Loewe Reference lD 55 User manual

Platzhalter
TV
Reference
Reference lD 55
Reference lD 46
Reference lD 40
User guide
35319022

Reference ID 40-55
User guide
2
Imprint
Loewe Technologies GmbH
Industriestraße 11
D-96317 Kronach
www.loewe.tv
Printed in Germany
Editorial date 11/16-4.0 TB
© Loewe Technologies GmbH,
Kronach
ID: 2.3.24
All rights including translation, technical modifications and errors
reserved.
n
Imprint

Reference ID 40-55
User guide
3

Table of contents
Imprint...........................................................................................2
Welcome........................................................................................5
Scope of delivery .......................................................................................... 5
About this user guide................................................................................... 5
For your safety..............................................................................6
Basic Functions ............................................................................8
Remote control.............................................................................9
Operating controls on the TV set............................................. 10
Connections rear side of the device .........................................11
Preparing the TV set .................................................................. 12
Installing the TV set.....................................................................................12
Set covers.....................................................................................................12
Connecting the TV set................................................................................12
Bundling the cables.....................................................................................13
Preparing the remote control unit.............................................................13
Switching the TV set ON/OFF ...................................................................14
Technical information .................................................................................14
General information on menu operation................................. 15
Info display....................................................................................................18
Operation without remote control.............................................................18
LED backlighting ........................................................................ 19
Initial installation...................................................................... 20
Initial installation wizard.............................................................................20
TV set as a monitor .....................................................................................31
Home view...................................................................................32
Home - Favourites ......................................................................................33
TV................................................................................................ 34
Setting the volume .....................................................................................34
Select station ..............................................................................................34
Status display..............................................................................................36
Function list ................................................................................................. 37
AV list ............................................................................................................ 37
Electronic Programme Guide – EPG........................................................38
Teletext..........................................................................................................41
Rotate TV.....................................................................................................42
HbbTV / MediaText....................................................................................43
Picture in Picture (PIP)...............................................................................44
Digital Recorder ..........................................................................................45
Digital-Recorder – Overview of functions ............................................45
TV viewing with time shift.......................................................................46
Archive recording..................................................................................... 47
DR+ archive ..............................................................................................49
DR+Streaming ........................................................................................53
Follow me function ..................................................................................53
Media+........................................................................................ 54
General information on media reproduction..........................................54
Accessing your media................................................................................54
Video............................................................................................55
Video playback............................................................................................56
Audio/Radio .............................................................................. 63
Audio playback ...........................................................................................64
Radio mode (DVB radio) ...........................................................................67
Radio mode (Internet radio) .....................................................................68
Photo .......................................................................................... 69
Photo display...............................................................................................70
Web .............................................................................................. 71
MediaNet ......................................................................................................71
Browser........................................................................................................ 73
Extras...........................................................................................74
Timer............................................................................................................ 74
Conditional Access module (CA module)...............................................79
DVB Common Interface Standard (CI)...................................................80
DR+ Streaming ...........................................................................................80
Special functions .........................................................................................81
Integrated features ......................................................................................81
Picture ..........................................................................................................83
Sound........................................................................................................... 87
Stations........................................................................................................88
Automatic scan TV+Radio.....................................................................89
Manual Scan TV / Radio.........................................................................90
Station lists TV / Radio ...........................................................................92
Compose / edit Personal list..................................................................93
Update station list automatically...........................................................94
Control .........................................................................................................95
Language ..................................................................................................96
EPG............................................................................................................96
Parental lock ............................................................................................. 97
Energy efficiency......................................................................................98
Quick start mode.....................................................................................98
Software update.......................................................................................99
On-screen displays................................................................................ 104
Time and date ........................................................................................104
DVB settings...........................................................................................105
PIP............................................................................................................105
DR+.........................................................................................................106
Standard Teletext................................................................................... 107
HbbTV.....................................................................................................108
CA module(s).........................................................................................109
LED light module.....................................................................................110
Rotate TV ..................................................................................................111
Record......................................................................................................112
WEB key function....................................................................................112
Hard disks................................................................................................113
Network settings.....................................................................................114
Multimedia settings................................................................................ 117
Renderer .................................................................................................. 117

Reference ID 40-55
User guide
4

Table of contents
System settings (continued) .................................................. 118
Connections...............................................................................................118
Sound components ...............................................................................119
Antenna DVB.......................................................................................... 123
AV connection settings ......................................................................... 123
Digital Link............................................................................................... 124
Gaming mode ........................................................................................ 124
Assign digital audio input...................................................................... 125
External devices .......................................................................126
Devices to the HDMI connections.......................................................... 126
Digital Link HD........................................................................................... 127
Devices on AV............................................................................................ 128
Devices on AVS......................................................................................... 129
Connecting the Loewe speaker system.................................................131
Connecting active loudspeakers............................................................ 132
Connecting the HiFi/AV amplifier........................................................... 132
Audio playback from external devices................................................... 133
Serial interface RS-232C (RJ12)............................................................. 133
Operating Loewe units............................................................................. 134
Teaching the remote control ..................................................135
Loewe Apps............................................................................................... 136
Loewe Apps............................................................................... 137
Troubleshooting .......................................................................139
Technical Data .......................................................................... 141
Technical data .......................................................................... 141
Function of the connections ................................................................... 142
Media.......................................................................................................... 143
Signals via AVS (PC IN) / HDMI.............................................................. 144
Signal input groups .................................................................................. 144
Accessories...............................................................................145
Upgrade kits / conversion kits / cables ................................................ 145
Equipment variants.................................................................................. 146
Mounting options ......................................................................................147
Environment .............................................................................148
Glossary ....................................................................................149
EC Declaration of Conformity.................................................153
Index .......................................................................................... 155
Service.......................................................................................158
Code page .................................................................................159
Notes ......................................................................................... 161

Reference ID 40-55
User guide
5
Scope of delivery
• LCD TV set
• Mains cable
• Antenna cable
• Remote control Assist with two batteries
• Quick guide
About this user guide
For best results regarding safety and the longevity of the set, we
recommend you read the chapter For your safety before switching
it on for the first time.
The glossary gives explanations of certain terms used in the TV set
and the user guide.
Paragraphs which begin with the symbol indicate important instruc-
tions, tips or conditions for the following settings.
Terms which you will find in the menus or printed on the remote control
or TV set are written in bold type.
The necessary control elements are shown in the descriptions to the
left of the text containing the instructions for action.
In addition to the remote control, a PC keyboard can be connected to
one of the USB ports on your TV and then used to control your TV set.
In the user guide, this symbol indicates places in which
the use of a keyboard is particularly advantageous.
Depending on the connected accessory equipment the menus in the
TV set can differ from those described here.
All the station names, programme contents, the illustrated photos,
titles, albums and album covers in this user guide are examples.
The user guide instructions for your TV set is updated at irregular
intervals. We recommend checking now and then, especially after a
software update.
General information on menu operation of
the TV set
For further information on the user interface and the general operation
of your TV set see chapter General information on menu operation.
Interactive data services
In some countries the stations also broadcast interactive data services
with their programmes, leading to the functions of individual buttons
not being available or only so to a limited extent. You can find out more
about this in chapter TV, section HbbTV / MediaText.

Welcome
Thank you,
for choosing a Loewe TV set!
At Loewe we combine the highest requirements regarding technol-
ogy, design and ease of use. This applies equally for TV, video and
accessories.
In addition to sleek design and a varied combination of colour and
mounting choices, your Loewe TV set offers a host of technological
options.
Loewe Image+
Image+ and state-of-the-art full HD LCD displays with LED backlit TV
technology guarantee the best image quality and high contrast values
and all this at lowest possible energy consumption.
Loewe Digital+
The integrated triple tuner for DVB-T/C/S enables the reception of
standard as well as high-definition contents and thanks to the CI Plus
interface even from Pay TV.
Loewe Sound+
Audio competence on the highest level - this is for what Loewe is unique:
an integrated multichannel decoder provides 5.1 Home Entertainment
of outstanding quality without any external devices.
Loewe DR+
Due to Loewe DR+, recording of TV transmissions on the integrated
hard disk by simply pressing a key or halting the current transmission
are no problem. Additionally, DR+ Streaming enables the retrieval of
films on further Loewe devices.
Loewe Assist+
The intuitive Loewe user interface Assist Media offers a simple access
to all device functions; by means of the HOME key on the remote con-
trol you can access all your favourite content as well as all multimedia
functions of your TV set.
Loewe Media+
The Loewe Miltimedia functions offer you a multitude of options; you
have access to your photos, videos and music in your home network
or on the USB stick.
Loewe MediaNet and MediaText help you to access numerous world-
wide web-applications and contents from HbbTV services.
Loewe Connectivity+
Network your TV set by means of numerous interconnection options.
Be it HDMI, USB, CI Plus or LAN/WLAN, discover the world of the
Loewe networking possibilities.

Reference ID 40-55
User guide
6
For your safety, and to avoid unnecessary damage to your unit,
please read and follow the safety advice below:
Use for the intended purpose and ambient conditions
This TV set is intended exclusively for receiving and playing visual and
audio signals. It must not be used in rooms with a high level of humid-
ity (e.g. bathroom, sauna) or a high dust concentration (e.g. work-
shops). The manufacturer‘s warranty is only valid for use in the
specified permissible environment.
If the unit is used outdoors, make sure that it is protected from moisture
(rain, dripping water and splashing water or dew). High humidity and
dust concentrations lead to leakage currents in the device. This can
result in a shock hazard by touching it or even fire.
If you have moved the unit out of
the cold into a warm environment,
leave it switched off for about an
hour to avoid the formation of
condensation.
Do not place objects containing
liquids on top of the unit. Protect
the appliance against dripping and
splashing water.
Candles or naked flames must
be kept away from the TV set at all
times to prevent it from catching
fire.
Never place the TV set in a location
where it is exposed to vibrations.
This may lead to damage.
Transporting
Move the device in vertical position only. Grasp the device on the
upper and lower edges of the housing.
The set is delivered ex factory without a mounting option. If the set
has to be put down during packing/unpacking, place the TV set with
its entire front surface lying flat on soft material such as a blanket or
the fleece from the packing material. Use a blanket or the fleece from
the packing material as an underlay.
The LCD screen is made of glass or plastic and can break if not handled
properly.
Always wear rubber gloves to carry the TV set if the LCD screen is
damaged and liquid crystal might be leaking out. In the case of skin
contact immediately rinse thoroughly with water.
Power supply
Incorrect voltages can damage the unit. This device may only be con-
nected to a power supply with the voltage and frequency indicated on the
type plate using the supplied mains cable. The mains plug of the TV set
must be easily accessible so that the device can be disconnected from
the mains at any time. When unplugging the unit from the mains, pull at
the connector body and not at the cable. The cables in the mains plug
could otherwise be damaged and could cause a short-circuit when
plugged in again.
Lay the mains cable so that it cannot be damaged. Do not step on
the mains cable. The mains cable may not be kinked or laid over sharp
edges nor be exposed to chemicals; the latter also applies to the unit
as a whole. A mains cable with damaged insulation can cause electric
shocks and poses a fire risk.
Air circulation and high temperatures
The vent slots on the rear panel of the set must always be kept un-
obstructed. Please do not place newspapers or cloths on/over the TV
set.
Ensure that there is at least
10 cm free space on the sides
and above the set for air cir-
culation, if the set is placed in
a cabinet or on a shelf.
Like any electronic device,
your TV set requires air for
cooling. Obstruction of the
air circulation can cause fires.
Prevent metal items, nee-
dles, paper clips, liquids, wax,
or similar items, from getting
into the interior of the device through the vent slots in the rear panel.
Such objects can cause short circuits in the set, which could pos-
sibly cause a fire.
If something should get into the interior of the set then immedi-
ately unplug the mains plug of the device and contact the field service
for more information.
About the LCD screen
The TV set with LCD screen you have purchased satisfies the most
rigorous quality requirements and has been inspected with respect
to pixel errors. Despite of thorough care when manufacturing the
display, it cannot be 100% guaranteed that no subpixel defects will
occur due to technical reasons. Please understand that these types
of effects, as long as they are within the limits specified in the standard,
cannot be considered as a device defect in terms of the guarantee.
Avoid displaying still images for long periods of time. It is possible that
a copy of the image may remain visible.
TV sets with 3D function
Read the following safety instructions before using the 3D function
of your TV set.
Please use the Loewe 3D TV sets only with the Loewe 3D glasses which
can be purchased as an accessory from your Loewe dealer.
People with a visual disorder may not be able to perceive 3D effects
or may only be able to perceive them to a limited extent. People who
are sensitive to flickering images (e.g. those with epilepsy) should only
use the 3D function after having consulted their doctor.
It might take some time for you to get used to the 3D glasses and
before you can perceive the 3D effects properly.
Stop using the 3D function immediately if you experience any feelings
of nausea, dizziness or malaise when viewing 3D content.
Supervise children whilst they are viewing 3D content, as they can be
particularly sensitive to it.
Allow more time for a break after having watched 3D movies, so that
you are able to relax. Failure to do so could result in headaches, fatigue,
dizziness or malaise.
Position yourself comfortably in front of the 3D TV set and ensure that
you are seated firmly. By doing this, you will avoid any injuries that may
occur due to reacting to extreme 3D content.
Switch off any artificial light sources (e.g., energy saving lamp) between
the TV set and the 3D glasses. These could impair the infrared recep-
tion or the TV picture may flicker as a result.
10 cm 10 cm 10 cm

For your safety

Reference ID 40-55
User guide
7

For your safety
Set-up
Loewe flatscreen TV sets are specified for Loewe accessories. The TV
set is suitable for mounting in many different ways. Note the assembly
instructions regarding the different possible mounting options.
When using accessories from other manufacturers take care that the
TV set can be easily inclined or rotated on the respective mounting
option.
For mounting options from other manufacturers with motor drive,
make sure that the TV set cannot be rotated manually. The use of
mounting options from other manufacturers with locks in certain
positions is generally discouraged.
When rotating the TV set it is essential to ensure
that the pressure exerted on the device frame is
not too large. Especially in case of large-format
displays there is a risk to damage the screen.
Before setting up the device, please check that
the final location is suitable to bear the load of
the device in terms of surface (sensitivity to
pressure) and stability (statics).
This is particularly the case for the high-gloss painted surfaces and
surfaces that are made from real wood / real wood veneer or plastic
surfaces.
Place the TV set with the floor stand only on a level, sturdy, horizon-
tal base. Particularly ensure that the set does not protrude to the
front when placed in or on pieces of furniture.
Place the TV set in a normal position for use. TV set may only be used
in an upright horizontal position. It may not be tilted by more than 10
degrees. The TV set must never be operated in portrait position, lying
flat or hanging overhead from the ceiling.
Set up the device where it is not exposed to direct insolation and
where it is not exposed to additional heating by radiators
.
Supervision
Do not let children operate the TV set unsupervised and do not let
them loiter and play close to the set. The set could tip over, be pushed
off or pulled down from the stand surface and injure someone.
Do not allow the switched-on TV set to run unattended.
Volume
Loud music can lead to ear damage. Avoid extreme volume espe-
cially over long periods and when using headphones.
Thunder storms
Pull out the mains plug and all connected antenna cables from the
TV set in a thunderstorm. Overvoltage caused by lightning strokes
can damage the set via the antenna system, as well as via the mains.
The mains plug and all connected antenna cables should also be pulled
out during long periods of absence.
±10°
D
Automatic shutdown
If the TV is not operated for 4 hours (adjustment of volume, pro-
gramme change, etc.) the TV will automatically switch to stand-by
mode to save energy. A prompt to terminate this shutdown process
appears one minute before expiry of the 4 hours.
The automatic shutdown is generally active for the TV mode as soon as
the energy efficiency mode Home Mode is enabled for at least one of
the six signal input groups (see chapter Technical Data, section Signal
input groups). This also applies if another energy efficiency mode is
selected during initial installation, but one of the signal input groups is
subsequently set to Home Mode.
Automatic shutdown does not occur when using the radio without
screen display (screen off).
Cleaning and care
Switch off the TV set with the main switch prior to cleaning.
Clean the TV set, the screen, and the remote control unit with a soft,
moist, clean and colour-neutral cloth only, without any aggressive
or scouring cleaning agents.
For TV sets with textile speaker grill:
Vacuum the surface regularly with a soft brush attachment.
In case of dirt or stains:
Moisten a soft, colour-neutral cloth with detergent or normal stain
remover and gently rub away the stain. You can also treat the mark/
stain directly with normal dry stain remover spray (vacuum up pow-
der).
Do not moisten the fabric cover directly with detergent or stain re-
mover (risk of encrustation). Do not use any solvents to clean the
fabric.
Follow the manufacturer‘s instructions when using stain removers.
There is an increased risk of encrustation when cleaning speaker
grills having nicotine deposits.
Repairs and accessories
Never remove the back of the TV set yourself. Have your TV set re-
paired or serviced by authorised television technicians only.
Only use original accessories such as Loewe stands, if possible (see
chapter Accessories).

Reference ID 40-55
User guide
8

Basic Functions
(1
The assignment of these keys can be changed (see chapter External devices,section Operating Loewe units).
(2
The assignment of these keys can be changed (see chapter System settings,section Control – Web key function).
On/Off of the television set
Switching the TV set ON / switching it OFF in Standby
mode (Mains switch must be switched ON)
When TV set is switched on:
Press key long: Switch TV set and all CEC-capable
devices connected to the HDMI interfaces OFF to
Standby mode (System Standby).
General navigation
Navigation on the user interface, select
objects
Select station
OK short: Call station list. Or:
OK long: Call expanded station list.
 Mark station,
OK switch over to station.
Or:
P+/P– Next/previous channel
Or:
Select station with numerical keys
Sound
V+/V– Increase/reduce volume
Sound on/off
Colour key function during TV operation
Red key: Start HbbTV or value-added network
service
Yellow key: Last selected station
Blue key: Call function list
(selection of language/sound,
subtitles or channel/video track)
Function of the coloured keys in audio mode
Green key: Switch screen ON/OFF
Yellow key: Lastselectedstationin DVBradiomode
Key functions
TV operation
Call radio mode (standard assignment) (1
Call Home view,
Select the operating mode or the function
Pressing briefly, during screen fade-in function: Info
display,
info text appropriate to the content that can assist you
further, should you have any questions about your TV
device;
Pressing briefly without on-screen display: access
status display.
With status display open and repeatedly pressing the
key call / close the detailed information on the broad-
cast
Pressing long: show key explanation
Pressing briefly: Open the DR+ archive
Pressing long: Call up the timer list
Add current object to Home favourites
Call MediaNet (standard assignment) (2
On/Off EPG (Electronic Programme Guide)
On/Off PIP (picture in picture)
Turn Teletext/MediaText on/off
Pressing briefly: Call function list for the active
operating mode
Pressing long: call System settings
Pressing briefly: step / level back
Pressing long: close all displays

Reference ID 40-55
User guide
9

Remote control
(1
The assignment of these keys can be changed (see chapter External devices,section Operating Loewe units).
(2
The assignment of these keys can be changed (see chapter System settings,section Control – Web key function).
(3
Depending on the corresponding settings.
1
Sound mute/on
2
LED display for currently operated device
3
Switch to TV mode
4
Reassign remote control to SetTop-Box (PACE DS440N)(1
5
DR+ archive on/off
6
Define active object as favourite
7
Electronic Programme Guide on/off
8
Teletext/MediaText(3 on/off
9
Call function list
10
V+/V- Increase/reduce volume
11
Call station list / expanded station list
In the menu: confirm/call up
12
Green coloured key: screen on/off
13
Red coloured key: call preferred value-added network service (3
14
Jump / wind
15
Direct recording (One Touch Recording)
16
Start / interrupt timeshift television
17
Finish timeshift
18
Jump / wind
19
Start / continue timeshift television
20
Blue coloured key: call station function list with subfunctions
21
Yellow coloured key: switching to previously received station
22
In menu / in lists: selecting/setting
 with Motor Unit connected: Rotate TV set
23
P+/P– Select stations up/down
24
Press briefly: back to previous window (step back)
Press long: close all displays
25
Status display on/off
In menu: context-relevant Info on/ off
26
PIP (picture in picture) on/off
27
Open/close Home view
28
AV list
29
Select station directly
In the menu: Enter numbers or letters
30
Call MediaNet (2
31
Reassign remote control to BluTech Vision 3D (1
32
Switch to radio mode(1
33
Switch ON/OFF to standby mode
System standby
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
32
18
19
20
21
22
23
24
25
26
27
28
29
30
31
33
17
The key assignment displayed here is valid for the main level of the TV set. The key assignment may vary in certain operating modes (see the cor-
responding chapter in this user guide).

Reference ID 40-55
User guide
10
Functions of the operating elements
1Mains switch:
The mains switch is located on the rear side of the set.
Always return the TV set to Standby mode before switching it off
with the main switch.
The TV set will be completely separated from mains only when
you unplug the mains cable.
2 Display:
white: TV set in standby
white, intermittent: TV set starts
green: TV set switched on
red: timer recording active
blue:
TV set in standby and background opera-
tion active (EPG data updating, software
update or DR+ streaming server function)
3 IR receiver:
Infrared receiver for receiving the remote control commands.
4 Infrared transmitter:
When showing 3D content, the 3D glasses Loewe Active
Glasses 3D are controlled via the infrared sensor.
5 On/Off key:
Switching on in standby mode
Switching off to the standby mode
6 Key – :
reduce volume
Direct control on TV set: to the left 
7Key +:
increase volume
Direct control on TV set: to the right 
8 Key MENU:
TV set in standby mode: switch TV set on in TV mode
TV set switched on: call direct control on TV set
Direct control on TV set: up 
9 Key RADIO:
TV set in standby mode: switch TV set on in radio mode
TV set switched on: toggle TV mode and radio mode
Direct control on TV set: down 
10 Key :
For TV sets without LED backlighting: No function.
For TV sets with LED backlighting: dimming / switching on/off
of the LED backlighting.

Operating controls on the TV set
4
1
8 9
10
2
76
3
5
– VOL + MENU RADIO *

Reference ID 40-55
User guide
11
1
AC IN - Mains connection
2
RS-232C - Serial interface
3
CONTROL - Rotating stand control
4
IR LINK - Infrared transmitter connection
5
AUDIO OUT - Audio output (analogue)
6
CENTER IN - Centre audio input (analogue)
7
AV - Mini AV socket (1
8
A NT-TV - Antenna/cable analogue/digital
9
ANT SAT - Satellite antenna (Sat tuner 1)
10
ANT SAT 2 - Satellite antenna (Sat tuner 2)
11
SPDIF OUT - Digital audio output
12
DIGITAL AUDIO LINK - Surround audio outputs (digital)
13
HDMI 1 - HDMI input 1 (with HDMI ARC support)
14
HDMI 2 - HDMI input 2
15
LAN - Network connection
16
USB - USB connection
17
HDMI 3 - HDMI input 3
18
HDMI 4 - HDMI input 4
19
CI COMMON INTERFACE - Common interface 1 (CI slot 1)
20
CI COMMON INTERFACE - Common interface 2 (CI slot 2)
21
- Headphone connection
22
AVS - Mini AV socket (1
23
SPDIF IN - Digital sound input
24
USB - USB connection
25
USB - USB connection

Connections rear side of the device
(1 Adaptor set is available as an accessory (see chapter Accessories).
1 2
11 10
9
12 13 15
4 5
23
3 8
19
20
22
21
18
24
25
6 7
14
17
16

Reference ID 40-55
User guide
12
Installing the TV set
Mounting options
Your Loewe specialist dealer can assist you in finding other mounting
options that correspond to your needs. Use exclusively Loewe mount-
ing options (e.g., wall bracket, floor stand), which you will find in the
chapter Accessories, section Mounting options.
After you have decided on a mounting option, follow the directions
found in the corresponding assembly instructions.
Installation notes
Choose a place for installing your TV set where no bright light or
sunlight shines directly onto the screen. This could cause reflections
which impair the picture.
3 times the screen diagonal can be taken as a guide value for the view-
ing distance (e.g., for a 46-inch set approx. 3.5 m for SD signal). The
viewing distance can be reduced with an HD signal.
Set covers
Covers for rear and side connections
In order to remove the rear side cable cover pull them simply from
the device.
To attach the cable cover, place the lugs of the cover at the correspond-
ing cut-outs in the rear panel.
Press the cover into the cutouts until the lugs snap into the device.
Press only on the exact positions where the lugs are (see figure for the
positions), otherwise the glass rear panel may be damaged.
The side cover of the TV set can also be completely removed. For this,
open it as far as it will go and gently pull on the open cover.
The cover detaches from the holder and gives free access to the
connection area. To replace the cover, simply push it until it latches
back into place.
Connecting the TV set
Connecting to the mains supply
Remove the cover for the connections.
Connect the TV set to a 220-240V mains socket:
First plug the small plug of the power cable into the mains connection
on the back of the TV and then the large mains plug into a mains socket.
Connecting antennas
Cable (analogue) / DVB-C / DVB-T antenna:
Plug the cable of antenna, cable TV system or room antenna into the
ANT TV socket.
If you want to use analogue cables / DVB-C connection and a DVB-T
antenna together, use an external antenna switch (available from
your dealer).
Satellite antenna DVB-S:
Depending on the used satellite system, connect a connecting cable
from the multi-switch or directly from the LNC to the ANT-SAT and
ANT-SAT2 sockets of the TV set respectively.
When connecting the TV set to a single cable community antenna,
connect the ANT-SAT and ANT-SAT2 sockets directly to the appro-
priate SAT antenna socket.
When connecting the TV set to a DiSEqC single cable community
antenna (in accordance with EN 50494), connect the ANT-SAT
socket directly to the appropriate SAT antenna socket.
In case of a DiSEqC one cable communal system you require only
one antenna cable. Further distribution of the signal to the two
reception routes is accomplished by the TV set's satellite tuner.
Ask your dealer in this regard.
R TV
DVB-T DVB-SKabel
analog /
DVB-C

Preparing the TV set

Reference ID 40-55
User guide
13
Connecting the TV set to the Home network
You may link your TV set to the home network by a wired connection
(Ethernet, Powerline) or by a wireless radio connection (WLAN).
Please contact your specialist dealer for more information on Power-
line.
For the network adaptor configuration, see chapter System settings,
section Multimedia / Network– Network settings.
Under no circumstances may the TV set be wired and at the
same time connected by a wireless connection to the same
network, e.g. router. This may cause severe operational faults!
Example for a wired connection
Connect the LAN socket of your TV set to the LAN switch/router of
your home network with a network cable (available from your dealer).
Example for a wireless connection
You can connect the TV set to your home network by a wireless radio
connection via the WLAN antenna inside the set.
Shadow effects of various materials, such as reinforced concrete,
metal surfaces, etc., attenuate the WIFI signal sometimes signifi-
cantly or completely.
.
LAN-Switch / Router
TV-Gerät
Home Server,
z.B. PC
WLAN-Router TV-Gerät
Home Server,
z.B. PC
Bundling the cables
Bundle the connected cables at the middle of the TV set and feed the
cables through the cutout in the cover.
Then attach the cover for the connections (see chapter Preparing
the TV set, section Set covers).
The cables connected to the TV set are held by the cover and fixed
on the TV set.
Depending on the installation version, the cables should be laid accord-
ingly (see installation instructions of the mounting option).
Preparing the remote control unit
Inserting or replacing batteries
Press on the embossed arrow whilst pushing the battery cover down.
Only use leak-proof micro-cells of the LR 03 (AAA) Alkali-Manganese
type. Do not use different types of batteries and old and new batter-
ies together.
The batteries used must not be exposed to excessive heat such as
sunlight, fire or similar!
Pay attention to the correct polarity of + and – when inserting the
batteries.
If the batteries are too weak after longer use, the TV set prompts you
to change the batteries.
Dispose of used batteries in an environmentally friendly way (see
chapter Environment / Legal information).
Push the cover back on from below after having inserted the batteries.
Adjusting the remote control for operating the TV set
Press the TV key.
See in chapter External devices,section Operating
Loewe units how to operate other Loewe appliances
and how to re-programme the remote control keys.
AAA LR03
AAA LR03

Preparing the TV set

Reference ID 40-55
User guide
14
Switching the TV set ON/OFF
Switching TV set to the standby mode
Press the mains switch at the rear side of the set.
The indicator in the Loewe eye on the front side lights up white. The
set is now in standby mode.
Switching the TV set on/off via the local operating panel
To switch the TV set into operating mode or switch it off to standby
mode, press the button on top of the set for about 2 seconds.
Meaning of the colour of the LEDs in the Loewe eye:
white: TV set in standby
white, intermittent: TV set starts
green: TV set switched on
red: Timer recording active
blue: TVsetinstandby and background opera-
tion active (EPG data updating, software
update, DR+ streaming server function)
After switching on the TV set, it takes a few seconds for further
operating commands to be processed (Exception: Quick start
mode, see chapter System settings, section Control – Quick
start mode). Your TV set is ready to operate as soon as the status
indicator in the Loewe eye lights up in green.
Mains
switch
– VOL + MENU RADIO
Switching the TV set on by means of the remote control
Press the on/off key.
Or:
Press the TV key.
The previously watched station will be called.
Or:
Press numerical keys 1-9.
The corresponding station will be called.
After switching on the TV set, it takes a few seconds for further
operating commands to be processed (Exception: Quick start
mode, see chapter System settings, section Control – Quick
start mode). Your TV set is ready to operate as soon as the status
indicator in the Loewe eye lights up in green.
Switching the set off with the remote control (Standby)
Press the on/off key.
Before switching off the set with the mains switch,
we recommend you to switch it to standby mode.
Switching off the TV set and connected additional devices
(System standby)
Press on/off key long:
Switch TV set and all CEC-capable devices connected
to the HDMI interfaces OFF to Standby mode (System
Standby).
Technical information
Switching off the TV set with the mains switch during operation or an
inadvertent disruption to the power supply (e.g. power failure) can
cause damage to the hard disk file system and hence loss of the re-
corded broadcasts. Always return the TV set to Standby mode before
switching it off with the main switch. Never ever disconnect the USB
storage device from the TV set during a copy process.
However, if unexpected problems occur when operating the hard disk,
formatting the hard disk may rectify this. Refer to the instructions in
chapter System settings, section Control – Hard disks. This applies
also to the use of external USB hard disks with the TV set.
Loewe are not liable for the loss of data on the integrated hard disk
of your TV set. To avoid data loss, we recommend copying important
recordings to an external storage medium.

Switching the TV set ON/OFF

Reference ID 40-55
User guide
15

General information on menu operation
General information on menu operation
Some keys of the remote control for operating the TV set you will use
more often than others. The most important keys for navigation will
be explained in general. The numbers in the text refer to the figure
showing the remote control in chapter Remote control.
The arrow keys
22 help you to navigate in the menus and lists of the
TV set and for selecting menu items. They are arranged in the middle
of the remote control in a circle around the OK key
11 . Later in this
quick guide they will be represented as follows:
 Select the desired item.
The OK key
11 is used to confirm a selection, for calling the highlighted
menu item and for opening the station list. In this quick guide, an
instruction for this key looks like the following:
OKconfirm.
Using the numerical keys of your remote control
29 you enter pro-
gramme channels and teletext pages directly. With key 0you open
the AV list. In this user guide, entering numbers with numerical keys
is shown as follows:
Entering programme channel directly.
The numerical keys are also used to enter text (see chapter General
information on menu operation,section Entry of characters by
remote control).
The Home view is the central overview page for all of your TV set‘s
operating modes. You reach Home view with the HOME key
27 .
HOME: Call Home view.
Pressing the BACK key
24 briefly brings you one level up in the wizard.
Pressing the BACK key longer closes all opened fade-ins. An example
for the BACK key in this quick guide:
BACK: Stop text entry and exit entry box.
Prolonged pressure on the INFO key
25 shows a key guide window that
gives you information on the currently most important key functions.
If the function for a key is not available, this will be indicated by an
inserted symbol on the right above.
Structure of the Menu screen
Basically, the structure of the different menu screens is similar, de-
pending on the fact if a wizard, rendering media content or a setup
menu are concerned. The structure is explained by means of three
different screens.
The functions of these menu screens are explained more detailed in
the respective chapters.
Screen structure: Wizard
(A) Title bar with name of the wizard and the current operating step.
(B) Selected items, whose number can be different according to the
operating step.
(C) Bottom line showing the available operating controls. If required,
instructions and information are inserted.
Screen structure: Rendering of media content (example:
Audio player)
(A) Title bar with selected album / subdirectory.
(B) Menu item Back to exit the menu or to go back to the previous
menu item.
(C) Selection of album or title
(D) Time bar
(E) Bottom line with the different symbols for controlling the playback
function.
A
C
B
INITIAL INSTALLATION - Menu language
Proceed withBack with
Which menu language do you want to use for operation?
Deutsch (de) Ελληνικά (el) Svenska (sv)
English (en) Polski (pl) Dansk (da)
Français (fr) Magyar (hu) Português (pt)
Italiano (it) Suomi (fi) Русский (ru)
Español (es) Slovenščina (sl) Norsk (no)
Nederlands (nl) Slovenčina (sk) ₼㠖 (zh)
Čeština (cs) Türkçe (tr)
Chasing Cars Shut Your EyesHands Open
Snow Patrol / Eyes Open
00:00 02:56 04:27
A
C
B
D
E
Back

Reference ID 40-55
User guide
16

General information on menu operation
Screen structure: Setup (example: picture)
(A) Selected function in the Home overview (here: system settings)
(B) Home Menu System settings, with selected menu item Picture.
(C) Menu items Picture focusing on 3D
(D) Help text for the selected menu item Picture > 3D
Navigation: Selection of elements (example: On-screen displays)
Highlighting and thus selecting the symbols/elements or menu items
on the screen can be effected by the arrow keys on the remote control.
So you can see all the time where you are. As soon as there is a bar
above a symbol or text, this is a selected element.
(A) Selectable elements / menu items.
(B) The text in the line where the marker is currently located is white.
(C) Move the selection marking by means of the arrow keys 
to the menu item to be set.
The position of the marking is easy to see by the blue line.
In most cases, the marked menu item will be automatically
adopted. The font colour of the previously active item will change
to grey, that of the newly selected item to white.
In a few menus, to confirm a selected menu item is required by
pressing OK.
ACB D
Picture 3D
Picture ad-
justment
Contrast
Brightness
Colour in-
tensity
Image+
Active
Picture for-
mat
more ...
If your desired display format has not been automatically
selected then you can choose it in the 3D settings menu.
You may display the 3D image in 2D or vice versa.
...... On-screen
displays Display time
Volume display
Automatic menu info
Key explanation
Permanent clock display
Automatic HDMI hint
On-screen displays
If you select "on" here, the informational text belonging to each selected menu item will always appear
simultaneously.
Back
< 7s >
off on
off on
off on
off on
off on
< 7s >
off on
on
off on
off on
on
A
BC
Navigation: Wizards
If the menu item(s) (marked white) is/are already
correctly preset:
Go to next step.
Otherwise:
Mark the menu items to be changed. The
update will be adopted automatically. The
fount colour of the previously active item will
change to grey. If not,
OK confirm the selection.
Go to next step.
Navigation: Element selection in lists using initials
Using the numerical keys of the remote control you can jump into list,
e.g., Internet radio station lists.
If the list is sorted in alphabetical order, you jump to the entered letter.
For example, when pressing the key 7three times you jump to the first
list element starting with letter R.
In case of numerical sorting, you can directly select the stations with
the numerical keys.
Please specify whether you want to search for scrambled stations too.
Note: Scrambled stations can only be received with an integrated CA module and
additional card.
Scrambled stations
Search method
Symbol rate
Accept Logical Channel Number
DVB-S settings (ASTRA1 19,2°E)
Back with Proceed with
no
yes
Network search
Frequency search
22000
no
yes

Reference ID 40-55
User guide
17

General information on menu operation
Entering characters with on-screen keyboard
For certain functions, entering letters or characters is required, e.g., for
Web addresses (URLs) in the browser or for renaming archive entries.
An on-screen keyboard appears for entering text.
highlight character / on-screen button,
OK Adopt character.
In the event of letters with a triangular, additional
letters are displayed when pressing the OK button
longer (2 sec).
For the selection of special characters use the .-/
field.
To conclude the entry:
 Mark Adopt,
OK confirm the selection.
Entry of characters by remote control
Alternatively to the on-screen keyboard you can also enter the desired
characters by means of the remote control (as with the keypad of a
mobile phone).
 Mark text entry field.
Under the 1st letter of the name you will see a line
indicating the current input position.
Input position one character to the right (also for
blanks).
Input position one character to the left.
Input the letters one after another. When using the
remote control, press the numerical keys just as on
a mobile phone keypad (0-9) until the desired symbol
is displayed. The available letters are printed on the
individual numeric buttons.
You find the exact key assignment in the character
table in the right column.
To conclude the entry:
 Mark Adopt,
OK confirm the selection.
q
a
y
1
w
s
x
2
e
d
c
3
r
f
v
4
t
g
b
5
z
h
n
6
u
j
m
7
i
k
.-/
8
o
l
9
P
I
0
ABC
http://www.loewe.de
.com .net . /.dewww.
Enter/change internet address
Back
Adopt Cancel
Delete Cancel AdoptSpace
(2 sec) on a letter with a triangle shows more letters
OK
Table of characters for entering text by means of the remote
control
Key Characters (uppercase - lowercase)
1[space] 1
2A B C 2 Ä Æ Ã Å Ā À Á Ć Ç Č - a b c 2 ä æ ã å ā â à á ć ç č
3D E F 3 Ė Ë Ē Ę Ê È É - d e f 3 ė ë ē ę ê è é
4G H I 4 Ï Ī Į Î Ì Í - g h i 4 ï ī į î î ì í
5J K L 5 - j k l 5
6M N O 6 Ö O E Õ Ō Ô Ò Ó Ø - m n o 6 ń ñ ö o e õ ō ô ò ó ø
7P Q R S 7 ß - p q r s 7 ß
8T U V 8 Ü Ū Û Ù Ú - t u v 8 ü ū û ù ú
9W X Y Z 9 - w x y z 9
0. 0 - / _ : + , ; ? ! = & # % ~ @ $ * ’ ( ) ” § \ { } [ ] < > ´ ` ^ |

Reference ID 40-55
User guide
18

General information on menu operation
Operation without remote control
Local control at the TV set
Changing volume
Increase/reduce volume.
Switching radio on or off or switching to radio
Turn on the radio or switch between TV and Radio.
Calling direct control on TV set
Call direct control on TV set.
RADIO: Scroll down.
MENU: Scroll up.
– Scroll to the left.
+ Scroll to the right, accept settings, confirm.
Close all displays
Press longer.
Explanations of the settings:
Operating
mode
Switch between TV and radio operation.
Station
selection
Call Station selection.
AV selection Select AV interface.
3D Calling 3D settings.
Contrast Set contrast.
The power consumption of the TV set depends
directly on the value set here.
format
Selecting the picture format.
Service The Service menu item is provided for service
purposes by dealers only.
– VOL + MENU RADIO– VOL + MENU RADIO
– VOL +– VOL +
RADIO
RADIO
MENU
MENU
Operating
mode
Station selec-
tion
AV selection
3D
Contrast
Picture for-
mat
Service
MENUMENU
Info display
The info display provides an info text appropriate to the on-screen
display that can assist you further with the operation of your TV set.
An on-screen display is faded in.
The factory setting is that the info display is shown
automatically for each menu item. In this case you can
temporarily hide the info texts with the INFO key.
The automatic info display can be hidden via a menu
setting. Then it can be displayed temporarily by press-
ing the INFO key.
Permanently display or hide the automatic info display
Once you have become familiar with how to operate the TV set, you
can switch off the automatic info display.
HOME: Call Home view.
 Mark System settings,
OK call system settings.
Mark Control,
go to next column.
Mark more ...,
move to next column.
 Mark On-screen displays,
 call on-screen display settings.
 Select Automatic menu info,
select on / off.
OK adopt settings.
... Energy effi-
ciency
Home Mode
Premium
Mode
Shop Mode
The priority here is low energy consumption in home use. In this
case, the TV switches off automatically for the sake of saving
energy, after it has been out of operation for four hours.
...... On-screen
displays Display time
Volume display
Automatic menu info
Key explanation
Permanent clock display
Automatic HDMI hint
On-screen displays
If you select "on" here, the informational text belonging to each selected menu item will always appear
simultaneously.
Back
< 7s >
off on
off on
off on
off on
off on
< 7s >
off on
on
off on
off on
on

Reference ID 40-55
User guide
19

LED backlighting
LED backlighting
The LED backlighting (1 turns your TV set into a shining decoration
object.
The LED backlighting is temporarily controlled via the local control of
the TV or the remote control.
The function of the LED backlighting is reset to the default of the
general preset of System settingsטControlטmore...טLED
light module as soon as the TV set changes its operating mode
(switching on or off). See chapter System settings, section LED
light module for further information.
For playback of movies in 3D mode we recommend to disable the
LED backlighting (1 (see chapter System settings, section Picture
– 3D settings).
When activating the LED backlighting with TV set switched off
(standby mode), further operation commands will only be handled
after several seconds.
Controlling the LED backlighting via the local control
Press briefly: Switch the LED backlighting temporarily
on/off.
Press longer: Change brightness of the LED backlight-
ing (dim the lighting).
As long as you keep the key depressed, the display
is in an endless loop alternately reducing the lighting to
its minimum and then increasing it to the maximum
again.
When desired brightness is reached:
Release the key.
Controlling the LED backlighting via the remote control
Press briefly: Switch the LED backlighting temporarily
on/off.
When backlighting is active and when there are no
further on-screen menu displays:
 Increase / decrease brightness of the LED
backlighting.
– VOL + MENU RADIO
(1 Depending on the type of TV set.

Reference ID 40-55
User guide
20

Initial installation
Initial installation wizard
Initial installation after switching on for the first time
The Initial installation wizard starts automatically with an initial instal-
lation. It may be called repeatedly again (see chapter Extras ,section
Special functions – Repeat initial installation).
If at least one station is locked, the access code must be entered
before repeating initial installation (see chapter System settings,
section Control – Parental lock).
For information on navigation within the wizard refer to chapter
General information on menu operation.
First installation wizard routine
The selected settings affect the routine of the Initial installation wizard.
 Select desired Menu language.
Selecting the language of the user guidance is the
wizard’s first step. Then you simply follow the instruc-
tions on your TV screen.
Proceed to next step.
 Select Energy efficiency.
Determine how energy efficient your TV set shall
be. The value for the contrast (and thus the bright-
ness of the background lighting) is adapted and
the automatic dimmer activated or deactivated
depending on the presetting.
Choosing Home mode automatically activates
shutdown. For Premium mode or Shop mode,
automatic shutdown is initially deactivated.
See chapter For your safety for further informa-
tion on automatic shutdown.
Deutsch (de) ǼȜȜȘȞȚțȐ (el) Svenska (sv)
English (en) Polski (pl) Dansk (da)
Français (fr) Magyar (hu) Português (pt)
Italiano (it) Suomi (fi) ȇɭɫɫɤɢɣ (ru)
Español (es) Slovenščina (sl) Norsk (no)
Nederlands (nl) Slovenčina (sk) 中文(zh)
Čeština (cs) Türkçe (tr)
INITIAL INSTALLATION - Menu language
Proceed with
Which menu language do you want to use for operation?
Menu
language
Here you define how energy efficiently you operate your TV. With the "Home Mode"
setting you put the focus on low energy consumption for home use. The "Premium Mode"
is optimised to a brighter environment with a higher energy consumption. The "Shop
Mode" is designed for operation in a showroom.
Note: If you select "Home Mode" here, the TV set will automatically switch off to save
energy after no longer being operated for 4 hours.
Energy efficiency
Back with Proceed with
Home mode Premium mode Shop mode
Energy
efficiency
Home mode:
The emphasis for home use is on low energy consump-
tion. The automatic dimmer is activated.
Premium mode:
This mode optimises the settings to a brighter environ-
ment at a higher energy consumption. The automatic
dimmer is activated.
The use of this energy efficiency setting must be con-
firmed afterwards once again.
Shop mode:
The picture settings are aligned to operation in the
presentation room. The automatic dimmer is deacti-
vated. If the ambient brightness diminishes, the energy
consumption is not reduced.
The use of this energy efficiency setting must be con-
firmed afterwards once again.
The presetting can be changed later in Extras ט
Energy efficiency or in the System settings under
PictureטPicture adjustment.
Proceed to next step.
 Select the Operating mode.
Use the TV set as a TV set:
Continued with Location of TV set (see below).
Use the TV set just as a monitor:
see chapter Initial installation, section TV set as a
monitor.
 Select Location of TV set (national defaults
are adopted).
For certain locations (e.g., Australia), there
is finally a selection screen where you can
indicate in which state/territory the device
is being operated.
Proceed to next step.
Energy
efficiency
(continued)
Operating
mode
Please specify if you wish to use the full TV function of your set, or if you wish to use it
purely as a monitor.
Operating mode
As TV set As monitor only
Back with Proceed with
Please specify the location of your TV set so that the available stations can be sorted
according to the specify country.
Location of TV set
Back with Proceed with
(DK) Denmark
(E) Spain
(F) France
(FIN) Finland
(H) Hungary
(I) Italy
(IRL) Ireland
(L) Luxembourg
(N) Norway
(NL) Netherlands
(NZ) New Zealand
(P) Portugal
(PL) Poland
(RUS) Russia
(S) Sweden
(SK) Slovakia
(SLO) Slovenia
(TR) Turkey
(UK) United Kingdom
Other country
Location of
TV set
