Lion Energy Safari UT 1300 User manual

Safari UT
™
1300
User Manual
12.8V / 105Ah / 1344Wh Lithium Iron Phosphate Battery
lionenergy.com | @lionenergy

2
USER GUIDE
WELCOME TO
THE PRIDE
Our mission is to provide portable products that are safe, silent and renewable so you
can use them wherever and whenever you want. We make products that are good
for people and good for our planet. Period. We are driven by this passion. Lion
Energy products are designed for everyday use – around the house, at work, on
the go or during emergencies.
Our products are high-quality, lithium battery based solutions for everyday living.
They range from small portable power banks and silent solar generators to RV
batteries for auxiliary power and residential energy storage. We help you become
energy independent with power to live life on your terms.
The Safari UT™ line is the latest in Lithium battery technology. It replaces traditional deep
cycle lead acid batteries with the safest and longest lasting Lithium Iron Phosphate
batteries.
For latest info go to www.lionenergy.com

3
USER GUIDE
READ THIS MANUAL IN ITS ENTIRETY
BEFORE OPERATING THE UNIT.
At Lion Energy we provide portable power that is safe, silent and renewable. Our products
are used in emergencies and for work and play. Please read the user manual carefully
before using the product and always take care when using this product. This product is not
intended for use by young or inrm persons without supervision.
Package Contents
Lion Safari UT™ 1300: 1 pc
User Manual: 1 pc
Attentions and Warnings
1. Do not disassemble, resemble or repair the battery. Incorrect reassembly may
cause combustion or electric shock.
2. If the battery is damaged, contact the place you purchased it.
3. Do not short-circuit the battery, use it near heat or water sources, or allow it to
become wet.
4. Do not insert nails or other objects into the battery, strike it, or weld directly on the
battery.
5. Do not use a badly damaged battery or operate it with damaged cables or charging
adapters.
6. Do not operate this product in explosive atmospheres (i.e. ammable liquids, gases
or dust) or set the unit on ammable materials (i.e. carpeting, upholstery, paper,
cardboard).
7. Do not permit the battery to freeze. Never charge a frozen battery.
8. In case of skin or eye contact, rinse immediately with clean water and seek medical
attention.
9. Do not keep using this product if it is damaged, waterlogged, distorted or broken.
10. This product contains lithium ion batteries. When it is worn out dispose it properly
using local laws and regulations.

4
USER GUIDE
Battery Pack Electrical Specication
# Item Parameter
1Nominal Voltage
(Works with 12V Systems)
12.8
(12V)
2 Technical Rated Capacity 105Ah
3 Minimum Capacity ≥104.5Ah
4 Internal Resistance ≤5mΩ
5 Standard Charging Current 45A
6 Max Charging Current 100A
7 Max Charging Volt 14.6V
8 Max Continuous Discharge Current 150A
9 Discharge Over Current Protection >150A @ > 50sec
10 Battery Low Voltage Cut-Off 10V
11 Operating Temperature
Charge: 32~113°F 45 ~ 85%
RH Discharge: -4 ~ 131°F
45 ~ 85% RH
12 Storage Temperature 14 ~ 95°F 45 ~ 85% RH
13 Product Size 10.2”L x 6.6”W x 8.8”H
14 Product Weight 23 pounds

5
USER GUIDE
Capacity LED1 LED2 LED3 LED4 LED5
05S-2HZ
(FLASH) OFF OFF OFF OFF
1% - 10% 5S (ON) OFF OFF OFF OFF
11% - 30% 5S (ON) 5S (ON) OFF OFF OFF
31% - 50% 5S (ON) 5S (ON) 5S (ON) OFF OFF
51% - 75% 5S (ON) 5S (ON) 5S (ON) 5S (ON) OFF
76% - 100% 5S (ON) 5S (ON) 5S (ON) 5S (ON) 5S (ON)
Function Description
• When the battery is ON and not charging, briey press the button, the
correspondence between LED and capacity is as follows:
• When the product is non-responsive, hold the button on top of the unit for 3
seconds and LED lights will illuminate indicating the unit has been reset.
• If the battery is short circuited, remove the cause of the short-circuit and
briey press the button on top of the unit. After one second press the button
again and hold for 5 second, then release.
Each single battery can be used independently as well as be used in series. If the batteries
are to be used in series, connect with professional tools and make sure the poles are
connected correctly. This may lead to battery failure or safety concern. Do not connect
more than four (4) batteries in series.
The diagram on the next page is a reference on how to connect batteries in series and
parallel in a 12V (12.8V nominal) system. Before connecting, each battery must be
independently fully charged.
Charging Protection in Dierent Temperatures

6
USER GUIDE
• For series, all batteries must be charged and discharged at the same time for
proper functionality.
• The battery must be charged within a specied charging rate and the ceiling
voltage of charging should be within the specication limits to avoid over
charging. Over charging will lead to poor performance, mechanical instability,
and possible safety issues.
• The battery should be used within specied discharge rate and the lowest
voltage should be within the specication requirements to avoid over
discharging. Over discharging will lead to poor performance, over heat, lead to
battery failure, and possible safety issue
• The battery must be used under required ambient environment according to
specication. Too high or too low temperature may affect the performance of
the battery.
• Constant charge and discharge rate should not exceed 0.5C to maximize the
life span of the cell.
• Use the battery within 80% DOD to extend the service life of the cells.

7
USER GUIDE
Maintenance Suggestions
Limited Warranty
• For storage over one month, place the battery in a dry and ventilated room that
is within the recommended storage temperatures.
• Do not store near corrosive material, re, or heat sources.
• Discharge and charge the battery until full once every six months if not being
used.
• In order to avoid over discharge, charge the battery periodically at the
suggested battery storage voltage (12.8V 13.24V, 30 ~ 50% SOC) to avoid
over discharge.
• Failure to follow the instructions in the User’s Manual.
• Accidental or unreasonable use, misuse, over charging or loading, or normal
wear.
• Extended storage without recharging or repairs done by an unauthorized
person or modication.
• Opening or modifying the battery casing.
For repair or replacement, contact customer service at 1-385-375-8191. Do not ship unit
until you receive a Return Merchandise Authorization (RMA) number from customer service
at Lion Energy. Lion Energy will not be responsible for any shipping or handling damage.
This warranty for the unit is extended to the original purchaser or user, and it covers defects
in materials and workmanship. The Safari UT 1300 has a lifetime warranty of the battery
cells, rated at 80% of the capacity (105Ah x .8 = 84Ah)
Under extreme use (maximum charge and discharge rates) the battery cells expected life
cycle is 3500. At “normal usage” the expected life cycles will be greater.
This warranty is invalidated if any of the following occurs, but not limited to:
This warranty is in lieu of all other express warranties. Lion Energy will not be liable for
consequential or incidental damages. Changes or modications not expressly approved by
Lion Energy could void the user’s authority to operate this device.
Warranty Repairs/Replacements
Service Address
Lion Energy
www.lionenergy.com
Address: 735 S. Auto Mall Drive
American Fork, UT 84003
Email: [e-mail]
Tel: [phone]

8
USER GUIDE
Serial Number:
Purchase Date:
Warranty Information
735 S. Auto Mall Drive
Suite 200
American Fork, UT 84003
385.375.8191
Monday - Friday
9:00 AM - 5:00 PM
[e-mail]
www.lionenergy.com
@lionenergy
Power Your Life.
