Zeus Appollo Z10I13KDT User manual

User Manual V3.2
User Manual
-Installation
-Operation
Z10I13KDT
Z10I17KDT
Z10I20KDT
Zeus Appollo Solar

1
Contents
1. Notes on this manual........................................................................................................................................................3
1.1 General notes..............................................................................................................................................................3
1.2 Symbols Used .............................................................................................................................................................3
1.3 Target Group...............................................................................................................................................................4
2. Preparation ........................................................................................................................................................................5
2.1 Safety Instructions.......................................................................................................................................................5
2.2 Explanations of Symbols on Inverter ...........................................................................................................................7
3. Product Information..........................................................................................................................................................8
3.1 Overview......................................................................................................................................................................8
3.2 Major Characteristics...................................................................................................................................................9
3.3 Technical Data.............................................................................................................................................................9
4. Packing checklist ..........................................................................................................................................................101
4.1 Assembly parts........................................................................................................................................................110
4.2 Product Appearance................................................................................................................................................112
4.3 Product Identification...............................................................................................................................................133
4.4 Further Information....................................................................................................................................................14
5. Installation .....................................................................................................................................................................156
5.1 Safety ......................................................................................................................................................................156
5.2 Dimensions and Weight...........................................................................................................................................156
5.3 Mounting Instructions ..............................................................................................................................................157
5.4 Safety Clearance.....................................................................................................................................................178
5.5 Mounting Procedure ................................................................................................................................................179
6. Electrical Connection......................................................................................................................................................22
6.1 Safety ........................................................................................................................................................................22
6.2 Overview of Connection Area....................................................................................................................................23
6.3 DC Side Connection..................................................................................................................................................24
6.4 AC Side connection...................................................................................................................................................26
6.5 Communication and Monitoring connector ................................................................................................................29
7. Display..............................................................................................................................................................................30
7.1 Main interface............................................................................................................................................................30
7.2 LCD Display...............................................................................................................................................................31
7.2.1. Curve.......................................................................................................................................................................32
7.2.2. Parameters.........................................................................................................................................................….37
7.2.3. Tools & Options.......................................................................................................................................................39
7.2.4. Information...............................................................................................................................................................42

2
7.2.5. Error.........................................................................................................................................................................44
7.2.6. Update.....................................................................................................................................................................45
7.3 State Information.......................................................................................................................................................46
8. Troubleshooting..............................................................................................................................................................48
9. Warranty...........................................................................................................................................................................50
10. Abbreviation ....................................................................................................................................................................52
11. Contact.............................................................................................................................................................................53

3
1.Notes on this manual
1.1 General notes
The main purpose of this User’s Manual is to provide instructions and detailed procedures for
installing, operating, maintaining, and troubleshooting the following three types of Z10 series
Inverters:
Z10I13KDT
Z10I17KDT
Z10I20KDT
1.2 Please keep this user manual available at all times in case of emergency.
1.3 Symbols Used
CAUTION
CAUTION indicates a hazardous condition which, if not
avoided, can result in minor or moderate injury.
or moderate injury.
WARNING
WARNING indicates a hazardous situation which, if not
avoided, can result in death or serious injury or moderate
injury.
DANGER
DANGER indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
NOTICE
NOTICE indicates a situation that can result in property
damage, if not avoided.

4
1.4 Target Group
Chapter 1, 2, 3, 4, 7, 8, 9, 10 and chapter 11 are provided for anyone who is intending
to use a Z10 Series Grid-tied Solar Inverter. Before any further action is taken, the
operators must first read all safety regulations and be aware of the potential danger
when operating high-voltage devices. Operators must also have a complete
understanding of this device’s features and functions.
Chapter 5 and Chapter 6 are only for qualified personnel who are intending to install or
uninstall the Z10 Series Grid-tied Solar Inverter. Installation must be suitable for the on-site
conditions and comply with local regulations and technical rules.
NOTICE
Qualified personnel means he/she has a valid license from the
local authority in:
•Installing electrical equipment and PV power systems (up to
1000 V).
•Applying all relevant installation codes.
•Analyzing and reducing the hazards involved in performing
electrical work.
•Selecting and using Personal Protective Equipment (PPE).
WARNING
Do not use this product unless it has been successfully installed
by qualified personnel in accordance with the instructions in
Chapter 5, “Installation”.

5
2.Preparation
2.1 Safety Instructions
WARNING
The installation, service, recycling and disposal of the
inverters must be performed by qualified personnel who
must comply with national and local standards and
regulations. Please contact your dealer to obtain details
about an authorized repair facility if the inverter requires
maintenance or repair. Any unauthorized activities including
the modification of product functionality of any kind will affect
the extent of the warranty; Such actions may result in Zeus
Appollo Solar not accepting any responsibility for that
warranty.
DANGER
DANGER due to electrical shock and high voltage
DO NOT touch the operating component of the inverter, it
might result in burning or death.
TO prevent risk of electric shock during installation and
maintenance, please make sure that all AC and DC terminals
are unplugged.
DO NOT remains close to the instruments while there are
severe weather conditions including storms, lightning etc.

6
CAUTION
The PV inverter will become hot during operation; please
don’t touch the heat sink or adjacent surface during or shortly
after operation.
Risk of damage due to modifications. Never modify or
manipulate the inverter or other components of the system.
NOTICE
Public utility only
The PV inverter is designed to feed AC power directly into
the public utility power grid; do not connect the AC output of
the device to any private AC equipment.

7
2.2 Explanations of Symbols on Inverter
Symbol
Description
Dangerous electrical voltage
This device is directly connected to public grid,
consequently all work on the inverter shall only be
carried out by qualified personnel.
DANGER to life due to high electrical voltage!
There might be residual currents present within the
inverter because of large capacitors. Wait 10
MINUTES before you remove the front lid.
NOTICE, danger!
This device directly connected with electricity
generators and the public grid.
Danger of hot surface
The components inside the inverter will generate heat
during operation, DO NOT touch aluminum housing
during operation.
An error has occurred
Please go to Chapter 8 “Trouble Shooting” to remedy
the error.
This device SHALL NOT be disposed of in
residential waste
Please go to Part 9 “Recycling and Disposal” for
correct disposal management.
Without Transformer
This inverter does not use a transformer for the
isolation function.
CE Mark
Equipment with the CE mark fulfils the basic
requirements of the Guidelines Governing Low-
Voltage and Electromagnetic Compatibility.
No unauthorized perforations or modifications
Any unauthorized perforations or modifications are
strictly forbidden, if any defect or damage
(device/person) occurs, Zeus Appollo Solar will not
accept any responsibility for it.

8
3.Product Information
3.1 Overview
Industrial Layout
Excellent Heat Elimination
Effective Shield For DC/AC/Communication Connections

9
3.2 Major Characteristics
The Z10 series inverter has the following characteristics which ensures that it delivers on
the promise of “High Efficiency, High Reliability, and having a High Cost Effective Ratio”
•Complies with multiple safety regulations of European, Asia Pacific and Oceania
countries.
•Double MPPT Tracking, MPPT tracking accuracy up to 99.9%.
•Max. Efficiency 98.2%, European Efficiency 97.8%.
•Professional radiating design, protection Level IP65, which will ensure that the unit will
perform correctly in severe outdoor conditions.
•Complete safety protection, with an integrated DC switch.
•Flexible input and output connections which support RS485, Ethernet and USB
communication.
•Transformerless design and high power density, ensuring lighter and more convenient
for installation.
3.3 Technical Data
Type
Z10I13KDT
Z10I17KDT
Z10I20KDT
Input (DC)
Max. PV Power
13500W
17600W
21200W
Max DC Voltage
1000V
1000V
1000V
Nominal DC Voltage
640V
640V
640V
Operating MPPT Voltage Range
250-800V
250-850V
250-850V
MPPT Voltage Range at Nominal Power
400-800V
440-850V
480-850V

10
Start up DC Voltage
300V
300V
300V
Turn off DC Voltage
250V
250V
250V
Max. DC Current (A/B)
22A/11A
22A/22A
22A/22A
Max. Short Circuit Current for each MPPT
25A/15A
25A/25A
25A/25A
Number of MPP trackers
2
2
2
Number of DC Connection
A:3/B:3
A:3/B:3
A:3/B:3
DC Connection Type
MC4 connector
MC4 connector
MC4 connector
Output (AC)
Max. AC Apparent Power
13000VA
17000VA
19200VA
Nominal AC Power (cos phi = 1)
13000W
17000W
19200W
Nominal AC Voltage
3/N/PE; 220/380V
3/N/PE; 230/400V
3/N/PE; 240/415V
3/N/PE; 220/380V
3/N/PE; 230/400V
3/N/PE; 240/415V
3/N/PE; 220/380V
3/N/PE; 230/400V
3/N/PE; 240/415V
Nominal Grid Frequency
50Hz/60Hz
50Hz/60Hz
50Hz/60Hz
Max. AC Current
20.0A
26.0A
29.0A
Grid Voltage Range*
185-276V
185-276V
185-276V
Grid Frequency Range*
45-55Hz/55-65Hz
45-55Hz/55-65Hz
45-55Hz/55-65Hz
Power Factor
0.9i…1…0.9c
0.9i…1…0.9c
0.9i…1…0.9c
Total Harmonic Distortion (THD)
<2%
<2%
<2%
Feed in Starting Power
60W
60W
60W
Night time Power Consumption
<1W
<1W
<1W
Standby Consumption
<12W
<12W
<12W
AC Connection Type
Plug-in connector
Plug-in connector
Plug-in connector
Type
Z10I13KDT
Z10I17KDT
Z10I20KDT
Efficiency
Max. Efficiency
98.0%
98.1%
98.2%
Euro Efficiency
97.5%
97.6%
97.8%
MPPT Efficiency
99.9%
99.9%
99.9%
Safety and Protection
DC Insulation Monitoring
Yes
DC Switch
Optional
Residual Current Monitoring Unit (RCMU)
Integrated
Grid Monitoring with Anti-islanding
Yes
Protection Class
I (According to IEC 62103)
Overvoltage Category
PV II / Mains III (According to IEC 62109-1)
Reference Standard
Safety Standard
EN 62109, AS/NZS 3100
EMC Standard
EN 61000-6-1, EN 61000-6-2, EN 61000-6-3, EN 61000-6-4, EN 61000-3-
11, EN 61000-3-12
Grid Standard
VDE-AR-N-4105, VDE 0126-1-1, RD1699, G59/2, AS4777, CEI0-21, CQC
Physical Structure
Dimensions (WxHxD)
575x655x240mm
Weight
44.5kg
45kg
45kg
Environmental Protection Rating
IP 65 (According to IEC 60529)
Cooling Concept
Fan cooling
Mounting Information
Wall bracket
General Data
Operating Temperature Range
-20°C to +60°C(derating above 45℃)

11
Relative Humidity
0% to 98%, no condensation
Max. Altitude (above sea level)
2000m
Noise Level
<45dB (with fan<50dB)
Isolation Type
Transformerless
Display
800x480 TFT Graphic Display
Data Communication Interfaces
RS485 (Wi-Fi, GPRS optional)
Computer Communication
RS232 (USB)
Standard Warranty
5 Years (10 years optional)
*The AC voltage and frequency range may vary depending on the specific country grid.
4.Packing checklist
4.1 Assembly parts
After you receive the Z10 series inverter, please check to see if there is any damage
to the carton, and then examine the inverter and accessories for any visible external
damage. Contact your dealer if anything is damaged or missing.
A
B
C
D
E
F
G
H
I
J

12
Object
Quantity
Description
A
1
Z10 series inverter
B
1
Wall mounting bracket
C
1
User manual
D
4
Screws (ST6x50)
E
4
Expansion tubes
F
1
AC cover
G
6
DC connectors (6 x positive,6 x
negative)
H
1
Ground nut (M6)
I
5
Cord end terminals
J
4
Screws (M4X12)
4.2 Product Appearance
Front
Object
Description
A
B
C
H
D
E
G
F

13
A
LED light(Green) –RUN
B
LED light(Red) –FAULT
C
LED light(Yellow) –COM
D
< left choice
E
> Right choice
F
∧up choice
G
∨down choice
H
Ok identify key
Bottom
Left and right
A
H
B
F
G
E
D
C

14
Object
Description
A
DC switch
B
Plug connectors for DC input.
C
RS232 interface
D
RS485 interface
E
Earthing
F
Ethernet interface
G
USB interface
H
Terminal for grid connection (AC output)
I
Update and reset switch for display
I

15
4.3 Product Identification
You can identify the inverter by the side name plate. Information such as the type of inverter,
as well as the inverter specifications are contained on the side name plate. The name plate is
located on the middle part of the right hand side of the inverter housing. The following figure is
an example of the side name plate on the Z10I17KDT
4.4 Further Information
If you have any further questions concerning the type of accessories or installation, please
check our website www.zeusappollo.com or contact our service hotline.

16
5.Installation
5.1 Safety
5.2 Dimensions & Weight
Model
weight
Dimension (L×W×D)
Z10I13KDT
44.5kg
575mm×650mm×240mm
Z10I17KDT
45kg
575mm×650mm×240mm
Z10I20KDT
45kg
575mm×650mm×240mm
NOTICE
NOTICE An inadequate or incorrect installation may
impact on the published lifespan of the inverter.
An Installation under the direct sun is not recommended.
The installation site MUST have adequate ventilation.
DANGER
DANGER to life due to potential fire or electricity shock.
DO NOT install the inverter near any flammable or
explosive items.
This inverter will be directly connected with a HIGH
VOLTAGE power generation device, the installation must
be performed by qualified personnel only in compliance with
national and local standards and regulations.

17
5.3 Mounting Instructions
The Z10 series inverter is designed for both interior and exterior installations.
Please mount the inverter in the direction as illustrated above.
It is recommended that the inverter is installed vertically, with a max.15 degrees
backwards tilt.
In order to view the LCD display and undertake maintenance activities, please install
the inverter at eye level.
Ensure that the wall selected for installation is strong enough for the mounting
screws and can bear the weight of the inverter.
Ensure the device is properly fixed to the wall.
It is not recommended that the inverter is exposed to strong sunshine. The excess
heat may lead to power reductions.
The ambient temperature of the installation site should be between -20 °C and
+60 °C ( between -4 °F and 140 °F ).
Ensure the installation location is well ventilated. Insufficient ventilation may reduce
the performance of the electronic components inside the inverter and shorten the
lifespan of the inverter.

18
5.4 Safety Clearance
Observe the following minimum clearances to walls, other devices or objects to guarantee
sufficient heat dissipation and enough space for pulling the electronic solar switch handle.
Direction
Minimum clearance
Above
20 cm
Below
40 cm
Sides
30 cm
20cm
30cm
30cm
40cm
