincoln
Foodservice Products, LLC Service Representative. This service is required by LincolnFoodservice Products, LLC in order
to assist the purchaser in proper start-up of the oven on site. Please note the specific details on the Warranty and make
certain connections are made to proper utility services.The warranty shall not apply if the oven(s) are started up and
operated prior to the utilities and oven being inspected and check-out made by a Factory Authorized Servicer or a
Lincoln Foodservice Products, LLC Service Representative.
27"
(686 mm)
39-5/8"
(1006 mm)
57-1/8"
(1451 mm)
44-1/2"
(1130 mm)
62"
(1575 mm)
30-1/2"
(775 mm)
48"
(1219 mm)
35-3/4"
(908 mm)
17-1/2"
(444 mm)
17-1/2"
(444 mm)
18-1/4"
(464 mm)
9-1/2"
(241 mm)
62"
(1575 mm)
13"
(330 mm)
22"
(559 mm)
30-1/2"
(775 mm)
39-1/2"
(1003 mm)
48"
(1219 mm)
57"
(1448 mm)
17-1/2"
(444 mm)
Side view of two Impinger® II Gas Ovens showing Gas
Valve Installation point and piping spacing.
Side view of three Impinger® II Gas Ovens showing Gas
Valve Installation point and piping spacing.

Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 9
Section 2
Operation
Sequence of Operation – Impinger II Domestic Advantage Digital, Gas
S/N: 2038616 to S/N: 2106100101444 (Ovens with push button controls)
Old Model Number "New Model Number Gas Type Voltages Hz Phase
1116-080-A (or A1)
"1116-xxx-U Natural
120 VAC 60 HZ 1
1116-062-8A
1116-023-A
1178-xxx-U Natural
1117-080-A (or A1)
"1117-00z-U
1117-xxx-U LP Gas
1117-023-A
POWER SUPPLY Electrical power is supplied to the oven by a three-conductor cord set.
Voltage from the black conductor to the white conductor is 120VAC.
Black conductor is hot.
White conductor is neutral.
Green conductor is ground.
CONTROL BOX AUTO
COOL DOWN
When the temperature in the control boxes reaches 120°F ±3° (49°C ± 1.7°), the cooling fan thermostat
will switch power to the cooling fans. The thermostat will interrupt power to the cooling fans when the
temperature falls to 100°F ± 3° (37°C ± 1.7°).
MAIN FAN CIRCUIT Power is permanently supplied, through a 10 amp fuse, to the normally open main power switch. Power is
also supplied to the normally open cooling fan thermostat. Closing the main power switch supplies 120VAC
to the main fan motor, the cooling fan motors, the primary of the control transformer, the conveyor motor
and to the ignition control.
BURNER CIRCUIT Closing the main power switch supplies 120VAC to the burner blower motor. 120VAC is also supplied,
through the main fan centrifugal switch (this switch closes when the main fan reaches approx. 1600 RPM)
and the normally closed oven cavity hi-limit thermostat, to the primary of the burner transformer. 120VAC is
also supplied to the oven control.
IGNITION CONTROL The ignition control operates on both 24VAC and 120VAC. When the control is energized by 24VAC from
the transformer, 120VAC is switched by the ignition control to the hot surface igniter for 45 seconds for the
hot surface igniter warm up. The igniter glows red, 24VAC is switched to the gas valve, which opens, and
ignition should now occur.
TEMPERATURE CONTROL Closing the oven power switch supplies line voltage, through the 10A fuse, through the oven power relay,
to the primary of the control transformer. 24VAC is supplied to the oven control. The oven control is set
to desired temperature. The right thermocouples will provide varying millivolts to the oven control. The
oven control supplies line voltage to the temperature regulation valve at intermittent intervals to maintain
desired temperature. The display on the oven control will indicate when the temperature regulation valve is
energized. NOTE: The display also indicates oven temperature of the oven.
CONVEYOR DRIVE Closing the oven power switch supplies line voltage, through the 10A fuse, through the oven power relay to
the conveyor motor and to the primary of the control transformer. Secondary voltage, 24VAC, is supplied to
the oven control. Setting the oven control to the desired time outputs voltage, through a reversing switch,
to the conveyor motor. NOTE: The conveyor system uses a magnet and Hall Effect sensor to prove operation
of the conveyor motor. If the conveyor motor is not running, “BELT JAM” is indicated on the display.

10 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Operation Section 2
Unit Plugged Into Power
• F1 fuse energized with L1
• Main Rocker Power Switch Input Energized with L1 and
Neutral. Green Light ON
Note: Green light will not be implemented with
first generation units
• Cooling Fan Thermostat energized with L1
• Blower Main and Cooling Fans energized with Neutral
Power Switch Turned ON
• Blower Main energized with L1
• Blower Burner energized with L1 and Neutral Power
• Cooling Fans energized with L1
• IO Board on-board SSR/Relay (COM) energized with L1
• High Heat Valve energized with Neutral Power
• Ignition Module L1 and L2 energized with L1 and
Neutral Power
• Cooling Fan Thermostat energized with L1
• Thermal capillary disc energized with L1
• Transformer energized with L1 and Neutral Power (If
both Thermal capillary disc and Blower Main centrifugal
switch are not tripped)
• Ignition Module input energized with 24VAC (If Blower
Burner centrifugal switch is not tripped)
• 24VDC Power Supply Energized with L1 and Neutral
Power
• DC 4A fuse Energized, which protects the DC
components: UI and IO board
• IO Board Energized
• IO Board boots up UI
• UI initiates with Welbilt BOOT screen
• UI Loads to Home Screen after small delay in time
• Optional Motor Drive Energized with 24VDC
Press and Go Selected
• UI displays Recipes
• Recipe Selected
• Once Pre-Heating is complete, Recipe Mode is engaged
• Oven will maintain temperature set point
• Conveyor will turn on to recipe cook time speed
Chef Mode (Manual Mode) Selected
• Enter Temperature Set Point
• Enter Conveyor belt speed (min:sec)
• In this mode, temperature and motor speed values will
change automatically when on this screen, but these set
points can be saved into a recipe when the save button
is pressed
• Blower Main and Cooling Fans energized with Neutral
Power
• Save Button Pressed
Select Recipe
Change icon or color if applicable
Press the save button
NOTE: See Section 5 - Wiring Schematics
for reference.
Sequence of Operation – Impinger II Domestic 1116,1117 easyTouch, Gas
S/N: 2106100101445 and above (easyTouch controls)

Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 11
Section 2 Operation
Old Model Number "New Model Number Gas Type Voltages Hz Phase
1154-000-EA "1154-xxx-E Natural 230VAC 50 Hz
1
1154-080-EA
1154-V80-EA "1157-xxx-N 220 VAC 60 Hz
1155-000-EA "1155-xxx-E
LP Gas 230 VAC 50 Hz
1155-080-EA
1155-V80-EA "1158-xxx-N 220 VAC 60 Hz
POWER SUPPLY Electrical power to be supplied to the oven by a three-conductor service.
CONTROL BOX AUTO
COOL DOWN
When the temperature in the control box reaches 120°F ±3° (49°C ± 1.7°), the cooling fan thermostat
will switch power to the cooling fans. The thermostat will interrupt power to the cooling fans when the
temperature falls to 100°F ± 3° (37°C ± 1.7°).
MAIN FAN CIRCUIT Power is permanently supplied through a 10 amp oven fuse to the normally open double pole oven fan
switch. Closing the oven fan switch supplies line voltage to the main fan motor. Closing the main fan switch
also supplies voltage to the cooling fans and the EMI Filter to the primary of the control transformer, the
conveyor motor, and the burner system.
BURNER CIRCUIT Closing the oven fan switch supplies line voltage through the normally open air pressure switch (closed by
the air pressure from the main fan), through the normally closed oven cavity hi-limit thermostat (opens at
662°F, 350°C), and to the ignition control.
IGNITION CONTROL The ignition control switches line voltage to the combustion blower motor. The combustion air pressure
switch switches from normally closed to normally open upon sensing air pressure in the burner housing.
After a pre-purge period of between 30 and 60 seconds, the spark is energized, the main gas valve and the
burner pilot light are energized, and ignition should now occur.
TEMPERATURE CONTROL When the power supply is passed through the EMI Filter the load will supply line voltage to the primary
of the control transformer. Secondary voltage, 24VAC, is supplied to the oven control. The oven control is
set to desired temperature. The thermocouple will provide varying millivolts to the oven control. The oven
control supplies line voltage to the temperature regulation valve at intermittent intervals to maintain the
desired temperature. The display on the oven control will indicate when the temperature regulation valve is
energized. NOTE: The display also indicates oven temperature.
CONVEYOR DRIVE When the power supply is passed through the EMI Filter the load will supply line voltage to the primary of
the control transformer. Secondary voltage, 24VAC, is supplied to the oven control. Setting the oven control
to the desired time outputs voltage, through a reversing switch, to the conveyor motor.
NOTE: The conveyor system uses a Hall Effect sensor and magnet to prove operation of the conveyor motor.
If the conveyor motor is not running, “BELT JAM” is indicated on the display.
Sequence of Operation – Impinger II International Advantage Digital, Gas
(Ovens with push button controls) S/N: 21111001007 and Below

12 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Operation Section 2
Unit Plugged Into Power
• F1 fuse energized with L1
• Main Rocker Power Switch Input Energized with L1 and
Neutral Power. Green Light ON
Note: Green light will not be implemented with
first generation units
• Cooling Fan Thermostat energized with L1
• Blower Main and Cooling Fans energized with Neutral
Power
Power Switch Turned ON
• Blower Main energized with L1
• Cooling Fans energized with L1
• IO Board on-board SSR/Relay (COM) energized with L1
• High Heat Valve energized with Neutral Power
• Cooling Fan Thermostat is energized with L1
• Air Pressure Switch Main energized with L1
• Thermal capillary disc is energized with L1 (If the air
pressure switch is not tripped)
• Ignition Module input energized with L1 and N (If APS1
and TH2 are not tripped). The Ignition Module provides
power to the Blower Burner and to Main Valve
• 24VDC Power Supply Energized with L1 and Neutral
Power
• DC 4A fuse Energized, which protects the DC
components: UI and IO board
• IO Board Energized
• IO Board boots up UI
• UI initiates with Welbilt BOOT screen
• UI Loads to Home Screen after small delay in time
• Optional Motor Drive Energized with 24VDC
Press and Go Selected
• UI displays Recipes
• Recipe Selected
• Once Pre-Heating is complete, Recipe Mode is engaged
• Oven will maintain temperature set point
• Conveyor will turn on to recipe cook time speed
Chef Mode (Manual Mode) Selected
• Enter Temperature Set Point
• Enter Conveyor belt speed (min:sec)
• In this mode, temperature and motor speed values will
change automatically when on this screen, but these set
points can be saved into a recipe when the save button
is pressed.
• Blower Main and Cooling Fans energized with Neutral
Power
• Save Button Pressed
Select Recipe
Change icon or color if applicable
Press the save button
NOTE: See Section 5 - Wiring Schematics
for reference.
Sequence of Operation – Impinger II International 1154,1155 easyTouch Gas
S/N: 2111100101008 and above (easyTouch controls)

Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 13
Section 2 Operation
Unit Plugged Into Power
• Power Failure Alarm Relay common terminals energized
with L1
• Power Failure Alarm Relay coil energized with Neutral
Power
• Push Button, Reset Alarm (PB2) energized with L1
• Alarm energized with L1 and Neutral Power
Unit plugged into power, PB2 pressed one time and no
power failure during machine operation
• After pressing Push Button, Reset Alarm one time, the
Power Failure Alarm Relay activates, bypassing PB2 and
disconnecting the alarm. The K1 coil will stay energized
unless there is a power failure
• F1 fuse energized with L1
• Main Rocker Power Switch input energized with L1 and
Neutral. The green light ON. Note: Green light will not be
implemented with first generation units.
• Cooling Fan Thermostat energized with L1
• Blower Main and Cooling Fans energized with Neutral
Power
Power Switch Turned ON
• Blower Main energized with L1
• Cooling Fans energized with L1
• IO Board on-board SSR/Relay energized with L1
• High Heat Valve energized with Neutral Power
• Cooling Fan Thermostat energized with L1
• Air Pressure Switch Main energized with L1
• Thermal capillary disc energized with L1 (If Air Pressure
Switch is not tripped).
• Ignition Module input energized with L1 and Neutral
Power (If Air Pressure Switch and Thermal capillary are
not tripped). The Ignition Module provides power to the
Blower Burner and to Main Valve
• 24VDC Power Supply is energized with L1 and Neutral
Power
• DC 4A fuse is energized, which protects the DC
components "UI and IO boards"
• IO Board energized
• IO Board boots up UI
• UI initiates with Welbilt BOOT screen
• UI Loads to Home Screen after small delay in time
• Optional Motor Drive Energized with 24VDC
Press and Go Selected
• UI displays Recipes
• Recipe Selected
• Once Pre-Heating is complete, Recipe Mode is engaged
• Oven will maintain temperature set point
• Conveyor will turn on to recipe cook time speed
Chef Mode (Manual Mode) Selected
• Enter Temperature Set Point
• Enter Conveyor belt speed (min:sec)
• In this mode, temperature and motor speed values will
change automatically when on this screen, but these set
points can be saved into a recipe when the save button
is pressed.
• Blower Main and Cooling Fans energized with Neutral
Power
• Save Button Pressed
Select Recipe
Change icon or color if applicable
Press the save button
NOTE: See Section 5 - Wiring Schematics
for reference.
Sequence of Operation – Impinger II International (Korea) 1157,1158 easyTouch, Gas
S/N: 2111100101008 and above (easyTouch controls)

14 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Operation Section 2
Old Model Number "New Model Number Voltages Hz Phase
1130-080-A "1130-xxx-U 120/208
60
1
1130-080-A1
1130-08H-A N/A
1131-080-A "1131-xxx-U
120/240
1161-080-A
1131-080-A1 "1131-037-U
1131-08H-A N/A
1132-080-A
"1132-xxx-U
120/208
3
1132-023-A
1162-080-A
1132-080-A1 "1132-037-U
1132-08H-A "1172-xxx-U
1132-002-A "1174-xxx-U
1133-080-A "1133-xxx-U 120/2401133-080-A1
1133-08H-A "1173-xxx-U
POWER SUPPLY Electrical power to be supplied to the oven by a three conductor service for single phase and a four
conductor service for three phase.
Black conductor is hot.
Red conductor is hot.
Orange conductor is hot (used for three phase only).
White conductor is neutral.
Green conductor is ground.
CONTROL BOX AUTO
COOL DOWN
When the temperature in the control box reaches 120°F ±3° (49°C ± 1.7°), the cooling fan thermostat
will switch power to the cooling fans. The thermostat will interrupt power to the cooling fans when the
temperature falls to 100°F ± 3° (37°C ± 1.7°).
MAIN FAN CIRCUIT Power is permanently supplied through the 10 amp fuses, through the normally closed oven cavity hi-limit
thermostat, to the normally open main power switch. Power is also supplied to the normally open cooling
fan thermostat. Closing the main power switch energizes the coil of the oven start relay, it’s contacts close
enabling the 20 minute time delay relay. The 20 minute time delay relay supplies 120VAC to the oven fan
relay, these normally open contacts now close supplying 208/240VAC to the main fan motor. 120VAC is also
supplied to the cooling fans. 208/240VAC is supplied to the primary of the control transformer, the conveyor
motor and, through the air pressure switch, to the oven control.
TEMPERATURE CONTROL Closing the main power switch supplies 208/240VAC to the primary of the control transformer. Secondary
voltage, 24VAC, is supplied to the oven control. The oven control is set to desired temperature. The
thermocouple will provide varying millivolts to the oven control. The oven control supplies 208/240VAC to
the coil of the heater relay at intermittent intervals to maintain the desired temperature. The display on the
oven control will indicate when the heater relay is energized.
NOTE: The display also indicates oven temperature.
CONVEYOR DRIVE Closing the main power switch supplies 208/240VAC to the conveyor motor and to the primary of the
control transformer. Secondary voltage, 24VAC, is supplied to the oven control. Setting the oven control to
the desired time outputs voltage, through a reversing switch, to the conveyor motor.
NOTE: The conveyor system uses a Hall Effect sensor and magnet to prove operation of the conveyor motor.
If the conveyor motor is not running, “BELT JAM” is indicated on the display.
AUTOMATIC COOL DOWN When the oven is started, the time delay relay timing circuit is enabled, permitting the oven fans to run
approximately 20 minutes after the oven is shut off, to cool the oven. The time delay relay will keep the coil
of the fan relay closed, maintaining operation of the main fan and cooling fans.
Sequence of Operation – Impinger II Domestic Advantage Digital, Electric w/ Neutral
S/N 0809210000016 & Below
(Ovens with push button controls)

Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 15
Section 2 Operation
Old Model Number "New Model Number Voltages Hz Phase
1130-080-A "1130-xxx-U or (V) 208
60
1
1130-080-A1
1130-08H-A N/A
1131-080-A "1131-xxx-U or (V)
240
1161-080-A
1131-080-A1 "1131-037-U
1131-08H-A N/A
1132-080-A
"1132-xxx-U or (V)
208
3
1132-023-8
1162-080-A
1132-080-A1 "1132-037-U
1132-08H-A "1172-xxx-U
1132-002-8 "1174-xxx-U
1133-080-A "1133-xxx-U or (V) 2401133-080-A1
1133-08H-A "1173-xxx-U
POWER SUPPLY Electrical power to be supplied to the oven by a three conductor service for single phase and a four
conductor service for three phase.
Black conductor is hot.
Red conductor is hot.
Orange conductor is hot (used for three phase only).
Green conductor is ground.
CONTROL BOX AUTO
COOL DOWN
When the temperature in the control box reaches 120°F ± 3° (48.9°C ± 1.7°), the cooling fan thermostat will
switch power to the control box cooling fans. The thermostat will interrupt power to the cooling fans when
the control box temperature falls to 100°F ± 3° (37.8°C ± 1.7°).
MAIN FAN CIRCUIT Power is permanently supplied through the 10 amp fuses, through the normally closed oven cavity hi-limit
thermostat, to the normally open main power switch. Power is also supplied to the normally open cooling
fan thermostat. Closing the main power switch energizes the coil of the cool down timer relay, its contacts
close enabling the 30 minute time delay relay. The 30 minute time delay relay supplies 208/240VAC to the
oven fan relay, these normally open contacts now close supplying 208/240VAC to the main fan motor.
208/240VAC is also supplied to the cooling fans. 208/240VAC is supplied to the primary of the control
transformer, the conveyor motor and, through the air pressure switch, to the oven control.
TEMPERATURE CONTROL Closing the main power switch supplies 208/240VAC to the primary of the control transformer. Secondary
voltage, 24VAC, is supplied to the oven control. The oven control is set to desired temperature. The
thermocouple will provide varying millivolts to the oven control. The oven control supplies 208/240VAC to
the coil of the heater relay at intermittent intervals to maintain the desired temperature. The display on the
oven control will indicate when the heater relay is energized.
NOTE: The display also indicates oven temperature.
CONVEYOR DRIVE Closing the main power switch supplies 208/240VAC to the conveyor motor and to the primary of the
control transformer. Secondary voltage, 24VAC, is supplied to the oven control. Setting the oven control to
the desired time outputs voltage, through a reversing switch, to the conveyor motor.
NOTE: The conveyor system uses a Hall Effect sensor and magnet to prove operation of the conveyor motor.
If the conveyor motor is not running, “BELT JAM” is indicated on the display.
AUTOMATIC COOL DOWN When the oven is started, the time delay relay timing circuit is enabled, permitting the oven fans to run
approximately 30 minutes after the oven is shut off, to cool the oven. The time delay relay will keep the coil
of the fan relay closed, maintaining operation of the main fan and cooling fans.
Sequence of Operation – Impinger II Domestic Advantage Digital, Electric w/o Neutral
S/N 0809210000017 to S/N 2104100102812
(Ovens with push button controls)

16 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Operation Section 2
Unit Plugged Into Power
• F1 fuse energized with L1
• F2 fuse energized with L2
• Safety Contactor input energized with L1 and L2 power
• Optional Receptacle energized with L1 and L2
• Main Rocker Power Switch Input Energized with L1 and
L2. Green Light ON
Note: Green light will not be implemented with first
generation units
• Cooling Fan Thermostat energized with L1
• Main Blower and Cooling Fans energized with L2
Power Switch Turned ON
• Oven high limit capillary switch energized with L1
• Component hi-limit thermostat energized with L2
• Safety Contactor engaged/energized (If the oven
high limit capillary switch and the component hi-limit
thermostat are not tripped)
• If the Safety Contactor is engaged, all six heating
elements are energized with L1
• If the Safety Contactor is engaged, all three SSRs are
energized with L2
• Cooling Fans energized with L1
• Cooling Fan Thermostat energized with L1
• Main Blower energized with L1
• 24VDC Power Supply Energized with L1 and L2 power
• DC 4A fuse energized with 24VDC, which protects the
DC components: UI and IO board
• IO Board Energized
• IO Board boots up UI
• UI initiates with Welbilt BOOT screen. UI Loads to Home
Screen after small delay in time
• Optional Motor Drive Energized with 24VDC
Press and Go Selected
• UI displays Recipes
• Recipe Selected
• Once Pre-Heating is complete, Recipe Mode is engaged
• Oven will maintain temperature set point
• Conveyor will turn on to recipe cook time speed
Chef Mode (Manual Mode) Selected
• Enter Temperature Set Point
• Enter Conveyor belt speed (min:sec)
• In this mode, temperature and motor speed values will
change automatically when on this screen, but these set
points can be saved into a recipe when the save button
is pressed.
• Blower Main and Cooling Fans energized with Neutral
Power
• Save Button Pressed
Select Recipe
Change icon or color if applicable
Press the save button
NOTE: See Section 5 - Wiring Schematics
for reference.
Sequence of Operation – Impinger II Domestic 1130,1131 easyTouch, Electric 1 Phase
S/N: 2104100102813 and above (easyTouch controls)

Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 17
Section 2 Operation
Unit Plugged Into Power
• F1 fuse energized with L1
• F2 fuse energized with L2
• Safety Contactor input energized with L1, L2 and L3
power
• Optional Receptacle energized with L1 and L2
• Main Rocker Power Switch Input Energized with L1
and L2. Green Light ON Note: Green light will not be
implemented with first generation units
• Cooling Fan Thermostat energized with L1
• Main Blower and Cooling Fans energized with L2
Power Switch Turned ON
• Oven high limit capillary switch energized with L1
• SSR Switch Disconnect energized with L2
• Safety Contactor engaged/energized (If oven high limit
capillary switch and the SSR Switch Disconnect are not
tripped)
• If the Safety Contactor is engaged, heating elements HB
and HC are energized with L1
• If the Safety Contactor is engaged, heating elements HA
and HF are energized with L2
• If the Safety Contactor is engaged, heating elements HD
and HE are energized with L3
• If the Safety Contactor is engaged, the three SSRs are
energized with L1, L2 and L3 respectively
• Cooling Fans energized with L1
• Cooling Fan Thermostat energized with L1
• Main Blower energized with L1
• 24VDC Power Supply Energized with L1 and L2 power
• DC 4A fuse energized with 24VDC, which protects the
DC components: UI and IO board
• IO Board Energized
• IO Board boots up UI
• UI initiates with Welbilt BOOT screen
• UI Loads to Home Screen after small delay in time
• Optional Motor Drive Energized with 24VDC
Press and Go Selected
• UI displays Recipes
• Recipe Selected
• Once Pre-Heating is complete, Recipe Mode is engaged
• Oven will maintain temperature set point
• Conveyor will turn on to recipe cook time speed
Chef Mode (Manual Mode) Selected
• Enter Temperature Set Point
• Enter Conveyor belt speed (min:sec)
• In this mode, temperature and motor speed values will
change automatically when on this screen, but these set
points can be saved into a recipe when the save button
is pressed.
• Blower Main and Cooling Fans energized with Neutral
Power
• Save Button Pressed
Select Recipe
Change icon or color if applicable
Press the save button
NOTE: See Section 5 - Wiring Schematics
for reference.
Sequence of Operation – Impinger II Domestic 1132, 1133 easyTouch, Electric 3 Phase
S/N: 2104100102813 and above (easyTouch controls)

18 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Operation Section 2
Old Model Number "New Model Number Gas Type Voltage Hz Phase
N/A "1135-xxx-U N/A 480 60 Hz 3
POWER SUPPLY Electrical power to be supplied to the oven by a three conductor service for single phase and a four
conductor service for three phase.
Black conductor is hot.
Red conductor is hot.
Orange conductor is hot (used for three phase only).
Green conductor is ground. L1 and L2 pass through the 10 amp fuses and go to the step down 480VAC
transformer to 240VAC.
CONTROL BOX AUTO
COOL DOWN
When the temperature in the control box reaches 120°F ± 3° (48.9°C ± 1.7°), the cooling fan
thermostat will switch power to the control box cooling fans. The thermostat will interrupt power to
the cooling fans when the control box temperature falls to 100°F ± 3° (37.8°C ± 1.7°).
MAIN FAN CIRCUIT Power is permanently supplied through the 10 amp fuses, through the normally closed oven cavity hi-limit
thermostat, to the normally open main power switch. Power is also supplied to the normally open
cooling fan thermostat. Closing the main power switch energizes the coil of the cool down timer relay,
its contacts close enabling the 20 minute time delay relay. The 20 minute time delay relay supplies
240VAC to the oven fan relay, these normally open contacts now close supplying 208/240VAC to the main
fan motor. 240VAC is also supplied to the cooling fans. 240VAC is supplied to the primary of the control
transformer, the conveyor motor and, through the air pressure switch, to the oven control.
TEMPERATURE CONTROL Closing the main power switch supplies 240VAC to the primary of the control transformer.
Secondary voltage, 24VAC, is supplied to the oven control. The oven control is set to desired
temperature. The thermocouple will provide varying millivolts to the oven control. The oven
control supplies 240VAC to the coil of the heater relay at intermittent intervals to maintain the
desired temperature. The display on the oven control will indicate when the heater relay is
energized.
NOTE: The display also indicates oven temperature.
CONVEYOR DRIVE Closing the main power switch supplies 240VAC to the conveyor motor and to the primary of
the control transformer. Secondary voltage, 24VAC, is supplied to the oven control. Setting the
oven control to the desired time outputs voltage, through a reversing switch, to the conveyor
motor.
NOTE: The conveyor system uses a Hall Effect sensor and magnet to prove. If the conveyor motor is not
running, “BELT JAM” is indicated on the display.
AUTOMATIC COOL DOWN When the oven is started, the time delay relay timing circuit is enabled, permitting the oven fans to run
approximately 30 minutes after the oven is shut off, to cool the oven. The time delay relay will keep the coil
of the fan relay closed, maintaining operation of the main fan and cooling fans.
Sequence of Operation – Impinger II Domestic Advantage Digital, Electric
(Ovens with push button controls)

Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22 19
Section 2 Operation
Old Model Number "New Model Number Voltage Hz Phase
1164-000-EA "1164-xxx-E or (V) 400/230 50 3
1164-080-EA
POWER SUPPLY Electrical power to be supplied to the oven by a four-conductor service.
Brown conductor is hot.
Black conductor is hot.
Red conductor is hot.
Green conductor is ground.
MAIN FAN CIRCUIT Power is permanently supplied, through the 10 amp oven fuse, through the normally closed oven cavity
hi-limit (opens at 695°F, 368°C), to the normally open oven fan switch. Power is also supplied to the normally
open cooling fan thermostat. Closing the oven fan switch supplies line voltage to the main fan motor, the
cooling fans through the EMI Filter to the primary of the control transformer and to the oven control.
TEMPERATURE CONTROL Closing the oven fan switch supplies line voltage, through the normally open air pressure switch (closed by
air pressure from the main fan) to the oven control. When the power supply is passed through the EMI Filter
the load will supply line voltage to the primary of the control transformer. Secondary voltage, 24VAC, is
supplied to the oven control. The oven control is set to desired temperature. The thermocouple will provide
varying millivolts to the oven control. The oven control supplies line voltage to the coil of the solid state
relays at intermittent intervals to maintain the desired temperature. The display on the oven control will
indicate when the contactor is energized.
NOTE: The display also indicates oven temperature.
CONVEYOR DRIVE Closing the oven fan switch supplies line voltage, through the normally open air pressure switch (closed
by air pressure from the main fan) to the oven control. When the power supply is passed through the EMI
Filter the load will supply line voltage to the primary of the control transformer. Secondary voltage, 24VAC,
is supplied to the oven control. Setting the oven control to the desired time outputs voltage, through a
reversing switch, to the conveyor motor.
NOTE: The conveyor system uses a Hall Effect sensor and magnet to prove operation of the conveyor motor.
If the conveyor motor is not running, “BELT JAM” is indicated on the display.
Sequence of Operation – Impinger II Domestic Advantage Digital, Electric
(Ovens with push button controls)

20 Document #: LIN_EOGO_SM_IMPII_S1100_4608349 – 01/22
Operation Section 2
Unit Plugged Into Power
• F1 fuse energized with L1
• Safety Contactor input energized with L1, L2, and L3
power
• Main Rocker Power Switch Input Energized with L1 and
Neutral Power. Green Light ON Note: Green light will not
be implemented with first generation unit.
• Cooling Fan Thermostat energized with L1
• Main Blower and Cooling Fans energized with L2
• Electric Filter energized with Neutral Power
• All six heating elements energized with Neutral Power
Power Switch Turned ON
• Oven high limit capillary switch energized with L1
• Switch disconnect SSR energized with Neutral Power
• Safety Contactor engaged/energized (If oven high limit
capillary switch and the switch disconnect SSR are not
tripped)
• If the Safety Contactor is engaged, the Electric Filter is
energized with L1, L2 and L3 power
• If the Safety Contactor is engaged, all three SSRs are
energized with L1, L2 and L3 respectively
• Cooling Fans energized with L1
• Cooling Fan Thermostat energized with L1
• Main Blower energized with L1
• 24VDC Power Supply Energized with L1 and Neutral
Power
• DC 4A fuse energized with 24VDC, which protects the
DC components: UI and IO board
• IO Board Energized
• IO Board boots up UI
• UI initiates with Welbilt BOOT screen
• UI Loads to Home Screen after small delay in time
• Optional Motor Drive Energized with 24VDC
Press and Go Selected
• UI displays Recipes
• Recipe Selected
• Once Pre-Heating is complete, Recipe Mode is engaged
• Oven will maintain temperature set point
• Conveyor will turn on to recipe cook time speed
Chef Mode (Manual Mode) Selected
• Enter Temperature Set Point
• Enter Conveyor belt speed (min:sec)
• In this mode, temperature and motor speed values will
change automatically when on this screen, but these set
points can be saved into a recipe when the save button
is pressed.
• Blower Main and Cooling Fans energized with Neutral
Power
• Save Button Pressed
Select Recipe
Change icon or color if applicable
Press the save button
NOTE: See Section 5 - Wiring Schematics
for reference.
Sequence of Operation – Impinger II International 1164 easyTouch, Electric 3 Phase
S/N: 2104100102813 and above (easyTouch controls)
