Linemaster TREADLITE II User manual

TREADLITE II Cat. No. T-91-SCE Foot Operated Switch
CLASSIFICATION ==================================================================
RATINGS: 16(4)A 250 VAC~ 50/60 HZ FREQUENT OPERATION: +++ 1E5
16A ½ HP 125-250 VAC~ ACTUATING METHOD: FOOT OPERATED
EARTHING (GROUNDING): CLASS I CATEGORY A
MICRO DISCONNECTION: µ PROOF TRACKING INDEX: PTI 175
ENVIRONMENT: IP20, NEMA TYPE 1
SUITABLE FOR USE IN A NORMAL SITUATION (ORDINARY LOCATION).
NOTE: THIS IS NOT A MAINS DISCONNECT DEVICE.
WIRING ==========================================================================
1. WARNING: TO AVOID PERSONAL INJURY, DO NOT USE THIS SWITCH ON MACHINERY WITH AN
UNGUARDED POINT OF OPERATION.
READ WARNING STATEMENT on reverse side of this page.
2. When wiring up this device make sure POWER IS OFF AND LINES ARE DEAD.
3. Supply cord with flexible conductors (leads) to be prepared as shown. (See Diagram "A")
Supply cord with prepared flexible conductors. Use special purpose crimping tools to apply female quick-connect and
ring
terminal to conductors. Insulation support type terminals required. The female quick-connect terminals must be
insulated.
FOR CE MARKED SWITCHES, PLEASE NOTE THE FOLLOWING:
-The grounding conductor must be green or green/yellow in color.
-A cord guard or bend relief must be provided that extends beyond the cord clamp at least five times the overall diameter
of the flexible cord.
Use 3 conductor cord for single pole
normally open or normaly closed
operation. Maxim um flexible conducto
r
size: 1.5 m m2(#14 AWG)
Use UL/CSAconstructed cordage for
Nor th American applications and
Har monized corda ge for International
applications.
Base
CordClamp
6.3 x 0.8mm (1/4 IN.) female
quick-connect terminal.
Note: Quick-connect
term inals must be insulated.
DI AGRAM "A "
4mm Ø (#8
)
RING TYPETERMINAL
50.8mm (2IN.) 3.2mm ( 1/8 IN.)
146.05mm
(5 .75 IN.
)
Gr een / Yellow
4. Remove hinge screws and detach cover and cover return spring from base. (See Diagram "B").
5. Loosen or remove cord clamp screws, insert cord and connect inner conductors (leads) of cord to appropriate switch
terminals. (See Diagram "C")
Bas
e
Hinge s crew wit h lock
washer.Tighten to1.6 to
1.8Nm(14-16IN-LBS).
6.3 x 0.8mm(1/4 IN.) flat
quick connecttabsfor switch
terminations.
Co rd c lamp ac cept s c or d
sizes 6to11mmØ(.250to
.4 35 diame ter ) .
Tighten cordclamp screws
alternately1.4 to1.6Nm(12
to 14 IN-LB S).
DIAGRAM "C"
DIAGRAM "B"
Cover
Cover ReturnSpring
Pr ot ec tive ea rt hin g (G r ound in g)
terminal with lockwasher.
Tighten terminal screw1.2to
1.8Nm(11to16IN-LBS)
N.C. N.O.
COM
6. Re-assemble cover return spring and cover to base with hinge screws.
7. CLEANLINESS must be observed during installation and in use.
On a REGULAR BASIS inspect foot switch frequently to guard against wear, damage, unlawful alterations or removal
of guards, or for unusual enclosure deterioration and the like. Inspect the entire length of the connecting cord (or wiring
system) from where it enters the foot switch to the equipment it's wired up to for wear, loose strain relief connections
and the like. DO NOT OPERATE the foot switch if any of the above is observed or if the nameplate or warning label
has been obscured or removed.
It is IMPERATIVE that inspection authorities and users exercise more than ordinary care with regard to installation and
maintenance and that this information sheet be made available to the end user, operators, maintenance personnel and
to others responsible for proper installation and safe operation of this foot switch.
ADDITIONAL COPIES of this information sheet and warning labels are available upon request.
MOUNTING =======================================================================
1. Treadlite II foot operated switches are furnished with a non-skid base pad and can be mounted with the base pad
attached.
2. Use two number 4 thread-cutting (self-tapping) screws and two number 4 lock washers when mounting to full guard
(See Diagram “D”).
DIAGRAM “D”
#5 22 - B14 F u ll g ua rd w ith
assemblyhardware and
ins truc tions available upon
re qu es t.
#4 Flathead thread-cutting
sc rew
#4 L oc k w ash e
r
