OPERATING WINCH. Never put your ¿nger through the hook. If your ¿nger
should become trapped in the hook, you could lose your ¿nger. ALWAYS

. Be sure that the winch mounting location does not signi¿cantly reduce ground
4

the baseplate to mount the unit to a Àat surface.
.
SpeciÀcations 12 V and 24 V S5500, S5500
Working Load: 5,500 lbs (2495 kg)
Motor: 3.6hp(2.7kW)
Gear Ratio: 185:1
Freespool Clutch: Lever Action
DrumBarrel Diameter: 2.5” (63.5 mm)
DrumLength: 4.87” (123.7 mm)
Wire Rope: 9/32” X 60’ (7.1 mmX18.3 m)
Synthetic Rope: ¼” X 60’ (6.4 mmX18.3 m)
Installed Weight with Wire Rope: 51 lbs. (23.1 kg)
Installed Weight with Synthetic Rope: 42 lbs. (19.0 kg)
Switching Method: Sealed Handheld Rocker Switch
Fairlead: Roller Hawse™
Working Load: 7,500 (3402 kg)
Motor: 3.6 hp (2.7 kW)
Gear Ratio: 249:1
Freespool Clutch: Lever Action
DrumBarrel Diameter: 2.5” (63.5 mm)
DrumLength: 4.87” (123.7 mm)
Wire Rope: 5/16” X 55’ (7.9 mmX 16.8 m)
Synthetic Rope: 5/16” X 55’ (7.9 mmX 16.8 m)
Installed Weight with Wire Rope: 55 lb (24.9 kg)
Installed Weight with Synthetic Rope: 46 lbs (20.9 k g)
Switching Method: Sealed Handheld Rocker Switch
Fairlead: Roller Hawse™
SpeciÀcations 12 V and 24 V S7500, S7500 SR
5
Using the supplied M10
mounting bolts, washers,
and nuts, tighten the
mounting and
Roller-Hawse fairlead
hardware
to 32 ft-lb (43 N-m).

Using the supplied M10
mounting bolts, washers,
and nuts, tighten the
mounting and
Roller-Hawse fairlead
hardware
to 32 ft-lb (43 N-m).

Automotive batteries contain gasses which are Àammable and
-
+

If the motor stalls, do not continue to apply power. If the end of the
motor becomes hot
Install through
the holes & with
set screw or plug.
less than ¿ve (5)
To replace your rope, ¿rst completely remove the old rope. For

SWINCH, partsdiagram

13
REPLACEMENT PARTS LIST

Figure 15.
“If a problem arises please contact your nearest Superwinch®dealer or repair shop.”
14
TROUBLESHOOTING CHART
5

Designed, Engineered, and Tested by Superwinch®
Superwinch, LLC. Speci¿cations subject to change at any time. All photographs shown are copyrighted material. Repro
