Beijer Electronics BFI-E3 Series Installation manual

Sida 1 (28)
Beijer Electronics AB −a company in the Beijer Electronics Group
Parent Company (Reg. office) Subsidiaries
Beijer Electronics AB Norway, Drammen: Beijer Electronics AS, [phone]
P.O. Box 426 Denmark, Copenhagen: Beijer Electronics A/S,  [phone]
SE-201 24 MALMÖ, SWEDEN Germany, Nürtingen: Beijer Electronics GmbH, [phone]
Telephone [phone] UK, Castle Donington: Beijer Electronics Products, [phone]
Visiting address: Stora Varvsgatan 13a, Malmö Turkey Istanbul: Beijer Electronics ve Ticaret A.s 0090 216 366 32 0200
Beijer Electronics Frequency Inverter BFI-E3 KI00369C 2021-09
1 Start-up document
This document is a simple start-up guide describing basic functionality of the drive BFI-
E3, firmware 3.11. Detailed explanations are to be read in User Manual BFI-E3 and is
attached with the drive itself but also possible to download from
www.beijerelectronics.com.
2 Important Safety Information
Read IMPORTANT SAFETY INFORMATION below, especially Warnings and Caution.
Danger: Indicates a risk of electric shock, which, if not
avoided, could result in damage to the equipment and
possible injury or death.
Danger: Indicates a potentially hazardous
situation other than electrical, which if not
avoided, could result in damage to property.
This variable speed drive product is intended for professional incorporation into complete equipment or systems as part of a fixed installation. If installed
incorrectly it may present a safety hazard. The BFI uses high voltages and currents, carries a high level of stored electrical energy, and is used to control
mechanical plant that may cause injury. Close attention is required to system design and electrical installation to avoid hazards in either normal operation
or in the event of equipment malfunction. Only qualified electricians are allowed to install and maintain this product.
System design, installation, commissioning and maintenance must be carried out only by personnel who have the necessary training and experience.
They must carefully read this safety information and the instructions in this Guide and follow all information regarding transport, storage, installation and
use of the BFI, including the specified environmental limitations.
Do not perform any flash test or voltage withstand test on the BFI. Any electrical measurements required should be carried out with BFI disconnected.
Electric shock hazard! Disconnect and ISOLATE the BFI before attempting any work on it. High voltages are present at the terminals and within the
drive for up to 10 minutes after disconnection of the electrical supply. Always ensure by using a suitable multimeter that no voltage is present on any
drive power terminals prior to commencing any work.
Where supply to the drive is through a plug and socket connector, do not disconnect until 10 minutes have elapsed after turning off the supply.
Ensure correct earthing connections. The earth cable must be sufficient to carry the maximum supply fault current which normally will be limited by the
fuses or MCB. Suitably rated fuses or MCB should be fitted in the mains supply to the drive, according to any local legislation or codes.
Do not carry out any work on the drive control cables whilst power is applied to the drive or to the external control circuits.
Within the European Union, all machinery in which this product is used must comply with Directive 98/37/EC, Safety of Machinery. In particular, the
machine manufacturer is responsible for providing a main switch and ensuring the electrical equipment complies with EN60204-1.
The level of integrity offered by the BFI control input functions –for example stop/start, forward/reverse and maximum speed is not sufficient for use in
safety-critical applications without independent channels of protection. All applications where malfunction could cause injury or loss of life must be
subject to a risk assessment and further protection provided where needed.
The driven motor can start at power up if the enable input signal is present.
The STOP function does not remove potentially lethal high voltages. ISOLATE the drive and wait 10 minutes before starting any work on it. Never carry
out any work on the Drive, Motor or Motor cable whilst the input power is still applied.
The BFI can be programmed to operate the driven motor at speeds above or below the speed achieved when connecting the motor directly to the mains
supply. Obtain confirmation from the manufacturers of the motor and the driven machine about suitability for operation over the intended speed range
prior to machine start up.
Do not activate the automatic fault reset function on any systems whereby this may cause a potentially dangerous situation.
The BFI has an Ingress Protection rating of IP20 or IP66 depending on the model. IP20 units must be installed in a suitable enclosure.
When mounting the drive, ensure that sufficient cooling is provided. Do not carry out drilling operations with the drive-in place, dust and swarf from
drilling may lead to damage. BFI are intended for indoor use only.
The entry of conductive or flammable foreign bodies should be prevented. Flammable material should not be placed close to the drive
Relative humidity must be less than 95% (non-condensing).
Ensure that the supply voltage, frequency and no. of phases (1 or 3 phase) correspond to the rating of the BFI as delivered.
Never connect the mains power supply to the Output terminals U, V, W.
Do not install any type of automatic switchgear between the drive and the motor
Wherever control cabling is close to power cabling, maintain a minimum separation of 100 mm and arrange crossings at 90 degrees
Ensure that all terminals are tightened to the appropriate torque setting
Do not attempt to carry out any repair of the BFI. In the case of suspected fault or malfunction, contact your local Beijer Electronics office for further
assistance.

Beijer Electronics Frequency Inverter BFI-E3 KI00369C 2021-09
www.beijer.se www.beijer.no www.beijer.dk www.beijerelectronics.de www.beijerelectronics.com www.beijerelektronik.com.tr 2 (28)
3 Table of Contents
1START-UP DOCUMENT ............................................................................................................................................1
2IMPORTANT SAFETY INFORMATION...................................................................................................................1
3TABLE OF CONTENTS..............................................................................................................................................2
4INSTALLATION...........................................................................................................................................................3
4.1 PHYSICAL DIMENSIONS IP20......................................................................................................................................3
4.2 PHYSICAL DIMENSIONS IP66......................................................................................................................................4
4.3 FUSES,CABLE DIMENSIONS AND POWER LOSSES......................................................................................................5
4.4 OVERVIEW POWER INPUT AND OUTPUT TERMINALS...................................................................................................5
4.5 INSTALLATION OF POWER SUPPLY,GROUNDING AND MOTOR CABLE ........................................................................6
4.6 BRAKE TRANSISTOR AND EXTERNAL BRAKE RESISTOR..............................................................................................8
4.7 EMC-FILTER...............................................................................................................................................................9
4.8 IP66, MAIN SWITCH,START/STOP SWITCH AND POTENTIOMETER.............................................................................9
4.9 OVERVIEW CONTROL INPUTS/OUTPUTS ...................................................................................................................11
5BASIC PARAMETER SETTING..............................................................................................................................12
5.1 DIGITAL START IN 2DIRECTIONS AND 4FIXED PRESET SPEEDS..............................................................................12
5.2 DIGITAL START IN 2DIRECTIONS AND ANALOG FREQUENCY SET POINT ..................................................................13
5.3 DIGITAL MOTOR POTENTIOMETER ............................................................................................................................13
5.4 DIGITAL START SIGNAL AND FREQUENCY SET POINT BY LEDDISPLAY ...................................................................14
5.5 START/STOP BY INDIVIDUAL SIGNALS.......................................................................................................................14
5.6 CONTROL FROM LED DISPLAY.................................................................................................................................14
5.7 ANALOG OUTPUT,0-10 VDC...................................................................................................................................15
5.8 DIGITAL OUTPUTS .....................................................................................................................................................15
5.9 CONTROL OF MECHANICAL BRAKE OF THE MOTOR ..................................................................................................15
5.10 PTC-THERMISTOR....................................................................................................................................................15
5.11 VECTOR CONTROL WITH STANDARD INDUCTION MOTOR .........................................................................................16
5.12 CURRENT LIMIT CONTROL.........................................................................................................................................16
5.13 TUNING OF PM-MOTOR ............................................................................................................................................16
5.14 CONTROL OF BFI BY MODBUS RTU........................................................................................................................17
5.15 CONTROL OF BFI BY CANOPEN ..............................................................................................................................18
5.16 CONTROL OF BFI BY MODBUS TCP........................................................................................................................19
5.17 PI-CONTROL..............................................................................................................................................................20
5.18 ENERGY OPTIMIZATION FUNCTION...........................................................................................................................20
5.19 SPIN START...............................................................................................................................................................21
5.20 BFI-SMARTSTICK......................................................................................................................................................21
6KEYPAD......................................................................................................................................................................22
6.1 LED DISPLAY............................................................................................................................................................23
6.2 MONITORING FROM KEYPAD ....................................................................................................................................23
7SPECIFICATION........................................................................................................................................................24
7.1 DISPOSAL REQUIREMENTS UNDER WEEE REGULATIONS .....................................................................................25
7.2 ENERGY EFFICIENCY CLASSIFICATION ....................................................................................................................25
8WARNING AND ALARM CODES...........................................................................................................................26
Copyright © Beijer Electronics, 2021
This software/documentation/information (below referred to as ‘the material’) is the property of Beijer
Electronics. The holder or user has a non-exclusive right to use the material.
The holder is not allowed to distribute the material to anyone outside his/her organization except in cases where
the material is part of a system that is supplied by the holder to his/her customer.
The material may only be used with products or software supplied by Beijer Electronics. Beijer Electronics
assumes no responsibility for any defects in the material, or for any consequences that might arise from the use
of the material. It is the responsibility of the holder to ensure that any systems, for whatever applications, which
is based on or includes the material (whether in its entirety or in parts), meets the expected properties or
functional requirements.
Beijer Electronics has no obligation to supply the holder with updated versions.

Beijer Electronics Frequency Inverter BFI-E3 KI00369C 2021-09
www.beijer.se www.beijer.no www.beijer.dk www.beijerelectronics.de www.beijerelectronics.com www.beijerelektronik.com.tr 3 (28)
4 Installation
The drive should be mounted in a vertical position only on a flat, flame resistant vibration
free mounting using the integral holes. IP66 is allowed for outdoor mounting. But it is
recommended having an external roof to avoid snow directly on drive. BFI will not start if
ambient temperature is below -20°C. See User Manual BFI-E3 for more details.
4.1 Physical dimensions IP20
BFI-E3- IP20
Drive
size
A
Height
[mm]
B
[mm]
C
[mm]
D
[mm]
E
[mm]
F
Depth
[mm]
G
Width
[mm]
H
[mm]
I
[mm]
J
[mm]
Weight
[kg]
1 x 230 V
3 x 380-480 V
0023-0070
[0,37-1,5 kW]
0022-0041 [0,75-1,5kW]
1
173
160
109
162
5
123
83
50
5,5
10
1,0
0070- 0105
[1,5-2,2 kW]
0041-0095 [1,5-4,0 kW]
2
221
207
137
209
5.3
150
110
63
1,7
0153/ 4,0 kW
0140-0240 [5,5-11kW]
3
261
246
-
247
6
175
131
80
3,2
No
0300-0460 [15-22kW]
4
420
400
-
400
8
212
171
125
8,2
14,8
9,1
No
0610-0720 [30-37kW]
5
486
463
-
463
-
226
222
175
-
-
18,1
NOTE
1x230 BFI-E3-0070 and BFI-E3-0041 are without brake transistor for Size 1 and Size2 with.
Mounting bolts
Size 1-3: 4xM5, Size 4-5: 4xM8.
Control Terminal, Required Torque
All Frame Sizes: 0,5 Nm.
Power Terminal, Required Torque
Size 1-3 = 1 Nm, Size 4= 2 Nm, Size5= 4 Nm.
Drive IP-class
and
Size
X [mm]
Above &
Below
Y [mm]
Either
Side
Z [mm]
Between
drives
Minimum
Airflow
[m3/min]
IP20, size 1
50
50
33
0,14
IP20, size 2
75
50
46
0,27
IP20, size 3
100
50
52
0,74
IP20, size 4
100
50
52
1,48
IP20, size 5
200
25
70
1,28
IP66, All sizes
200
Minimum 10 mm
0
Z means that IP20 can be mounted side-by-side. Minimum airflow is
based on maximum output power at 50°C for IP20 and 40°C for IP66.
