Linear Nice 5mp series User manual

User Manual

IV400

Smart Surveillance Cameras | 5MP SERIES

Motorized Varifocal Lens

Bullet Camera

Fixed Lens

Bullet Camera Fixed Lens -&- Motorized

Varifocal Lens Dome Camera

2

Copyrights

any form or by any means, including photocopying, recording, or other electronic or mechanical

methods, without the prior written permission of the publisher, except in the case of brief

quotations embodied in critical reviews and certain other noncommercial uses permitted by

copyright law.

Nortek Security & Control LLC

Carlsbad, CA

www.linear-solutions.com

About This Document

This document intends to explain different aspects of the IV400 Cameras. It aims at simplifying

the tasks to be done with the application based on IV400. It will also help you learn some key

concepts. In this document, you will learn about different events and settings.

An overview of the Articial Intelligence (AI) events and settings is as follow,

Event

•AI Events are different occurrences or incidents triggered by the camera.

•Each AI event has individual settings which allow you to tune them for optimal accuracy in

your environment.

•Motion Detection

•Camera Tamper Detection

•Intrusion Detection

•Line Cross Detection

•Loiter Detection

•Object Left/Removed Detection

•Object Classification

Settings

•Camera settings allow you to tune your image quality.

•System settings allow you to manage users or also perform a reset for your camera.

•Event Output allows you to dene what the camera should do when a particular event

occurs.

3

Smart Surveillance

1. Abbreviations & Key Concepts ....................................................................................................................... 5

1.1 Abbreviations....................................................................................................................................................... 5

1.2 Key Concepts...................................................................................................................................................... 5

1.3 Prerequisites ....................................................................................................................................................... 6

2. Introduction to Linear IV400 Management Application ........................................................................ 6

2.1 Need of the Application ..................................................................................................................................... 6

2.2 Features ............................................................................................................................................................... 6

2.3 Technical Specications.................................................................................................................................... 7

2.4 Camera Types ..................................................................................................................................................... 8

Fixed Dome Camera Images for Illustration��8

Motorized Varifocal Lens Dome Camera Images for Illustration��9

Fixed Lens Bullet Camera Images for Illustration ��10

Motorized Varifocal Lens Bullet Camera Images for Illustration��11

2.5 Software Specications .................................................................................................................................. 12

3. Getting Started .................................................................................................................................................... 12

3.1 Accessing the IV400 camera in any Web Browser using HTTPS or HTTP Protocol:............................. 12

3.2 Logging into the Application ........................................................................................................................... 13

3.3. Changing the Password ................................................................................................................................. 14

4. Live View (Home/Landing Page)................................................................................................................... 15

5. Event Lists Section ............................................................................................................................................ 16

6. Settings................................................................................................................................................................... 17

6.1 System > Information...................................................................................................................................... 17

6.2 System > Time ................................................................................................................................................. 19

6.3 System > Maintenance ................................................................................................................................... 20

6.4 System > Logs ................................................................................................................................................. 22

7. Camera.................................................................................................................................................................... 23

7.1 Camera > Video ............................................................................................................................................... 23

7.2 Camera > Audio............................................................................................................................................... 24

7.3 Camera > Image .............................................................................................................................................. 25

General ��25

Image Quality ��26

Exposure��27

Privacy Mask��28

7.4 Events................................................................................................................................................................ 29

General �� 29

4

Motion Detector ��31

Camera Tamper Detector��32

Intrusion Detector��33

Line Cross Detector��34

Loiter Detector ��35

Object Left/Removed Detector ��36

Object Classication ��37

7.5 Storage ............................................................................................................................................................. 38

7.6 Network............................................................................................................................................................. 39

Static Setting��39

DHCP (Dynamic Host Conguration Protocol) Settings��40

Port Conguration ��41

SMTP/Email ��42

FTP ��43

HTTP Post��44

7.7 Security ............................................................................................................................................................ 44

Users ��44

HTTPS ��47

8. Logging Out .......................................................................................................................................................... 48

9 FAQs.......................................................................................................................................................................... 49

10 Troubleshooting................................................................................................................................................. 50

11 Customer Support............................................................................................................................................. 50

5

Smart Surveillance

1. Abbreviations & Key Concepts

1.1 Abbreviations

1.2 Key Concepts

Table 1: Description of Abbreviation

IP Cam Internet Protocol Camera

NTP Network Time Protocol

DST Daylight Saving Time

DHCP Dynamic Host Conguration Protocol

DNS Domain name server

CBR Constant Bitrate

VBR Variable Bitrate

FPS Frames per second

MJPEG Motion JPEG

SMTP Simple Mail Transfer Protocol

RTSP Real Time Streaming Protocol

FoV Field of View

IVA IntelliVision Analytics

FDFR Face Detection Face Recognition

RoI Region of Interest

Table 2: Description of Key Concepts

NTP Network Time Protocol used to synchronize computer clock times in a network.

Force sync Forcefully synchronizes time and date of the camera.

NTP Sync Interval How often the camera synchronizes time to the Network Time Server.

Factory Reset Used to reset all the settings to default values.

Reboot Shuts down and restarts the camera.

Restore Default Used to reset all the settings to default value, except for network settings.

HTTPS Security protocol designed to facilitate privacy & data security for communications over the internet.

H.264

H.265 Popular compression for HD video, achieving high quality video in relatively low bit rates.

MJPEG Motion JPEG (M-JPEG or MJPEG) is a video compression format in which each video frame or interlaced eld of

a digital video sequence is compressed separately as a JPEG image.

DHCP Dynamic Host Conguration Protocol (DHCP) is a network protocol that enables a server to automatically

assign an IP address to a computer from a dened range of numbers congured for a given network.

Static IP A static IP address is an address that is manually assigned to your network devices. The IP address remains

constant until manually changed.

PoE, Power over Ethernet provides Local Area Network (LAN) connection and Power to the IP Camera over the Ethernet cable.

6

2. Introduction to Linear IV400 Management Application

An Internet Protocol camera (IP) camera is a digital video camera that receives data and sends

image data via the LAN or WAN using Internet Protocol. They're used for surveillance and can

be directly accessed over a network connection. This makes them easy to install and connect

to your system, and you can view live camera feeds at any time with any web browser, RTSP

client, or on a smartphone mobile app. IP cameras can handle recording video, images and alarm

management. The camera can record directly to remote storage media such as a Network Video

Recorder (NVR), local SD card or cloud platform.

2.1 Need of the Application

A security camera system is required for effective surveillance of perimeter and internal monitoring,

as well as creating a record for events.

You can stay connected to your daily operations by monitoring with your surveillance system. This

allows you to manage store lines, employee activities, and streamline workflow based on live or

recorded video footage of your business or organization during working hours.

You can monitor, with clear video, large areas such as parking lots of any suspicious activity or

accidents with a powerful video surveillance system.

Video surveillance can help enormously with crowd control as well as prevent crime. It equips

security staff with real-time images from an event. Advance Security Systems can zoom in on

suspicious behavior before it becomes a problem. Law enforcement can also view a video of

public places like parks and common public places via a Security Operations Center (SOC), from

their smartphones or a vehicle laptop.

Video surveillance can help in monitoring traffic, such as counting the cars passing through or

improving the flow of traffic for better travel times. HD cameras can even record fast-moving cars

in challenging lighting conditions.

Video surveillance can help in transport Safety. Cameras can allow the vehicle or train operator to

confirm that people are clear of closing doors and that everyone is safe.

2.2 Features

The Linear®IV400 cameras includes advanced AI features including Motion Detection, Intrusion

Detection, Camera Tamper Detection, Object Classication, Loiter Detection, Line Crossing

Detection, Object Left/Removed Detection and Face Recognition (optional license required).

Feature descriptions are included with the event in the 7.4 Events section of the manual.

1.3 Prerequisites

The prerequisites are as follows:

•Make sure your camera is always connected to a PoE LAN connection.

•Web browser (Firefox/Chrome/Safari/Microsoft Edge).

7

Smart Surveillance

2.3 Technical Specications

The technical specications are listed in the following table. Understanding the technical

specications will help you technically know your camera better.

Model IV400- 5DFW IV400-5DVW IV400-5BFW IV400-5BVW

Product Description 5MP Fixed Lens Dome

Camera

5MP Varifocal Lens Dome

Camera

5MP Fixed Lens Bullet

Camera

5MP Varifocal Lens Bullet

Camera

SOC Information 64-bit ARM®Quad Core

Cortex™-A53

64-bit ARM Quad Core

Cortex™-A53

64-bit ARM Quad Core

Cortex™-A53

64-bit ARM Quad Core

Cortex™-A53

Flash 256MB 256MB 256MB 256MB

RAM 512MB 512MB 512MB 512MB

Scanning System Progressive Progressive Progressive Progressive

Image Sensor OV OS05A OV OS05A OV OS05A OV OS05A

Max Resolution 2592x1944 2592x1944 2592x1944 2592x1944

Lens 2.8 mm Fixed 2.8 -12 mm MFZ 4 mm Fixed 2.8 -12 mm MFZ

Angle of view for(h/v/d) 104/77/136 90-31/65-23/118-38 77/57/101 90-31/65-23/118-38

Day/Night Auto (ICR) / Color / B/W Auto (ICR) / Color / B/W Auto (ICR) / Color / B/W Auto (ICR) / Color / B/W

Wide Dynamic Range 120dB 120dB 120dB 120dB

Noise Reduction 3D DNR 3D DNR 3D DNR 3D DNR

Lens 2.8 mm Fixed 2.8 -12 mm MFZ 2.8 mm Fixed 2.8 -12 mm MFZ

Field of view for(h/v/d) 103°/79°/134° 88°-30°/65°-23°/115°-38° 103°/79°/134° 88°-30°/65°-23°/115°-38°

Ethernet RJ-45 (l0/l00Base-T) RJ-45 (l0/l00Base-T) RJ-45 (l0/l00Base-T) RJ-45 (l0/l00Base-T)

Internal Storage MicroSD/SDHC/SDXC MicroSD/SDHC/SDXC MicroSD/SDHC/SDXC MicroSD/SDHC/SDXC

Audio IO External audio I/O cable

Line in/Line out

Built-in Mic

External audio I/O cable Line

in/Line out

External audio I/O cable Line

in/Line out

External audio I/O cable Line

in/Line out

Power Input PoE IEEE 802.3af Class 2

DC 12V

PoE IEEE 802.3af Class 0

DC 12V

PoE IEEE 802.3af Class 2

DC 12V

PoE IEEE 802.3af Class 0

DC 12V

Power Consumption Max. 6.49 W (IR on)

Max. 3.6 W (IR off)

Max. 12.95 W (IR on)

Max. 9 W (IR off)

Max. 6.49 W (IR on)

Max. 3.6 W (IR off)

Max. 12.95 W (IR on)

Max. 9 W (IR off)

Dimensions Ø117 x 89.5 mm Ø133.15mm X10 9.82mm 177 x 72.3 mm 215.46 x 85 mm

Weight 558g 1.12kg 550g 760g

Operating Temperature Min: -30°C Max: +50°C

(Min -22° F Max 122° F)

Min: -30°C Max: +50°C

(Min -22° F Max 122° F)

Min: -30°C Max: +50°C

(Min -22° F Max 122° F)

Min: -30°C Max: +50°C

(Min -22° F Max 122° F)

Relative Humidity Less than 95% RH Less than 95% RH Less than 95% RH Less than 95% RH

Ingress Protection IP66 IK10 Housing IP66 IK10 Housing IP66 IK10 Housing IP66 IK10 Housing

Regulatory CE/FCC/UL CE/FCC/UL CE/FCC/UL CE/FCC/UL

8

2.4 Camera Types

There are four types of camera available: Fixed Dome, Motorized Varifocal Dome, Fixed Bullet and

Motorized Varifocal Bullet.

Fixed Dome Camera Images for Illustration

Figure 1: Fixed Lens Dome Camera

The following gure shows front view and rear view of the camera.

Figure 2: Front View of Fixed

Lens Dome Camera

Figure 3: Rear View of Fixed

Lens Dome Camera

9

Smart Surveillance

Motorized Varifocal Lens Dome Camera Images for Illustration

Figure 4: Motorized Varifocal Lens Dome Camera

The following gure shows front view and rear view of the camera.

Figure 5: Front View of Motorized

Varifocal Lens Dome Camera

Figure 6: Rear View of Motorized

Varifocal Lens Dome Camera

10

Fixed Lens Bullet Camera Images for Illustration

Figure 7: Fixed Bullet Camera

The following gure shows front view and rear view of the camera.

Figure 8: Front View of Fixed Lens

Bullet Camera

Figure 9: Rear View of Fixed Lens

Bullet Camera

11

Smart Surveillance

Motorized Varifocal Lens Bullet Camera Images for Illustration

Figure 10: Motorized Varifocal Lens Bullet Camera

The following gure shows front view and rear view of the camera.

Figure 11: Front View of Motorized

Varifocal Lens Bullet Camera

Figure 12: Rear View of Motorized

Varifocal Lens Bullet Camera

12

2.5 Software Specications

Computer must be installed with any of the following browser.

•Web browser (Firefox/Chrome/Safari/IE/Microsoft Edge).

3. Getting Started

3.1 Accessing the IV400 camera in any Web Browser using HTTPS or

HTTP Protocol:

1. Start your computer system, and launch any installed browser.

2. Enter the IV400 camera IP in the address bar to access its web UI. (for example:

https://192.168.0.230), then press Enter.

3. A warning message may appear on web browser UI.

4. If so, click Advanced.

Figure 14: Advanced button options

Figure 13: Connection Private

13

Smart Surveillance

5. Click the Continue to 192.168.0.230 unsafe link to access the IV400 Camera (IP). The Login

page is displayed.

Accessing the IV400 camera using HTTP protocol:

1. Launch any browser.

2. Enter the IV400 camera IP in the address bar to access its web UI. (for example:

http://192.168.0.230), then press Enter.

3. The Login page is displayed.

Notes:

•Make sure that IV400 camera is connected to the required power supply through "LAN/

WAN" network with POE Switch or NVR.

•Make sure the IV400 camera firmware is up to date and the camera is powered on.

•The default static IP for the IV400 Camera is 192.168.0.230.

•In the Mozilla Firefox browser, live view cannot be accessed using Self-signed certificate if

attempting to access IV400 Camera using HTTPS protocol.

3.2 Logging into the Application

To log into the system, follow these steps:

1. Launch any web browser, enter the IV400 camera (IP) then press Enter.

2. Enter valid User Name & Password on the Login page (Default User Name = admin /

Default Password = linear).

3. Click the Submit button.

Figure 15: Login Window

14

4. After authorizing provided credentials, the Change Password login screen will be displayed.

Figure 16: Change Password

3.3. Changing the Password

To change the default password provided:

1. Enter new password in Password and Conrm Password elds.

2. Click Update.

Figure 17: Update Password

Notes:

•Be certain the Password entries match. If needed, click the icon to confirm.

•If the new password is rejected, a prompt will be displayed. Confirm that all password

requirements have been met, and then try again.

NOTE: If for some reason the password cannot be recalled, a Factory Reset will be required.

3. After the password has been updated and user login is successful, the Live View tab will be

displayed.

15

Smart Surveillance

4. Live View (Home/Landing Page)

Figure 18: Live View (Homepage)

1. Live View Streaming: Monitor the camera's Live Streaming video.

2. Full Screen: Click (Live View lower right) to access Live View full-screen. To exit Full

Screen Live View, move your mouse to the top of the screen and click the Xicon, press the

Esc key or click (extreme bottom-right side) of screen.

3. Speaker: Adjust speaker volume (Minimum to Maximum level) using a slider. Click the speaker

icon to Mute or Unmute audio.

Figure 19: Adjust Speaker Volume / Mute

4. Microphone: Click the Mic icon to activate the mic and communicate (speak or announce).

This option is available only when accessing the IV400 camera web-UI using HTTPS method

rather than HTTP.

16

Figure 20: Events List

Figure 21: Filter Events List

5. Streams: Select a desired stream (“Stream 2” or “Stream 1”). Once selected, adjust options

for resolutions with encoding type supported by the IV400 camera. If any encoding type [for

example: H265 with higher resolution(5MP)] is not supported on Web browser UI, a warning

prompt will appear on the Live View screen.

6. Zoom: Increasing (+) or Decreasing (-) to Zoom the camera. Once the Zoom is set, a few

seconds must pass before the new Zoom view will appear on live streaming.

7. Focus: Adjust camera focus by Increasing (+) or Decreasing (-). Once the Focus is set, a few

seconds must pass before the new Zoom view will appear on live streaming.

8. Auto Focus: Click Autofocus to allow the camera to focus to an optimal level to better view

unclear objects in the scene.

NOTE: Zoom, Focus & Autofocus functionality is supported only for the IV400-5BVW and IV400-

5DVW Camera types.

5. Event Lists Section

1. This section will provide frequently generated events captured by the IV400 camera. A

maximum of 10 events can be listed.

2. To lter displayed Events, hover the mouse over the Column Filter icon, and select or deselect

checkboxes. Click Apply. Event data detailed information will display selected information.

17

Smart Surveillance

3. To sort event data, hover your mouse over the Event Type lter. Select or deselect desired

checkboxes, then select Apply. Only selected events type will be displayed.

Figure 22: Settings/System - Information

6. Settings

Congure various system settings to customize the live streaming experience.

6.1 System > Information

1. Displays general information such as; Camera Name, Camera Model, Firmware Version, Kernel

version, Mac Address, IVA Licenses and License for FDFR.

18

1. Edit Camera Name: Click the Edit icon adjacent to Camera Name. The Edit Camera

Name pop-up appears on-screen. Enter the new name, and then click Save.

2. FDFR License Validation: Enter a FDFR License key, then select Submit to validate the

license. Once validated, the camera's FDFR feature can be used.

Figure 23: Edit Camera Name

Figure 24: FDFR License

19

Smart Surveillance

Figure 25: Set Date and Time via NTP

6.2 System > Time

Set the Date & Time for the IV400 camera. There are

three methods available.

1. NTP - Network Time Protocol (NTP) synchronizes

computer clocks by periodically querying an

NTP Server. Date and Time settings for NTP are

displayed.

•Select Time Zone: On the map, click the

desired zone.

•Selected Zone: The selected location on the map is displayed.

•DST (Day Light Saving): After selecting a time zone, DST will be set to Enable by default (if

applicable to the location). Click Disable to turn off DST.

•NTP Server URL: For each region, an IP address or domain name for the timeserver can

be assigned. With no IP address or domain entered, the Network Camera connects to the

default time servers. For this option to take affect, the camera must have the access to the

Internet.

•NTP Server Interval (In Minutes): Click on the slider option and move left or right to adjust

the NTP Sync Interval time.

•Force Sync: Click the checkbox to forcefully sync camera time with NTP server time

whenever required.

Click Save to keep the new settings.

20

2. Manual: Manually Set the Date and Time by clicking on Date ( ) & Time ( ) and using the

popup menus.

3. Sync with Computer: Click the checkbox to synchronize the camera's date and time with the

computer's operating system.

Select Save to keep the updated date and time settings.

Figure 26: Set Date and Time Manually

Figure 27: System > Maintenance

6.3 System > Maintenance

Use Upgrade the camera rmware, Restore Default, Factory Reset and Reboot options to perform

camera maintenance on the IV400 camera.

Linear Nice 5MP Series User manual

Popular Digital Camera manuals by other brands
