SK-9060 Operational Description
Getting Started
Thank you for choosing this 2.4G Wireless Keyboard Kits. It operates with digital radio technology to ensure no hinder
communication between the keyboard and your computer without connecting cable.
The transmission and receiving of keyboard are free from angle restriction.
Preparing keyboard and Dongle
Before working with your new keyboard, look at the "Hardware Installation", and take a few one-time preparations.
Hardware Installation
●Place the dongle at least 20 cm from other electrical devices (e.g. monitor) to achieve optimum performance.
●The distance between the keyboard and dongle should not exceed 10 M.
●Do not place the dongle on metal surfaces.
Step 1: Connect the receiver
●Plug the dongle connector into an USB port.
●SYSTEM will take around 10 sec to find your keyboard and mouse automatically.
Step 2: Insert batteries
Inserting batteries in keyboard
The keyboard requires two alkaline batteries (AAA).
●Remove the battery compartment cover on the bottom of the keyboard by
pushing it in the direction of arrow.
●Insert two AAA batteries.
The illustration in the battery compartment shows how to insert the batteries properly.
●Recover the battery compartment by pushing the locking lug under the battery compartment.
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Use and replace only with correct size and type
(alkaline or zinc-carbon)of battery.
Working Keyboard
USB Transceiver and keyboard electrical specification
The Transceiver will have one main function: translate radio communications from the mouse to the PC via USB
Full Speed USB Specification Compliance., meets Universal Serial Bus Specification version 2.0.
Support USB Suspend Mode.
Keyboard
The following description of few keys applies for the operating systems that support these functions
(e.g. Windows 2000/XP/Vista/Windows 7).
Vista Key Press Vista key to open Start Manu
Application key Press Application key is same as Right Mouse key to open function Manu
Previous Track Combine keys to skip to the forward title in the active player.
Play/Pause Combine keys to Start or Pause the soundtrack in active player.
Stop Combine keys to end the soundtrack or video.
Next Track Combine keys to skip to the next title in the active player.
My Computer Open My Computer folder.
Mute Press this key to On/Off the volume.
Volume down Press this key to decreasing the volume.
Volume Up Press this key to increasing the volume.
Calculate Activate the Windows defaults Calculate
Search Activate the OS default search function
E-mail Use this key to start the standard e-mail program for your system

Technical data
Designation Value
Modulation GFSK
Operating Frequency 2403MHz~2480MHz
channel 78 channel 2.4GHz ISM Band
Storage temperature –20 °C ... +60 °C
Operating temperature 0 °C ... +40 °C
Keyboard Battery type two alkaline batteries, type
AAA
Keyboard Supply voltage 2.2~3.3V
Keyboard Current consumption max. 50 mA
USB Transceiver Supply voltage DC 5.0 V ±5 %
USB Transceiver Current consumption max..100 mA
