Lindsay LSA151 User manual

FEATURES
•1.2 GHz Gallium Arsenide (GaAs) technology
•3 db noise figure
•6 kV surge withstand
•Power LED indicator
•Surge & current protected power supply
•Compact, environmentally-hardened design
•15 PSI watertight seal
•Local & remote powering
•Diplex filters 42/54, 65/85 & 85/102 MHz
•360° F-pin seizure
LSA151 Subscriber Amplifier (1.2 GHz Extreme Bandwidth Series)
INSTALLATION MANUAL
Page 1 of 2
PRODUCT OVERVIEW
•Model: LSA151; Forward: 15 dB gain; Reverse: Passive
•Bandwidth: 5-42 MHz/54-1220 MHz; 5-65 MHz/85-1220 MHz; 5-85 MHz/102-1220 MHz
•Powering: 12-15 VDC
Lindsay’s extreme bandwidth LSA151 subscriber amplifiers are 2-way, 1.2 GHz devices supporting DOCSIS®3.1 frequencies. They offer
available upstream and downstream splits of 42/54, 65/85 and 85/102 MHz.
Customers with long drops and excessive splitter losses benefit from Gallium Arsenide (GaAs) technology delivering improved distortion
and noise performances. These amplifiers are specially designed for both indoor and outdoor applications with a 15 PSI watertight seal, a
protective coating, and 6 kV surge withstand capabilities for enhanced system reliability.
INSTALLATION
Two mounting holes permit a #6 screw to mount the LSA151 amplifier to a wood or wallboard surface. Nails are not advised due to possible
impact or vibration damage. Fasten a grounding wire to the amplifier housing. A grounding screw is located on two sides of the amplifier for
convenience of connection. Connect input and output cables to the amplifier ports and power the amplifer as described below.
POWERING
•The LSA151 amplifier can be powered with the supplied wall adapter (power pack) that is included in the box.
•Plug the wall adapter into a 120 VAC power socket. Then run an RG6 coaxial cable from the adapter to the amplifier PWR IN port.
•A red LED adjacent to the PWR IN port will illuminate.
•The LSA151 amplifier can also be remotely powered via the RF OUT/PWR IN port by using a power inserter (LBI-PI part # 15-100).
For example, when the amplifier is installed outside of the house in a CPE enclosure, then run one coaxial cable through the wall to the
amplifier. Inside the house, apply power to the POWER IN port of the power inserter, and take the RF signal feed for the house from the
RF ONLY port.
FORWARD & REVERSE PATH SET-UP
•The cable TV system entering the residence is connected to the RF IN port on the LSA151 subscriber drop amplifier. The
televisions or set-top boxes or modems are connected to the connections marked RF OUT.
•In reverse, the amplifier does not amplify upstream signals, but passes them through unaffected.
CAUTION
Risk of electric shock. Do not open rear plate.
LBI-PI power inserter
(front view)
LSA151
(front view)

LSA151 Subscriber Amplifier (1.2 GHz Extreme Bandwidth Series) INSTALLATION MANUAL
2-2035 Fisher Dr, Peterborough, ON K9J 6X6 Canada
+1.705.742.1350 • 1.800.465.7046 • [e-mail] • lindsaybb.com
© 2019 Lindsay Broadband Inc. All rights reserved. Printed in Canada. Non-Lindsay Broadband product marks,
service marks, and company names in this document are the property of their respective owners. All information is subject to change without notice.
Rev. 10/19 (LBB0163) • Page 2 of 2
SPECIFICATIONS
Parameter Typical Worst
Forward Path 54-1220 MHz or 102-1220 MHz
Gain (all ports) 15 dB 13 dB
Flatness ± 0.5 dB ± 1.0 dB
CTB
(1)
-75 dBc -70 dBc
CSO
(1)
-65 dBc -62 dBc
Noise Figure 3 dB 4 dB
Group Delay (any channel) (span 3.58 MHz) 20 ns
Return Path 5-42 MHz, 5-85 MHz
Gain (all ports) (amp powered) -1 dB -2 dB
Flatness ± 0.75 dB
Group Delay (span 1 MHz) 20 dB
General Specifications 5-85 MHz, 102-1220 MHz
Impedance
Return Loss (all ports) 5-42/85 MHz; 54/102-1220 MHz 20 dB 16 dB
Hum Modulation 5-42/85 MHz; 54/102-1220 MHz -70 dBc
Power Supply Noise
(2)
-50/-80/-100 dBm
Unterminated Oscillation
(3)
None
RFI 54/102-1220 MHz -100 dBc
Surge Withstand Capability
Forward Input & Power Pack 6 kV 3kA, 8/20 µs Combo Wave IEEE 587
(C62.41-1991) Category B3 Standard
Forward Outputs 6 kV 200 A, 0.5-100 KHz, Ring Wave IEEE 587
(C62.41-1991) Category A3 Standard
Port Diode Protection Yes
Waterproof (all F-ports) Withstand 15 PSI for 1 minute
Power, Environmental & Physical
Operating Temperature -40°C to +60°C (-40°F to +140°F)
DC Power Consumption (12-15 VDC) 150 mA
Dimensions (H x W x D) 4.0"H x 4.3"W x 1.1"D (10.2H x 10.9W x 2.8D cm)
Weight 0.3 lb (0.2 kg)
NOTES:
(1) 10 dBmV/ch flat input level (75 NTSC) + digital at 6 dB setback (550-1220 MHz)
(2) Max for (DC-500 kHz)/(500 kHz-1.5 MHz)/(1.5 MHz-1.2 GHz). Measure at RF OUT while using power
inserter to power the amplifier
(3) No oscillations should occur with IN & OUT ports terminated & unterminated
