LMS LMS080 Manual

LIGHT MOUNTING SYSTEMS AUSTRALIA – (LMS) UNIT 1, 33 MUSTANG DRIVE, RUTHERFORD NSW 2320
INSTRUCTIONS – LMS080 PH: 02 4932 9000 FX: 02 4932 9009 EM: [e-mail]
INSTALLATION, OPERATION and MAINTENANCE INSTRUCTIONS FOR WINCH TRACK SYSTEM
PART NO: LMS080
CAUTION: If working at heights always ensure area below is clear of personnel and carry out all site safety requirements before
commencing installation.
Note: Light Mounting Systems Australia accepts no responsibility or liability if modifications are made to the equipment originally supplied or if
supplied equipment is used in conjunction with materials or equipment that have not been tested as part of Light Mounting Systems Australia’s
engineering & certification processes for the equipment supplied. he adequacy of the handrail, mounting points and or support structure
should be verified by an approved site engineer. Light Mounting Systems Australia will accept no responsibility for failure due to the inadequacy
of the handrail, mounting points and or support structure to which Light Mounting Systems Australia equipment is mounted.
INSTALLATION:
Track system consists of nine main parts
1. Head track Section
2. Trolley
3. Hand inch Track Section
4. Track Joiner
5. Cable Cover
6. Locking Lever Arm
7. Stopper
8. Equipment Mounting Bracket
9. Tube Bracket
Before installation ensure surface that track is to be mounted to is flat and there are no obstructions to hinder trolley when
raising or lowering
It is recommended that installation start with hand winch track section (3). For ease of operation when installed section (3) hand
winch should be at approximately 1200mm from ground level. Use a minimum of four M10 bolts through mounting straps to
mount section (3).
hen hand winch track section (3) has been installed to mounting surface slide track joiner (4) onto top of this section until it
stops. (Note: If installing an extra track, install extra track into track joiner and fasten to surface using a minimum of four M10
bolts through mounting straps. When extra track section has been installed to mounting surface slide 2
nd
track joiner (4) onto top
of the extra track section until it stops)
Attach Locking Lever Arm Cable to Locking Lever Arm (6) of the head track section (1)
with D Shackle supplied.

LIGHT MOUNTING SYSTEMS AUSTRALIA – (LMS) UNIT 1, 33 MUSTANG DRIVE, RUTHERFORD NSW 2320
INSTRUCTIONS – LMS080 PH: 02 4932 9000 FX: 02 4932 9009 EM: [e-mail]
Note: When installing the Head rack Section the Locking Lever Arm Cable that is
attached to the Locking Lever Arm of the Head rack Section needs to be run through the
inside of the winch track section (3) so it ends up just above the hand winch assembly.
Install head track section (1) which includes installed trolley (2) onto track joiner (4) of
winch track section (3), and fasten to surface using a minimum of four M10 bolts
through mounting straps.
To attach winch cable to trolley unwind aproximately half of the cable on the winch.
Remove small plate above nylon pulley wheel on head track section (1), run winch cable up through track section (3) & head
section (1) and over pulley and down to trolley (2). Attach winch cable to welded D ring at top of trolley (2) with D shackle
supplied & replace previously removed plate above nylon pulley wheel.
ind excess winch cable back onto winch neatly until weight of trolley places tension on winch rope. At this point the Trolley
should be sitting on the Locking Lever Arm.
If equipment mounting bracket (8) has not been installed onto trolley, attach with the four hex head bolts centrally located on
the trolley.
DO NOT ATTEMPT TO ADJUST FOUR HEX HEAD SCREWS ON OUTER CORNERS OF THE TROLLE
Attach power cable (it is recommended to use flexible cable) onto trolley by wrapping cable around tube bracket (9) on bottom
of trolley (2). Pass cable up behind tube bracket wrapping from right to left around tube bracket a minimum of three turns and
then pass cable through cable gland (supplied by others) in equipment mounting bracket (8), tighten cable gland.
hen cable installation is complete install peaked Cable Cover (5) onto track section above winch and slide down onto stoppers
that are welded into the sides of the track.

LIGHT MOUNTING SYSTEMS AUSTRALIA – (LMS) UNIT 1, 33 MUSTANG DRIVE, RUTHERFORD NSW 2320
INSTRUCTIONS – LMS080 PH: 02 4932 9000 FX: 02 4932 9009 EM: [e-mail]
OPERATION:
CAUTION: - ALWAYS STAND TO THE SIDE OF OVERHEAD EQUIPMENT WHEN RAISING OR LOWERING
Lo ering trolley and Equipment
Remove cable cover (5) and remove cable ties if installed.
Rotate winch handle clockwise to raise trolley off locking lever arm (6).
Pull down on Locking Lever Arm cable adjacent to winch. This will pull Locking Lever Arm arm (6) back into track section (1)
allowing head trolley to lower. Rotate winch handle anti-clockwise and lower trolley past retained locking lever arm. Release
Locking Lever Arm cable and continue to turn winch handle anti-clockwise to lower trolley and equipment down for
maintenance.
Raising Trolley and Equipment
ith trolley in lowered position, turn handle clockwise to wind cable onto winch and raise trolley and equipment
Raise trolley until it passes Locking Lever Arm (6) which will spring back to normal position after trolley passes.
DO NOT keep winding winch with trolley against stopper (7) as this will put undue stress on winch cable and may cause damage.
Turn winch handle anti-clockwise to lower trolley onto Locking Lever Arm (6) so trolley and equipment is not supported on
winch cable. Leave just enough tension on winch cable to keep it tight.
If there is a small amount of slack cable after lowering trolley onto locking arm hand tension cable and install cable ties through
four holes in winch track section just above winch to keep cable flat on winch track section.
Install cable cover (5) onto track (3).
MAINTENANCE:
It is recommended that the following points be inspected or checked for operation whenever system is used.
1. Operation and condition of winch and cable
2. Operation of locking lever arm
3. Attachment point of cable to trolley
4. Condition of power cable
5. Condition of track sections

1
2
3
5
4
6
7
8
9
4
SHOWN WITH EXTRA TRACK SECTION
LMS080 - WINCH TRACK SYSTEM
1. Head Track Section
2. Trolley
3. Hand Winch Track Section
4. Track Joiner
5. Cable Cover
6. Locking Lever Arm
7. Stopper
8. Equipment Mounting Bracket
9. Tube Bracket
