Linkedpro LPCV Series User manual

1066.80mm
932mm
SISTEMAS Y SERVICIOS DE COMUNICACIÓN S.A. DE C.V.
Calle 20 de Noviembre #805, Col. Centro
[phone]
C.P. 31000, Chihuahua, Chih, México
Please read this user manual before using the
equipment and retain it for future reference.
User Manual
Vercal Cable Organizers
LPCV Series Organizers
LPCV21URM LPCV24URL
Individual Organizers
For a double installation,
use only 2 pairs of screws
and 1 pair of brackets to
hold both organizers.

45U 24U
Front Slot
LPCV21URM
LPCV24URL
LPCV24URL
(Does not include racks)
Introducción
Thank you for selecting one of our LPCV Series Rack Cable Organizers.
The information contained in this manual will help you in the assembly
of the product as well as finding physical characteristics, included parts
and recommendations for use.
Herramienta
Ratch with extension and 7/16 "socket
Modo de Instalación/ Operación
1.-Screw the organizer body to the fixing bracket, taking care that the
grooves on the front face down. To choose the organizer perforation.
2- Install the retaining brackets over the prepared holes in the back of
your EIRL or EIRA Series Rack (not included) using the included screw kit.
3.- Once you have properly distributed your wiring, position the door
following the steps as shown in the image. To remove the lid, first remove
the lid from the top organizer and then the bottom.
