LLOYTRON Bolero User manual

MODEL: J2005WH
OPERATING INSTRUCTIONS
‘Bolero’
AM/FM
Alarm Clock
Radio

2 3
FEATURES
thank you
Thank you for the purchase of this quality LLOYTRON product. Used carefully and in accordance with the
instructions enclosed, it should give you trouble free service over a long period of time. Please keep these
instructions for future reference.
• 0.6” Red LED Display
• AM/FM Wavebands
• 12hr Clock
• Radio Tuning Display
• Wake to Alarm or Radio
• Snooze & Sleep Function
• Mains Operation with Battery Backup (Battery not included)
SPECIFICATIONS
Operating Voltage: 220-240v~ 50Hz
Backup Battery: PP3 9v (Not included)
Frequency Range: FM 88 –108Mhz
AM(MW) 540–1600Khz
Antenna: Ferrite bar (MW), Wire Antenna (FM)
SAVE THESE INSTRUCTIONS
• Read all instructions carefully.
• For Household Use only.
• Only for use indoors.
• Do not use outside or in damp conditions.
• Keep away from hot surfaces, such as gas or electric hobs and ovens etc.
• Do not use for any purposes other than the appliances intended use.
• Do not use if any part of this appliance is damaged in any way.
• To prevent against the risk of electric shock, do not submerge any part of this appliance in water,
unless advised in this manual.
• This appliance should only be used on a at surface.
IMPORTANT SAFEGUARDS AND PRECAUTIONS
• To prevent possible hearing damage, do not listen at high volume levels for long periods.
• This appliance is not intended for use by persons with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning
use of the appliance, by a person responsible for their safety.
• Children should be supervised to ensure they do not play with this appliance.
• Cleaning and user maintenance shall not be made by children.
• Never let children push anything into holes or slots in the cabinet or casing – this could result in an
electric shock.
• Before plugging into mains socket, check whether supply line voltage and current rating are in
compliance with the rated electrical parameters shown on the rating label.
• To prevent damage to the mains cord, do not let it pass over sharp corners, edges or hot surfaces.
• If the supply cord is damaged, do not use. Check before each use!
• The supply cord cannot be replaced. If the cord is damaged the appliance should be scrapped.
• Always unplug when not in use.
• Do not use rechargeable batteries in this appliance.
• Do not mix old and new batteries, different types of batteries, alkaline or rechargeable batteries with
different capacity together – they may leak.
• Always turn the unit off, when not in use. Leaving it on will shorten the life of the batteries.
• If you plan not to use the unit for a length of time, remove the batteries. Old batteries can leak and cause
corrosion, damaging the unit.
• Should you nd the sensitivity or quality of sound deteriorating, replace all old batteries with new ones
as soon as possible.
• The use of long life alkaline batteries is recommended.
• DON’T throw the battery in re or dispose of in household waste. Consult your local authority in the
correct way to dispose of unwanted batteries.
• DON’T short-circuit the supply terminals of the batteries.
• Always check the correct polarity when inserting batteries. Incorrect polarity can damage this unit.

4 5
LOCATION OF CONTROLS OPERATION
LISTEN TO THE RADIO
Slide the Function Switch to ON position and rotate the Volume Control to turn on the radio. Adjust the
Volume Control to the desired listening level and select your favorite station with the Tuning Control and
Band Selector. To turn off the radio, slide the Function Switch to OFF position. Loose the cable antenna and
adjust the direction to get the best reception if the radio could not get a clear station.
TIME SETTING
Press and hold the Time Set Button and then press the Hour or Minute Button for hour and minute adjustment
of the time. Please make sure setting time is AM or PM has indication (A dot will light in the left upper corner
indicating that the time is the PM range if your unit is 12 hour version type.)
WAKE TO MUSIC
Press and hold the Alarm Set Button and then press Hour or Minute button to set the desired wake up time.
Release the Alarm Set Button to show the current time. Repeat the steps of “LISTEN TO RADIO” to your
desired station and listening level. Slide the Function Switch to AUTO position. The Alarm Indicator will on.
The radio will play your desired station and listening level automatically at the preset alarm time. Push the
Function Switch to OFF position to turn off the radio alarm.
WAKE TO BUZZER
Same operation as “WAKE TO MUSIC” to adjust the alarm time, and then rotate the Volume Control
clockwise until a clicking sound is heard. Your will be awakened by the buzzer alarm. Push the Function
Switch to OFF position to turn off the buzzer alarm.
SNOOZE FUNCTION
When you want a few extra minutes of sleep after the alarm wakes you, press the Snooze Button, the music
or buzzer alarm will be off and turn on again in approximately 9 minute. Push the Function Switch to OFF to
turn off the snooze function.
SLEEP TO MUSIC
1. Slide the Function Switch to the position either OFF or AUTO. Press the Sleep Button once and you
will have 59 minutes listen to the radio (the default setting).
2. If you want to increase or reduce the automatic shut off time, hold down the Sleep button and press Hour
or Minute to adjust as required. The maximum sleep time is 1 hour and 59 minutes.
TO GO TO SLEEP AND WAKE TO MUSIC
Repeat the steps of “WAKE TO MUSIC”, press Sleep Button to set for desired time of radio playing before
sleep. The radio will stop as your setting of sleep time automatically and will play again at your preset wake
up time.
BATTERY BACKUP
Insert a 9 Volt battery in the battery compartment. Should there be a power failure, the clock will continue to
function. Your will not see this however because the battery does not illuminate the clock display. When the
electric power turns on again, the display will indicate the correct time. For clarity alarm clock does not work
on battery. Replace the battery once a year.
1. Sleep Button
2. Minute Button
3. Hour Button
4. Time Set Button
5. Alarm Set Button
6. Speaker
7. LED Display
8. Tuning Scale
9. Volume Control
10. Function Switch (ON/OFF/AUTO)
11. Snooze Button
12. Tuning Control
13. AM/FM Band Selector
14. FM Cable Antenna
15. Power Cord
16. Battery Compartment
612345
1415
9
16
12
13
10
11
78

6 7
WEEE/ENVIRONMENTAL PROTECTION
Disposal of Electrical and Electronic Equipment
Do not dispose of this product with household waste. For the proper treatment, recovery and
recycling please take this product to the appropriate waste collection point. If you are unsure
where this may be, please contact your local authority. Improper disposal may be harmful to
the environment.
3A FUSE
(L) LIVE
(N) NEUTRAL
UK PLUG REWIRING
This appliance must be protected by a 3 Amp fuse in a 13 Amp type (BS1363) plug.
Should you need to replace the fuse, use only an ASTA approved BS1362 fuse.
Your appliance operates on 220-240V~50Hz AC Mains and comes tted with a 3-pin BSI Approved plug, so
that it is ready for use by simply plugging into AC Mains. Should you need to change or ret a plug, proceed
as follows: -
IMPORTANT:
The wires in the mains lead are coloured in accordance with the following code:
BLUE: NEUTRAL (N)
BROWN: LIVE (L)
As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings
identifying the terminals in your plug, proceed as follows:
The BLUE wire must be connected to the terminal which is marked with the letter “N” or coloured BLACK.
The BROWN wire must be connected to the terminal which is marked with the letter “L” or coloured RED.
DO NOT CONNECT EITHER WIRE TO THE EARTH TERMINAL OF A 3-PIN PLUG
Always ensure that the Mains Cord is located into the Plug through the Cord Guard or Cable Clamp, and that
the Cord Guard screws are tightened to clamp the Cord (outer sheath and inner coloured wires) in position
in the Plug. Make sure the Plug top is also tted securely.
The supply cord cannot be replaced. If the supply cord is damaged, the appliance should be scrapped.
MAINTENANCE:
This appliance has been designed to operate over a long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper care and regular cleaning.
CLEANING:
The exterior surface of the appliance should be wiped with a clean dry cloth only.
DO NOT USE ABRASIVE CLEANERS, SOLVENTS OR POLISH ON ANY PART OF THIS APPLIANCE.
CLEANING AND CARE

call: 08454 81 8808
email: [email protected]
web: www.lloytronhelpdesk.com
If you have any queries about this product, there are three ways to contact our customer service department:
To nd more details on a wide range of Lloytron products please visit our website at www.lloytron.com
Lloytron plc, Laltex House, Leigh Commerce Park, Greenfold Way, Leigh, Lancashire, WN7 3XH. England, U.K
CUSTOMER SERVICES
2011/65/EC
