LISEO L5 series Specification sheet

OPERATION AND INSTALLATION
MANUAL
European Standard Certification UNE EN-13229 inserts
European Standard Certification UNE EN-13240 stoves
LISEO s.r.o. Folknářská 1246/21 Děčín 2 – Nové Město 405 02

Version 01.2017
2
OPERATION AND INSTALLATION MANUAL
INTRODUCTION
1. GUARANTEE CONDITIONS
1.1. SAFETY WARNINGS…………………………………………………………………………………..3
1.2. GUARANTEE CONDITIONS…………………………………………………………………………..3
2. INSTALLATION IN ACCORDANCE WITH LOCAL AND NATIONAL STANDARDS
2.1. OPERATING AREA…………………………………………………………………………………….4
2.2. PRECAUTIONS…………………………………………………………………………………………4
2.3. CONNECTION TO THE EXTERNAL AIR INTAKE………………………………………………….4
2.4. CONNECTION TO THE FLUE PIPE………………………………………………………………….5
2.5. ASSEMBLY OF CLADDING…………………………………………………………………………...5
3. CONTROL OF THE APPLIANCES ……………………………………………………………………..6 - 8
4. DIMENSIONS AND TECHNICAL SPECIFICATIONS…………………………………………………….9
5. INSTALLATION AND ASSEMBLY
5.1. PREPARATION AND UNPACKING…………………………………………………………………..9
5.2. GENERAL ASSEMBLY RULES……………………………………………………………………….9
6. OPERATION
6.1. PRE-LIGHTING WARNINGS……………………………………………………………………..9
6.2. CHOICE OF FUEL ……………………………………………………………………………………10
6.3. FIRST LIGHTING ……………………………………………………………………………………10
6.4. CONTROL OF COMBUSTION …...…………………………………………………………………10
6.5. EMERGENCY SITUATIONS…………………………………………………………………………11
7. MAINTENANCE AND CLEANING IN CHARGE OF THE USER
7.1. CLEANING THE GLASS……………………………………………………………………………..11
7.2. CLEANING OUT THE ASHES……………………………………………………………………….11
7.3. CLEANING THE INTERIOR WALLS (refractory)………………………………………………….12
7.4. CLEANING THE DEFLECTOR IN CAST IRON……………………………………………………12
7.5. CLEANING OF PAINTED PARTS…………………………………………………………………..12
8. CLEANING TO BE DEALT WITH BY SPECIALIZED TECHNICIAN
8.1. CLEANING FLUE PIPE……………………………………………………………………………….12

Version 01.2017
3
OPERATION AND INSTALLATION MANUAL
INTRODUCTION
Dear customer,
We desire to thank you for the trust placed in LISEO products.
Throughout the years, you will appreciate the quality of our product, result of our interest in offering to you the best
technology, ease of use and, above all, safety.
For obtaining an optimal performance, we recommend you to read carefully this manual before the first firing.
MANUAL PRESERVATION
Ensure that this manual is always with the appliance even in the event of a change of owner, user or moved to
another location.
You can request another copy to the technical service in the area.
WARNING AND WARRANTY
CONDITIONS
The installation must be performed by authorized personnel. Request to your installer a declaration of
conformity of the installation, in which he will assume full responsibility for the final installation and therefore
the proper functioning of the installed product.
Pay special attention to the laws and regulations in the area of the device installation.
LISEO doesn't take any responsibility in the event of failure to comply with these precautions.
To ensure its proper operation, the stove components can only be replaced by original spare parts and repaired by an
authorized Assistance Technical Center.
These devices are not intended for use by persons with reduced physical, sensory or mental limited or without
experience or knowledge. Children should be supervised at all times to ensure that they do not play with the
equipment or come into contact with hot work surfaces.
After a long period of inactivity, before turning the appliance, check that there are no obstructions.
In this case, contact the Assistance Service Center.
In case of fire in the flue pipe, keep closed the door and the input of combustion air of the fireplace. Request the
intervention of the competent authorities.
EXCLUSIONS
Excluded from the warranty all parts that may be defective due to negligence or careless use, incorrect
maintenance or installation not compliant with that specified by LISEO.
They are not part of the guarantee those parts subject to normal wear such as joints, glass and any all parts that
can be removed from the fire box.
Replaced parts will be warranted for the remaining warranty period, with effect from the date of appliance purchase.
The glass are guaranteed until the moment when the authorized installer confirms its integrity and completes
commissioning.

Version 01.2017
4
OPERATION AND INSTALLATION MANUAL
2. INSTALLATION IN ACCORDANCE WITH LOCAL AND NATIONAL STANDARDS
2.1. OPERATING AREA
Ventilation: To allow proper operation, verify that the oxygen required for combustion can be
obtained in sufficient quantity in the place where it is to install the appliance.
Location of appliance: Choose a central location in the room that favors a good distribution.
Ensure that there aren't made or coated with materials that are flammable or degrade with heat effect
(wallpaper, carpet, light closures based on plastics, etc.)
The installation of the appliance is not allowed in bedrooms or bathrooms neither in places that has
been already installed another heating appliance or a fume extraction system without an independent
air intake (kitchen extractor, fireplace, stove, etc.).
It is forbidden to place the fireplace in explosive environments.
With wooden floors, provide for protection of the soil surface in accordance with the rules in force in
the country.
2.2. PRECAUTIONS
The installation and assembly of the fireplace must be performed by qualified personnel.
The chimney must be connected to an internal or external vertical duct in accordance with existing
laws, which can discharge smoke at the highest point of the house, waterproof and properly insulated.
2.3. CONNECTION WITH EXTERNAL AIR INTAKE
The chimney must have at least as much air as you need for a normal combustion of the appliance and the
ventilation of the place. Respect the UNI 10683 norm relative to the ventilation openings.
The ventilation grilles must be installed so that
it can’t be obstructed

Version 01.2017
5
OPERATION AND INSTALLATION MANUAL
2.4. CONNECTION TO THE EXTERNAL AIR INTAKE
The smoke exhaust system must be unique to the insert
(Not allowed pipe discharges common to other fireplace).
Fumes discharged is made from the opening situated at the top.
The discharge pipe must be connected to the outside using appropriate tubes and eventual isolation.
It’s necessary to use materials resistant to high temperatures.
2.5. ASSEMBLY OF CLADDING
The fireplace and the parts of the cladding must be attached together WITHOUT ANY CONTACT WITH STEEL
STRUCTURE to prevent heat transmission to the coating and allow thermal expansions. Beware of wood
finishes such as beams or shelves, which must be properly insulated.
In particular, the shelves should be placed at a distance upper to 30 cm from the top of the appliance.

Version 01.2017
6
OPERATION AND INSTALLATION MANUAL
3. CONTROL OF APPLIANCES
1º air combustion
2º air combustion
optional in some models
L71
L7
Valid for models of the L7 / K7 range

Version 01.2017
7
OPERATION AND INSTALLATION MANUAL
Clean glass
air
2º Air
combustion
1º Air
combustion
Premium
Canaria

Version 01.2017
8
OPERATION AND INSTALLATION MANUAL
Clean glass
air
1º Air
combustion
L71
L71 Black
L72

Version 01.2017
9
OPERATION AND INSTALLATION MANUAL
4. DIMENSIONS AND TECHNICAL SPECIFICATIONS
GENERAL INFORMATION
All our units are made of gray cast iron FG20.
All technical details and dimensions of the appliance are given in the data sheet attached to this manual.
5. INSTALLATION AND ASSEMBLY
IMPORTANT
The chimney can only be installed and connected to the flue by a specialized technician, respecting in
every time the national and local standards and in compliance with UNI 10683.
5.1. PREPARATION AND UNPACKING
When you unpack the fireplace, check for perfect operation, as well as the possible presence
of shipping damage. Any anomalies must be immediately reported to the transport carrier or
seller.
Check the accordance with what is provided.
The chimney must always be moved in VERTICAL position.
The glass is fragile, it's necessary to protect it.
If possible, unpack the fireplace near the area where you will install it.
5.2. GENERAL ASSEMBLY RULES
The appliance must always lean on a structure which support the weight and leave at least 5
cm air gap between the chimney and walls.
If the chimney is placed on a floor or near combustible walls, a proper insulation is
recommended.
6. OPERATION
6.1. PRE-LIGHTING WARNINGS
Make sure you have read and perfectly understood the contents of this instruction manual.
Remove from the fireplace and the door all accessories, adhesives and equipment that could burn.
During the first lighting, the paint completes its drying and hardens. If you touch the paint, it could
cause some damage.
During this phase the paint may release a little smoke and smell of paint. Make sure the room is
sufficiently ventilated during this phase.
Smoke and the smell of paint will vanish after about one hour of operation.
Please note, however, that are not harmful to health.
Do not overheat the chimney immediately, take it gradually to the desired temperature.
Do not try to immediately achieve maximum performance of the appliance.

Version 01.2017
10
OPERATION AND INSTALLATION MANUAL
6.2. CHOICE OF FUEL
Use only wood with suitable characteristics. Without moisture.
Get advice from your installer about the most appropriate wood for burning existing in your region.
Heat capacity of the timber in relation to the contained moisture.
6.3. FIRST LIGHTING
In the first lighting, you are advised to proceed with caution and use fine and dry wood.
Place the primary air input fully open.
DO NOT USE under any circumstances: alcohol, gasoline or any other explosive flammable substances.
During the first lightings, it could release fumes or unpleasant odors caused by the drying of the paint; it is not
hazardous, it's just necessary to ventilate the room. Once combustion is performed regularly, introduce wood
pieces of normal size.
When you open the door, do it slowly to avoid returns of smoke in the room.
Never load the fireplace with excessive wood (see technical data).
During use, the metal structure, the handles and the glass reach hot temperature; therefore, use proper
thermal protection for handling.
During normal use, keep the fireplace's door always closed completely.
6.4. CONTROL OF COMBUSTION
The regulation is in the front (under the door).
Moving the control (to –“or” +) we reduce or increase the quantity of air which contribute to combustion.
PRIMARY AIR air input from the bottom.
SECONDARY AIR air input from the back (deflector).
GLASS CLEAN AIR prevents the glass from getting dirty during combustion.
Once the flame in the fireplace is well underway, move the air primary lever to “minus”. In this
condition, the primary air input is reduced and the air flow passes to the second combustion, so we can
regulate the desired power of combustion.
Wood drying time (i.e.
beech)
Humidity
%
Heat power
kcal/h
Freshly cut
50
/
3 months
40
2410
6 months
35
2700
9 months
30
2900
12 months
25
3150
15 months
20
3400
18 months
15
3710
21 months
10
3980

Version 01.2017
11
OPERATION AND INSTALLATION MANUAL
6.5. EMERGENCY SITUATIONS
If, for any reason, you have to quickly extinguish the fire of the fireplace or intervene in a fire trapped in the flue
pipe, act following the proposals below:
Always leave the appliance door closed,
Close the air inputs,
Request urgently the intervention of the competent organisms.
7. MAINTENANCE AND CLEANING IN CHARGE OF THE USER
ATENTION
Only clean the chimney when it's completely cold
7.1. CLEAINING OF THE GLASS
To clean the glass, you can use specific products, or some white ash and a newspaper page.
Clean regularly the glass; an accumulation of dirt and soot increases the glass cleaning time.
7.2. CLEANING OUT THE ASHES
Exclusively with the fireplace off and cold. We recommend daily cleaning of the ash drawer.
Ash can contain small glowing embers that can stay incandescent for hours.
Store the ashes outdoor in a metal container until you are sure that pose no danger.
L5 / K7 / L7 / L9

Version 01.2017
12
OPERATION AND INSTALLATION MANUAL
7.3. CLEANING THE INTERIOR WALLS (refractory)
With the cold chimney, brush the soot that may be adhered.
7.4. DISASSEMBLY AND CLEANING THE CAST IRON DEFLECTOR
See technical sheet attached for your appliance
7.5. CLEANING OF PAINTED PARTS
Do not use abrasive or aggressive products or materials. Wipe with a paper or cotton wet cloth. Avoid cleaning
with wet cloths painted parts when hot, to avoid thermal shock to the paint.
8. CLEANING TO BE DEALT WITH BY SPECIALIZED TECHNICIAN
8.1. CLEANING FLUE PIPE
We recommend performing a mechanical cleaning of the flue pipe at least once a year. The slag buildup can
cause problems in the evacuation of the fumes and increases the risk of fire in the smoke flue.
ATTENTION
For maintenance, we advise to contact a specialized center that will be in a position to define,
according to the type of installation and depending on the use made of it, the frequency of
cleaning and maintenance.
