Liquid Ears LEBTWSWH User manual

1702/
TRUE
WIRELESS
BUDS
LEBTWSWH
LEBTWSBK

Read this user manual and in particular the safety notes, before
using the product.
Keep the user manual for future reference and include it when
passing the product on to third parties.
Liquid Ears will not in any way be held responsible for injury or
damage caused to persons or property arising from misuse of the
product.
Charging
For first time use, charge the battery to full capacity. To charge, plug
the charging cable into the product charging port connecting it to a
charger/pc with a USB port (5V, 1A). The blinking blue lights inside
the charging case shows the progress. When the lights are still, the
charging case is fully charged.
Once you place the earphones inside the charging case, the charge
will start and a red light will turn ON on each bud. When the red
light turns OFF, the earphones are completely charged.
Turning on and pairing
Remove the earphones from the charging case and they will
automatically turn ON. The earphones must be connected to a
device within 10 minutes, otherwise the earphones will go into
power saving mode. To activate the pairing mode again, simply put
the earphones back in the charging case and wait a few seconds
before doing the above procedure again. Turn ON the Bluetooth® on
your device, go to Bluetooth® menu, search for "LEBTWSWH" or
"LEBTWSBK", select to pair and connect. You will hear “Connected”
sound when pairing is complete.

Automatic reconnection
When the earphones are removed from the case they will
automatically turn ON and sync to each other. If they have
previously been paired to a device they will also automatically
re-connect provided it is within range.
MONO/STEREO function
You can also use only one earbud to listen to music and to take
calls. This function (MONO function) is available for both earbuds.
To use this function remove one earbud from the charging case. To
switch to the STEREO mode, remove the second earbud at any time.
To switch to MONO mode, place one earbud back into the charging
case.
Multifunction buttons
Play/pause
Reply/end calls
Refuse calls
Previous track
Next track
Volume -
Volume +
Voice assistant
Left earphone (L)
Single click
Single click
Press and hold
Double click
-
Press and hold
for 2 seconds
-
Triple click
Right earphone (R)
Single click
Single click
Press and hold
-
Double click
-
Press and hold
for 2 seconds
Triple click

Auto power off
Earphones will automatically turn off if there is no operation for 10
minutes after removing from charging case.
Pairing left and right earphone
If the connection from right to left is lost, put both earphones back
in the charging case. Wait a few seconds and then take out both
earphones from the charging case and they will re-connect
automatically. If this procedure does not work, disconnect the
earphones from your device, wait a few minutes, then reconnect
them (both earphones must be placed inside the charging case).
For both procedures it is necessary that the earphones inside the
charging case are charging, so make sure that the charging case is
sufficiently charged to guarantee the charging of the earphones.
Maintenance
1. Do not use abrasive cleaning solvents to clean the product.
2. Do not touch the product with any sharp object as this will cause
scratching and damage.
3. Please keep the product away from high-temperature, dust and
humidity.

Specifications
Bluetooth® version: 5.1
Earphones charging time: 1.5h
Charge case charging time: 2h
Earphones battery type: Li-polymer 3.7V/50mAh
Charge case battery type: Li-polymer 3.7V/300mAh
Microphone sensitivity: -42dB±3dB
Frequency response: 20Hz-20KHz
Bluetooth® range: 10m
Talk time: 5h
Playing time: 7h
Standby time: 80h
Operation temperature: 0° - 40° C

WARNING Do not dispose of unit in fire or water. • Never attempt
to disassemble and reassemble. • Waste electrical products
should not be disposed of with household waste, please recycle
where facilities exist. • Check with your local authority for recycle
advice.
• Keep your device and all accessories out of the reach of children
and animals. • Small parts may cause choking or serious injury if
swallowed. • Avoid exposing your device to very cold or very hot
temperatures (below 0˚C or above 45˚C). • Extreme temperatures
can cause deforming of the device and reduce the charging
capacity and life of your device. • Do not allow your device to get
wet—liquids can cause serious damage. • Do not handle your
device with wet hands.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.,
and any use of such marks by The Crest Company is under licence. Other trademarks and trade
names are those of their respective owners.
5
