Arlink 7000 Workstation
Instructions for Assembly
Basic Bench Assembly
Undersurface Accessories
Above SurfaceAccessories
VSI Mounting Instructions
Making Workspace Work® is a trademark of Lista International Corporation.
Creation Date Document Number Rev Description
Feb/01/06 AS70007 B Arlink 7000 Workstation
This manual is proprietary information of Lista International Corporation. Unauthorized
reproduction of any portion of the manual is prohibited without consent of Lista
International Corporation. The material in this manual is for informational purposes
only. It is subject to change without notice. Lista International Corporation assumes
no responsibility for any typographical errors contained in the manual.
© 2006 by Lista International Corporation, all rights reserved.
106 Lowland Street
Holliston, MA 01746-2094
E-mail: sales@ listaintl.com
All rights reserved.
For questions or technical support, call 1-800-722-3020
ISO 9001 Certified
Table of Contents
Basic Bench Assembly Step 1 .............3
Basic Bench Assembly Step 2...............3
Basic Bench Assembly Step 3...............3
Basic Bench Assembly Step 4...............3
Back & End Stops .................................4
Rear & End Modesty Panels .................4
Footrest..................................................4
Drawer Installation................................4
Powerbeam Installation.........................5
Riser Shelf—Box Style.........................5
Riser Shelf—Column Style...................5
VSI-8 Vertical Space Integrator............5
Basic Bench Assembly
Step 1
Install adjustable glides into inserts in the bottom of the leg
extenders.
Step 2
Assemble frame by attaching load beams and
stiffener to legs using the 1/4”-20 x 3/4” hex bolts
1/4” flat washers and 1/4” lock washers included.
Leave bolts loose until all are in place, then square
up the frame and tighten bolts. Note: One flange
on each load beam has holes used to securer
the worksurface. Ensure the holes are at the
top of the frame.
Arlink 7000
Assembly Instructions
Step 3
Invert worksurface onto soft, clean surface to avoid
damage to laminate.
Step 4
Invert assembled frame onto the underside of the
worksurface. Ensure stiffener is located at the rear
of the worksurface. (Square edge). Center the
frame on the worksurface. Fasten frame to the
worksurface through the holes in the load beams
and leg flanges using the #10 x 1” wood screws
provided.
Back & End Stops (Optional)
Back and end stops are pre-punched
for easy installation. After worksurface
has been mounted on frame, fasten
stops to back and sides of worksurface
with the #10 x 1” wood screws
provided.
Rear & end Modesty Panels (Optional)
Fasten all 3 panels to leg frame using the #8 x
3/4” self-drilling screws provided.
Footrest (Optional)
Fasten footrest into crossbeam of leg
assembly using the #10-32 Phillips
machine screws provided.
Drawer Installation (Optional)
For ease of assembly the drawers can be removed by releasing the
disconnects on both sides of the slides and pulling the drawer forward
to separate the slides. Using 1/4”-20 x 1” machine screws loosely
fasten “L” shaped hangers to the rear of the drawer. Swing the front of
the hangers away to form a “V”. Lift drawer into position. Set drawer
hangers on rear load beam flange. Swing the front of the hangers
back in, and rest them on the front load beam. Fasten the drawer to
the front of the hangers, slide into position along the length of the
Hangers for 30” deep workbench are shown.
Hangers for 36” deep workbench are
approximately 6” longer, while the drawer
mounts in the same position.
Power Beam Installation (Optional)
Position Power Beam where desired on top or underside of worksurface. Note
on Static Dissipative worksurfaces install insulating washers
provided between power beam and worksurface. Use power
beam as template and drill 5/16” diameter x
5/16” deep holes for insulators. ***Read
Warning Box Page 4. Fasten to bench with
the #10 x 1” wood screws provided.
Riser Shelf—Box Style (Optional)
Invert instrument shelf onto soft, clean surface
to avoid damage to laminate. Place box
supports flush with end and rear of riser shelf.
Fasten with the #10 x 1” wood screws provided.
Invert shelf and boxes. Place flush with end
and rear of worksurface. Screw to worksurface
with the #10 x 1” wood screws provided. Note:
On static dissipative worksurfaces place
insulator between riser box and
worksurface. Using box as a template, drill
5/16 diameter X 5/16” deep holes for
insulator. Install box support cover or optional
electrical panels. ***Read Warning Box on
Page 4.
Riser Shelf—Column Style (Optional)
This system requires drilling four 3/8” diameter holes, on
36”, 48” or 60” centers, depending on the module size
required. The “J” bolts provided hook over the embosses in
the center of the columns. Place the mounting plate under
the column and mount to worksurface using the 5/16”-18
lock nuts, 5/16” flat washers provided. Align rear of shelf
with rear of top mounting plate. Fasten riser shelf through
holes in the plate using wood screws provided. Note: On
Static Dissipative worksurfaces place insulator
between mounting plate and worksurface. ***Read
Warning Box on Page 4
Note: Prior to drilling bench tops ensure that there will
not be interference with any undersurface components.
VSI-8 Vertical Space Integrator (Optional)
Position the mounting plates of the columns on the worksurface approximately 3/4” from the
rear of the surface. Using the modesty panel as a guide, centre the columns horizontally on
36”, 48”, 60”, or 72” centers as required. Using the mounting plates as templates, mark and
drill eight 5/16” diameter holes. Using the 1/4”-20 bolts, washers and lock nuts provided install
the columns as shown. Do not tighten the hardware until the modesty panel is installed. Note:
On Static Dissipative worksurfaces place insulator between mounting plate and
worksurface. ***Read Warning Box Below.
Note: Prior to drilling bench tops ensure that there will not be interference with any
undersurface components.
***Warning!
Failure to comply with the proper installation of
insulating grommets or gaskets may result in
hazardous electrical conditions for personnel.
The ultimate responsibility for personnel safety
lies with the end user.
