LINK ELECTRONICS, INC.
SYNC GENERATOR WITH BLACK & COLOR BARS
MODEL IEC-833
FEATURES
RS-170A
Gen-Lock
SC/H Phase
Blackburst Output
Color Bars Output
All Drives Output
TheIEC-833isaprofessionalcolorsyncgenerator
designedtomeetthedemandingspecificationsfor
performance and stability.
One output of each SMPTE color bars and
blackburst are provided on the rear panel. Two
outputs of sync and subcarrier and one output of
each HD, VD, BL and Burst Flag. The color bar
signal meets the SMPTE specifications for
reversed bars.
TheIEC-833willgen-locktoastablevideosource,
blackburst or a personal computer with unstable
sync. The temperature compensated, voltage
contolled crystal oscillator (TCVCXO) is accurate
to ± 1ppm over the operating temperature range.
Horizontal phase has a timing range of ±4µS.
Subcarrier phase is adjustable over a range of
360° continuous.
The unique “PC Lock” feature allows the IEC-833
to produce a synchronous color burst and
sbucarrier output while referenced to a
monochromeinput. The IEC-833 is areliable high
performance product with flexibility and economic
value.
This product is produced by the same people that
have been building sync generators and other
video terminal equipment since 1971. Ten-year
warranty on parts and labor is provided on all
products.
LINKELECTRONICS, INC. 2137 Rust Avenue Cape Girardeau, MO 63703-7668
Phone [phone] FAX [phone]
MADE IN THE USA

Model IEC-833
SYNC GENERATOR with COLOR BARS
AND BLACKBURST
PULSES:
Outputs:
Sync................................................................Two(2)
Blanking: ............................................................One(1)
H.Drive:............................................................ One(1)
V.Drive: .............................................................One(1)
BurstFlag: ........................................................... One(1)
Levels: ................................................... 4.0Vpp±5%fixed
Impedance: .............................................75Ω, ±1%, source term.
Widths:................................................ NormFCC,EIA&NTSC
Tilt & Overshoot: ........................................................ <1%
Jitter: ............................................. <5nS,referencetoSubcarrier
RiseTime: ......................................................140nS ±20nS
SUBCARRIER:
Outputs:...............................................................Two(2)
Frequency: ................................................. 3.579545 MHz ±1Hz
Output Impedance: .....................................................75Ω±1%
OutputLevel:................................................. 2.0Vp-padj.±20%
HarmonicDistortion: ............................................. >-45dB @ 2Vp-p
GEN-LOCK MODE:
Video Level: ......................................................1.0Vp-p±6dB
Video Input Impedance: .............................................. .>20Kloop
PulseJitter: .................................................. <5nS,reftoinsync
SubcarrierJitter: ......................................................... <0.5°
Color Lock Range: ....................................................... ±4Hz
BLACKBURST:
Outputs:...............................................................One(1)
Impedance: ...............................................75Ω, ±1 % source term.
Tilt & Overshoot: ......................................................... <1%
SubcarrierJitter: ................................................. <5nS,ref.toSC
S/NRatio: ............................................................. >66dB
COLOR BARS:
Outputs:...............................................................One(1)
Type: .....................................................Standard SMPTE Bars
FRONT PANEL CONTROLS:
SubcarrierPhase: ......................................................... 360°
HorizontalPhase: ....................................................... ±3.5µS
Crystal Frequency: ..........................................±3Hzat3.579545MHz
INTERNAL CONTROLS:
Factoryset: .......................................... Thereare27internalcontrols
ENVIRONMENTAL:
Temperature: ............................................... 0°to50°C,Ambient
Power:............................................................... 12watts
MECHANICAL:
Height:............................................................ 1.75Inches
Width: .............................................................. 19Inches
Depth: ............................................................... 8Inches
Weight: ...........................................................4.75Pounds
