LIVING BASICS LB-IC-16D3 User manual

- 1 -
PLEASE READ THIS INSTRUCTION MANUAL
CAREFULLY BEFORE YOU USE
USER MANUAL
INDUCTION COOKER
Power Source: AC 120V~, 60Hz
Power consumption: 1800W

- 1 -
Caution & Safeguards
Read all instructions thoroughly before operating the induction cooker unit to avoid injury to
yourself and others,property or damage the cooker itself. Keep this User Manual as a handy
reference.
Electrical Hazards（Observe the following cautions）
Only qualified experts may perform repair and maintenance work on the cooker.
CAUTION: This cooker unit emits an electromagnetic field,therefore people with
pacemakers should consult with their physician before using.
DO NOT
submerse the unit or electrical cord in
liquid, touch the unit with wet
hands,or use in a wet outdoor
environment.
use if cooker surface is cracked.
operate if the electrical cord is frayed
or if wires are exposed.
let the electrical cord hang over the
edge of a table or counter-top.
move the unit by pulling on the power
cord.
keep cookware on the cooker when the
unit in use.
DO NOT
touch the cooker surface or cookware bottom for several minutes
after using as both will be hot.
move the cooker unit while cooking or with cookware4 on cooker
surface.
place any metal objects on the cooker surface other than
authorized metal cookware or an Induction Interface Disk.
place the cooker on any metal surface as the surface could
become hot.
heat unopened cans of food.The cans could explode.
use in or around flammable or explosive environments.
allow children in the immediate vicinity or around the cooker
while in use.
leave cooker or other objects on the cooker unattended when
plugged in.
DO NOT
heat empty containers on the cooker surface.
place any metal object other than cookware on the cooker surface.
place objects weighing more than 25 pounds on the cooker surface.
block the cool air inlet and fan.
operate cooker on flammable surfaces.
clean a induction cooker in a dishwasher.
use the cooker unit for anything other than its intended purpose.
Place objects affected by a magnet, such as a credit card,radio,television,etc,near the unit while
operating the cooker.
share a 120V,15amp electrical outlet with another electrical item.
block the rear and sides for the unit-keep at least 4” from walls for proper ventilation.

- 2 -
Operating Instruction
THE CONTROLS:
①OFF/ON BUTTON ⑧Warm
②HOT POT ⑨Energy saving
③Temperature adjustment button (DOWN) ⑩Child Lock
④PAUSE ⑪LED DISPLAY
⑤Temperature adjustment button (down) ⑫Low temperature light
⑥Timer ⑬High temperature light
⑦Boiling Water
[ON/OFF]
1. After inserting the plug into the socket,a “Beep” will emit and all the indicators and
display screen will flashing 1 second,the cooker will in standby mode.
2. Put a suitable cookware on the center of the cooking zone.
3. Press [On/Off] l,some kind of cookers will start working directly ,some will show ‘ON’,after
choosing function will start working.
4. When the cooker in use,Stop the operation by pressing [On/Off].
[LOCK]
1.Press [Lock] ,the display will show [Loc] representing that the cooker is locked.
2.During Lock mode, all buttons conclude [ON/OFF]can’t be adjustable.
3.To Cancel it,press [Lock] and hold for 3 second ,the cooker will be unlocked.
[TIMER]
1.Press [Timer] ,the display will show [00:00],user can press[+] or [-] key to set for the
desired time.
2.Slightly press[+] or [-] key once can increase or decrease 1minute.
3.Long press[+] or [-] key once can increase or decrease 10 minutes.

- 3 -
4.After setting,The display will show desired power or temperature and remaining timer
alternately.
5.When timer finish,the cooker will have a beep signal then stop working.
6. If want to cancel timer,users can either press the [On/Off]or hold the function key to
resume the desired power or temperature operation.
7.After timer setting,user can change the power or temperature,this action won’t cancel the
timer setting.
[POWER AND TEMPERATURE]
When the cooker in use,press[+] or [-] key once can increase or decrease working power or
temperature.
Working principle
Induction cooker is a safe, advanced, efficient, and economical cooking technology. It works
by electromagnetic vibrations generating heat directly in the pan, rather than indirectly
through heating the glass surface. The glass becomes hot only because the pan eventually
warms it up.
SELECTTING THE PROPER COOKWARE
Your induction cooker will not operate without the proper cookware.
Read the following information in this section carefully to get the maximum efficiency from your unit. The
rule of thumb for selecting cookware is if a magnet sticks to the cookware bottom,the cookware will work on
your cooker.
The bottom surface of the cookware must be made of ferrous magnetic material.
The cookware must be touch the cooker or rise no more than 1 inch above it.
Safety mechanism: The cooker may not operate(displays “E0” error code)
iron pot
magnetic circuit
ceramic glass plate
induction coil
induced currents

- 4 -
if:The cookware does not have a flat bottom surface with a minimum bottom diameter of 4-6 inches.
The cooker bottom is made of material with a low ferrous magnetic content, even if a magnet sticks to the
cookware bottom.
1. FRIENDLY COOKWARE
Material: Iron or stainless steel.
Shape: Bottom diameter about 12-20cm saucepan or square pot.
Stainless Iron pot Magnetic stainless Color iron Magnetic Iron pan
Steel kettle steel pot pot iron kettle
2. AND NON-FRIENDLY COOKWARE
Material: Non-iron metal, ceramic, glass or bottom is made of cooper or aluminum pot.
Shape: Bottom uneven, diameter less than 12cm.
Heat-resistant Ceramic pot Bottom Bottom Small diameter Aluminum
Kettle Glass pot not smooth with feet of bottom
CARE AND MAINTENANCE
1. Remove the power plug prior to clean the unit.Do not clean it until the surface cools down.
2. Glass Plate,Panel and Shell：Soft Cloth for slight stain；For greasy,dirt,blot by using a clean damp cloth
with neutral detergent.
3. While the radiator-fan working,dust and dirt would remain on the gas vent,please clean it by brush or
cotton stick regularly.
4. Remember do not washing the unit by water directly to avoid damaging.
5. To protect induction cooker, be sured to have a good contact between plug and socket before using.
6. Do not pull out the power cord directly during operation.To extend the appliance’s using life,press the
“On/Off” button first,then pull out the power cord.
7. In order to make operating time longer,the fan would still work for cooling the plate,is better to plug out
after the fan stops working.
8. Please pull out the power cord and put it away when not used for a long time.

- 5 -
9. Some models have structural design to against cockroaches,if needed,can put something like mothball to
expel the cockroaches.
TROUBLESHOOTING GUIDE
During operations, if any error occurred, please check the following table before
calling for service.
Remedies/controls can not fix the problem,unplug the appliance immediately, contact
PHENOMENON
CHECK POINTS
REMEDY
Get through power supply but no
Bi sound and press the ON/OFF
key
Is the electricity in suspension?
Check whether the electricity
was cut off.
Is the plug connected firmly?
Check whether plug is good
working circumstance.
Check whether fuse is in good
circumstance or not.
Is the fuse broken down?
Induction Cooker send out Bi
Sound
Incompatible cookware or no
cookware is used?
Check the pit using is proper or
not.
Is the cookware not considerable
placed from the center of the heating
zone?
Check whether the pot is sitting
in the center of the plate or not.
Is the cookware bigger than 12cm?
Check whether the diameter of
the pot is bigger than 12cm or
not.
No Operation during the heating
being in use
Is the cookware empty or the
temperature too high?
Please check whether the
appliance is being misused
Is the air intake/exhaust vent clogged
or dirt has accumulated
Remove the stuff clogging the air
intake/exhaust vent. Operate the
appliance again after cooling
down.
Is the cooker working over 2 hours
without any external instruction?
Reset cooking modes or use
timer function
Error codes occur E0
Without Cookware or Incompatible
cookware used
When showing error signal E0,
E3, E5, please check whether the
cookware is not suitable,or
switch on the appliance again
after it is cooled down naturally.
When showing E1, E2, E4, E6, E7,
please contact service center for
checking and repairing
Error Codes occur E1
Low-Voltage
Error Codes occur E2
High-Voltage
Error Codes occur E3
Top plate Overheat
Error Codes occur E4
Top Plate Sensor Open Circuit
Error Codes occur E5
IGBT Overheat
Error Codes occur E6
Top Plate Sensor Short Circuit
Error Codes occur E7
Internal circuit error

- 6 -
service center for inspection and repairing,note the error code and report it to service center
ltd.To avoid any danger and damage to the cooker ,do not disassemble or repair it by
yourself.
Warning
Switch Off the induction cooker in case of any crack on the cook-top panel
1. Do not place the cooker in any place that is near gas or hot environment in order to avoid
damages or malfunction.
2. To reduce the risk and damage, this plug should be fit into and individual outlet. The rated
electrical current is not less than 16A.
3. Place the cooker on a level surface,the distance between it and its background
surrounding must be not less than 12cm.
4. Do not immerse the cooker and electric cord in water liquid,or allow liquid to go into the
cabinet and get short/contact inner electrical parts,the power cord must be plugged out
before cleaning.
5. Do not cover gas vent with anything during cooking,otherwise it will cause danger.
6. To avoid danger,please uncap the cover before heating tinned food.
7. If it is still not working after the inspection by self,please immediately contact with our
service points,do not apart the cooker to avoid any danger.
8. Be sure to use the power cord recommended by the cooker manufacturer after it is
damaged.
9. It would get dangers when the metal gets heated directly or indirectly.
10. Do not place any metal on the plate,also the nonmetal pad within 10cm.
11. Do not cook with an empty pot,it will cause malfunction or danger.
12. Always clean the cooker to avoid any dirt goes into the fan to effect normal Working.
13. Do not touch the plate while the unit is working,to avoid getting burned.
14. Do not let children operating alone to avoid getting burned or danger.
15. Who with cardiac pacemaker,please operating the unit after confirm with doctor there’s
no any effect.
16. Do not operate the cooker upon the gas stove to avoid any danger.
17. Please do not place paper, cloth or other articles under the bottom of the pan to get
heated, to avoid the danger of fire.
18. Do not place the cooker on the cloth,carpet to avoid blocking the gas vent.
19. Please kindly avoid hitting the plate of the induction cooker,in case of getting
cracked,should turn off the unit and plug out immediately,and then contact with
service points of our company.
20. Do not touch the control panel with any sharp implements.
21. Do not place any metal on the cooker while operating.

- 7 -
VEUILLEZ LIRE CE MANUEL D'INSTRUCTIONS
SOIGNEUSEMENT AVANT VOTRE UTILISATION
MANUEL DUTILISATEUR
PLAQUE À INDUCTION
Source d'énergie: AC 120V ~, 60Hz
Consommation d'énergie: 1800

- 8 -
Attention et Sauvegardes
Lisez attentivement toutes les instructions avant d'utiliser la plaque à induction pour éviter de
vous blesser ou de blesser d'autres personnes ou d'endommager la cuisinière elle-même.
Conservez ce manuel d'utilisation pour la référence pratique.
Risques électriques
Observez les mises en garde suivantes:
Risque d'électrocution.
Seuls des experts qualifiés peuvent effectuer des travaux de réparation et d'entretien sur la
cuisinière.
MISE EN GARDE: Cette unité de cuisson émet un champ électromagnétique, par conséquent
les personnes avec des stimulateurs cardiaques doivent consulter leur médecin avant de
lutiliser.
NE PAS
immerger l'appareil ou le cordon électrique dans un liquide, toucher l'appareil avec les
mains mouillées ou l'utiliser dans un environnement humide à l'extérieur.
Utiliser la cuisinière si sa surface est fissurée.
Faire fonctionner l’appareil si le cordon électrique est effiloché ou si les fils sont exposés.
laisser le cordon électrique pendre sur le bord d'une table ou d'un comptoir.
déplacer l'unité en tirant sur le cordon d'alimentation.
placer les ustensiles sur la cuisinière lorsque elle est utilisée.
NE PAS
toucher la surface de la cuisinière ou le fond de la casserole après quelques minutes
d'utilisation, car les deux seront chauds.
Déplacer la plaque à induction pendant la cuisson ou avec les ustensiles de cuisine sur sa
surface.
placer des objets métalliques sur la surface de la cuisinière, à l'exception des ustensiles de
cuisson en métal autorisés ou du disque d'interface à induction.
Placer la cuisinière sur toute surface métallique car la surface pourrait devenir chaude.
chauffer les boîtes de conserve non ouvertes. Les boîtes pourraient se exploser.
utiliser lappareil dans ou autour d'environnements inflammables ou explosifs.
permettre aux enfants dêtre près ou autour de cuisinière pendant l'utilisation.
laisser d'autres objets sur la cuisinière sans surveillance lorsqu'elle est branchée.

- 9 -
Dommages aux produits et aux biens
Pour éviter d'endommager la zone environnante de la cuisinière:
Mode d'emploi
LES COMMANDES
○
1Bouton ON/OFF ○ 8Chaud
○
2POT AU FEU ○ 9Économie d'énergie
○
3Bouton de réglage de la température (BAISSER) ○
10 Verrouillage des Enfants
○
4PAUSE ○
11 AFFICHAGE LED
○
5Bouton de réglage de la température (BAISSER) ○
12 Voyant à basse température
○
6Minuteur ○
13 Voyant à haute température
○
7Bouillir de l'eau
NE PAS
chauffer les récipients vides sur la surface de la cuisinière.
placer tout objet métallique autre que ustensiles de cuisine sur la surface de la cuisinière.
placer les objets pesant plus de 25 livres sur la surface de la cuisinière.
bloquer l'entrée d'air froid et le ventilateur.
faire fonctionner la cuisinière sur des surfaces inflammables.
nettoyer une plaque à induction dans un lave-vaisselle.
utiliser l'unité de cuisson pour autre chose que son usage prévu.
placer les objets affectés par un aimant, tels qu'une carte de crédit, la radio, la télévision,
etc., près de l'appareil pendant l'utilisation de la cuisinière.
partager une prise électrique de 120 V, 15 ampères avec un autre article électrique.
bloquer l'arrière et les côtés de l'unité - gardez au moins 4 "des murs pour une bonne
ventilation.
