Linear GSLG-A User manual
GSLG-A
INSTALLATION GUIDE
UL325 COMPLIANCE REQUIRES THE USE OF CONTACT EDGES
OR PHOTOELECTRIC CONTROLS ON ALL AUTOMATIC OR
REMOTELY-CONTROLLED GATE OPERATORS.
USA & Canada (800) 421-1587 & (800) 392-0123
(760) 438-7000 - Toll Free FAX (800) 468-1340
www.linearcorp.com
GSLG-A OPERATOR INSTALLATION GUIDE
- 2 -
TABLE OF CONTENTS
PRE-INSTALLATION INFORMATION
Gate Operator Classifications ...................................................................................................................................... 3
Safety Information and Warnings ................................................................................................................................. 3
Pre-Installation Information .......................................................................................................................................... 3
INSTALLATION
Wiring Specifications.................................................................................................................................................... 4
Post Mounting Instructions ........................................................................................................................................... 5
Gate Bracket and Chain Assembly Instructions ........................................................................................................... 6
Vent Plug Installation.................................................................................................................................................... 7
Torque Limiter Adjustments.......................................................................................................................................... 7
Electrical Connection and Adjustments........................................................................................................................ 8
Limit Nut Adjustments .................................................................................................................................................. 8
CONTROL BOARD ADJUSTMENTS and ACCESSORY CONNECTIONS
Control Board Adjustments .......................................................................................................................................... 9
Terminal Connection Descriptions.............................................................................................................................. 10
Current Sensing Adjustments .................................................................................................................................... 11
Close Direction Current Sense Adjustment................................................................................................................ 11
Open Direction Current Sense Adjustment ................................................................................................................ 11
Maximum Run Timer Adjustment ............................................................................................................................... 11
Auto Close Timer Adjustment..................................................................................................................................... 11
Master/Slave Connection ........................................................................................................................................... 11
Onboard L.E.D. Indicator Descriptions ....................................................................................................................... 12
Important Notes for Installation of Master/Slave Applications .................................................................................... 13
Surge Protector Instructions....................................................................................................................................... 13
Control and Accessory Connection Illustrations....................................................................................................14-17
ILLUSTRATIONS
Loop Layout Illustration .............................................................................................................................................. 18
Edge Layout Illustration #1......................................................................................................................................... 19
Edge Layout Illustration #2......................................................................................................................................... 20
Photo Eye Illustration ................................................................................................................................................. 21
Picket Gate Illustration ............................................................................................................................................... 22
Track Gate Illustration................................................................................................................................................. 23
TROUBLESHOOTING .................................................................................................................................................. 24
PARTS LISTS
How to Order Replacement Parts .............................................................................................................................. 24
Model GSLG-A Mechanical Parts Exploded View...................................................................................................... 25
Model GSLG-A Mechanical Parts List........................................................................................................................ 26
Model GSLG-A Single Phase Control Box Exploded View and Parts List ................................................................. 27
Model GSLG-A Three Phase Control Box Exploded View and Parts List .................................................................. 28
PREVENTATIVE MAINTENANCE ................................................................................................................................ 30
GATE OPERATOR INSTALLATION CHECKLIST ........................................................................................................ 32
CAUTION!
DO NOT INSTALL
CONTROLS ON A
GATE OR FENCE
LINE
CAUTION!
ONLY QUALIFIED SERVICE
TECHNICIANS SHOULD
WORK ON A LINEAR
SLIDE GATE OPERATOR
CAUTION!
DO NOT INSTALL
CONTROLS
ON THE OPERATOR
GSLG-A OPERATOR INSTALLATION GUIDE
- 3 -
Read the following before beginning to install LINEAR slide
gate operators:
1. Read the yellow “Safety Instructions” brochure enclosed
with the packet of information. If you do not have one,
please call LINEAR at 1-800-333-1717 to request one.
Read and follow all instructions.
2. All electrical connections to the power supply must be
made by a licensed electrician and must observe all
national and local electrical codes.
3. A separate power-disconnect switch should be located
near the operator so that primary power can be turned
off when necessary.
4. A minimum of two (2) WARNING SIGNS shall be in-
stalled, one on each side of the gate where easily vis-
ible.
5. Never reach between, through or around the fence to
operate the gate.
6. You must install all required safety equipment.
GATE OPERATOR
CLASSIFICATIONS
PRE-INSTALLATION INFORMATION
Before unpacking, inspect the carton for exterior damage. If
you find damage, advise the delivery carrier of a potential
claim.
Inspect your package carefully.You can check your accessory
box parts with the enclosed packing slip for your convenience.
Claims for shortages will be honored for only 30 days from
the date of shipment.
Before installing the operator, read this manual completely
to ensure all requirements for proper installation are pres-
ent. Verify that the voltage to be used matches the voltage
of the operator.
SAFETY INFORMATION
AND WARNINGS
IMPORTANT!!
Before installing the gate operator, make sure the gate’s slide
is free and level throughout the entire opening distance. If
the gate does not seem to operate properly, it may affect the
operator performance or greatly shorten the life of the unit.
The gate should be designed so that airflow through the fabric
is ample to prevent wind resistance and drag.
All gate operators can be divided into one of four different
classifications, depending on their design and usage.
Class I: Residential
A vehicle gate operator (or system) intended for use in a
home of one to four single-family dwellings, or a garage or
parking area associated therewith.
Class II: Commercial or General Public Access
A vehicular gate operator (or system) intended for use in
a commercial location or building such as a multi-family
housing unit (five or more single-family units), hotel, garage,
retail store, or other building servicing the general public.
Class III: Industrial or Limited Access
A vehicular gate operator (or system) intended for use in
an industrial location or building such as a factory or load-
ing dock area or other locations not intended to service
the general public.
Class IV: Restricted Access
A vehicular gate operator (or system) intended for use in
a guarded industrial location or building such as an airport
security area or other restricted access locations not ser-
vicing the general public, in which unauthorized access is
prevented via supervision by security personnel.
The following contact or non-contact obstruction
detection devices have been approved for use
with LINEAR slide gate operators as part of a UL325
compliant installation:
Contact Edges:
Miller Models*: MG0-20, MGR-20, MGS-20, and
ME-120
Photoeyes:
2520-441 MMTC Model IR-55 photoeye, 165’ with
mounting hardware
2520-031 MMTC Model E3K photoeye, 28’ with
mounting hardware
*for LINEAR part numbers, contact a sales representative for details
GSLG-A OPERATOR INSTALLATION GUIDE
- 4 -
USE COPPER WIRE ONLY!
ACCESSORY WIRING
All Models
24VDC
*Over 350 ft. use DC power.
0-2000
14
24VAC
250
350*
14
12
Volts
Maximum
Distance (ft.)
Wire
Gauge
1. Select from the chart at the bottom of this page corresponding to the
model, voltage and horsepower rating of your operator.
2. The distance shown on the chart is measured in feet from the operator
to the power source. DO NOT EXCEED THE MAXIMUM DISTANCE.
These calculations have been based on standard 115V and 230V sup-
plies with a 10% drop allowable. If your supply is under the standard
rating, the runs listed may be longer than what your application will
handle, and you should not run wire too near the upper end of the chart
for the gauge of wire you are using.
3. When large-gauge wire is used, a separate junction box (not supplied)
may be needed for the operator power connection.
4. All control devices are now 24VDC, which can be run considerable
distances. 24VAC is available for other devices, such as loop detectors
and photo eyes.
5. Wire run calculations are based on the National Electrical Code, Article
430 and have been carefully determined based on motor inrush, brake
solenoids, and operator requirements.
WIRING SPECIFICATIONS
6. Connect power in accordance with local codes. The green ground
wire must be properly connected.
7. Wire insulation must be suitable to the application.
8. Control wiring must be run in a separate conduit from power wiring.
Running them together may cause interference and faulty signals in
some accessories.
9. Electrical outlets are supplied in all 115VAC models for convenience with
occasional use or low power consumption devices only. If you choose
to run dedicated equipment from these devices, it will decrease the
distance for maximum run and the charts will no longer be accurate.
10. A three-wire shielded conductor cable is required to connect master and
slave operators.You must use Belden 8760 Twisted Pair Shielded Cable
(or equivalent) only – LINEAR part number 2500-1982, per foot). See
page 9for details of this connection, as well as dip switch selection.
Note: The SHIELD wire should be connected in both the master
and slave operators
